OE-254

1
(No Transcript)
2
DESCRIPTION
The antenna consists of Antenna AS-3166/GRC,
Mast AB-1244?GRC, and Cable Assembly Radio
Frequency CG-1889B/U (80 ft) all parts are
stowed in a transit bag. The feedcone
assy. Mounts the six antenna elements and the
balun assembly and provides for mechanical
connec- tion to the mast by use of an insulating
extension. The balun assembly is connected to the
radio set by Cable Assembly, Radio frequency
CG-1889B/U. Mast AB-1244/GRC is used to elevate
the antenna above ground and is held in a
vertical position by eight guy ropes. The
equipment is designed for hand or vehicular
transportation. When disassembled, it is packed
in a nylon fabric roll bag 42 inches long and 39
inches in circumference.
