Title: HDV Storage


1
HDV Storage
  • Mel Medina
  • Product Manager

Professional Audio / Video Group
SONY ELECTRONICS, INC.
2
  • New Additions to the Family

3
SONY
4
HVR-M15U HVR-M25U
  • Sonys Entry Level Digital HD Videocassette
    Recorders
  • Both models will be multiformat capable
    (recording and playback) for easy migration from
    SD to HD
  • HDV
  • DVCAM
  • DV
  • Mini Standard cassette compatibility
  • Record time of up to 276 minutes using new
    PHDV-276DM video tape

5
HDV VTR Common Features
  • Downconversion capability
  • 60 / 50 Hz (NTSC / PAL) switchable
  • HDV / DV input w/TC
  • External TC copy
  • Flexible I/O
  • i.LINK I/O, S-Video I/O, Composite I/O, Analog
    audio I/O
  • Component Output

6
HVR-M15U unique features
  • Menu Key
  • The DSR-11 menu can only be accessed via remote
    control.
  • Audio recording volume adjustment
  • Select either -6 / 0 / 6 dB

7
HVR-M15U Rear Panel
8
HVR-M15U
9
HVR-M15U vs. DRS-11
10
HVR-M15U vs. DSR-11
HVR-M15U DSR-11
Standard/Mini Cassette Compatible Yes Yes
HDV Recording Playback Yes No
Tape Counter OSD OSD
HDV/DV IN TC YES (HDV/DVCAM/DV) YES (DVCAM)
Auto Repeat Yes Yes
Cassette Memory Function No Yes
TC/UB Settings TC Reset only from Menu TC Reset only from Menu
Audio Rec. Volume -6, 0, 6dB, AGC No
Menu Key Yes (Front Panel) No (Remote Control)
Component Output Yes (RCA) No
Power AC Adaptor (DV8.4V) AC Adaptor (DV12V)
Size 18073265 18073265
11
HVR-M25U
  • 2.7 Video Monitor
  • 169, 211K pixel Clear Photo LCD plus panel
  • HDMI interface
  • Easy connectivity to consumer TVs
  • Edge Crop Adjustment
  • Custom Repeat
  • Selectable repeat times, cycle, start time
  • 1080i60 to 720p30 conversion
  • Analog component HDMI
  • Duplicate Plus Functionality
  • Format selectable HDV / DVCAM / DV SP

12
HVR-M25U vs. DSR-25
13
HVR-M25U vs. DSR-25
HVR-M25U DSR-25
Standard/Mini Cassette Compatible Yes Yes
HDV Recording Playback Yes No
LCD Panel 2.7 169 Clear Photo LCD plus (211K) 2.0 43 (123K)
Tape Counter LCD Time Counter Display
Assign Button Yes No
HDV/DV IN TC YES (HDV/DVCAM/DV) Yes (DVCAM only)
Duplicate plus HDV / DVCAM / DV (A / V / TC / UB) DVCAM (A /V /TC / UB / ATN / INDEX)
Repeat function Custom Repeat Auto Repeat
Cassette Memory Function No Yes
Edge Crop Adjustment Yes No
HDMI Output Yes No
Component Output Yes (BNC) No
Power AC100240V AC100240V
Size 21288380.7 21288392.8
14
HVR-M25U vs. HVR-M15U
LCD Panel Yes No
Tape Counter LCD OSD
HDV/DV IN TC Yes Yes
Duplicate plus Yes No
TC/UB Settings Yes ? (TC Reset only)
Repeat function Custom Repeat Auto Repeat
Edge Crop Adjust Yes No
Assign Button Yes No
Audio Rec. Volume Yes (Volume) ? (Yes (-6, 0, 6dB, AGC))
i.LINK Yes (4pin) Yes (4pin)
HDMI Output Yes (HDMI Connector) No
Component Output Yes (BNC) Yes (RCA)
Composite IN/OUT Yes (BNC) Yes (RCA)
S-Video IN/OUT Yes Yes
Headphone jack Yes No
Control-S Yes Yes
LANC Yes Yes
15
DSR-M15U vs. DSR-M25U
16
  • Sample Applications

17
HDV NLE Feeder Recorder
i.LINK
18
Backup HDV Recording
i.LINK
19
Replacement of DSR-25/11
20
Digital Conversion to HD-SDI
Miranda HD-Bridge DEC
i.LINK
HD-SDI
21
POP w/Auto-Repeat
HDMI
22
HD POV camera system w/HDC-X310
HFU-X310 w/ HFBK-TS1 installed
i.LINK
23
  • Competitive Review

24
Front Views
25
Rear Views
26
HVR-M25U 4000.00 (tentative) HVR-M15U 2700.00 (tentative) BR-HD50U 3399.00
LCD Panel Yes No No
Tape Counter LCD OSD LED
HDV/DV IN TC Yes Yes Yes
Duplicate plus Yes No No
TC/UB Settings Yes ? (TC Reset only) Yes
Repeat function Custom Repeat Auto Repeat Yes
Edge Crop Adjust Yes No No
Assign Button Yes No No
Audio Rec. Volume Yes (Volume) ? (Yes (-6, 0, 6dB, AGC)) Yes
i.LINK Yes (4pin) Yes (4pin) Yes
HDMI Output Yes (HDMI Connector) No Yes
Component Output Yes (BNC) Yes (RCA) Yes (BNC)
Composite IN/OUT Yes (BNC) Yes (RCA) Yes (BNC)
S-Video IN/OUT Yes Yes Yes
Headphone jack Yes No Yes
Control-S Yes Yes No
LANC Yes Yes No
All features, specifications, and pricing subject
to change without prior notice.
27
720p30 HVR Decks
28
HDV 1080i60 JVC
HDV 1080i60
29
  • John Holmes
  • Marketing Manager

Professional Audio / Video Group
SONY ELECTRONICS, INC.
30
Deck Transition Strategy
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
New flagship DVCAM plus HDV
4000
3300
Step up for future ready HD pathway
2700
Cute, priced attractive for traditional DVCAM
customer
2000
31
