Injuries%20to%20the%20Lower%20Leg,

1
Chapter 16

• Injuries to the Lower Leg,
• Ankle, and Foot

2
Anatomy Review
Bones and Ligaments of the Ankle and Foot

Note the subtalar joint that is responsible
for inversion and eversion of the foot
3
Anatomy Review (cont.)

• Foot Bones (medial view)

4
Ligaments

• The deltoid ligament is the _________ _________of
  the medial side of the talocrural (ankle) joint.

5
Ligaments (cont.)

• Ligaments of the Ankle (lateral view)
• The three primary ligaments are

6
The Lateral Ankle

• These ligaments are NOT as large or strong as the
  deltoid.
• The talocrural joint is strongest in dorsiflexion
  and weakest in plantar flexion.

7
Anatomy Review

• The innervation of the three compartments is
  supplied by the tibial, superficial, and deep
  peroneal nerves.
• The illustration shows the ______
  _______________ _____________________________.

8
Common Sports Injuries

• Fractures
• Most often caused by direct trauma through
  contact. Contact causes most fractures to the
  lower leg and foot.
• Avulsion fracture of 5th metatarsal can occur
  with a lateral ankle sprain.

9
Fractures

• Signs and symptoms include
• Swelling and/or deformity at the site of
  fracture.
• Possible broken bone end projecting through skin.
• Inability to bear weight on the affected leg.
• For a stress fracture or growth plate fracture
  that did not result from traumatic event, the
  athlete complains of extreme point tenderness and
  pain at the site of injury.

10
Fractures (cont.)

• First Aid
• Watch and treat for shock, if necessary.
• Carefully immobilize the foot and leg using a
  splint.

11
Soft Tissue Injuries

• Ankle Injuries
• Ankle sprains are one of the most common injuries
  to this region.
• Eversion sprains, while less frequent, are often
  severe.

12
Ankle Injuries Sprains

• Signs and symptoms depend on degree of sprain.
• 1st degree Pain, mild disability, point
  tenderness, little laxity, little or no swelling
• 2nd degree
• 3rd degree Pain and severe disability, point
  tenderness, loss of function, laxity, moderate to
  severe swelling

13
Ankle Injuries Sprains (cont.)

• First Aid

Courtesy of Brent Mangus
14
Ankle Injuries Sprains (cont.)

• First Aid (cont.)
• If there is any question regarding the severity
  of the sprain, refer athlete to a medical
  facility for physicians evaluation.

15
Ankle Injuries Sprains (cont.)

• Tibiofibular (tib-fib) Sprains
• These injuries are often treated inappropriately
  as lateral ankle sprains, hindering recovery.
• Symptoms include a positive sprain test, but
  athlete is also in great pain. Squeeze test
  elicits pain in syndesmosis area.

16
Ankle Injuries Sprains (cont.)

• First Aid
• Immediately apply ice and compression, and
  elevate the leg.
• Have athlete rest and use crutches for first 72
  hours, followed by wearing a walking boot for 3
  to 7 days.

17
Preventing Ankle Injuries

• Prophylactic adhesive taping supports the ankle
  only for a short time.
• Bracing combined with some high-top shoes may be
  helpful.

Courtesy of McDavid
18
Tendon-Related Injuries

• Achilles tendon is commonly injured by
  long-distance runners, basketball players, and
  tennis players.
• Athletes who dramatically increase workout times
  or running distances, or who run on hard, uneven,
  or uphill surfaces are prone to Achilles
  tendonitis.
• The injury can be either acute or chronic. Acute
  injuries often associated with explosive jumping
  or blunt trauma.

19
Achilles Tendon Injuries

• Signs and symptoms include
• Swelling and deformity at site of injury.
• Athlete reports a pop or snap associated with the
  injury.
• Loss of function, mainly in plantar flexion.
• First Aid
• Immediately apply ice and compression.
• Arrange for transport to nearest medical
  facility.

20
Compartment Syndrome

• Compartment syndrome usually involves the
  anterior compartment of the lower leg.
• Chronic form is related to overuse of the
  compartments muscles that causes swelling of
  tissues.
• Acute trauma, such as being kicked in the leg,
  can result in swelling within the compartment as
  well.
• In either case, swelling puts pressure on vessels
  and nerves.
• Properly sized shin guards can protect lower leg
  in soccer.

21
Compartment Syndrome (cont.)

• Signs and symptoms include
• Pain and swelling in the lower leg.
• Athlete may complain of chronic or acute injury
  to the area.
• There can be loss of pulse in the foot.
• First Aid
• Apply ice and elevate. Do _____ apply
  compression.
• If there is numbness, loss of movement, or loss
  of pulse to the foot, seek medical advice
  immediately this is a true medical emergency.

22
Shin Splints

• Shin splints is a very common disorder of lower
  leg. Term describes exercise-induced leg pain.
• The types of activities that produce this problem
  and the manifestations of the injury vary
  depending on the athlete.

23
Shin Splints (cont.)

• Signs and symptoms include
• Lower leg pain either medially or
  posteromedially.
• Pain can be unilateral or bilateral.
• First Aid
• Apply ice and have the athlete rest.
• Athlete may need to have his or her gait analyzed
  for biomechanical deficiencies.
• If problem worsens, athlete should seek medical
  advice.

24
Plantar Fasciitis

• The plantar fascia is a dense collection of
  tissues that traverses from the plantar aspect of
  the metatarsal heads to the calcaneal tuberosity.
• If this tissue becomes tight or inflamed by
  overuse or trauma, it can produce pain and
  disability.
• Athlete also has point tenderness in the region
  of the calcaneal tuberosity.

25
Plantar Fasciitis (cont.)

• Treatment is typically conservative and includes
• Rest.
• Anti-inflammatories.
• Applying cold and heat alternatively to enhance
  healing.
• A heel pad and stretching the Achilles tendon
  complex can assist in recovery.
• Use of semirigid orthoses is also effective, but
  some athletes find it difficult to participate
  with such an orthotic in their shoes.
• Re-aggravating the injury increases the healing
  time.

26
Heel Spurs

• Heel spurs can be related to chronic plantar
  fasciitis.
• Chronic inflammation can result in ossification
  at the site of attachment on the plantar aspect
  of the calcaneus.
• Treatment of Heel Spurs
• Athlete should consult a physician if spurs
  become incapacitating.
• Applying a doughnut-shaped pad beneath the heel
  spur may help but rarely do they ameliorate the
  problem.

27
Mortons Foot

• Mortons foot
• The result shifts weight bearing to the 2nd
  metatarsal instead of along the 1st metatarsal.
• Results in pain throughout the foot during
  ambulation.

28
Mortons Foot

• Mortons foot may result in Mortons neuroma.
• The problem is usually with the nerve between the
  3rd and 4th metatarsal heads.
• A neuroma is an abnormal growth on a nerve.
• Tight-fitting shoes may be the cause. Going
  barefoot may help.

29
Arch Problems

• There are two groups of arch problems pes planus
  and pes cavus.
• Pes planus (_______) related to pronation.
• Excessive pronation can cause difficulties in the
  navicular bone and some of the joints around the
  ankle.
• Arch taping has limited effectiveness.
• Corrective arch orthoses may be beneficial.
• Pes cavas (_________) associated with plantar
  fasciitis and clawing of the toes.
• Athlete may benefit from orthotic device.

30
Bunions

• Bunions are uncommon in high school and college
  athletes.
• Can be caused by improperly fitting shoes.
• Chronic bunion should be evaluated by physician.

31
Blisters Calluses

• Blisters and calluses are very common formations,
  resulting from friction between layers of skin.
• When a blister forms, fluid collects between skin
  layers, occasionally the fluid will contain
  blood.
• When draining a blister, it is best to leave top
  layer of skin in place.
• Use sterile instruments and wear latex gloves or
  some other barrier to avoid contact with
  athletes body fluid.

32
Blisters Calluses (cont.)

• NSC First Aid Procedures
• Wash area with soap and warm water sterilize
  area with rubbing alcohol.
• Use sterile needle to puncture the base of the
  blister and drain by applying light pressure.
  Process may need to be repeated during the first
  24 hours.
• Apply antibiotic ointment to the top and cover
  with sterile dressing.
• Check daily for signs of infection (redness or
  pus).
• After 37 days, remove the top of blister and
  apply antibiotic ointment and sterile dressing.

33
Toe Injuries

• Common injuries are torn-off nails or hematoma
  formation under the nail.
• Use commercially available nail bore to drill
  small hole in nail to release blood.
• Ingrown toenails may result from improperly
  fitting shoes.
• Elevate toenail by placing a small cotton roll
  under it and leave in place as nail grows.
• Have athlete obtain shoes that fit more
  comfortably.

34
Basic Taping
1.
2.
3.
35
Basic Taping (cont.)
4.
5.
6.
36
Basic Taping (cont.)
7.
8.
9.
37
Basic Taping (cont.)
10.
11.
12.
38
Basic Taping (concluded)
13.
15.
14.
