Multi-Query Optimization

1
Multi-Query Optimization

• Prasan Roy
• Indian Institute of Technology - Bombay

2
Overview

• Multi-Query Optimization What?
• Problem statement
• Multi-Query Optimization Why?
• Application scenarios
• Multi-Query Optimization How?
• A cost-based practical approach
• Prototyping Multi-Query Optimization
• On MS SQL-Server at Microsoft
• Research prototype at IIT-Bombay

3
Multi-Query Optimization What?

• Exploit common subexpressions (CSEs) in query
  optimization
• Consider DAG execution plans in addition to tree
  execution plans

4
Example
B
A
C
D
B
C
Best Plan for A JOIN B JOIN C
Best Plan for B JOIN C JOIN D
5
Example (contd)

• Alternative

D
A
B
C
Common Subexpression
6
Multi-Query Optimization Why?

• Queries on views, nested queries,
• Overlapping query batches generated by
  applications
• Update expressions for materialized views
• Query invocations with different parameters
• . . .

Practical solutions needed!
7
Multi-Query Optimization How?

• Set up the search space
• Identify the common subexpressions
• Explore the search space efficiently
• Find the best way to exploit the common
  subexpressions

8
Problems

• Materializing and sharing a CSE not necessarily
  cheaper
• Mutually exclusive alternatives
• (A JOIN B JOIN C)
• (B JOIN C JOIN D)
• (C JOIN D JOIN E)
• What to share (B JOIN C) or (C JOIN D) ?

Huge search space!
9
Earlier Work Practical Solutions

• As early as 1976
• Preprocess query before optimization Hall,
  IBM-JRD76
• As late as 1998
• Postprocess optimized plans Subramanium and
  Venkataraman, SIGMOD98

Query optimizer is not aware!
10
Earlier Work Theoretical Studies

• Sellis, TODS88, Cosar et al., CIKM93, Shim
  et al., DKE94,...
• Set of queries Q1, Q2, , Qn
• For each query Qi, set of execution plans
  Pi1, Pi2, , Pim
• Pij is a set of tasks from a common pool
• Pick a plan for each query such that the cost of
  tasks in the union is minimized

Not integrated with existing optimizers, no
practical study
11
Microsoft Experience

• with Paul Larson,
• Microsoft Research

12
Prototyping MQO on SQL-Server

• Add multi-query optimization capability to
  SQL-Server
• Well integrated with the existing optimization
  framework
• another optimization level
• minimal changes, minimal extra lines of code
• First cut exhaustive
• How slow can it be?
• A working prototype by the summer-end

13
What (almost) already exists in the SQL-Server
Optimizer

• AND/OR Query-DAG representation of plan space

Group (OR node)
14
What actually exists in the SQL-Server Optimizer

• Relations cloned for each use

B1
A
C1
D
B2
C2
15
Preprocessing Step Query-DAG
Unification

• Performed in a bottom-up traversal

?
?
?
?
?
?
B1
A
C1
D
B2
C2
16
Common Subexpression Identification

• Unified nodes are CSEs

Common Subexpression
A
B
C
D
17
Exploring the Search Space A Naïve Algorithm

• For each set S of common subexpressions
• materialize each node in S
• MatCost(S) sum of materialization costs of the
  nodes in S
• invoke optimizer to find the best plan for the
  root and for each node S
• CompCost(S) sum of costs of above plans
• Cost(S) MatCost(S) CompCost(S)
• Pick S with the minimum Cost

18
Doing Better Incremental
Reoptimization

• Goal best plan for Si ? best plan for Sj
• Observation
• Best plans change for only the ancestors of
  nodes in Si XOR Sj
• Algorithm
• Propagate changed costs in bottom-up
  topological order from nodes in Si XOR Sj
• Update min-cost plan at each node visited
• Do not propagate further up if min-cost plan
  remains unchanged at a node

Work done at IIT-Bombay
19
Incremental Optimization Example

• Si ?

min-cost
A
B
C
D
20
Incremental Optimization Example

• Si ? Sj (B JOIN C)

?
?
Now materialized
?
Previous min-cost
New min-cost
A
B
C
D
21
Current Status

• A first-cut implementation working
• Lines of C code added 1500 approx.

22
Future Work

• Performance tuning and smarter data structures
  needed
• Ways to restrict enumeration taking DAG structure
  into account

23
Research at IIT-Bombay Heuristics for
MQO

• with S. Sudarshan, S. Seshadri

24
A Greedy Heuristic

• Pick nodes for materialization one at a time, in
  benefit order
• Benefit(n) reduction in cost on materialization
  of n

Benefit computation is expensive
25
Monotonicity Assumption

• Benefit of a node does not increase due to
  materialization of other nodes
• Exploited to avoid some benefit computations

Optimization costs decrease by 90
26
A Postpass Heuristic Volcano-SH

• No change in Volcano best plan computation
• Cost-based materialization of nodes in best
  Volcano plan
• Implementation easy
• Low overhead

Optimizer is not aware
27
A Volcano Variant Volcano-RU

• Volcano best plan search aware of best plans for
  earlier queries
• Cost based materialization of best plan nodes
  that are used by later queries
• Implementation easy
• Low overhead

Local decisions, plan quality sensitive to query
sequence
28
Experimental Conclusion

• Greedy
• Expensive, but practical
• Overheads typically offset by plan quality
• especially for expensive canned queries
• Almost linear scaleup with query batch size
• typically, only the width of the Query DAG
  affected
• Volcano-RU
• Mostly better than Volcano-SH, same overhead
• Negligible overhead over Volcano
• recommended for cheap but complex queries

29
Conclusion

• Multi-query optimization is needed
• Multi-query optimization is practical!
• Multi-query optimization is an easy next step for
  DAG-based optimizers
