Title: Basic Electricity


1
Basic Electricity
  • Facts and Diagrams

2
Cable Types
  • Determine your need to determine the type of
    cable (Romex) needed
  • Gage
  • Size of the wire (common 12 or 14)
  • 2 wire
  • 1 black, 1 white, and 1 bare/green ground wires
  • 3 wire
  • 1 black, 1 red, 1 white, 1 bare/green ground wires

3
Wire Types
  • There are 4 basic types of wire
  • Black wire hot
  • White wire neutral
  • Bare/Green wire ground
  • Red hot

4
Wire Types
5
Device Types
  • Various devices are needing in wiring
  • Light fixture
  • Single-pole switches
  • 3-way switch
  • Duplex receptacles

6
Device Types
7
Device Types
8
Device Types
9
Device Screws
  • There is 3 basic types of screws
  • Brass (gold) hot (black)
  • Silver neutral (white)
  • Green ground (bare/green)

10
Device Screws
11
Connector Types
  • Connecting caps are colored by size and use
  • Red
  • Yellow
  • Green primarily for ground

12
Connector Types
13
Wiring Rules
  • Neutral wire goes without interruption to every
    place in the circuit where current may be used
  • Neutral wire is connected to the silver-colored
    terminal.
  • The neutral wire is white.

14
Wiring Rules
  • Black or red wire is always connected to a brass-
    colored terminal.
  • Black or red wires carry hot power or current
    from the source to the devices within the circuit

15
Wiring Rules
  • The green, or bare, grounding wire is connected
    to the grounding terminal (green screw) of a
    grounding-type electrical fixture.
  • All wires must be spliced or connected to a
    terminal screw in each box.
  • Only one wire is allowed to be fastened under a
    terminal screw.

16
A single-pole switch to a light fixture
17
Duplex Receptacle with continuous Circuit
18
A single pole switch to two light fixtures
19
A single-pole switch controlling a light fixture
with a line coming in and a line extending beyond
the fixture.
20
Two 3-way switches controlling a light fixture
with the power coming in through the first switch.
21
Draw the Schematics
  • Keyless lamp fixture
  • Black wire
  • Gold screw
  • Single pole switch
  • Red wire
  • Duplex Receptacle
  • Ground wire
  • Traveler screw
  • 3 way switch
  • White wire

22
Draw a Schematic
  • Single pole switch to a keyless lamp
  • Duplex receptacle
  • Single pole switch to two keyless lamps
  • Two duplex receptacles both GFI, but only one a
    GFI receptacle
