Title: Unit 4 - MoLECULES


1
Chemical Bonds Continued
  • Unit 4 - MoLECULES

2
NaCl vs. CO2
  • What do you already know?
  • Imagine!
  • Close your eyes and picture a piece of salt. Now
    zoom in..what does it look like at the atomic
    level?
  • Now imagine carbon dioxide what does it look
    like at the atomic level?
  • How are these two compounds different?

3
How do non-metals bond with each other?
  • Recall non-metals have______(high or low)
    ionization energy when compared to metals.
  • Reason
  • Result
  • What is electronegativity? Why does it exhibit a
    distinct periodic trend?
  • How do nonmetals bond?

4
Electronegativity - Linus Pauling
5
Covalent bonding
  • Atoms are bonded because both nuclei () are
    attracted to the same electrons (-).

6
Covalent vs Ionic
7
Using electronegativities
  • Electronegativity Difference /Bond Character
  • gt 1.7 and above / ionic
  • 0.4 - 1.7 / polar covalent
  • 0 -0.4 /nonpolar covalent

8
What is a molecule?
  • Two or more atoms covalently bonded to make a
    neutral particle is a unit called a molecule.
  • A polyatomic ion (i.e. NO3-) is very similar to a
    molecule, except that it has a charge.
  • Covalent compounds AND most non-metal elements
    are composed of molecules.
  • H2O CO2 O2 P4

9
MORE KEY TERMS
  • All diatomic molecules are NONPOLAR COVALENT
  • Practice lewis dot structure
  • Electronegativity tendency of an atom to
    attract shared electrons to itself! (greatest
    attraction for electrons)

10
What is a Lewis symbol?
  • Lewis symbols
  • are simple pictures of atoms
  • are used to represents covalent bonds

Lewis Symbol
Ne
Each dot is a valence electron
Gilbert N. Lewis
11
(No Transcript)
12
Molecular Representations
13
(No Transcript)
14
Diatomic nonpolar molecules
15
(No Transcript)
16
Polar covalent vs. nonpolar covalent
17
What determines the structure of molecule?
  • Octet rule - atoms usually form covalent bonds
    with each other resulting in a total of 8 valence
    electrons around each atom.
  • What is special about eight e-?
  • Why usually but not always 8?
  • Whats the actual REASON that non-metals share
    electrons?

18
Drawing Lewis Dot Structure
  • 1. Write symbols of the elements.
  • - if 3 or more elements figure out which one is
    the central one ( typically C , N, P, S
    sometimes O) If all of these are present
    usually C is the central one.
  • 2. Determine total of valence electrons
  • Dont forget about adding or subtracting an
    electron/s if you are dealing with the polyatomic
    ions
  • 3. Use a single bond to connect each atom
    together
  • -gt then fill in the remaining electrons
    around the atoms to complete the octet rule
  • - if total of electrons wont fulfill octet
    rule double or triple bonds are
    necessary

19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
Example Lewis structure for water
  • Formula of water is H2O
  • Total valence electrons
  • Lewis structure to obey octet rule
  • Practice on your own PCl3 and SF2

25
Lewis structures have limitations
  • What does a Lewis structure show us about a
    molecule?
  • What does it NOT show?

26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
CF4
31
CF4
32
NH3
33
NH3
34
What about the ammonium ion? NH4
35
(No Transcript)
36
(No Transcript)
37
N2
38
N2
39
nomenclature for molecules
  • Rules for naming covalent molecules
  • 1. Use prefixes to indicate the of atoms
    present
  • EXCEPTION
  • Never use mono for the first element in the
    molecule
  • 2. Same rules for ide ending for the last
    element in molecule
  • Prefixes
  • Mono -1 hexa -6
  • Di- 2 hepta -7
  • Tri -3 octa -8
  • Tetra- 4 nona -9
  • Penta- 5 deca -10

40
Practice!
  • Name these compounds
  • PCl3
  • H2O
  • N2O4
  • SF6
  • Write formulas for these compounds
  • Diphosphorus pentoxide
  • Carbon tetrachloride

41
VSEPR theory
42
Linear shape (2/0)
43
Trigonal planar 3/0
44
Tetrahedral 4/0
45
(No Transcript)
46
Trigonal Pyramidal(3/1)
47
Bent 2/2 or 2/1
48
Bonds to central atom lone pairs on central atom Molecular geometry Bond Angle example
2 0 Linear 180
2 1 Bent 120
2 2 Bent 104.5
3 0 Trigonal Planar 120
3 1 Trigonal Pyramidal 107
4 0 Tetrahedral 109.5
49
(No Transcript)
50
Molecular Structures and the Periodic table
51
Summary of 4 major structural units of C.
52
VSEPR video
  • http//www.youtube.com/watch?vi3FCHVlSZc4NR1

53
Intramolecular Forcesvs. Intermolecular
  • Intermolecular Forces
  • Hydrogen bonding
  • Dipole forces
  • London forces (dispersion forces)

54
Intra vs Inter
  • Intramolecular forces (within a compound)
  • Covalent and ionic bonds
  • Intermolecular forces (between compounds)
  • IMFs Intermolecular Forces
  • Dipole Forces
  • Hydrogen Bonding
  • LDFs London Dispersion Forces

55
Bond Polarity vs. Molecule Polarity
  • Bond Polarity results from unequal sharing of
    the electrons in the covalent bond. Use the
    electronegativity differences to figure out how
    polar the bond is.
  • Molecule Polarity a molecule is polar if it has
    1 or more polar bonds and its shape does not
    cancel out the polarity.
  • Nonpolar covalent molecules (nonpolar)
  • Ex All diatomics such as N2, H2, etc
  • Polar covalent molecules (polar)
  • Ex water, carbon monoxide, etc

56
Intramolecular ForceTutorial Video Advanced,
But Slow and Methodical
57
Using electronegativities
  • Electronegativity Difference /Bond Character
  • gt 1.7 and above / ionic
  • 0.41 - 1.7 / polar covalent
  • 0 -0.4 /nonpolar covalent
  • Dipole molecule -

58
(No Transcript)
59
Polar Molecule notations/representations
60
Intermolecular Forces Hydrogen bonding
61
Hydrogen bonding
62
Hydrogen bonding characteristics
  • 1. Must involve a hydrogen that is bonded to
    highly electronegative element (O, F, N)
  • 2. The slight positive on the hydrogen is
    attracted to a neighboring molecules nonbonding
    electron pair.

63
Dipole Forces (Vander wall)
  • Dipoles molecules that have separate centers of
    partial negative and partial positive charges.
  • Note dipole forces are only 1 as strong as an
    ionic bond attraction.

64
London dispersion forces (LDFs)
  • They are small, transient , attractive forces
    between NONPOLAR molecules
  • Larger or heavier atoms typically exhibit
    stronger dispersion forces than smaller, lighter
    molecules
  • http//www.youtube.com/watch?v3t1Jn_jrsQk
  • http//dl.clackamas.edu/ch104/lesson9molecular_pol
    arity.html

65
(No Transcript)
66
(No Transcript)
67
Ionic vs molecular compounds
  • Melting point
  • Conductivity

68
Intermolecular forces and boiling points!
  • The GREATER The force of attraction between
    molecules the higher the melting or evaporation
    point will be.
  • Think about Ionic bonding..
  • Which would melt the quickest when heated and
    why?
  • Aluminum nitride
  • Sodium chloride
  • Calcium oxide
  • Now what about covalent compounds..

69
Boiling points of ionic vs. molecular
  • Melting Points and Boiling Points of Substances
    with Similar Formula Weights Substance FW (g/mol)

Covalent molecules b.p. (Celsius) Ionic compounds b.p. (Celsius)
CS2 46.0 NaF 1695
CH4O 64.7 CaCO3 825
propane -42.1 NaCl 801
CO2 -57 MgSO4 1125
ethanol 78.5 TiO 1750
Glucose 146
H2O 100
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
