Object-Relational Database Systems:

1

• Object-Relational Database Systems
• Evolution Beats Revolution

Michael J. Carey IBM Almaden Research Center
Smalltalk
Java
New Data Types
Queries
Navi- gation
Appl. Dev. Tools
SQL
C
2

• Plan for the Talk

• The relational DBMS revolution
• Relational model and query language
• Why relational succeeded
• Why relational isn't enough, and some options
• The object-oriented DBMS revolution
• Object-oriented model(s) and query language(s)
• Why object-oriented "failed"
• Why wrappers will fail as well
• The object-relational DBMS evolution
• The object-relational model and query language
• Current products and examples
• Performance and other challenges

3

• The Relational DBMS Revolution

• The pre-relational era (1970's)
• Graph-based data models
• Hierarchical model (e.g., IMS)
• Network model (e.g., Codasyl)
• Low-level, navigational interfaces
• Labor-intensive and error-prone
• The relational era (1980's)
• Simple, abstract data model
• Database set of relations ("tables")
• 3 schema levels views, base tables, physical
  schema
• Algebra of set-oriented operations
• High-level, declarative interfaces
• SQL, Quel, QBE
• Embedded languages, 4GLs

4

• The Relational Model (by example)

• Employees and departments

Department
dno
name

10
Toy

20
Shoe
Employee
eno
name
salary
dept

1
Lou
10000000
10

7
Laura
150000
20

22
Mike
80000
20
?
select E.name, E.salary, D.no from Employee E,
Department D where E.salary lt 100000 and D.name
'Shoe' and E.dept D.dno
5

• Relational DBMS "Goodies"

• Relational query processing
• Queries range over tables and/or views
• Programmers use a declarative language (SQL)
• Query optimizer picks the lowest-cost query plan
• Alternative access paths, join orders, join
  methods, and so on (based on indices and database
  characteristics)
• Result data independence
• Support for (shared) business logic
• Integrity constraints
• Check constraints, referential integrity
  constraints
• Triggers, stored procedures, views, authorization
• Performance and robustness
• Buffering, locking, crash recovery, replication,
  ...

6

• We've Achieved Nirvana ... Right?

• Relations are surely the answer!
• Simple, high-level model for programmers
• Easy to distribute data and parallelize queries
• But what was the question?
• Sometimes difficult to model "real world" data
• Entities and relationships (versus tables)
• Variance among entities (versus homogeneity)
• Set-valued attributes (versus normalization)
• Demanding new database applications
• New applications bring new data types
• Complex objects are problematic
• "A relational database is like a garage which
  forces you to take your car apart and store the
  pieces in little drawers..."

7

• What are the Options?

• Throw in the towel
• OOPL your favorite file system
• Object-oriented DBMS
• Tightly integrated OOPL w/built-in DBMS
• Object-oriented client wrapper
• Loosely integrated OOPL relational DBMS
• Object-relational DBMS
• Newly integrated Relational model OO features

Which solution is the "right" one...?
8

• Let's Examine the Problem Space

• Stonebraker's 4-quadrant model

Complex
Simple
Complex
9

• The Object-Oriented DBMS Revolution

• Motivated by new database applications, e.g.
• Computer-aided engineering
• Document management
• Geographic data management
• Engineering applications were early drivers
• Complex data structures ("pointer spaghetti")
• Navigational data access required
• Tight coupling between applications and data
• Version management support needed
• Approach OOPL DBMS OO-DBMS
• Commonly based on C or Smalltalk
• Persistence, collections, versions, queries, ...

10

• No OO "Ted Codd" Stepped Forward

• Object-Oriented Database System Manifesto
• Mandatory features
• Complex objects, identity, encapsulation
• Inheritance w/substitutability and late binding
• Computationally complete methods
• Extensible type system, persistence
• Secondary storage, concurrency and recovery
• Ad hoc queries
• Optional features
• Multiple inheritance, static type checking
• Distribution, long transactions, versions
• Individual choices
• Programming paradigm/language
• Details and uniformity of object model

11

• OO-DBMS Technology Today

• Lots of research results
• Object data models and features
• OO query languages and processing techniques
• Client-server architectures and performance
• Significant commercial progress
• Important and innovative systems
• E.g., O2, ObjectStore, ODE
• Quite a few commercial product offerings
• GemStone, Objectivity, ObjectStore, Ontos, O2,
  Matisse, Poet, Versant, others
• The ODMG-93 standard (release 2.0)
• Consortium of OO-DBMS startups
• Three key parts ODL, OQL, C binding

12

• But the Revolution "Failed" (0B)

• Lingering OO-DBMS differences
• Query power, API details, implementation twists
• Piecewise ODMG standard conformance (ex OQL!)
• Still behind R-DBMSs in important ways
• Codasyl-like schema compilation cycle
• Schema evolution painful, if supported
• Typically missing many useful "goodies"
• Support for multiple application languages
• Query optimization, views, authorization,
  constraints, triggers, multi-user scalability and
  robustness, ...
• Other factors (niche market)
• SQL-based application building tools
• Architecturally biased towards "fat clients"

13

• OO Client Wrappers are the Answer...

• Available from a number of vendors
• Persistence Software, Ontologic, HP, Next, ...
• Language-specific relational wrappers
• Proxy classes for C or Smalltalk (or Java)
• Mapping of row data into language objects
• Client-side (or middle-tier) object caching and
  method execution
• Why is this approach attractive?
• Can develop OO applications today, against
  existing enterprise data, for "business objects"

14

• ...Not!

• Paradigm mismatch for querying
• C or Smalltalk for simple business logic
  and navigation, against object-oriented schema
• SQL for queries, against relational schema
• Choice forced for business logic rules
• Do on server, using DBMS facilities?
• Check constraints, referential integrity
  constraints, triggers, stored procedures,
  authorization
• Do on client, using OO wrapper facilities?
• C or Smalltalk (or Java) programming
• This had better be a stop-gap solution
• R-DBMS could become a storage manager, throwing
  away 20 years of successful RD!

15

• The Object-Relational DBMS Evolution

• Third Generation Database System Manifesto
• Support rich object structures and rules
• Rich type system, inheritance, encapsulation
• Functions, optional unique ids, rules/trigggers
• Subsume second generation database systems
• High-level query-oriented interface
• Stored and virtual collections
• Updatable views
• Data model/performance feature separation
• Open to other subsystems (tools, middleware)
• Accessible from multiple languages
• Layered persistence-oriented language bindings
• SQL support ("intergalactic dataspeak")
• Query-shipping architecture

16

• "Not Your Father's Employee Type"

• Beyond name, rank, and serial number
• Several new attribute types
• Location (2-d point), job description (text),
  photo (image), ...
• Associated functions
• Distance(point, point), contains(text, string),
  ...
• Beyond your basic employee record
• Employees come in different flavors
• Emp, RSM, Programmer, Manager, Temp, ...
• Employees have many known relationships
• Manager, department, projects, ...
• Employees have behavior
• Age(Emp), qualified(Emp, Job), hire(Emp), ...

An Employee is a "business object"
17

• Two Flavors of O-R Object Extensions

• Object extension 1 Abstract data types (ADTs)
• New column types and functions
• E.g.,text, image, audio, video, time series,
  point, line, OLE...
• For modeling new kinds of facts about enterprise
  entities
• Object extension 2 Row types
• Types and functions for rows of tables
• Includes inheritance, references, set-valued
  attributes
• For modeling business objects with relationships
  behavior
• Impact on schemas and query language SQL3
• Schemas tables at the top, OO richness within
• Queries extensions to support the added richness
• Structured types support both ADT and row type
  object modeling needs (unified type system)

18

• ADTs (Black Box)

• To define and use a "black box ADT", a user will
• Implement its internal structure and functions in
  an external programming language (e.g., C/C,
  Java)
• Use the DDL to register the type with the DBMS
• Size of an instance of the type
• Input (constructor) and output functions
• Other functions and operators, including
  signatures and linkable implementations
• Costs and other properties for query optimizer
• Use the new type like a built-in data type
• Now available for defining columns of tables
• Functions and operators become available in
  queries

19

• Example Illustra Black Box ADT

• Point as a "black box ADT" (written in C)

create type Point ( internallength 16
-- typedef struct double x, double y
point input point_in -- for
reading in Point constants output point_out
-- for displaying Point
results ) create function point_in(Text)
returns Point as external name
'MI_HOME/functions/point.so' language C create
function point_out(Point) returns Text
as external name 'MI_HOME/functions/point.so' la
nguage C
20

• Example Illustra Black Box ADT (cont.)

• Now we can put an end to "Pointless" queries...!

create function further_west(Point, Point)
returns Boolean as external name
'MI_HOME/functions/pointfuns.so' language
C select E1.name, E1.location from Emp E1, Emp
E2 where further_west(E1.location, E2.location)
and E2.name 'Mike' create binary operator
binding to further_west select E1.name,
E1.location from Emp E1, Emp E2 where E1.location
gtgt E2.location and E2.name 'Mike'
21

• ADTs (White Box)

• To define and use a "white box ADT", a user will
• Describe its internal structure using SQL3 DDL
• Attribute definitions are column-like
• Advantages heterogeneity, nulls, nesting,
  constraints, ...
• Implement its functions either directly in SQL or
  in his/her favorite external programming language
• Utilize system-generated accessors and mutators
• Finish explaining the type to the DBMS using DDL
• For query optimizer, as before
• Use the new type like a built-in data type
• In tables and queries, as before
• Note this is just a SQL3 structured type
  definition that's primarily intended for use in
  columns

22

• Example DB2 UDB/OSF White Box ADT

• Point as a "white box ADT" (written in SQL3)

create type Point as ( x double, y
double, ) create function distance(p1 Point, p2
Point) returns Point language SQL inline not
variant return sqrt((p2..y-p1..y)(p2..y-p1..y)
(p2..x-p1..x)(p2..x-p1..x)) select
E.name from Emp E, City C where C.name 'San
Jose' and distance(E.location, C.center) lt 25
23

• Of Extenders, Blades, and Cartridges

• High performance demands "deep" integration
• Optimizer must know about an ADT operator's...
• Execution cost (especially for expensive
  functions)
• Logical properties (e.g., transitivity, negator,
  ...)
• Selectivity estimates (i.e., filtering/matching
  power)
• Relationship to access methods (both old and new)
• DBMS runtime must invoke functions efficiently
• Static vs. dynamic loading, fenced vs. unfenced
  execution
• Partnerships and third-party packages
• E.g., DB2's text, image, and spatial extenders
• Package contains types, functions, access
  methods, optimizer information, and SQL DDL
  statements for all of the above

24

• Row Types

• To define and use a "row type", a user will
• Create the desired structured type using SQL3 DDL
• Columns, plus (optional) specification of a
  supertype
• Create functions/methods involving the type
• Arguments of the new type, w/overloading in the
  case of methods
• Create one or more tables of the indicated type
• Type hierarchy (if any) yields corresponding
  table hierarchies

25

• Example SQL3 Row Types (plus Sets...)

• Employees are people, so ...

create type Emp_t under Person_t as ( salary
Float, job_description Varchar(100), department
ref(Dept), projects set(ref(Project) ) create
table IBM_Emps of Emp_t under IBM_People (...)
create type Person_t as( name Varchar(20), birth
date Date) method age( ) returns Integer
language SQL create method age( ) for
Person_t return year(current date) -
year(birthdate) create table IBM_People of
Person_t (ref is self) (Note this is
approximate SQL3 syntax)
26

• Queries Over Row Types

• SQL's query constructs, extended with the ability
  to access these features (a la SQL3 plus sets)
• User-defined functions in queries (w/late method
  binding)
• Dereferencing of references (path expressions)
• Queries over nested collections (table
  expressions)
• For example, find unexplainable discrepencies
  between employees' and managers' salaries

select E.name, E.manager-gtname,
display(E.photo) from IBM_Emps E where E.salary gt
E.department-gtmanager-gtsalary and
E.department-gtmanager-gtage( ) gt E.self-gtage(
) and not contains(E.job_description, "Java")
27

• Other OR-Related Features

• Support for large objects
• Multimedia data types aren't small (e.g., video)
• Special handling required for efficiency
• Minimal copying, piecewise retrieval, optional
  logging, movement to/from files, separate storage
  area from other attributes
• DB2 has blob, clob, and dbclob types (up to 2GB)
• Support for active data (triggers and
  constraints)
• Ex

create trigger me_too after insert on
IBM_Emps referencing new as newemp foreach row
mode db2sql when salary gt department-gtmanager-gtsal
ary begin atomic set newemp.department-gtmanager-gt
salary newemp.salary end
28

• OR-DBMS Technology Status

• Many OR-DBMS research results
• Postgres, EXODUS, Starburst, ...
• OODB query processing research
• Commercial systems exist today
• IBM DB2 CS (V2.1) and CA-Ingres
• User-defined types functions, large objects,
  triggers
• Illustra, UniSQL/X
• Early providers of ADTs, row objects, inheritance
• IBM DB2 UDB, Informix, Oracle
• "Universal server" products contain subsets of
  all this stuff
• Standards right around the corner
• SQL3 is "hardening" and has an object part with
  structured types, table hierachies, user-defined
  functions and methods, object views, ....

29

• Some OR-DBMS Performance Issues

• Bucky OR-DBMS benchmark from UW-Madison
• Based on a hypothetical university schema
• Exercised a range of OR-DBMS features
• Row types, inheritance, late binding, subtables
• Queries involving path expressions and/or sets
• ADTs (black or white box) and functions
• In Proc. 1997 ACM SIGMOD Conference
• Tested a first-generation OR-DBMS product
• OR versus relational simulation, same DB engine
• Showed benefits of (complex) ADTs, indexes on
  functions
• Indicated areas where query optimization needs
  schema support scope for path expressions,
  inverse relationships
• Turned up bugs and performance problems (e.g.,
  sets)

30
OR Enterprise Scenerio (w/Challenges)

• Object-relational server managing the database
• ADTs w/inheritance and multi-language support
• Row types, integrated with all of SQL (OO views,
  authorization, triggers, constraints, etc.)
• High-function, OO, caching front-ends
• Support for desktop and middle-tier (web!)
  applications
• OR object model at all levels, for queries and
  navigation
• Clean bindings for OOPLs (Java, C, Smalltalk)
• Methods/queries running on client or server
• Likewise for triggers and constraints
• Business rules specified implemented once!
• In SQL ( OOPL), running where appropriate

31

• Multi-Tier Integration Challenges

• Good mappings and interfaces to provide
  object-relational objects to OOPLs
• Java, C, Smalltalk, others
• Full query support in addition to navigation
• Challenges in querying and caching
• Intelligent querying over cache database
• Correct and efficient caching of view objects
• Update-related challenges
• Triggers and constraints of all types
• View objects (both directions)
• Method execution on client or server
• Java should be very useful here

32

• Legacy Data Access Challenges

• Some data will live outside the OR-DBMS
• Older DBMSs (both relational pre-relational)
• Specialized data stores (documents, images, ...)
• Applications (i.e., legacy transactions)
• Object-relational middleware is the answer!
• Table functions can handle simple cases now
• Distributed OR query engine (a la DataJoiner) can
  mediate between new applications and legacy data
• Resulting appearance is that of an integrated OR
  database, accessible via SQL3 APIs and OO tools

33

• Front-End Integration Legacy Data Access

34

• Conclusions

• Relational DBMS era 1980's, early 1990's.
• Significantly raised the levels of abstraction
  productivity
• Only "real" parallel computing success story to
  date, too!
• Object DBMS era Should have been early 1990's...
• Never made it out of the (mainstream) starting
  gate
• Object-relational DBMS era You are there!
• Object enhancements to relational DBMSs
• ADTs (white box, black box) and functions
• Row types with inheritance, references, sets, ...
• Vastly reduces the "impedence mismatch" w/OOPLs
• Today's OO wrappers are an interim solution
• Possibilities abound for nice OO/OR tools
• Will have OR middleware as well as engines
