Gas exchange in Mammals

1
Gas exchange in Mammals
2
Gas Exchange in Mammals

• Delivery of O2 to gas exchange surface (alveoli)
  and removal of CO2 from capillaries and out of
  the body (ventilation).

3
In Larger Organisms

• Diffusion alone cannot meet the needs of the
  inner-most cells of larger organisms. They have a
  higher demand for O2 and removal of CO2.
• Larger organisms must have some form of internal
  transport system for gases.

4
Pathway

• Air (outside) ? nasal passages (or mouth) ?
  pharynx ? larynx ? trachea ? bronchus ?
  bronchiole ? alveoli ? bloodstream

5

• Nasal passages
• - Air is warmed and moistened. Dust and
  bacteria removed by mucous and nasal hairs
  (cilia).

6
Cilia - creates wave-like movement to sweep
mucous upwards to be expeled at the mouth/nose
(along with trapped debris)
7
Cilia animation

• http//www.bioscope.org/taste/cd1/a0255a.htm

8
Trachea

• Hollow tube held open by C shaped bands of
  cartilage.
• It branches into the two bronchi (one bronchus)
  which also have cartilaginous rings.

9
Alveolus

• Bronchus then branch into smaller tubes called
  bronchioles which lead into grape-like clusters
  of thin-walled air sacs called alveoli (one
  alveolus) which are surrounded by blood
  capillaries.

10

• Oxygen diffuses across the moist lining of the
  alveoli into the capillaries.
• CO2 diffuses out of the capillary and into the
  air in the alveoli.

11
Surfactant

• Lipoprotein produced by alveolar cells
• Reduced surface tension (if no surfactant lung
  cannot inflate normally)

12
Pigment

• Oxygen is picked up by a red pigment called
  haemogoblin (in red blood cells) and is carried
  around the body in the circulatory system .
• As the blood carrying the oxygen (oxygenated
  blood) passes through the body the haemoglobin
  releases oxygen which diffuses into the cells.

13
Other bits

• Diaphragm is a sheet of muscle at bottom of
  these cavities
• Pleural membrane lines each cavity and covers
  each lung, and encloses pleural space (which
  contains fluid to help membranes slide past each
  other during breathing)

www.tcnj.edu/mckinney
14
Breathing/Ventilation
15
(No Transcript)
16
Inhalation Breathing In

• Diaphragm contracts (lowered), intercostal
  muscles contract - lifts ribs up and out.
• Increases volume of chest cavity ? cause the air
  from outside to rush in and fill up the increased
  space.

17
Exhalation Breathing out

• Diaphragm and intercostal muscles relaxes
• Diaphragm moves up and the ribs down
• Air is forced out as the volume in the chest
  cavity returns to normal.

18

• The breathing action (diaphragm etc.) uses
  considerable energy but allows the animal to
  change the rate of gas exchange quickly to suit
  activity/environment requirements.

19
Increased Surface Area for Gas Exchange

• Alveoli ?s surface area exposed for diffusion of
  O2 into capillaries and CO2 out into alveoli.
• 300 million alveoli creates 40x the surface area
  of the body.

20
Moist Surfaces

• Moist surface within nasal passages, alveoli and
  capillaries help O2 in air to dissolve into the
  watery substance for diffusion into capillaries.

21
Thin Exchange Surface

• Thin surface of alveoli and capillaries ?s
  barrier for diffusion of O2 into capillaries and
  CO2 out.

22

• A more specialised system is required for the
  increased size of the animal to deal with
• ? the inefficiency of diffusion over longer
  distances
• ? higher demand for O2 and removal of CO2.
• Internal lungs are well protected from
• ? physical damage
• ? drying out in a dry environment. Enables
  mammals to have a wider range of habitats e.g.
  dry, wet, water on land.
• Lungs have a higher surface area to maximise rate
  of diffusion of O2 into capillaries and removal
  of CO2.
• Then the O2 and CO2 is transported around the
  body in the bloodstream of the circulation system.

23
Blood vessels in the lung
24
Some more interesting info/pictures

• Warning some pictures are a bit gory so stop
  here if you are sensitive to blood and gore.

25
Cross-section of the lung and heart
Figure 238
26
Cilia can be immobilized by smoking
Smokers lung tissue
Normal lung tissue
www.orangeusd.k12.ca.us/date/
27
Cystic fibrosis

• Faulty chloride channel leads to thick mucus ?
  difficult to clear ? blockage and infection

Normal lung tissue
Lung tissue from cystic fibrosis patient
www.pathguy.com/lectures
www.orangeusd.k12.ca.us/date/
28
Black lung disease
An electron micrograph scan of coal dust (marked
by dark patches) in lung tissue infected with
black lung disease. A disease found primarily in
older coal workers, black lung is characterized
by thickening and scarring of lung tissue.
29
Pneumothorax air trapped in the chest cavity.
Pneumothorax air trapped in the chest cavity.
(Tension pneumothorax life-threatening)
(Tension pneumothorax life-threatening)
30
