Title: Introduction%20to%20AutoCAD%20Features


1
Introduction to AutoCAD Features
  • Sacramento City College
  • EDT 310

2
Objectives
  • Describe methods and procedures used in CAD.
  • Explain the value of planning your work and
    system management.
  • Describe the appropriate locations for saving
    drawing files.
  • Load AutoCAD from the Windows Desktop
  • Describe the AutoCAD screen layout and user
    interface.
  • Describe the functions of dialog boxes.

3
Objectives
  • Use the keyboard and an input device to select
    commands, enter text and pick locations on the
    screen
  • Identify the function of the AutoCAD DesignCenter
    and the Properties window.
  • Review Help.
  • Define function, control and shortcut keys.

4
The Tools of CAD
  • Computer
  • Software
  • These components together make up a system
    referred to as CAD.

5
Users of CAD
  • CAD is used by
  • Drafters
  • Designers
  • Engineers
  • Architects
  • They develop designs and drawings and plot them
    on paper.

6
CAD Power
  • CAD is extremely powerful.
  • Because of its speed, power, accuracy and
    flexibility it has surpassed manual drafting.

7
CAD Limitations
  • CAD does have limitations
  • CAD files are only electrical impulses
  • Computers cause repetitive strain injury.

8
The Applications of AutoCAD
  • We will learn how to construct, layout, dimension
    and annotate two-dimensional drawings.
  • Advanced AutoCAD classes will study
    three-dimensional drawing.

9
The Applications of AutoCAD
  • A drawing can have hundreds of colors and layers
    which contain different kinds of information.
  • The drawing objects can have intelligence in
    the form of attributes.
  • 3D models can be constructed, and rendered.
  • Animation can be used to rotate models so they
    can be viewed from any direction.

10
The Applications of AutoCAD
  • The entire project must be considered when
    developing a drawing plan.
  • A detailed knowledge of AutoCAD and its tools
    will assist you.

11
The Applications of AutoCAD
  • Learn the X,Y,Z Coordinate System
  • Drawings are constructed using the Cartesian
    coordinate system X-Y-Z
  • Origin (0,0)
  • Rectangular coordinates
  • X horizontal
  • Y vertical
  • Z third dimension
  • Distance measure horizontally is an X value
  • Distance measured vertically is a Y value.
  • Add the Z, creates 3D drawing.

12
Planning Your Drawing
  • Set a plan prior to working.
  • Determine drawings to be created
  • Determine how they will be titled and numbered
  • Seat of the pants approach does not work well
    here.

13
Planning Your Drawing
  • Use Drawing Standards
  • Standards are guidelines for operating
    procedures, drawing techniques, and record
    keeping.
  • Most companies and schools have established
    standards.
  • It is important that standards exist and are used
    uniformly by all CAD personnel.

14
Planning Your Drawing
  • Standards may include
  • Methods of file storage Location and name
  • Dimensioning techniques
  • File naming conventions
  • Text styles
  • Drawing sheet sizes and title blocks to be used
  • Linetypes
  • Drawing symbols
  • Color schemes for plotting
  • File backup methods and times of backup
  • The most important aspect of standards is that
    they are used.

15
Planning Your Work
  • Plan Your Work FIRST!
  • The time spent on a project will be shortened if
    good planning is performed up front.

Good Planning
Poor Planning
Time Spent
Project Progress
Time Spent
Project Duration/Time Expenditure Pyramid
16
Variables Customize AutoCAD
  • Learn the Function of Variables
  • AutoCAD uses variables to customize how it
    functions for each user.
  • Most variables can be changed by typing the name
    of the variable at the Command prompt, and
    changing a value.

17
SAVETIME Variable
  • One variable is SAVETIME.
  • SAVETIME saves your work at a user-defined time
    period.
  • Use SAVETIME variable to regularly save your
    work.

18
Drawing Planning Sheets
  • Use Drawing Planning Sheets
  • Good work plans save time
  • Planning should include sketches and drawing
    planning sheets.

19
Drawing Planning Sheets
  • Drawing Planning Sheets
  • These tools help in the following ways
  • Determines the drawing layout.
  • Sets the overall size of the drawing by laying
    out the views and required free space
  • Confirms the drawing units based on the
    dimensions provided
  • Predetermines the point entry system and locates
    the points
  • Establishes the GRID and SNAP settings

20
Drawing Planning Sheets
  • Presets some of the drawing variables such as
    LINETYPE, FILL and polyline width.
  • Establishes how and when various activities are
    to be performed.
  • Determines the best use of AutoCAD
  • Results in an even workload
  • Provides maximum use of equipment.

21
Planning Checklist
  • Take the time and plan your work.
  • Avoid tendency to want things to happen
    immediately.
  • Analyze the problem.
  • Study all engineering sketches.
  • Locate all available resources and list for
    future use.
  • Determine the applicable standards for the
    project.
  • Sketch the problem.
  • Decide on the number and kind of views required.

22
Planning Checklist
  • Determine the final plotted scale of the drawing,
    and of all views.
  • List the AutoCAD commands to be used.
  • Determine the drawing sequence (lines, features,
    dimensions, notes, etc.).
  • Follow the standards and refer to resources as
    you work.

23
Working Procedures Checklist
  • Several skills are required for you to become a
    proficient CAD user.
  • Establish a Working Procedures Checklist to
    assist you.

24
Working Procedures Checklist
  • Here are some hints
  • Plan all work with pencil and paper before using
    the computer
  • Check the Object Properties toolbar at the top of
    the display screen and the status bar at the
    bottom to see which layers and drawing aids are
    in effect.

25
Working Procedures Checklist
  • Read the command line at the bottom of the
    display screen before entering data. Constantly
    check for the correct command, instructions, or
    proper keyboard entry of data.
  • Watch disk drive lights to see when the disks are
    being accessed.
  • Think ahead.

26
Working Procedures Checklist
  • Learn new commands every day.
  • Don't rely on just a few that seem to work.
  • Find commands that can speed your work and do it
    more efficiently. (Shortcuts).
  • Save your work every 10 to 15 minutes in case of
    power failure or system crash.

27
Working Procedures Checklist
  • If you're stumped ask the computer for help.
  • Use on-line help.
  • Read the command line after entering data and
    before pressing the ENTER key.

28
Starting AutoCAD
  • AutoCAD operates with
  • Windows 95, 98, NT, 2000, XP.
  • Windows versions are almost identical with regard
    to functionality.
  • When AutoCAD is installed, Windows places a
    Program Icon on the desktop.
  • AutoCAD can be started from the Start Menu or
    from the Program Icon.

29
Starting AutoCAD
  • Sacramento City College runs AutoCAD version 2005
    with Windows XP.

30
Starting AutoCAD
  • To start AutoCAD
  • 1. Double-click the AutoCAD 2005 icon on the
    desktop
  • or
  • 2. Select
  • Start
  • Programs
  • AutoCAD 2000 Folder
  • AutoCAD 2000

31
Standard Screen Layout
  • Graphical User Interface
  • One of the most important aspects of AutoCAD is
    the Graphical User Interface (GUI).
  • Most common component of the GUI is the dialog
    box.

32
The AutoCAD Graphics Window
  • The AutoCAD graphics window is similar to any
    other window within the Windows operating system.
  • Maximize and minimize buttons
  • Close buttons, in the upper right corner
  • Window sizing operations are done as with any
    other window.
  • AutoCAD uses the Windows Guidelines for
    appearance
  • Buttons, pull-down menus, and dialog boxes.

33
Standard Screen Layout
  • The Standard Screen Layout provides a large
    graphics or drawing area.
  • The drawing area is bordered by the toolbar at
    the top and the command line at the bottom.

34
(No Transcript)
35
Standard Screen Layout
  • Items are floating, meaning they can be freely
    moved about on the screen.
  • When an item is floating, it has the standard
    Windows border and title bar.
  • Floating windows can be moved and adjusted for
    size like other windows.

36
Standard Screen Layout
  • Floating Items can be docked around the edges of
    the graphics window.
  • Toolbars can be docked or floated.
  • To dock an item,
  • drag it to the edge of the graphics window (top,
    bottom, left or right).
  • The border will change shape.
  • The item will dock at that location.

37
(No Transcript)
38
Standard Screen Layout
  • Floating Command Window -
  • In default position the window is docked at the
    bottom of the graphics window.
  • Displays the "Command" prompt at the bottom of
    the graphics window.
  • It also displays prompts that supply information
    to you or request input.

39
Standard Screen Layout
  • The Floating Command Window is the primary
    communications area with AutoCAD ! !.

40
(No Transcript)
41
Standard Screen Layout
  • Menu bars
  • Appears just below the title bar and displays a
    number of menu names.
  • File
  • Edit
  • View
  • Insert
  • Format
  • Tools
  • Draw
  • Dimension
  • Modify
  • Window
  • Help

42
Standard Screen Layout
  • Use the cursor to point at a menu name and press
    the left mouse button.
  • A pull-down menu is displayed.
  • Any time you pick an item followed by an ellipsis
    () a dialog box is displayed.

43
Standard Screen Layout
  • Dialog Box
  • A dialog box is a rectangular area that appears
    on the screen after you type or select certain
    commands.
  • Dialog Boxes
  • Contain specific information related to a
    specific command or function.

44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
Standard Screen Layout
  • Scroll bars
  • Allow you to adjust your view of the drawing
    area.
  • Horizontal scroll bars
  • Vertical scroll bars.
  • Graphics cursor size
  • The graphics cursor size can be adjusted -
    preferences, tools cursor size.
  • A value of 100 is full-screen cursor.

48
(No Transcript)
49
(No Transcript)
50
Standard Screen Layout
  • Coordinate System Icon
  • Displays the current coordinate system.
  • Floating toolbars
  • Toolbars can be hidden, moved, resized, modified
    or docked as needed.

51
(No Transcript)
52
Standard Screen Layout
  • Status bar
  • Contains several display fields that reflect the
    current state of specific drawing control
    features.
  • When a menu item is highlighted a brief
    explanation of the item is shown here.
  • Coordinate display
  • Shows the x, y, z cursor location according to
    the current setting.

53
(No Transcript)
54
Standard Screen Layout
  • Standard toolbar
  • When you move the pointing device to the toolbar,
    the crosshairs change to the Windows arrow
    pointer.
  • ToolTips
  • Holding the pointer over a button for a moment
    displays ToolTips which show the function of the
    buttons.

55
Standard Screen Layout
  • Flyout Buttons
  • Some buttons show a small black triangle in the
    lower-right corner.
  • These buttons are called flyouts.
  • Press and hold the pick button while pointing at
    a flyout to display a set of related buttons.

56
(No Transcript)
57
Standard Screen Layout
  • Object Properties toolbar
  • Contains buttons and display fields for commonly
    used AutoCAD commands.

58
Standard Screen Layout
  • Object Properties toolbar
  • Make Object's Layer Current
  • Allows selection of a drawing object to change
    the current layer to that of the selected object
  • Layers
  • Accesses the Layer Linetype Properties dialog
    box.
  • Allows you to create and manage drawing layers
    and linetypes

59
(No Transcript)
60
Standard Screen Layout
  • Object Properties toolbar
  • Layer Control
  • Shows the current layer and its properties
  • Picking the drop-down box shows information on
    all drawing layers and provides a handy shortcut
    to common layer control options.
  • Color Control
  • Displays the current object creation color and
    when picked displays the four most recently used
    colors and the seven standard colors
  • Also allows access to the Select Color dialog box.

61
Standard Screen Layout
  • Object Properties toolbar
  • Linetype
  • Access the Layer Linetype Properties dialog box
    for selecting and loading object linetypes.
  • Linetype Control
  • Displays the current object linetype. Clicking
    on the down arrow to the right allows you to
    select a new linetype from the currently loaded
    line-types.
  • Properties
  • Allows modification to the properties of existing
    objects in a drawing.

62
Standard Screen Layout
  • Pull-Down Menus
  • Pull-down menus are located on the menu bar at
    the top of the screen.

63
Standard Screen Layout
  • Pull-Down Menus
  • AutoCAD contains ten pull-down menu items
  • File
  • Edit
  • View
  • Insert
  • Format
  • Tools
  • Draw
  • Dimension
  • Modify, and Help

64
(No Transcript)
65
Standard Screen Layout
  • Dialog Boxes
  • A dialog box is a box that allows you to set
    variables and select items using your cursor.
  • Information, options, and choices are displayed
    graphically for you by the software.
  • Colors can be displayed by number.
  • Dialog boxes eliminate typing, save time and
    increase productivity.

66
(No Transcript)
67
Standard Screen Layout
  • Dialog Boxes
  • A pull-down selection that is followed by an
    ellipsis (. . .) displays a dialog box when
    picked.
  • Buttons in a dialog box that are followed by an
    ellipsis display yet another dialog box which is
    displayed on top of the first dialog box.
  • You must make a selection from the second dialog
    box before returning to the first dialog box.

68
(No Transcript)
69
Standard Screen Layout
  • Dialog Boxes
  • Command buttons
  • Most common buttons are OK, Cancel, Help
  • Button with the dark gray border is the default.
  • Radio buttons
  • Only one button can be selected at a time, like a
    car radio
  • Check boxes
  • A check mark is displayed when it is active
  • Box is empty when not selected.

70
Standard Screen Layout
  • List boxes
  • Contain a list of options
  • Drop-down list boxes
  • Similar to list boxes but initially, only one
    choice is shown
  • Other choices are shown by clicking on the arrow
    pointing downward on the right side of the screen.

71
Standard Screen Layout
  • Text boxes
  • You can enter a name or a single line of
    information in a text box.
  • Existing text appears highlighted, typing when
    highlighted text exists replaces the text.
  • Pressing either the Backspace key or the Delete
    key deletes all of the highlighted text.

72
Standard Screen Layout
  • Text boxes
  • You can edit the highlighted text by first moving
    the cursor
  • Right and left arrow keys move the cursor one
    character at a time.
  • Using the Ctrl key with the arrows, causes the
    cursor to jump words.

73
Standard Screen Layout
  • File Dialog boxes
  • Provide a simple means of locating and specifying
    file names using the familiar Windows dialog box.
  • Double-clicking a folder opens it.

74
(No Transcript)
75
Standard Screen Layout
  • File Dialog boxes
  • The Look In drop-down list displays the
    directory tree and allows you to browse other
    directories.
  • The Files of Type drop-down list is used to
    specify the type of file being searched for.
  • Selecting a file with one click causes its name
    to appear in the Filename box, and its image to
    appear in the Preview box.

76
(No Transcript)
77
Standard Screen Layout
  • File Dialog boxes
  • The four buttons above the upper-right corner of
    the list box allow you to
  • Backup one folder level.
  • Create a new folder.
  • Display the files as a list of icons or names
    with all file details.
  • The Find File button allows you to browse for a
    file.

78
(No Transcript)
79
Standard Screen Layout
  • Scroll bars and buttons
  • Click above the scroll box to page up.
  • Click below the scroll box to page down.
  • Drag scroll box to move through list of items.
  • Click on up and down arrows individually to move
    through a list of values.

80
Standard Screen Layout
  • Preview Box or Image Tile
  • A preview box is an area of a dialog box that
    displays a "picture" of the item you select such
    as a hatching style, linetypes or text fonts.

81
Standard Screen Layout
  • Dialog Box Tab
  • A dialog box tab is like an index tab used to
    separate files.
  • Many dialog boxes contain two or more pages of
    information, each with a tab at the top.
  • The dialog box is only dismissed when the OK or
    Cancel are selected.

82
(No Transcript)
83
Function Keys
  • Function Keys provide instant access to commands.
  • They can also be programmed to perform a series
    of commands.
  • AutoCAD uses only nine function keys

84
Function Keys
  • F1 - Help
  • F2 - Flip screen from graphics to text toggle
  • F3 - displays Osnap Settings dialog box
  • F4 - Tablet mode toggle
  • F5 - Isoplane left, right, top
  • F6 - Coordinate display
  • F7 - Grid mode toggle
  • F8 - Ortho mode toggle
  • F9 - Snap mode toggle
  • F10 - Polar mode toggle

85
Getting Computer Help
86
Getting Help
  • Help is a powerful and convenient on-line system.
    Help can be activated three ways
  • F1 key
  • Pressing the ? Mark icon on the right end of the
    Standard toolbar
  • Picking AutoCAD help topics from the Help
    pull-down menu
  • Displays Table of Contents Index Find
  • AutoCAD does not have to be running to obtain
    help
  • Pick, Start, Programs, AutoCAD R14, and On-line
    Help.

87
Exploring Help
  • Contents Tab
  • Displays eight book icons and topic names
  • Using Help
  • Tutorial
  • How To
  • Command Reference
  • Users Guide
  • Installation Guide
  • Customization Guide
  • ActiveX Automation

88
Exploring Help
  • Using Help

89
Selecting AutoCAD Commands
  • Commands may be selected in four ways
  • 1. Executed by picking a toolbar button or icon
  • 2. Selected from one of the pull-down menus
  • 3. Selected from the digitizer table menu overlay
  • 4. Typed at the keyboard

90
Selecting AutoCAD Commands
  • Command Line Editing
  • You can select previously used commands by using
    the up and down arrow keys
  • This capability allows for fast, repeated use of
    the same command.

91
Keys
  • The Esc key
  • Control Keys
  • Function Keys
  • Button Functions

92
Keys
  • The Esc key
  • Cancels a command and returns to the Command
    prompt

93
Keys
  • Control Keys
  • Control functions are activated by pressing and
    holding the Ctrl key while pressing a second
    key.

94
Keys
  • Ctrl B - Snap mode (toggle)
  • Ctrl C - Copy
  • Ctrl D - coordinate display on/off toggle
  • Ctrl E - crosshairs in isoplane toggle
    (left/right/top)
  • Ctrl G - Grid on/off toggle
  • Ctrl H - same as backspace
  • Ctrl K - PICKADD system variable toggle
  • Ctrl L - Ortho mode toggle
  • Ctrl O - Open
  • Ctrl P - Print (Plot)

95
Keys
  • Ctrl R - toggle viewport
  • Ctrl S - Save
  • Ctrl T - Tablet mode toggle
  • Ctrl V - Paste
  • Ctrl X - Cut
  • Ctrl Y - Redo
  • Ctrl Z - Undo
  • Provides detailed information on using Windows
    help system.
  • To open a topic, simply double-click on the topic
    name or the book icon that precedes it.

96
Exploring Help
  • Picking an item preceded by a ? Mark, displays a
    Windows Help dialog box.
  • Three buttons are located at the top of this
    window
  • Help Topics - returns to the Help Topics Dialog
    box.
  • Back - flips back to the previous Windows Help
    page
  • Options

97
Exploring Help
  • Options
  • Annotate - allows you to write a note that
    relates to the current help topic.
  • Picking Save attaches your note to the help topic
    with a paper clip icon.
  • To read the annotation, click on the paper clip
  • Copy - copies the entire content of the Windows
    help to the Clipboard.
  • Print Topic - displays the Print dialog box,
    allows you to send the contents of Help to the
    printer.

98
Exploring Help
  • Options
  • Font - allows you to select between small,
    normal, and large fonts for the display of
    Windows Help dialog box text.
  • Keep Help on Top - Allows you to keep the Help
    window on top of all other windows.
  • Use System Colors - returns the help windows to
    the default Windows system colors.

99
Exploring Help
  • Concepts and How To assist you in understanding
    and using AutoCAD drawing concepts and techniques.

100
Exploring Help
  • Index Tab
  • Used by typing the first few letters of the word
    youre looking for
  • As you type the lower list changes to match your
    entry as close as possible
  • Hypertext - is green underlined text
  • If a hypertext item is selected, it automatically
    displays the help screen it is linked to.
  • When the cursor is on hypertext, it becomes a hand

101
Exploring Help
  • Additional information displayed just below the
    command name
  • Quick Help
  • Displays a pop-up topic box that provides
    definitions of the buttons in the AutoCAD Help
    dialog box
  • Up A Level
  • Displays an alphabetical listing of AutoCAD
    commands and system variables
  • See Also
  • Displays a pop-up topic box that provides links
    to commands and variables that are related to the
    one currently displayed

102
Exploring Help
  • Find
  • Allows you to conduct a detailed search based on
    one or more words
  • Glossary
  • Provide a quick definition of a topic

103
5 Minute Assessment
104
5 Minute Assessment
  • What system is used to construct drawings in
    AutoCAD?
  • A. the X-Y-Z system.
  • B. the Cartesian System.
  • C. the orthographic system.
  • D. both A and B.
  • E. none of the above.

105
5 Minute Assessment
  • Drawing Standards. Which of the following
    statements are TRUE.
  • A. Standards are guidelines for operating
    procedures, drawing techniques, and record
    keeping.
  • B. Most companies and schools have established
    standards.
  • C. It is important that each drafter have their
    own standards and adhere closely and uniformly to
    the standards.

106
5 Minute Assessment
  • What is the difference between a button and a
    key?

107
5 Minute Assessment
  • What is the difference between a button and a
    key?
  • A button is located on the screen on a Toolbar.
  • A key is located on the keyboard.

108
5 Minute Assessment
  • What do you call a value that is maintained by
    the computer until you change it?

109
5 Minute Assessment
  • What do you call a value that is maintained by
    the computer until you change it?
  • A variable

110
5 Minute Assessment
  • The Menu Bar is located
  • A. At the bottom of the screen
  • B. At the top of the screen
  • C. On the side of the screen
  • D. Any, or all of the above, because the user can
    move the Menu Bar around.
  • E. The menu bar is not used in AutoCAD.

111
5 Minute Assessment
  • The Menu Bar is located
  • A. At the bottom of the screen
  • B. At the top of the screen
  • C. On the side of the screen
  • D. Any, or all of the above, because the user can
    move the Menu Bar around.
  • E. The menu bar is not used in AutoCAD.

112
5 Minute Assessment
  • When using AutoCAD, why should your work be
    saved frequently?

113
5 Minute Assessment
  • When using AutoCAD, why should your work be
    saved frequently?
  • Frequently saving your work will help avoid
    losing work in the event of a power outage or
    computer crash.

114
5 Minute Assessment
  • Why should you read the Command window at the
    bottom of the screen?

115
5 Minute Assessment
  • Why should you read the Command window at the
    bottom of the screen?
  • Because AutoCAD displays very important
    information to the user in this window.

116
5 Minute Assessment
  • Name two ways to start AutoCAD.

117
5 Minute Assessment
  • Name two ways to start AutoCAD.
  • 1. Double-click the AutoCAD icon on the desktop.
  • 2. Double-click an AutoCAD file
  • 3. Choose Start, Programs, AutoDesk, AutoCAD

118
5 Minute Assessment
  • Name two ways to close AutoCAD.

119
5 Minute Assessment
  • Name two ways to close AutoCAD.
  • File Exit
  • Click the Close Box in the upper right corner of
    the AutoCAD window.

120
5 Minute Assessment
  • What is the function of drawing limits?

121
5 Minute Assessment
  • What is the function of drawing limits?
  • Limits define a drawing space.
  • Example if you have an 11 x 8.5 paper, you may
    want to set the limits to
  • Lower left 0,0
  • Upper right 11, 8.5

122
5 Minute Assessment
  • What is the grid?

123
5 Minute Assessment
  • What is the grid?
  • A rectangular pattern of dots visible on the
    screen drawing area that assists the AutoCAD user
    when creating drawings.

124
5 Minute Assessment
  • Sue likes to draw using the grid. What function
    key should she press to cause the grid to be
    displayed?

125
5 Minute Assessment
  • Sue likes to draw using the grid. What function
    key should she press to cause the grid to be
    displayed?
  • F7 turns GRID on/off

126
5 Minute Assessment
  • To cause the cursor to snap to the grid points,
    what function key should be used?

127
5 Minute Assessment
  • To cause the cursor to snap to the grid points,
    what function key should be used?
  • F9 (turns SNAP on/off)

128
5 Minute Assessment
  • To cause the coordinates to be displayed, what
    function key should be used?

129
5 Minute Assessment
  • To cause the coordinates to be displayed, what
    function key should be used?
  • F6

130
5 Minute Assessment
  • To save an existing AutoCAD drawing that is open
    to a new drawing file, what command sequence
    should be used?

131
5 Minute Assessment
  • To save an existing AutoCAD drawing that is open
    to a new drawing file, what command sequence
    should be used?
  • File, Save As

132
5 Minute Assessment
  • Name three ways an AutoCAD command can be
    executed.

133
5 Minute Assessment
  • Name three ways an AutoCAD command can be
    executed.
  • Toolbar
  • Typed in at the Command prompt
  • Pull-Down menus

134
5 Minute Assessment
  • The fastest method of performing the AutoCAD
    command COPY is
  • A. Selecting it from a menu.
  • B. Typing in the command
  • C. Pressing Ctrl-C.
  • D. Clicking on the Copy button.

135
5 Minute Assessment
  • Edgar would like to use the Object Properties
    toolbar, but it is not showing on his screen.
  • What are two methods you would show him to
    display this toolbar?

136
5 Minute Assessment
  • What is the difference between a docked toolbar
    and a floating toolbar?

137
5 Minute Assessment
  • What happens when you press the Space Bar after
    successfully executing a command?

138
5 Minute Assessment
  • What happens when you press the Up Arrow after
    successfully executing a command?

139
5 Minute Assessment
  • Give an example of a sub-command.
