Electron Configuration

1
Electron Configuration
2
Order of Energy Levels

• Inner shell electrons shield outer electrons
  from the full positive effect of the nucleus
  screening effect
• Different orbitals shield the outer electrons
  more effectively than others
• Not all orbitals experience the same charge
  from the nucleus
• Therefore different orbitals have different
  potential energies

3
(No Transcript)
4
Degenerate Orbitals

• Orbitals that have the same energies

5
Electron Spin

• Electron behaves as if it is spinning on its axis
• Fourth Quantum number (ms) is the spin number
• It can be either 1/2 or 1/2

6

• Spinning electrons produce magnetic fields

7
Pauli Exclusion Principle

• No two electrons can have the same set of four
  quantum numbers (n, l, ml, ms)
• If an orbital has two electrons in it, they must
  have different spins
• Electrons in the same orbital with different
  spins are called paired electrons

8
Configuration

• Arrangement of electrons in the atom
• Aufbau Principle orbitals fill in order of
  increasing energy

9
Orbital Diagram of Li ( 3 e-)

• 1s22s1

10
Orbital Diagram of B (5 e-)

• 1s22s22p1

11
Hunds Rule

• Electrons occupy degenerate orbits singly first

12
Orbital Diagram of C (6 e-)

• 1s22s22p2

13
Orbital Diagram of Ne (10 e-)

• Configuration 1s22s22p6

14
Valence Electrons

• Outer shell electrons
• Ones in the last main energy level
• ? K 1s22s22p63s23p64s1 1 valence e
• Fe 1s22s22p63s23p64s23d6 2 valence e
