Dynamic Programming

1
Dynamic Programming Hidden Markov Models.

• Alan Yuille
• Dept. Statistics UCLA

2
Goal of this Talk
1. Chair

• This talk introduces one of the major algorithms
  dynamic programming (DP).
• Then describe how it can be used in conjunction
  with EM for learning.

3
Dynamic Programming

• Dynamic Programming exploits the graphical
  structure of the probability distribution. It can
  be applied to any structure without closed loops.
• Consider the two-headed coin example given in Tom
  Griffiths talk (Monday).

4
Probabilistic Grammars

• By the Markov Condition
• Hence we can exploit the graphical structure to
  efficiently compute

The structure means that the sum over x2 drops
out. We need only sum over x1 and x3. Only four
operations instead of eight.
5
Dynamic Programming Intuition

• Suppose you wish to travel to Boston from Los
  Angeles by car.
• To determine the cost of going via Chicago you
  only need to calculate the shortest cost from Los
  Angeles to Chicago and then, independently, the
  shortest cost from Chicago to Boston.
• Decomposing the route in this way gives an
  efficient algorithm which is polynomial in the
  number of nodes and feasible for computation.

6
Dynamic Programming Diamond

• Compute the shortest cost from A to B.

7
Application to a 1-dim chain.

• Consider a distribution defined on a 1-dim chain.
• Important property directed and undirected
  graphs are equivalent (for 1-dim chain).
• P(A,B) P(AB) P(B)
• or P(A,B) P(BA) P(A)
• For these simple graphs with two nodes -- you
  cannot distinguish causation from correlation
  without intervention (Wus lecture Friday).
• For this lecture we will treat a simple
  one-dimensional cover directed and undirected
  models simultaneously. (Translating between
  directed and undirected is generally possible for
  graphs without closed loops but has subtleties).

8
Probability distribution on 1-D chain
9
1-D Chain.
10
1-Dim Chain

• (Proof by induction).

11
1-Dim Chain

• We can also use DP to compute other properties
  e.g. to convert the distribution from undirected
  form
• To directed form

12
1-Dim Chain

13
Special Case 1-D Ising Spin Model
14
Dynamic Programming Summary

• Dynamic Programming can be applied to perform
  inference on all graphical models defined on
  trees The key insight is that, for trees, we can
  define an order on the nodes (not necessarily
  unique) and process nodes in sequence (never
  needing to return to a node that have already
  been processed).

15
Extensions of Dynamic Programming

• What to do if you have a graph with closed loops?
• There are a variety of advanced ways to exploit
  the graphical structure and obtain efficient
  exact algorithms.
• Prof. Adnan Darwiche (CS, UCLA) is an expert on
  this topic. There will be an introduction to his
  SamIam code.
• Also can use approximate methods like BP.

16
Junction Trees.

• It is also possible to take a probability
  distribution defined on a graph with closed loops
  and reformulate it as a distribution on a new
  nodes without closed loops. (Lauritzen and
  Spiegelhalter 1990).
• This lead to a variety of algorithm generally
  known as junction trees.
• This is not a universal solution because the
  resulting new graphs may have too many nodes to
  make them practical.
• Google junction trees to find nice tutorials on
  junction trees.

17
Graph Conversion

• Convert graph by a set of transformations.

18
Triangles Augmented Variables

• From triangles to ordered triangles.

Original Variables Loops
Augmented Variables No Loops
19
Summary of Dynamic Programming.

• Dynamic Programming can be used to efficiently
  compute properties of a distribution for graphs
  defined on trees.
• Directed graphs on trees can be reformulated as
  undirected graphs on trees, and vice versa.
• DP can be extended to apply to graphs with closed
  loops by restructuring the graphs (junction
  trees).
• It is an active research area to determine
  efficient inference algorithms which exploit the
  graphical structures of these models.
• Relationship between DP and reinforcement
  learning (week 2).
• DP and A. DP and pruning.

20
HMMs Learning and Inference

• So far we have considered inference only.
• This assumes that the model is known.
• How can we learn the model?
• For 1D models -- this uses DP and EM.

21
A simple HMM for Coin Tossing

• Two coins, one biased and the other fair, with
  the coins switched occasionally.
• The observable 0,1 is whether the coin is head or
  tails.
• The hidden state A,B is which coin is used.
• There are unknown transition probabilities
  between the hidden states A and B, and unknown
  probabilities for the observations conditioned on
  the hidden states.
• The learning task is to estimate these
  probabilities from a sequence of measurements.

22
HMM for Speech
23
HMM for Speech
24
HMM Summary

• HMM define a class of markov models with hidden
  variables. Used for speech recognition, and many
  other applications.
• Tasks involving HMMs involve learning,
  inference, and model selection.
• These can often be performed by algorithms based
  on EM and DP.
