Title: TCP and UDP Performance Over A Wireless LAN


1
TCP and UDP Performance Over A Wireless LAN
  • Professor?????
  • Speaker???
  • Date2004/04/16

2
Outline
  • Introduction
  • Experimental Setup
  • Testing
  • Analysis Of Test results
  • Conclude
  • Reference

3
Outline
  • Introduction
  • Experimental Setup
  • Testing
  • Analysis Of Test results
  • Conclude
  • Reference

4
Our Goals
  • In order to ameliorate WLAN performance problems
    we need a clearer understanding of WLAN behavior
    and analyzing it.
  • Our aim was to compile a comprehensive set of
    data describing the performance of a WaveLAN
    system in terms of throughput and loss under
    various realistic conditions.

5
Network Performance
  • Be Influenced by(difficult to perceive)
  • 1?Network and Host Processing Hardware.
  • 2?Interface Device Drivers.
  • 3?Network Protocol Implementation in the OS.

6
Methods
  • We aims to extend published results in many ways
  • 1?System Heterogeneity
  • 2?New Implementations
  • 3?Bidirectional Communications
  • 4?Error Modeling
  • 5?Operating System

7
Methods Description (1)
  1. We used hosts with varying processing power and
    different wireless interface implementation.
  2. Use 2.4 GHz version. Also used faster processors
    that could potentially achieve higher
    throughputs.
  3. We measured the performance of TCP, in addition
    to UDP.

8
Methods Description (2)
  • 4. We present additional measurements and also
    analyze bidirectional traffic effects.
  • 5. We employed the Linux OS instead of BSD UNIX
    derivatives used in previous work.

9
Outline
  • Introduction
  • Experimental Setup
  • Testing
  • Analysis Of Test results
  • Conclude
  • Reference

10
Hardware
  • Buffer of PCMCIA cards has single buffer.
  • Buffer of ISA cards have multiple buffers

11
Equipment
  • Digital RoamAbout 2.4GHz DSSS system, an OEM
    version of the Lucent WaveLAN.
  • IOS (better) and MYKONOS (poor) are desktops(PC).
  • SYROS is a laptop , and its processor operates at
    a lower clock frequency but has more on_chip
    cache memory.
  • Use CAMA/CA to handle collision problems.

12
Software (1)
  • All hosts ran the Linux OS, in multiuser mode,
    but with no user tasks executing, testing time is
    late in the evening.
  • We made a minor modification to the wireless
    interface drivers to record and report detailed
    statistics plus histograms of signal and noise
    levels.

13
Software (2)
  • Two benchmarks were used
  • 1?TTCP
  • Sends a number of packets of a specified size
    to a receiver using either TCP or UDP.
  • 2?ETTCP (For UDP test)
  • Uses packet sequence number so that the
    receiver can detect and report packet losses.

14
Software (3)
  • Use nstat to gather IP, UDP and TCP statistics
    aggregated across all interfaces to check for
    unexpected network activity during the tests.
  • Use tcpdump to record detailed logs of all
    packets set and received by the wireless
    interfaces during each tests.

15
Location map
45
60
45
feet
16
Environment
  • A floor plan of the area (5th floor) where the
    experiments took place.
  • All rooms are laboratories and machine rooms
    containing numerous hardware devices but no
    direct sources of interference.
  • Hosts were kept immobile during each test to
    avoid mobility induced problems.

17
Outline
  • Introduction
  • Experimental Setup
  • Testing
  • Analysis Of Test results
  • Conclude
  • Reference

18
Testing Scenario
19
Testing Methods (1)
  • The main test parameters were transfer direction,
    peer names, packet size, protocol.
  • A test script first reset and dumped interface
    statistics and nstat output, then started tcpdump
    to record all packets through the wireless
    interface, and finally started ettcp to transfer
    10000 packets.

20
Testing Methods (2)
  • All tests were performed in both directions
    between the peers to reveals any performance
    asymmetries.
  • All tests were performed for both TCP and UDP,
    with four IP datagram sizes100, 500, 1000 and
    1500 bytes to show the effects of varying amounts
    of overhead and packet error probability on
    throughput.

21
Testing Methods (3)
  • Throughput and loss rate are comparable across
    all tests since their units are independent of
    packet size. These can be used to determine the
    optimal packet size where overhead and loss are
    best balanced.

22
Outline
  • Introduction
  • Experimental Setup
  • Testing
  • Analysis Of Test results
  • Conclude
  • Reference

23
Scenario 1
  • Two hosts were placed next to each other to avoid
    signal degradation.
  • Goal
  • It was to determine the peak performance of ISA
    cards and reveal processing power induced
    asymmetries.

24
Result (1-1)
Receiver view
25
Result (1-2)
  • When the slower host (MYKONOS) is sending, packet
    loss is negligible. In contrast, the faster host
    (IOS) overwhelms a slower receiver, leading to
    loss (0.3-0.6) which grows with packet size.

26
Result (2-1)
Receiver view
Mykonos
Ios
27
Result (2-2)
  • Net UDP throughput increases with packet size
    since UDP/IP overhead drops.
  • TCP throughput is not only below UDP, it actually
    drops with large packet sizes.
  • Slower sender makes fewer losses.

28
Result (3-1)
Data sent (I)
Data received (M)
Data sent (M)
Data received (I)
29
Result (3-2)
  • The gaps between sent and received curves for
    both packet types show considerable loss on the
    link, growing with packet size.
  • Since the gaps are roughly the same, we conclude
    that their magnitude represents the number of
    undetected collisions of CSMA/CA.

30
Result (4-1)
31
Result (4-2)
32
Result (4-3)
  • A collision occurs when one data and one
    acknowledgment packet are shown on the sender but
    not on the receiver.

33
Result (5-1)
34
Result (5-2)
  • Both histograms are nearly symmetric since the
    peer interfaces were exactly the same and host
    processing power does not influence the radios.

35
Scenario 2
  • It employs one ISA and one PCMCIA host, again
    placed next to each other, to establish a
    performance baseline for mixed interface tests.
  • The processing power of SYROS and MYKONOS is
    roughly equivalent, thus comparisons with the
    first scenario are direct.

36
Result (1-1)
37
Result (1-2)
  • When the faster host is sending, implying that
    both ISA and PCMCIA receivers are overwhelmed by
    faster senders.
  • In Syros to Ios direction, the perceived losses
    are due to packets never leaving the sending
    interface.

38
Result (2-1)
Ios to Syros (UDP)
Ios to Syros (TCP)
Syros to Ios (UDP)
Syros to Ios (TCP)
39
Result (2-2)
  • In the IOS(ISA) to the SYROS(PCMCIA) direction
    UDP is faster than TCP, due to less header
    overhead and the absence of TCP retransmissions
    and acknowledgments.
  • TCP throughput in the reverse direction is
    slightly lower, verifying previous claims that
    PCMCIA cards are slower senders.

40
Result (3-1)
41
Result (3-2)
42
Result (3-3)
  • Sequence numbers increase faster with an ISA
    sender despite occasional retransmissions. The
    PCMCIA sender leaves short gaps between
    transmission bursts due to the transmit buffer
    shortages
  • PCMCIA card has single transmit buffer, and ISA
    has multiple buffers. So PCMCIA is easy to
    overrun.

43
Scenarios 3 4 (1)
  • Scenarios 3
  • The same as 1, just indicating again that a
    faster sender overruns a slower receiver. But
    signal level are uniformly lower.
  • Scenarios 4
  • The same as 2. But signal level are uniformly
    lower.

44
Scenarios 3 4 (2)
  • We conclude that this distance and obstacles do
    not have measurable effects on performance in
    both ISA/ISA and ISA/PCMCIA tests.

45
Scenarios 5
  • The main difference with 2 4 is a nearly zero
    loss rate in the ISA to PCMCIA direction. This
    shows that hosts matched in processing power
    avoid losses due to receiver overruns.

46
Scenario 6
  • The only difference with scenario 4 is a slightly
    higher loss rate, both due to the increased
    distance and obstacles. And the signal level is
    lower than scenario 4.

47
Outline
  • Introduction
  • Experimental Setup
  • Testing
  • Analysis Of Test results
  • Conclude
  • Reference

48
Conclude
  • Fast senders can overwhelm slower receivers (both
    ISA and PCMCIA), leading to semi-periodic packet
    loss.

49
Outline
  • Introduction
  • Experimental Setup
  • Testing
  • Analysis Of Test results
  • Conclude
  • Reference

50
Reference
  • TCP and UDP Performance over a Wireless LAN (
    George Xylomenos and George C. Polyzos )
