Characterizing, measuring and visualizing forest resources

1
Characterizing, measuring and visualizing forest
resources

• An inadequate treatment by an unqualified
  presenter.

2
Things in this talk

• Remote Sensing 001
• Ways Were Measuring Forests at UConn
• Quick Note on Visualization

3
Geospatial Technologies

• Geographic Information Systems (GIS)
• Remote Sensing (RS)
• Global Positioning Systems (GPS)

• Internet

4
And since were talking forest rather than trees

• Remote sensing is the art and science of
  detecting, identifying, classifying, and
  analyzing the earths surface using special
  sensors onboard airplanes and satellites.

5
Landscape Features Reflect Light Differently
Value
Value
Band
Band
6
Examples of RS Data

• Imagery

Land Cover
Elevation
7
RS Imagery

• General reference/Base mapping
• Visual background to other data
• Digitize new data
• Update existing data

8
What is land cover?

• RS image

Land cover map
9
Land Cover vs Land Use

• Land Cover Literally, what is covering the land
  (forest, wetland, pavement)
• Land Use What is planned, practiced or
  permitted on a given area (commercial,
  residential, dedicated open space)

10
Things in this talk

• Remote Sensing 001
• Ways Were Measuring Forests at UConn
• Quick Note on Visualization

11
Analysis Characterization

• Forest cover maps
• Forest block maps
• Forest fragmentation analysis
• Distance from a road analysis
• Buffer analysis

12
2002 Land cover
13
2002 Land cover forest only
(and water)
Coniferous Forest
Deciduous Forest
Forested Wetland
Water
Non-forest
14
2002 Forest Cover by town
Town of Coventry 67 forested
15
2002 Forest Cover by county
Tolland County 68 forested
16
2002 Forest Cover by watershed
Willimantic Regional Basin 73 forested
17
Forest Cover Advantages

• Easy to understand
• Total cover relates to watershed research,
  possible watershed plan goals
• Can easily fit into Basic NEMO educational
  approach

18
Analysis Characterization

• Forest cover maps
• Forest block maps
• Forest fragmentation analysis
• Distance from a road analysis
• Buffer analysis

19
Forest Block Analysis

• Isolate forest cover
• Remove any polygons smaller than the size of
  interest
• Block size is key for birds and others
• Considerable evidence that powerline corridors
  and roads reduce the quality of habitat for many
  species of forest birds in the surrounding
  habitat
• Powerlines appear to be a conduit that brings
  predators and cowbirds deep into the forest
  interior

20
Forest Blocks by Town
Town of Coventry
21
Forest Blocks by County
Tolland County
22
Forest Blocks by Watershed
Willimantic Regional Basin
23
Forest Block Advantages

• Easy to generate once you have cover data
• Relates well to specific habitat concerns
• Allows the important distinction between amount
  of forest and amount of usable forest for wildlife

24
Analysis Characterization

• Forest cover maps
• Forest block maps
• Forest fragmentation analysis
• Distance from a road analysis
• Buffer analysis

25
UConn CLEAR FF Analysis

• Original method developed by Riitters et al.
  (2000) of the USDA/USFS to assess global forest
  fragmentation from 1 km land cover data.
• Adapted by CLEAR for use on Landsat-derived land
  cover information (30-meter spatial resolution).

26
Pixel-by-pixel analysis

• A moving analysis window (9x9 is shown) is used
  to look at each center pixel in relation to all
  the surrounding pixels.

27
Forest Classes

• Core Forest - all surrounding grid cells are
  forest.
• Perforated Forest - the interior edge of a forest
  tract such as would occur around a small clearing
  or house lot.
• Edge Forest - grid cell is on the exterior edge
  of a forest tract such as would occur along a
  large agricultural field or urban area.
• Transitional Forest - about half of the
  surrounding grid cells are forest.
• Patch Forest - less than 40 of surrounding grid
  cells are forest.

28
Forest Classes

• Core Forest - all surrounding grid cells are
  forest.
• Perforated Forest - the interior edge of a forest
  tract such as would occur around a small clearing
  or house lot.
• Edge Forest - grid cell is on the exterior edge
  of a forest tract such as would occur along a
  large agricultural field or urban area.
• Transitional Forest - about half of the
  surrounding grid cells are forest.
• Patch Forest - less than 40 of surrounding grid
  cells are forest.

29
Forest Classes

• Core Forest - all surrounding grid cells are
  forest.
• Perforated Forest - the interior edge of a forest
  tract such as would occur around a small clearing
  or house lot.
• Edge Forest - grid cell is on the exterior edge
  of a forest tract such as would occur along a
  large agricultural field or urban area.
• Transitional Forest - about half of the
  surrounding grid cells are forest.
• Patch Forest - less than 40 of surrounding grid
  cells are forest.

30
Forest Classes

• Core Forest - all surrounding grid cells are
  forest.
• Perforated Forest - the interior edge of a forest
  tract such as would occur around a small clearing
  or house lot.
• Edge Forest - grid cell is on the exterior edge
  of a forest tract such as would occur along a
  large agricultural field or urban area.
• Transitional Forest - about half of the
  surrounding grid cells are forest.
• Patch Forest - less than 40 of surrounding grid
  cells are forest.

31
Forest Classes

• Core Forest - all surrounding grid cells are
  forest.
• Perforated Forest - the interior edge of a forest
  tract such as would occur around a small clearing
  or house lot.
• Edge Forest - grid cell is on the exterior edge
  of a forest tract such as would occur along a
  large agricultural field or urban area.
• Transitional Forest - about half of the
  surrounding grid cells are forest.
• Patch Forest - less than 40 of surrounding grid
  cells are forest.

32
Forest Cover Map
2002
Forested area 1,886,426 acres 59.3 of CT
33
Forest Fragmentation Map
( 9x9 analysis window )
2002
Core Forest 576,764 acres 18.1 of CT
34
(No Transcript)
35
Forest Blocks by Town
Developed 2672
Non-forest 5098
Water 546
Core/Interior Forest 3461
Perforated Forest 4876
Edge Forest 5724
Transitional Forest 1780
Patch Forest 548
36
Forest Blocks by County
Developed 32439
Non-forest 47377
Water 6065
Core/Interior Forest 57771
Perforated Forest 50610
Edge Forest 53491
Transitional Forest 14505
Patch Forest 5490
37
Forest Blocks by Watershed
Developed 16372
Non-forest 20325
Water 3209
Core/Interior Forest 30216
Perforated Forest 29549
Edge Forest 31042
Transitional Forest 7780
Patch Forest 2325
38
Forest Frag Advantages

• Provide data about quality as well as quantity of
  forest
• Can be run at different scales/grid sizes
  depending on concerns
• Tells you something about pattern of the forested
  landscape and its suitability for habitat

39
Forest Cover
Forest Cover
Forest Blocks
Forest Fragmentation

• all based on the same input data (land cover)
• best use(s) for each???

40
The Forest Frag Wizard!
41
There are many other Forest Fragmentation tools
out there
42
Analysis Characterization

• Forest cover maps
• Forest block maps
• Forest fragmentation analysis
• Distance from a road analysis
• Buffer analysis

43
A Road Runs Through It

• A nationwide study by Foreman (2000) estimates
  that 22 of total land area is affected
  ecologically by roads (within 100m of roads).
• This is further supported by Riitters Wickham
  (2003).
• A study in Massachusetts along Rte. 2 by Foreman
  Deblinger (2000) reports that the maximum
  distance that could be directly impacted by roads
  is up to 300m (984ft).

44

• 11 of Connecticut forest is within 100 ft of
  roads
• 29 of Connecticut forest is within 300 ft of
  roads
• 52 of Connecticut forest is within 600 ft of
  roads

45
Distance of Forest From Roads
100 feet
A nationwide study by Foreman (2000) estimates
that 22 of total land area is affected
ecologically by roads (within 100m of roads).
5400 feet
46
Analysis Characterization

• Forest cover maps
• Forest block maps
• Forest fragmentation analysis
• Distance from a road analysis
• Buffer analysis

47
Land Cover Within Buffers
48
Land Cover Within Buffers
100 ft
200 ft
300 ft
49
What we measured
Developed
Turf Grass
Other Grasses Ag.
Deciduous Forest
Coniferous Forest
Water
Forest Wetland
Non-forested Wetland
Tidal Wetland
Barren
Utility Right-of-way

• Natural Vegetation

50
25 Basins with greatest Natural Vegetation loss
(percent) 1985-2002
51
Combined Indicators of Stream Health
Stream Health Impervious Watershed Natural Veg. 100 ft riparian buffer
Excellent lt 6 gt 65
Good lt10 gt60
Fair 10-25 40-60
Poor gt25 lt40
After Goetz et al., 2003
52
Visualization
53
Stupid PPT Photoshop Tricks
54
Economic modeling
55
Web Tools
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
Build Out Analysis

• ArcGIS and Scenario360

60
Potential New Homes
61
Google Earth
Residential buildout analysis
62
Are you insinuating that my talk wasnt all it
was supposed to be??!
