VLSI Testing

1
VLSI Testing

• Term Project Presentation
• Daniel Milton

2
Project Accomplishments (so far)

• Each student is challenged to create own logic
  simulator for BENCH format and include an
  extension for hierarchy.

3
UML Class Diagram
4
Program Implementation

• Used Java 1.5 update 6 SDK
• jGRASP IDE
• Approx 2000 lines of code.

5
Simulation Algorithm

• Vector generation automatically generated
  according to Primary Inputs
• Each sim_node contains code for simulating every
  type of gate

6
Performance Results
4- Bit Adder Test Data
7
ISCA85 Performance Results
AMD Athlon (Thunderbird) 1.2 GHz , 384 MB RAM,
Windows XP Home SP2
8
Questions?
