Title: CSE 599F: Formal Verification of Computer Systems


1
CSE 599F Formal Verification of Computer Systems
2
Course information
  • Instructor Shaz Qadeer
  • Office 454 Allen Center
  • Lectures CSE 303, Wed-Fri, 12pm-120pm
  • Office hours Wed-Fri, by appointment
  • Web page http//www.cs.washington.edu/education/c
    ourses/599f/

3
What is this course about?
  • Techniques for improving reliability of computer
    systems
  • Applicable to both software and hardware
  • Focus on software
  • Automated techniques for verification of partial
    specifications

4
This course is not about
  • Programming languages and type systems
  • Software engineering methodology
  • Dynamic analysis
  • Software testing

5
Prerequisites
  • Algorithms
  • Formal language theory
  • Elementary mathematical logic
  • But, none of that matters if you really want to
    understand the material

6
Goals
  • Learn about the fundamental ideas
  • Understand the current research problems
  • Do novel research

The best advances come from a combination of
techniques from different research areas!
7
Grades
  • Homeworks
  • Work out examples and theoretical problems
  • Use prototype verification tools to verify simple
    examples
  • Discussion and review of research articles
  • Project (in groups of 1-2)
  • Independent research
  • Survey of a research area
  • Use a verification tool to verify a realistic
    system

8
Why should we care?
  • NIST (National Institute of Standards and
    Technology) report
  • software bugs cost 60 billion annually
  • High profile incidents of systems failure
  • Therac-25 radiation overdoses, 1985-87
  • Pentium FDIV bug, 1994
  • Northeast blackout, 2003
  • Air traffic control, LA airport, 2004

9
Intellectual challenge
  • Civil engineering
  • Bridges dont fail

10
Reliable Engineering
11
Intellectual challenge
  • Civil engineering
  • Bridges dont fail
  • Mechanical engineering
  • Cars are reliable

12
(No Transcript)
13
Intellectual challenge
  • Civil engineering
  • Bridges dont fail
  • Mechanical engineering
  • Cars are reliable
  • Software engineering

14
(No Transcript)
15
Why is software hard?
  • The human element
  • Getting a consistent and complete set of
    requirements is difficult
  • Requirements often change
  • Human beings use software in ways never imagined
    by the designers

16
Why is software hard?
  • The mathematical element
  • Huge set of behaviors
  • Nondeterminism
  • External due to inputs
  • Internal due to concurrency
  • Even if the requirements are unchanging, complete
    and formally specified, it is infeasible to check
    all the behaviors

17
Bubble Sort
BubbleSort(int a, int n) for (i0
iltn-1 i) for (j0 jltn-1-i j)
if (aj1 lt aj)
tmp aj aj aj1
aj1 tmp
  • n inputs
  • 232
  • 264
  • ..
  • ..

Even for a small program, enumeration of the set
of all possible behaviors is impossible!
18
Simple programming language
x ? Variable P ? Program assert x x
x-- P1 P2 if
x then P1 else P2 while x P
Assertion checking for this language is
undecidable!
19
Holy grail of algorithmic verification
  • Soundness
  • If the algorithm reports no failure, then the
    program does not fail
  • Completeness
  • If the algorithm reports a failure, then the
    program does fail
  • Termination
  • The algorithm terminates

It is impossible to achieve the holy grail in
general!
20
Methods
  • Model checking
  • Axiomatic verification

21
Model checking
  • Create a model of the program in a framework that
    is decidable
  • Finite state system
  • Pushdown system
  • Manual model creation
  • Automated model verification

22
Axiomatic verification
  • Program verification similar to validity checking
    in a mathematical logic
  • Axioms
  • Rules of inference
  • Programmer attempts to find a proof using the
    axioms and the rules of inference
  • Manual proof discovery
  • Automated proof checking

23
Recently
  • Combination of model checking and axiomatic
    verification
  • Iterated abstration and refinement
