Laser Tracking System (LTS)

1
Laser Tracking System (LTS)
Son Nguyen Jassim Alshamali Aja
Armstrong Matt Aamold
2
Presentation Outline

• CDR Checklist
• Digitization Sub-Systems
• Controls Sub-Systems
• Target Detection
• Project Schedule

3
Slight Changes to Project

• B/W sampling instead of Color
• B/W uses intensity sampling
• Color uses phase sampling from the back porch
• Black background instead of white
• Better laser detection
• Two power supplies instead of one

4
CDR Checklist

• Timing for digitization
• Obtained main schematics
• Functioning servos
• Creating PWM design
• Designing structure

5
Digitization Sub-System

• Video Frame Timing
• Video Line Timing
• Sync Separator Outputs
• State Machine Diagram
• Timing Counters
• Timing Schematic

6
Digitization Video Frame Timing

• Odd/Even Fields
• Not every line in output of NTSC is valid data
• Last line on each field is half line

7
Digitization Video Line Timing

• 63.5 us line time not all is valid data
• B/W is intensity based

8
Digitization Sync Separator
9
Digitization State Machine
10
Digitization Timing Counters

• Counter A Divides 50Mhz to 12.5Mhz sampling
  clock
• Counter B - Throw out invalid lines starts from
  line sync 1,111,250ns _at_50Mhz 55,562 cycles
• Counter C Throw out invalid line data starts
  from Counter B 9.4us _at_50Mhz 470 cycles
• Counter D Sampling counter starts from Counter
  C 640 samples throughout 52.6us Uses 12.5Mhz
  clock (Coordinate Counter A)
• Counter E Keeps track of which line in frame
  242 valid full lines (Coordinate Counter B)

11
Digitization Timing Schematic
12
Controls Sub-System

• Structure Design
• Servo Testing
• Pulse Wave Modulator Design
• Power Supply Design

13
Controls - Structure

• Rotary Base will serve as the x-axis
• Designs for the y-axis movement are in progress

14
Controls - Servo Testing

• Dual Timer Chip Used to Implement Hardware PWM
• 50hz Base Signal Required
• Changing the duty cycle changes the relative
  position of the servo

15
Controls - Servo Testing

• HiTec HS-50 Servo
• Full Counter-Clockwise 4.2 Duty Cycle
• Full Clockwise 9.8 Duty Cycle
• Center 7.0 Duty Cycle
• Airnotics.Servo
• Full Counter-Clockwise 3.2 Duty Cycle
• Full Clockwise 9.8 Duty Cycle
• Center 5.6 Duty Cycle

16
Controls - Pulse Wave Modulator Design

• Pulse Wave Modulator (PWM) controls the duty
  cycle required to move the servos.
• Implementation of the PWM will be on board the
  FPGA
• Design of PWM will be designed in Verilog

17
Controls - Pulse Wave Modulator

• PWM consists of several parts
• Clock Divider to bring the 50Mhz clock of the
  FPGA down to 45hz-55hz for the base frequency of
  the PWM.
• Verilog code to generate the behavior of a PWM
• Accumulator and registers will be used to adjust
  the duty cycle of the 45hz-55hz waveform

18
Controls - Pulse Wave Modulator

• The clock divider was made with flip flops to
  bring the frequency down to 47hz

19
Controls - Power Supply Design

• Servos
• 9 Volt unregulated transformer
• With a 5 volt regulator
• Digitizing Board
• 12-15 Volt unregulated transformer
• With 12 and 5 regulated voltages

20
Overall Power

• Components
• Camera
• 12V 200 mA 2.4 Watts
• Servos
• Maximum of (9V-5V) 1A 4 Watts
• All ICs will go off of FPGA
• FPGA will use a regulated 5V

21
Target Detection

• Four main state machines
• Target detector
• Choosing mode
• Static mode
• Dynamic mode

22
State Machine for Target Detector
23
Project Schedule
24
