Title: Lab. on Finite State Machine


1
Lab. on Finite State Machine
  • Sequence Recognizer

2
Homework 3 Design a circuit to recognize the
sequence 1101 in a input sequence
  • Output Z1 when 1101 is recognized
  • Thus, the sequential machine must remember that
    the first two one's have occurred as it receives
    another symbol.
  • Also, the sequence 1101101 contains 1101 as both
    an initial subsequence and a final subsequence
    with some overlap, i. e., 1101101 or 1101101.
  • The sequence 1101 must be recognized each time it
    occurs in the input sequence.

3
State Diagram (Moore model)
  • Use
  • JK F.F.
  • binary coding for the states
  • dont care for unused states

4
Simulation
  • Feed a sequence containing 1101 into the designed
    circuit
  • Show the output and states of the circuit
