THE SPARC ARCHITECTURE:

1
THE SPARC ARCHITECTURE

• THE SUPERSPARC MICROPROCESSOR

Presented By OZAN AKTAN ozan.aktan_at_boun.edu.tr
2
THE OUTLINE

• INTRODUCTION
• THE SPARC PROCESSOR
• The Modules
• Integer Unit (IU)
• The Register Window Concept
• Floating Point Unit (FPU)
• Coprocessor
• Instructions
• Traps
• THE SUPERSPARC PROCESSOR
• System Interconnect
• IU Capabilities
• FPU Capabilities
• Cache Memory Organization
• CONCLUSIONS

3
INTRODUCTION

• SPARC stands for Scalable Processor ARChitecture.
• SPARC, formulated at Sun Microsystems in 1985, is
  based on the RISC I II designs engineered at
  the University of California at Berkeley from
  1980 through 1982.
• SPARC is a CPU instruction set architecture
  (ISA), derived from a Reduced Instruction Set
  Architecture (RISC).
• The SPARC architecture is a public property in
  the sense that the semiconductor manufacturers
  are encouraged to produce their own
  implementation of the SPARC architecture.

4
THE DESIGN GOALS

• Provide the scalability of the cost/performance
  ratio of successive implementations with the
  current improvements in circuit technology.
• Construct a simple instruction set, well-matched
  to compiler technology, allowing for
  implementations with very high MIPS rates and
  short development cycles.
• Enable easily pipelined, cost-effective,
  high-performance implementations across a range
  of device integration levels and technologies.

5
THE SPARC PROCESSOR

• The SPARC processor is divided into three parts
• an Integer Unit (IU)
• a Floating-Point Unit (FPU)
• an optional CoProcessor (CP), each with its own
  registers. (32-bits wide).
• The SPARC processor can be in either of 2 modes
• Supervisor mode The processor can execute any
  instruction, including the privileged
  instructions.
• User mode User Application programs will be
  executed in user mode.

6
THE MODULES
Integer Unit (IU)
CoProcessor (CP)
Floating-Point Unit (FPU)
7
THE MODULES
Integer Unit (IU)
Floating-Point Unit (FPU)
8
THE MODULES
Integer Unit (IU)
Floating-Point Unit (FPU)
9
THE MODULES
Integer Unit (IU)
CoProcessor (CP)
Floating-Point Unit (FPU)
10
THE INTEGER UNIT (IU)

• Contains the general purpose registers and
  controls the overall operation of the processor.
• Executes the integer arithmetic instructions and
  computes memory addresses for loads and stores.
• Maintains the program counters and controls
  instruction execution for the FPU and the CP.
• May contain from 40 to 520 general-purpose 32-bit
  registers which corresponds to a grouping of the
  registers into 8 global registers and a circular
  stack of from 2 to 32 sets of 16 registers, known
  as register windows.

Integer Unit (IU)
11
THE REGISTER WINDOW CONCEPT

• Each instruction can access the 8-globals and a
  register window into the 24 registers.
• A register window comprises a 16-register set-
  divided into 8 in and 8 local registers- together
  with the 8 in registers of an adjacent register
  set, addressable from the current window as its
  out registers.

Integer Unit (IU)
12
THE REGISTER WINDOW CONCEPT (CONT.)

• The active window is identified by the 5-bit
  Current Window Pointer (CWP).
• Decrementing the CWP at procedure entry causes
  the next window to become active.
• Incrementing the CWP at procedure entry causes
  the previous window to become active.
• Register window overflow and underflow conditions
  are handled in software by a kernel trap handler.
• The Window Invalid Mask (WIM) can tag any window
  so that an overflow or underflow trap is
  generated whenever the CWP is about to point a
  tagged window.

Integer Unit (IU)
13
THE ADVANTAGES OF USING MULTIPLE WINDOWS

• Make very fast procedure calls as they avoid the
  need to save a processors current in memory,
  further reducing off-chip traffic.
• Instead, the state variables are held in the
  current window, and the next window is opened for
  the new procedure.
• A refinement on this idea in that the input and
  output registers of adjacent windows overlap,
  allowing variables and parameters to be passed to
  the next process without physically moving data.

Integer Unit (IU)
14
THE SPARCs CIRCULAR REGISTER WINDOWS

• The additional registers are hidden from view
  until you call a subroutine or other function.
  Where other processors would push parameters on a
  stack for the called routine to pop off, SPARC
  processors just "rotate" the register window to
  give the called routine a fresh set of registers.
• The old window and the new window overlap, so
  that some registers are shared.

Integer Unit (IU)
15
THE FLOATING-POINT UNIT (FPU)

• The FPU has thirty-two 32-bit-wide registers.
• Double-precision values occupy an even-odd pair
  and extended-precision values occupy an aligned
  group of four registers.
• The FPUs registers are accessed externally only
  via load and store instructions there is no
  direct path between the IU and the FPU.
• If the enable floating-point (EF) bit in the PSR
  is 0, an attempt to execute a floating point
  instruction will generate an fp-disabled trap.

Floating-Point Unit (FPU)
16
THE COPROCESSOR

• The coprocessor instructions mirror the
  floating-point instructions
• Load/store coprocessor,
• Branch on coprocessor condition codes,
• Coprocessor operate (CPop).
• Coprocessor operate instructions can execute
  concurrently with integer instructions.
• The coprocessor unit has its own set of 32-bit
  registers.
• The actual configuration of registers is
  implementation-dependent.

CoProcessor (CP)
17
INSTRUCTIONS

• Instructions fall into six basic categories
• Load/Store
• Arithmetic/Logical/Shift
• Control Transfer
• Read/Write Control Register
• Floating-point Operate
• Coprocessor Operate

18
TRAPS

• A trap is an unexpected procedural call.
• Traps
• decrement the CWM to the next register window.
• cause the hardware to write the trapped program
  counters and state of the registers into the
  local registers of the new window.
• A comparison is made between the interrupt
  request level (bp_IRL) and the processor
  interrupt level (PIL) field of the PSR.

19
A CASE STUDY The SuperSPARC Microprocessor

• A highly integrated superscalar microprocessor
  fully compatible with the SPARC v8 architecture.
• The processor contains
• an integer unit,
• double precision floating point unit,
• fully consistent instruction and data caches
• a SPARC reference memory management unit
• a dual mode bus interface supporting either the
  SPARC standard MBUS, or an interface optimized
  for connection to a companion second level cache
  controller chip.

20
SYSTEM INTERCONNECT

• The dual bus interface allows for systems to be
  designed either with or without an external
  cache.
• Processor modules, are constructed of the
  SuperSPARC processor and optionally an external
  cache built from synchronous SRAM and the
  SuperSPARC cache controller chip.
• The primary bus used by these modules is the
  Level2 SPARC Mbus which is a 64-bit
  multiplexed, cache consistent bus interface
  specification.

21
INTEGER UNIT CAPABILITIES

• The integer unit dynamically selects a group of
  up to three instructions in each cycle.
• This is accomplished by grouping logic which
  scans the next available instructions, and
  selects from zero to three for execution.
• The remaining instructions from either the
  sequential or target instruction queue are
  recirculated back into the sequential target
  queue.

22
INTEGER EXECUTION ORGANIZATON

• Allows for most combinations of independent, as
  well as dependant integer operations to be
  completed.
• Memory reference address calculations are
  performed using a dedicated set of register file
  ports, and a dedicated virtual address adder.
• The virtual address is then used by the cache and
  MMU to access load/store data.

23
BASIC INTEGER PIPELINE OPERATION
24
FLOATING POINT UNIT CAPABILITIES

• Capable of executing single and double precision
  floating point operations.
• Optimized for double precision operations.
• The FPU provides a 4-entry floating point
  instruction queue and a five port floating point
  register file.
• One unique feature of the FPU is that dependant
  floating point instructions may be issued in the
  same instruction group. An example is given
  below.

25
CACHE MMU OPERATION

• SuperSPARC uses fully physically addressed
  caches.
• The caches are organized as set associative
  caches, each set of the cache is required to be
  equal to the minimum page size. (4KBytes)
• The Caches are accessed in parallel with the MMU.

26
CONCLUSIONS

• The SPARC architecture allows for high
  performance processor and system implementations
  at a variety of technology points
• The SPARC Architecture is presented.
• The basic modules of SPARC processor, namely the
  integer, floating point and coprocessor units are
  studied, in detail.
• The register window concept, which differs the
  SPARC processor from other processors is
  described.
• The internal operation and capabilities of
  SuperSPARC microprocessor has been given.

27
REFERENCES

• The SPARC Architecture Manual Version 8, Sun
  Microsystems
• The SuperSPARC microprocessor, Compcon Spring
  '92. Thirty-Seventh IEEE Computer Society
  International Conference, Digest of Papers.
  , 24-28 Feb. 1992 Pages136 141
• Bright Sparc RISC-based microprocessor, IEEE
  Review, Volume 36, Issue 9, 4 Oct. 1990
  Pages331 335
• The Scalable Processor Architecture (SPARC),
  Compcon Spring '88. Thirty-Third IEEE Computer
  Society International Conference, Digest of
  Papers , 29 Feb.-3 March 1988 Pages278 - 283
