Title: Processor Design 5Z032


1
Processor Design 5Z032
Processor Pipelining Chapter 6
Henk Corporaal Eindhoven University of
Technology 2009
2
Topics
  • Pipelining
  • Pipelined datapath
  • Pipelined control
  • Hazards
  • Structural
  • Data
  • Control
  • Exceptions
  • Perfomance improvements
  • Scheduling
  • Branch prediction
  • Superscalar processors

3
Pipelining
  • Improve performance by increasing instruction
    throughput

4
Pipelining
  • Ideal speedup number of stages
  • Do we achieve this?

5
Pipelining
  • What makes it easy
  • all instructions are the same length
  • just a few instruction formats
  • memory operands appear only in loads and stores
  • What makes it hard?
  • structural hazards suppose we had only one
    memory
  • control hazards need to worry about branch
    instructions
  • data hazards an instruction depends on a
    previous instruction
  • Well build a simple pipeline and look at these
    issues
  • Well talk about modern processors and what
    really makes it hard
  • exception handling
  • trying to improve performance with out-of-order
    execution, etc.

6
Basic Idea
  • What do we need to add to actually split the
    datapath into stages?

Fig. 6.10
7
Pipelined Datapath
  • Can you find a problem even if there are no
    dependencies? What instructions can we execute
    to manifest the problem?

Fig. 6.12
8
Corrected Datapath
0
M
u
x
1
I
F
/
I
D
E
X
/
M
E
M
M
E
M
/
W
B
A
d
d
A
d
d
4
A
d
d
r
e
s
u
l
t
S
h
i
f
t
l
e
f
t

2
n
o
A
d
d
r
e
s
s
P
C
i
t
c
u
r
t
s
n
I
n
s
t
r
u
c
t
i
o
n
I
m
e
m
o
r
y
0
0
3
2
Fig. 6.18
9
Graphically Representing Pipelines
  • Can help with answering questions like
  • how many cycles does it take to execute this
    code?
  • what is the ALU doing during cycle 4?
  • use this representation to help understand
    datapaths

10
Pipeline Control
Fig. 6.25
11
Pipeline control
  • We have 5 stages. What needs to be controlled in
    each stage?
  • Instruction Fetch and PC Increment
  • Instruction Decode / Register Fetch
  • Execution
  • Memory Stage
  • Write Back
  • How would control be handled in an automobile
    plant?
  • a fancy control center telling everyone what to
    do?
  • should we use a finite state machine?

12
Pipeline Control
  • Pass control signals along just like the data

Fig. 6.29
13
Datapath with Control
Fig. 6.30
14
Hazards
15
Hazards
  • Hazards problems due to pipelining
  • Hazard types
  • Structural
  • same resource is needed multiple times in the
    same cycle
  • Data
  • data dependencies limit pipelining
  • Control
  • next executed instruction is not the next
    specified instruction

16
Structural hazards
  • Examples
  • Two accesses to a single ported memory
  • Two operations need the same function unit at the
    same time
  • Two operations need the same function unit in
    successive cycles, but the unit is not pipelined
  • Solutions
  • stalling
  • add more hardware

17
Structural hazards
  • Simple pipelining diagram (not MIPS!)
  • IF instruction fetch
  • ID instruction decode
  • OF operand fetch
  • EX execute stage(s)
  • WB write back

time
Instruction stream
Pipeline stalls due to lack of resources
load
time
IF ID OF EX WB
IF ID OF EX WB
IF ID OF EX EX EX WB
Instruction stream
IF ID OF EX WB
IF ID OF EX WB
Shared memory port
One FU
18
Structural hazards
  • Non-pipelined units

Same non-pipelined FU
time
IF
ID
OF
EX
WB
IF
ID
OF
EX
WB
EX
Instruction stream
IF
ID
OF
EX
WB
EX
IF
ID
OF
EX
WB
IF
ID
OF
EX
WB
Stall cycle
19
Structural hazards on MIPS
  • Q Do we have structural hazards on our simple
    MIPS pipeline?

20
Data hazards
  • Data dependencies
  • RaW (read-after-write)
  • WaW (write-after-write)
  • WaR (write-after-read)
  • Hardware solution
  • Forwarding / Bypassing
  • Detection logic
  • Stalling
  • Software solution Scheduling

21
Data dependences
  • Three types RaW, WaR and WaW
  • add r1, r2, 5 r1 r25
  • sub r4, r1, r3 RaW of r1
  • add r1, r2, 5
  • sub r2, r4, 1 WaR of r2
  • add r1, r2, 5
  • sub r1, r1, 1 WaW of r1
  • st r1, 5(r2) Mr25 r1
  • ld r5, 0(r4) RaW if 5r2 0r4

WaW and WaR do not occur in simple pipelines, but
they limit scheduling freedom! Problems for
your compiler and Pentium! ? use register
renaming to solve this!
22
RaW dependence
add r1, r2, 5 r1 r25 sub r4, r1, r3 RaW of
r1
Without bypass circuitry
time
add r1, r2, 5
sub r4, r1, r3
OF
EX
WB
IF
ID
With bypass circuitry
time
add r1, r2, 5
Saves two cycles
sub r4, r1, r3
23
RaW on MIPS pipeline
Fig. 6.36
24
Forwarding
  • Use temporary results, dont wait for them to be
    written
  • register file forwarding to handle read/write to
    same register
  • ALU forwarding

Fig. 6.37
25
Forwarding hardware
ALU forwarding circuitry principle
buf
from register file
buf
to register file
from register file
buf
26
Forwarding
Fig. 6.38
27
Forwarding check
  • Check for matching register-ids
  • For each source-id of operation in the EX-stage
    check if there is a matching pending dest-id

Q. How many comparators do we need?
28
Can't always forward
  • Load word can still cause a hazard
  • an instruction tries to read register r following
    a load to the same r
  • Need a hazard detection unit to stall the load
    instruction

Fig. 6.44
29
Stalling
  • We can stall the pipeline by keeping an
    instruction in the same stage

Fig. 6.45
30
Hazard Detection Unit
I
D
/
E
X
.
M
e
m
R
e
a
d
H
a
z
a
r
d
d
e
t
e
c
t
i
o
n
I
D
/
E
X
u
n
i
t
W
B
e
t
E
X
/
M
E
M
i
r
W
M
D
I
/
C
o
n
t
r
o
l
M
W
B
u
F
M
E
M
/
W
B
I
x
0
E
X
M
W
B
I
F
/
I
D
e
t
i
r
W
M
n
C
u
o
P
i
t
x
c
u
r
t
R
e
g
i
s
t
e
r
s
s
n
D
a
t
a
I
n
s
t
r
u
c
t
i
o
n
I
A
L
U
P
C
m
e
m
o
r
y
M
m
e
m
o
r
y
u
x
M
u
x
I
F
/
I
D
.
R
e
g
i
s
t
e
r
R
s
I
F
/
I
D
.
R
e
g
i
s
t
e
r
R
t
R
t
I
F
/
I
D
.
R
e
g
i
s
t
e
r
R
t
M
E
X
/
M
E
M
.
R
e
g
i
s
t
e
r
R
d
u
I
F
/
I
D
.
R
e
g
i
s
t
e
r
R
d
R
d
x
I
D
/
E
X
.
R
e
g
i
s
t
e
r
R
t
R
s
F
o
r
w
a
r
d
i
n
g
M
E
M
/
W
B
.
R
e
g
i
s
t
e
r
R
d
u
n
i
t
R
t
Fig. 6.46
31
Software only solution
  • Have compiler guarantee that no hazards occur
  • Example where do we insert the NOPs
    ? sub 2, 1, 3 and 12, 2, 5 or 13,
    6, 2 add 14, 2, 2 sw 15, 100(2)
  • Problem this really slows us down!

32
Control hazards
  • Control operations may change the sequential flow
    of instructions
  • branch
  • jump
  • call (jump and link)
  • return
  • (exception)

33
Branch
  • Branch actions
  • Compute new address
  • Determine condition
  • Perform the actual branch (if taken) PC new
    address
  • Squash pipeline
  • When we decide to branch, other instructions are
    in the pipeline!
  • We are predicting branch not taken
  • need to add hardware for flushing instructions if
    we are wrong

34
Branch with predict not taken
Clock cycles
Branch L
IF
ID
EX
MEM
WB
Predict not taken
IF
ID
EX
MEM
WB
IF
ID
EX
MEM
WB
L
35
Branch example
Fig. 6.50
36
Branch speedup
  • Earlier address computation
  • Earlier condition calculation
  • Put both in the ID pipeline stage
  • adder
  • comparator

37
Improved branching / flushing IF/ID

Fig. 6.51
38
Exception support
  • Types of exceptions
  • Overflow
  • I/O device request
  • Operating system call
  • Undefined instruction
  • Hardware malfunction
  • Page fault
  • Precise exception
  • finish previous instructions (which are still in
    the pipeline)
  • flush excepting and following instructions, redo
    them after handling the exception(s)

39
Exceptions
  • Changes needed for handling overflow exception of
    an operation in EX stage(see fig. 6.55)
  • Extend PC input mux with extra entry with fixed
    address
  • Add EPC register recording the ID/EX stage PC
  • this is the address of the next instruction !
  • Cause register recording exception type
  • In case of overflow exception insert 3 bubbles
    flush
  • IF/ID stage
  • ID/EX stage
  • EX/MEM stage

40
Performance improvements
41
Performance improvements
  • Scheduling
  • avoiding data hazards
  • avoiding control hazards
  • Branches
  • delay slot
  • branch prediction
  • Superscalar

42
Scheduling, why?
  • Lets look at the execution time
  • Texecution Ncycles x Tcycle
  • Ninstructions x CPI x Tcycle
  • Scheduling may reduce Texecution
  • Reduce CPI (cycles per instruction)
  • early scheduling of long latency operations
  • avoid pipeline stalls due to structural, data and
    control hazards
  • allow Nissue gt 1 and therefore CPI lt 1
  • Reduce Ninstructions
  • compact many operations into each instruction
    (VLIW)

43
Scheduling data hazards example 1
  • Try and avoid RaW stalls (in this case load
    interlocks)!
  • E.g., reorder these instructions

lw t0, 0(t1) lw t2, 4(t1) sw t0, 4(t1) sw
t2, 0(t1)
lw t0, 0(t1) lw t2, 4(t1) sw t2, 0(t1) sw
t0, 4(t1)
?
44
Scheduling data hazards example 2
Avoiding RaW stalls
Reordering instructions for following program (by
you or the compiler)
Code a b c d e - f
45
Scheduling control hazards
  • Texecution Ninstructions x CPI x Tcycle
  • CPI CPIideal fbranch x Pbranch
  • Pbranch Ndelayslots x miss_rate
  • Modern processors tend to have large branch
    penalty, Pbranch,due to many pipeline stages
  • Note that penalties have larger effect when
    CPIideal is low

46
Scheduling control hazards
  • What can we do about control hazards and CPI
    penalty?
  • Keep penalty Pbranch low
  • Early computation of new PC
  • Early determination of condition
  • Visible branch delay slots filled by compiler
    (MIPS)
  • Branch prediction
  • Reduce control dependencies (control height
    reduction) Schlansker and Kathail, Micro95
  • Remove branches if-conversion
  • Conditional instructions CMOVE, cond skip next
  • Guarding all instructions TriMedia

47
Branch delay slot
  • Add a branch delay slot
  • the next instruction after a branch is always
    executed
  • rely on compiler to fill the slot with
    something useful

48
Branch delay slot scheduling
Q. What to put in the delay slot?
op 1
beq r1,r2, L
.............
op 2
.............
'fall-through'
L op 3
branch target
.............
49
Branch prediction
  • Predict (not)taken schemes use fixed prediction
  • Can we remember (dynamically) branch directions?
  • 1-bit scheme
  • 2-bit schemes
  • multi-level branch predictors
  • hybrid schemes

50
1-bit prediction, using prediction buffer
Branch address
2 K entries
(Lower K bits)
prediction bit
  • Problems
  • Aliasing lower K bits of different branch
    instructions could be the same
  • Solution Use tags however very expensive
  • Loops are predicted wrong twice
  • Solution Use n-bit saturation counter
    prediction
  • taken if counter ? 2 (n-1)
  • not-taken if counter lt 2 (n-1)
  • A 2 bit saturating counter predicts a loop wrong
    only once

51
Using n-bit Saturating Counters
n-bit saturating Up/Down Counter
Branch address
Prediction
a
2-bit saturating counter scheme
N
10/T
11/T
T
T
N
T
00/N
N
01/N
N
T
52
Superscalars
  • issue (start) multiple instructions per cycle
  • multiple function units (like ALU, LD-ST,..)
  • extend forwarding circuitry, detection logic
  • extend ID logic
  • check for independent operations
  • dynamic scheduling

53
Multiple (2) instructions per cycle
Clock cycle
Instruction
54
Multiple (2) instructions per cycle
  • Q How will the following code be executed on
    2-issue machine, with one extra ALU?

Loop lw r0, 0(r1) addu r0, r0,
r2 sw r0, 0(r1) addi r1, r1, -4 bne r1,
r0, Loop
A Check dependencies Only instr. 3 4 can
be executed in parallel Use loop unrolling
and scheduling to improve execution
55
Dynamic Scheduling
  • The hardware performs the scheduling
  • hardware tries to find instructions to execute
  • out-of-order (o-o-o) execution is possible
  • register renaming to avoid WaW and WaR stalls
  • dynamic branch prediction
  • speculative execution

56
Dynamic scheduling architecture
Instr. fetch and decode
forwarding buses
FUs
Register file(s)
57
Dynamic scheduling
  • Q Check the same example, now for a dynamic
    scheduling 2-issue superscalar (a MIPS with one
    extra ALU).

Loop lw r0, 0(r1) addu r0, r0,
r2 sw r0, 0(r1) addi r1, r1, -4 bne r1,
r0, Loop
58
Superscalar processors
  • All modern processors are extremely complicated
  • Deep pipelines
  • Many support o-o-o execution
  • Multi-level branch prediction
  • Speculative execution beyond 4 or more branches
  • Multiple outstanding cache misses
  • Multiple threads
  • .......
  • Compiler technology important

59
Performance Increase
Processor Year Freq SpecInt92 Specfp92 Issue
rate pipelining Intel8096 1978 5 0.2 0.1 1 - In
tel 286 1982 6 1.0 0.5 1 - Intel
386 1986 16 3.1 1.6 1 - Intel 486 1989 25 15 7
1 5 Intel Pent P5 1993 66 67.4 63.6 2 5 Intel
Pent Pro 1995 150 245 220 3 14 Intel Pent
III 1999 450 750 550 3 14 Intel Pent
IV 2001 1400 1850 1950 - 20 M68040 1989 2
5 21 15 1 3 Sparc micro 1992 50 26 21 1 5 Sparc
Ultra I 1995 167 275 305 4 9 Sparc Ultra
III 1999 600 1400 2400 - - Mips
3000 1989 33 18 19 1 5 Mips 4000 1992 100 59 61 1
8 Mips 10K 1995 200 300 600 5 5 HP
7000 1990 66 48 75 1 5 HP 7200 1994 140 150 25
0 2 5 HP 8000 1996 180 400 600 4 7 Alpha
21064 1992 200 133 200 2 7 Alpha
21164 1994 300 300 500 4 7 Alpha
21264 1997 500 1100 1900 4 7 Alpha
21364 2001 1000 2800 4800 4 6 MPC
601a 1993 50 40 60 3 4 MPC 604 1994 100 160 165 4
4 MPC 620 1995 130 225 300 5 4
60
Performance Increase
SPECfp92 data
SPECint92 data
1000
SPECfp92 growth
SPECint92 growth
100
10
SPECint and SPECfp ratings
1.0
0.1
78
80
82
84
86
88
90
92
94
96
98
00
02
Year
  • Microprocessor SPEC Ratings
  • 50 SPECint improvement / year
  • 60 SPECfp improvement / year

61
Summary
  • Modern processors are (deeply) pipelined, to
    reduce Tcycle and aim at CPI 1
  • Hazards increase CPI
  • Several measure to avoid or reduce hazards are
    taken
  • Multi-issue further reduces CPI
  • Branch prediction to avoid high branch penalties
  • Dynamic scheduling
  • In all cases a scheduling compiler needed

62
