Chapter 24: Kingdom Plantae

1
Chapter 24 Kingdom Plantae

• Leaving Certificate Biology
• Higher Level

2
Structure of Flowering Plant

• The flowering plant (also called angiosperm) is
  an example of a living organism that has
  organisational complexity
• Root
• Stem
• Leaf
• Flower
• Seed
• Vascular (transport) structures

3
Structure of Flowering Plant
4
Structure of Flowering Plant

• Function of root and shoot system
• Roots
• Anchorage
• Absorb water and minerals
• Transport water and minerals up plant
• Some root store food
• Shoot
• Transport water, minerals, food
• Sexual reproduction
• Photosynthesis

5
Roots

• Types
• Tap roots main root that originates from the
  radicle at germination
• Lateral emerge from the primary root
• Fibrous roots equal size roots that emerge from
  the stem common in monocotyledonous plants,
  e.g. grass

6
Root Zonation

• Protection root cap protects growing tip
• Meristematic tissue region of high cell
  production (mitosis) and growth
• Elongation new cells formed within the meristem
  then elongate under the influence of growth
  regulators
• Differentiation elongated cells differentiate
  into specialised cells (dermal, ground, vascular)

7
(No Transcript)
8
Meristem

• The meristem is the region of the shoot tip or
  root tip where there is rapid mitosis occurring
  and is responsible for the growth of the plant
• The meristematic regions are present in the root
  and shoot tips and in peripheral regions such as
  in the axillary buds, leaves and fruits

9
Stems

• The stem supports the plant and carries the
  leaves, flowers and fruits of the flowering plant
• Depending on the plant species the stem is either
  herbaceous (soft, green stem) or woody (hard,
  usually brown stem)
• The leaves and branches emerge from points on the
  stem called nodes whereas the section in
  between the nodes is called the internode
• Woody stems also have lenticels present on their
  surface which are responsible for gas exchange

10
Functions of the Stem

• Support
• Transport of water, minerals and food
• Herbaceous stems carry out photosynthesis
• Some store food

11
Leaf

• The leaf is an organ of food production the
  site of photosynthesis
• The leaf of a plant is attached to the stem or
  branch by the petiole located at the node
• The leaf is a flattened structure (blade/lamina)
  designed to capture sunlight
• The leaf has a midrib and veins which are
  continuations of the petiole and which contain
  vascular tissues

12
(No Transcript)
13
Leaf Venation

• Leaf venation depends son the plant species and
  can be either parallel or net/reticulate
• Parallel veins run parallel to each other and
  are most common in monocotyledonous plants such
  as grasses
• Reticulate veins form a network of veins by
  branching out filling the leaf structure and are
  most common in dicotyledonous plants such as
  horse chestnut (see leaf structure on previous
  slide)

14
Function of the Leaf

• Photosynthesis and food production
• Gas exchange
• Transpiration process of losing water
• Food storage

15
Flower Structure
16
Function of the Flower

• The flower function in sexual reproduction by
  attracting insects (presence of nectar) and
  animals (seed and fruit formation after
  fertilisation)

17
Types of Plant Tissue

• Dermal
• Functions in protection by having a thick cuticle
• Also has stomata and controls gas exchange
• Also has root hairs and controls absorption of
  water and minerals
• Ground tissue
• Is responsible for photosynthesis, food storage
  and gives strength and support to the plant
• Vascular tissue
• Xylem transports water and minerals
• Phloem transports food

18
Xylem

• Xylem is a vascular tissue made up of two
  different types of cell
• Xylem tracheids
• Xylem vessels
• Tracheids long, tapered, hollow and dead cells
  whose walls contain pits that allow water
  movement
• Vessels they are strong (supported by lignin),
  long, hollow, dead, tubular cells with their end
  walls broken down to form a continuous tube
  throughout the tissue

19
(No Transcript)
20
Tracheid
21
Vessels
22
Phloem

• Phloem is a transport system running alongside
  xylem that allows products of photosynthesis to
  be redistributed by the plant
• Phloem consists of sieve tubes that transport the
  sugars and companion cells that help in
  transferring the sugars to the sieve tubes

23
Structure of Phloem
24
(No Transcript)
25
Xylem versus Phloem
26
Transverse Section of the Root
27
(No Transcript)
28
(No Transcript)
29
Structure of Leaf
30
Monocots versus Dicots

• Monocotyledonous plants
• 1 cotyledon (storage leaf) in seed
• Mostly herbaceous plants soft, green stem
• Long, narrow leaf with parallel venation
• Vascular bundles arranged randomly in stem
• Petals, leaves arranged in 3s or multiples of 3
• Dicotyledonous plants
• 2 cotyledons (storage leaves) in seed
• Herbaceous or woody
• Broad leaves with network or reticulate venation
• Vascular bundles arranged in ring in stem
• Petals, leaves arranged in 4s or 5s or multiples
  of 4s or 5s
