Title: Market driven developments


1
(No Transcript)
2
(No Transcript)
3
Market driven developments
Trends ACM Development Strategy
Environmental pressure and legislation Lightweight systems Low emission systems Recyclable and recoverable
Improve acoustic comfort Improve acoustic performance
Cost reduction Lightweight systems Fast cycle times
4
ACM MATERIALS
5
ACM MATERIALS
6
WHERE CAN WE FIND ACM APPLICATIONS
7
ACM MATERIALS - THE MARKET
8
ACM ENGINEERING
ACOUSTIC PERFORMANCE vs. MATERIAL PROPERTIES
Acoustic test and Material tests CAUSE-EFFECT
RELATIONSHIPS Material Properties, Cork, Rubber
and compounding impacts BENCHMARKING within ACC
materials, and competitor materials PROCESS
APPLICATION requirements why and how
international standard's, trends
9
ACM TESTING
SOUND TRANSMISSION LOSS ISO 140-3 ASTM E90 ?
Full characterization of the ACM range at Peutz
(Netherlands) ? Data from ISVR (UK) available
for most of ACM grades
  • DAMPING
  • Oberst bar as per ASTM E758 and SAE J1637
  • DMTA according with ASTM E1640
  • ? Material development programs in place with
    universities
  • Material charactherization in progress at KS
    (US)
  • Material development with DMTA at ACC lab

10
SOUND TRANSMISSION LOSS
ISVR
11
SOUND TRANSMISSION LOSS
ISVR
12
DAMPING OBERST BAR
This is a very important test to understand
damping performance in extension of the material
in use as a Single damping layer (SD)
13
DAMPING DMTA
Dynamic Mechanical Thermal Analysis (ACC Lab.)
According with ASTM E1640
Loss factory as a function of temperature. Some
material have a limited temperature range with
high loss factor level (recicled rubbers) and
others are very stable in temperature. In
designing a single damping layer this is
important to be consider.
14
FIRE PERFORMANCE
ACM87
  • PROPAGATION
  • M2 (NF P 92503) _at_ 3mm
  • Class 1 (BS 476 part 1) _at_ 3mm
  • V0 according with UL94
  • EN ISO 11925-2 pass
  • FMVSS 302 pass
  • SMOKE DENSITY AND TOXICITY
  • F3 (NF F16 101) _at_ 3mm

15
FIRE PERFORMANCE
ACM89
  • PROPAGATION
  • M2 (NF P 92503) _at_ 3mm
  • M1 (NF P 92503) _at_ 8mm
  • Class 1 (BS 476 part 1) _at_ 3mm
  • Critical Radiant Flux 1,0 W/cm2 (ASTM E 648)
  • FMVSS302
  • SMOKE DENSITY AND TOXICITY
  • BS 6853-Anex B2 and D8.6,
  • Ao241 (density)
  • R0,31 (toxicity)
  • ASTM E662 (Smoke Density)
  • Ds, 4.0 70
  • ASTM E162 (Surface Flammability)
  • Is 35
  • PASS
  • BS 6853 (UK)
  • Railway flooring
  • Underground flooring, Cat1b (tunnels with exits)
  • Docket 90A and Railroad Federal Specifications
    (US)
  • Wall Ceiling Panels and Floor Covering

16
(No Transcript)
17
MARINE
Structural panel with CorkRubber core which offer
excellent soundproofing properties. Its high
soundwave damping and thermal insulating
capacity, together with its excelent mechanical
properties, make this panel ideal for partitions
and applications requiring excellet environmental
comfort.
Marine deck covering Excelent non skid
properties Shock absorbing Long life time Remains
cool, also at high temperatures Wear
negligible Easy installation
18
BUS
Sound and thermal condicioning In a Bus with 25
m2 of composite panel ACM15 core material can
reduce up to 140 kg with an equivalent CO2 saving
of more than 300 kg/year
19
RAIL TRANSPORTATION
Sound and thermal condicioning Panel weight
reduction up to 44 in comparision with HML core
plywood panels Use of natural, reclaimable raw
materials.
20
ON HIGHWAY TRUCK CABS
Mack Trucks (Volvo)
  • Effective in damping
  • Light weight
  • Cost effective
  • Fire Ratings
  • Green material
  • Recyclable
  • Product interest
  • Full coverage sheets
  • CLD Patch
  • Patch Panel

21
(No Transcript)
22
ENVIRONMENTAL RESPONSABILITY
ACMTM products ensure conformity with all
present regulations for hazardous substances and
are free of PVC
Heavy Metals (Pb, Cd, Hg and Cr(VI))
Formaldehyde and
Comply with RoHS and ELV 2000/53/EC
European Directives
23
ENVIRONMENTAL RESPONSABILITY
Several Amorim Divisions are FSC (Forest
Stewardship Council) certified. Recent studies in
the Iberian Peninsula state that cork oak forest
contributes with more than 20 Millions tons of
CO2 sequestration, making it a significant world
resource for the environmental balance.
Each time cork is harvested, cork bark
regenerates itself. Cork oak trees store CO2 in
order to regenerate, and therefore a harvested
cork oak tree absorbs 3 to 5 times more than one
which is not harvested, thus benefiting the
atmosphere.
24
(No Transcript)
25
COMMUNICATION TOOLS
NRS NOISE REDUCTION SIMULATOR
26
COMMUNICATION TOOLS
BROCHURE
27
COMMUNICATION TOOLS
MATERIAL DATA SHEET
28
(No Transcript)
