Title: Systems Design Project Deliverable 3


1
Systems Design Project Deliverable 3
2
Deliverable 3 Context
  • You have developed data flow diagrams and
    structure chart
  • You have developed system sequence diagrams,
    design class diagrams, and basic method
    definitions
  • Now it is time to create user interfaces and
    database design tasks for the proposed system.

3
User Interface Design
  • Create a set of menu hierarchies for the proposed
    system based on the 10 events/ use cases. Then
    add more menu hierarchies for system utilities
    based on controls, user preferences, and help.
    (Refer Figure 14-8).
  • Write dialog between the user and the computer
    with a natural sequence and appropriate exchange
    of information for each event/ use case. For
    example, refer the dialog given in page 546 of
    your text.

4
User Interface Design (Continued)
  • Using the guiding principles from Chapter 14,
    develop a storyboard (user interaction flow) for
    each event/use case
  • Essentially, you are creating screen mock-ups for
    each use case and sketching a storyboard of the
    forms needed to implement each dialog. (Refer
    Figure 14-9)
  • Be sure to use input controls that minimize data
    entry such as list boxes, radio buttons, check
    boxes etc.
  • Make up some sample data to show in your design
    as needed.

5
Storyboard
6
Database Design
  • For all the 10 events, develop entity-relationship
    diagram (refer figure 13-5)
  • Develop an initial set of Tables representing the
    entities in the ERD with the primary keys added
    (refer figure 13-7)
  • Represent one-to-many many-to-many
    relationships by adding foreign key attributes
    and adding new tables (refer figures 13-8 13-9)
  • Normalize all the tables in the database upto the
    3rd Normal form.
  • Develop class diagram for the database (refer
    figure 13-15)

7
Deliverable
  • A Word document
  • 11 point Arial font
  • Double spaced 1.25 inch margin top and bottom.
    1 inch left and right.
  • Good document format same as previous
    deliverable

8
Grading
  • Document Structure 10
  • Document Content 90
  • User Interface Design 50
  • Database Design 40
