INJEX Pharma GmbH

1
INJEX Pharma GmbH
Needle-Free Injection Technology
INJEX Operation
2
Preparation of Transporter (I)
- turn the green knurled nut of the Transporter,
as shown, anticlockwise, until the cartridge can
be placed in the Transporters compartment.
Transporter
3
Preparation of Transporter (II)
- take the cartridge and put it into the
Transporters compartment.
cartridge
4
Preparation of Transporter (III)

• for a safe and firm seat of the cartridge, turn
  the green knurled nut of the Transporter
  clockwise, as shown, until the plunger softly
  touches the rubber end of the cartridge.

5
Preparation of Transporter (IV)
- take the Transporter Adapter out of its
sterile packaging.

• screw the Transporter Adapter on to the
  Transporter. Ensure that the
• adapter needle pierces the rubber seal of the
  cartridge.

6
Filling of Ampoule (I)

• take an INJEX-Ampoule out of its sterile
  packaging and press the plunger completely into
  the INJEX-Ampoule to force the air out of the
  Ampoule.

Ampoule
plunger
7
Filling of Ampoule (II)
- open the protective cap of the Transporter
Adapter.

• screw the INJEX-Ampoule, clockwise, as shown,
  into the open end of the Adapter until it fits
  tightly.

8
Filling of Ampoule (III)

• turn the green knurled nut at the upper end of
  the Transporter, clockwise, as shown, until the
  desired dose of the pharmaceutical agent is in
  the INJEX-Ampoule.

9
Filling of Ampoule (IV)

• unscrew the filled INJEX-Ampoule from the Adapter
  in an anticlockwise direction and close the
  protective cap.

10
Preparation of the Injector (I)

• take the loaded and safeguarded Injector out of
  the Reset Box.

Injector
Reset-Box
11
Preparation of the Injector (II)

• screw the filled INJEX-Ampoule clockwise into the
  open end of the Injector (the last round goes a
  little bit harder, this is normal).

12
Preparation of the Injector (III)
- push the green safety ring towards the Ampoule
into Safe off position. Now the Injector is
ready for use.
13
The Injection

• hold the Injector under firm pressure
  perpendicularly to the injection site (i.e.
  abdomen), until a clear indentation forms on the
  skin. Press the trigger and release the
  injection. Hold the Injector on the injection
  site for another 1 2 sec.

14
After the Injection (I)
- unscrew the INJEX-Ampoule and discard it
domestic waste -.
15
After the Injection (II)

• push the green safety ring back into the Safe
  position.
• store the secured and non-reset Injector and its
  accessories in the INJEX Case.

16
Thank youfor your attention
INJEX Pharma GmbH Buckower Damm 114 12349 Berlin,
Germany 49-30-667 915 63 www.injex.de
