Computer Math

1
Computer Math

• CPS120 Lecture 3

2
Binary and Computers
Binary computers have storage units called binary
digits or bits
Low Voltage 0 High Voltage 1 all
bits have 0 or 1
22
3
Binary and Computers
8 bits 1 byte The number of bytes in a word
determines the word length of the computer
32-bit machines 64-bit machines etc.
23
4
Binary Representations

• One bit can be either 0 or 1. Therefore, one bit
  can represent only two things.
• To represent more than two things, we need
  multiple bits. Two bits can represent four things
  because there are four combinations of 0 and 1
  that can be made from two bits 00, 01, 10,11.

5
Binary Representations (Contd)

• If we want to represent more than four things, we
  need more than two bits. Three bits can represent
  eight things because there are eight combinations
  of 0 and 1 that can be made from three bits.

6
Binary Alphanumeric Codes

• A binary code is a group of n bits that assume up
  to 2n distinct combinations of 1s and 0s with
  each combination representing one element of the
  set that is being coded- i.e. permutations
• With two bits we can form a set of four elements
• With three bits we can represent 8 elements
• With four bits we can represent 16 elements

7
Binary Representations (Contd)
Figure 3.4 Bit combinations
8
Binary Representations (Contd)

• In general, ? bits can represent 2? things
  because there are 2? combinations of 0 and 1 that
  can be made from n bits. Note that every time we
  increase the number of bits by 1, we double the
  number of things we can represent.

9
Memory Units

• 1 nibble
• 1 byte
• 1 word
• 1 long word
• 1 quad word
• 1 octa-word

• 4 consecutive bits
• 8 consecutive bits
• 2 consecutive bytes
• 4 consecutive bytes
• 8 consecutive bytes
• 16 consecutive bytes

10
Larger Units of Memory

• 1 Kilobyte
• 1 Megabyte
• 1 Gigabyte
• 1 Terabyte
• 1 Petabyte
• 1 Exabyte

• 1024 bytes
• 106 bytes
• 109 bytes
• 1012 bytes
• 1015 bytes
• 1018 bytes

32 Mb 32103 Kb 32 103 1024 bytes
32,768,000 bytes
11
Representing Data

• The computer knows the type of data stored in a
  particular location from the context in which the
  data are being used
• i.e. individual bytes, a word, a longword, etc
• 01100011 01100101 01000100 01000000
• Bytes 99(10, 101 (10, 68 (10, 64(10
• Two byte words 24,445 (10 and 17,472 (10
• Longword 1,667,580,992 (10

12
Numbers
Natural Numbers Zero and any number obtained by
repeatedly adding one to it. Examples 100, 0,
45645, 32
Negative Numbers A value less than 0, with a
sign Examples -24, -1, -45645, -32
2
13
Numbers (Contd)
Integers A natural number, a negative number,
zero Examples 249, 0, - 45645, - 32
Rational Numbers An integer or the quotient of
two integers Examples -249, -1, 0, ¼ , - ½
3
14
Natural Numbers
How many ones are there in 642?
600 40 2 ? Or is it 384 32 2 ? --
Octal Or maybe 1536 64 2 ? -- Hexadecimal
4
15
Natural Numbers
642 is 600 40 2 in BASE 10 The base of a
number determines the number of digits and the
value of digit positions
5
16
Positional Notation
Continuing with our example 642 in base 10
positional notation is 6 x 10² 6 x
100 600 4 x 10¹ 4 x 10
40 2 x 10º 2 x 1 2
642 in base 10
The power indicates the position of the number
This number is in base 10
6
17
Positional Notation
R is the base of the number
As a formula
 dn Rn-1 dn-1 Rn-2 ... d2 R d1
n is the number of digits in the number
d is the digit in the ith position in the
number
642 is  63 102  42 10  21
7
18
Positional Notation
What if 642 has the base of 13? 642
in base 13 is equivalent to 1068 in base 10
6 x 13² 6 x 169 1014 4 x 13¹
4 x 13 52 2 x 13º 2 x 1
2 1068 in base 10
6
8
19
Binary
Decimal is base 10 and has 10 digits
0,1,2,3,4,5,6,7,8,9 Binary is base 2 and has 2
digits 0,1
For a number to exist in a given number system,
the number system must include those digits. For
example The number 284 only exists in base 9 and
higher.
9
20
Codes

• Given any positive integer base (RADIX) N, there
  are N different individual symbols that can be
  used to write numbers in the system. The value of
  these symbols range from 0 to N-1
• All systems we use in computing are positional
  systems
• 495 400 90 5

21
Number Systems

• We use the DECIMAL (10 system
• Computers use BINARY (2 or some shorthand for it
  like OCTAL (8 or HEXADECIMAL (16

22
Power of 2 Number System

Binary Octal Decimal
000 0 0
001 1 1
010 2 2
011 3 3
100 4 4
101 5 5
110 6 6
111 7 7
100 10 8
1001 11 9
1010 12 10
16
23
Bases Higher than 10
How are digits in bases higher than 10
represented?
Base 16 0,1,2,3,4,5,6,7,8,9,A,B,C,D,E, and F
10
24
Conversions
25
Decimal Equivalents

• Assuming the bits are unsigned, the decimal value
  represented by the bits of a byte can be
  calculated as follows
• Number the bits beginning on the right using
  superscripts beginning with 0 and increasing as
  you move left
• Note 20, by definition is 1
• Use each superscript as an exponent of a power of
  2
• Multiply the value of each bit by its
  corresponding power of 2
• Add the products obtained

26
Converting Octal to Decimal
What is the decimal equivalent of the octal
number 642?
6 x 8² 6 x 64 384 4 x 8¹
4 x 8 32 2 x 8º 2 x 1
2 418 in base 10
11
27
Converting Hexadecimal to Decimal
What is the decimal equivalent of the hexadecimal
number DEF?
D x 16² 13 x 256 3328 E x 16¹
14 x 16 224 F x 16º 15 x 1
15 3567 in base 10
Remember, base 16 is 0,1,2,3,4,5,6,7,8,9,A,B,C,D,E
,F
28
Converting Binary to Decimal
What is the decimal equivalent of the binary
number 1101110?
1 x 26 1 x 64 64 1 x 25 1
x 32 32 0 x 24 0 x 16 0 1
x 23 1 x 8 8 1 x 22 1 x 4
4 1 x 21 1 x 2 2 0 x 2º
0 x 1 0 112 in base 10
13
29
Horners Method

• Another procedure to calculate the decimal
  equivalent of a binary number
• Note This method works with any base
• Horners Method
• Step 1 Start with the first digit on the left
• Step 2 Multiply it by the base
• Step 3 Add the next digit
• Step 4 Multiply the sum by the base
• Step 5 Continue the process until you add the
  last digit

30
Converting Binary to Octal

• Groups of Three (from right)
• Convert each group
• 10101011 10 101 011
• 2 5 3
• 10101011 is 253 in base 8

17
31
Binary to Hex

• Step 1 Form four-bit groups beginning from the
  rightmost bit of the binary number
• If the last group (at the leftmost position) has
  less than four bits, add extra zeros to the left
  of the group to make it a four-bit group
• 0110011110101010100111 becomes
• 0001 1001 1110 1010 1010 0111
• Step 2 Replace each four-bit group by its
  hexadecimal equivalent
• 19EAA7(16

32
Converting Decimal to Other Bases

• Step 1 Divide the number by the base you are
  converting to (r)
• Step 2 Successively divide the quotients by (r)
  until a zero quotient is obtained
• Step 3 The decimal equivalent is obtained by
  writing the remainders of the successive division
  in the opposite order in which they were obtained
• Know as modulus arithmetic
• Step 4 Verify the result by multiplying it out

33
Converting Decimal to Hexadecimal
222 13 0
16 3567 16 222 16 13 32
16 0
36 62 13 32 48
47 14 32
15
D E F
21
34
Addition Subtraction Terms

• A B
• A is the augend
• B is the addend
• C D
• C is the minuend
• D is the subtrahend

35
Addition Rules All Bases

• Addition
• Step 1 Add a column of numbers
• Step 2 Determine if there is a single symbol for
  the result
• Step 3 If so, write it and go to the next
  column. If not, write the accompanying number
  and carry the appropriate value to the next column

36
Addition of Binary Numbers

• Rules for adding or subtracting very similar to
  the ones in decimal system
• Limited to only two digits
• 0 0 0
• 0 1 1
• 1 0 1
• 1 1 0 carry 1

37
Arithmetic in Binary
Remember there are only 2 digits in binary 0
and 1 Position is key, carry values are
used
Carry Values
1 1 1 1 1 1 1 0 1 0 1 1 1
1 0 0 1 0 1 1 1 0 1 0 0 0 1 0
14
38
Number Overflow

• Overflow occurs when the value that we compute
  cannot fit into the number of bits we have
  allocated for the result. For example, if each
  value is stored using eight bits, adding 127 to 3
  overflow
• 01111111
• 00000011
• 10000010
• Overflow is a classic example of the type of
  problems we encounter by mapping an infinite
  world onto a finite machine.

39
Subtraction Rules All Bases

• Step1 Start with the rightmost column, if the
  column of the minuend is greater than that of the
  subtrahend, do the subtraction, if not
• Step 2 Borrow one unit from the digit to the
  left of the once being processed
• The borrowed unit is equal to borrowing the
  radix
• Step 4 Decrease the column form which you
  borrowed by one
• Step 3 Subtract the subtrahend from the minuend
  and go to the next column

40
Subtracting Binary Numbers
Remember borrowing? Apply that concept here
1 2
2 0 2 1 0 1 0 1 1 1
- 1 1 1 0 1 1
0 0 1 1 1 0 0
15
41
Addition Subtraction of Hex

• Due to the propensity for errors in binary, it is
  preferable to carry out arithmetic in hexadecimal
  and convert back to binary
• If we need to borrow in hex, we borrow 16
• It is convenient to think in decimal and then
  translate the results back to hex

42
Representing Real Numbers

• Real numbers have a whole part and a fractional
  part. For example 104.32, 0.999999, 357.0, and
  3.14159 the digits represent values according to
  their position, and those position values are
  relative to the base.
• The positions to the right of the decimal point
  are the tenths position (10-1 or one tenth), the
  hundredths position (10-2 or one hundredth), etc.

43
Representing Real Numbers (Contd)

• In binary, the same rules apply but the base
  value is 2. Since we are not working in base 10,
  the decimal point is referred to as a radix
  point.
• The positions to the right of the radix point in
  binary are the halves position (2-1 or one half),
  the quarters position (2-2 or one quarter), etc.

44
Representing Real Numbers (Contd)

• A real value in base 10 can be defined by the
  following formula
• The representation is called floating point
  because the number of digits is fixed but the
  radix point floats.

45
Representing Real Numbers (Contd)

• Likewise, a binary floating point value is
  defined by the following formula
• sign mantissa 2exp

46
Representing Real Numbers (Contd)

• Scientific notation is a term with which you may
  already be familiar, so we mention it here.
  Scientific notation is a form of floating-point
  representation in which the decimal point is kept
  to the right of the leftmost digit.
• For example, 12001.32708 would be written as
  1.200132708E4 in scientific notation.

47
Representing Text

• To represent a text document in digital form, we
  simply need to be able to represent every
  possible character that may appear.
• There are finite number of characters to
  represent. So the general approach for
  representing characters is to list them all and
  assign each a binary string.
• A character set is simply a list of characters
  and the codes used to represent each one. By
  agreeing to use a particular character set,
  computer manufacturers have made the processing
  of text data easier.

48
Alphanumeric Codes

• American Standard Code for Information
  Interchange (ASCII)
• 7-bit code
• Since the unit of storage is a bit, all ASCII
  codes are represented by 8 bits, with a zero in
  the most significant digit
• H e l l o W o r l d
• 48 65 6C 6C 6F 20 57 6F 72 6C 64
• Extended Binary Coded Decimal Interchange Code
  (EBCDIC)

49
The ASCII Character Set

• ASCII stands for American Standard Code for
  Information Interchange. The ASCII character set
  originally used seven bits to represent each
  character, allowing for 128 unique characters.
• Later ASCII evolved so that all eight bits were
  used which allows for 256 characters.

50
The ASCII Character Set (Contd)
51
The ASCII Character Set (Contd)

• Note that the first 32 characters in the ASCII
  character chart do not have a simple character
  representation that you could print to the
  screen.

52
The Unicode Character Set

• The extended version of the ASCII character set
  is not enough for international use.
• The Unicode character set uses 16 bits per
  character. Therefore, the Unicode character set
  can represent 216, or over 65 thousand,
  characters.
• Unicode was designed to be a superset of ASCII.
  That is, the first 256 characters in the Unicode
  character set correspond exactly to the extended
  ASCII character set.

53
The Unicode Character Set (Contd)
A few characters in the Unicode character set
54
Representing Signed Numbers

• Remember, all numeric data is represented inside
  the computer as 1s and 0s
• Arithmetic operations, particularly subtraction
  raise the possibility that the result might be
  negative
• Any numerical convention needs to differentiate
  two basic elements of any given number, its sign
  and its magnitude
• Conventions
• Sign-magnitude
• Ten's complement
• Twos complement
• Ones complement

55
Representing Negatives

• It is necessary to choose one of the bits of the
  basic unit as a sign bit
• Usually the leftmost bit
• By convention, 0 is positive and 1 is negative
• Positive values have the same representation in
  all conventions
• However, in order to interpret the content of any
  memory location correctly, it necessary to know
  the convention being used used for negative
  numbers

56
Comparing the Conventions
57
Representing Negative Values

• You have used the signed-magnitude representation
  of numbers since grade school. The sign
  represents the ordering, and the digits represent
  the magnitude of the number.

58
Representing Negative Values (Contd)

• There is a problem with the sign-magnitude
  representation
• There are two representations of zero.
• There is plus zero and minus zero. Two
  representations of zero within a computer can
  cause unnecessary complexity.

59
Sign-Magnitude

• For a basic unit of N bits, the leftmost bit is
  used exclusively to represent the sign
• The remaining (N-1) bits are used for the
  magnitude
• The range of number represented in this
  convention is 2 N1 to 2 N-1 -1

60
Sign-magnitude Operations

• Addition of two numbers in sign-magnitude is
  carried out using the usual conventions of binary
  arithmetic
• If both numbers are the same sign, we add their
  magnitude and copy the same sign
• If different signs, determine which number has
  the larger magnitude and subtract the other from
  it. The sign of the result is the sign of the
  operand with the larger magnitude
• If the result is outside the bounds of 2 n1 to
  2 n-1 1, an overflow results

61
Other Ways of Representing Negative Values

• If we allow only a fixed number of values, we can
  represent numbers as just integer values, where
  half of them represent negative numbers.
• For example, if the maximum number of decimal
  digits we can represent is two, we can let 1
  through 49 be the positive numbers 1 through 49
  and let 50 through 99 represent the negative
  numbers -50 through -1.

62
Representing Negative Values (Contd)

• To perform addition within this scheme, you just
  add the numbers together and discard any carry.

63
Representing Negative Values (Contd)

• A-BA(-B). We can subtract one number from
  another by adding the negative of the second to
  the first.

64
Representing Negative Values (Contd)

• There is a formula that you can use to compute
  the negative representation
• This representation of negative numbers is called
  the tens complement.

65
Representing Negative Values (Contd)
Twos Complement To make it easier to look at
long binary numbers, we make the number line
vertical.
66
Representing Negative Values (Contd)

• Addition and subtraction are accomplished the
  same way as in 10s complement arithmetic
• -127 10000001
• 1 00000001
• -126 10000010
• Notice that with this representation, the
  leftmost bit in a negative number is always a 1.

67
Twos Complement Convention

• A positive number is represented using a
  procedure similar to sign-magnitude
• To express a negative number
• Express the absolute value of the number in
  binary
• Change all the zeros to ones and all the ones to
  zeros (called complementing the bits)
• Add one to the number obtained in Step 2
• The range of negative numbers is one larger than
  the range of positive numbers
• Given a negative number, to find its positive
  counterpart, use steps 2 3 above

68
Twos Complement Operations

• Addition
• Treat the numbers as unsigned integers
• The sign bit is treated as any other number
• Ignore any carry on the leftmost position
• Subtraction
• Treat the numbers as unsigned integers
• If a "borrow" is necessary in the leftmost place,
  borrow as if there were another invisible
  one-bit to the left of the minuend

69
Overflows in Twos Complement

• The range of values in twos-complement is 2
  n1 to 2 n-1 1
• Results outside this band are overflows
• In all overflow conditions, the sign of the
  result of the operation is different than that of
  the operands
• If the operands are positive, the result is
  negative
• If the operands are negative, the result is
  positive

70
Ones Complement

• Devised to make the addition of two numbers with
  different signs the same as two numbers with the
  same sign
• Positive numbers are represented in the usual way
• For negatives
• STEP 1 Start with the binary representation of
  the absolute value
• STEP 2 Complement all of its bits

71
One's Complement Operations

• Treat the sign bit as any other bit
• For addition, carry out of the leftmost bit is
  added to the rightmost bit end-around carry
