CSE 661 PAPER PRESENTATION

1
CSE 661 PAPER PRESENTATION

• ON-CHIP INTERCONNECTION ARCHITECTURE OF THE TILE
  PROCESSOR
• By D. Wentzlaff et al

Presented By SALAMI, Hamza Onoruoiza g201002240
2
OUTLINE OF PRESENTATION

• Introduction
• Tile64 Architecture
• Interconnect Hardware
• Network Uses
• Network to Tile Interface
• Receive-side Hardware Demultiplexing
• Protection
• Shared Memory Communication and Ordering
• Interconnect Software
• Communication Interface
• Applications
• Conclusion

3
INTRODUCTION

• Tile Processors five on-chip 2D mesh networks
  differ from
• traditional bus based scheme requires global
  broadcast hence not scalable beyond 8 16 cores
• 1D ring not scalable bisection BW is constant
• Can support few or many processors with minimal
  changes to network structure

4
TILE64 ARCHITECTURE

• 2D grid of 64 identical compute elements (tiles)
  arranged in 8 x 8 mesh
• 1GHz clock, 3-way VLIW, 192 bil. 32-bit
  instructions/sec
• 4.8MB distributed cache, per tile TLB
• Supports DMA and virtual memory
• Tiles may run independent OSs. May be combined to
  run multiprocessor OS such as SMP Linux
• Shared memory.
• Cores directly access other cores cache through
  on-chip interconnects

5
TILE64 ARCHITECTURE (2)
Off chip memory BW 200Gbps I/O BW 40Gbps
6
TILE64 ARCHITECTURE (3)
Courtesy http//www.tilera.com/products/processor
s/TILE64
7
INTERCONNECT HARDWARE

• 5 low latency mesh networks
• Each network connects tile in five directions
  north, south, east, west and processor
• Each link made of two 32-bit unidirectional links

8
INTERCONNECT HARDWARE(2)
1.28Tb/s BW in and out of a single tile
9
NETWORK USES

• 4 dynamic networks
• packet header contains destinations (x, y)
  coordinate and packet length (128 words)
• Flow controlled, reliable delivery
• UDN low latency comm. between userland
  processes without OS intervention
• IDN direct communication with I/O devices
• MDN communication with off-chip memory
• TDN direct tile-to-tile transfers requests
  through TDN, response through MDN
• 1 static network
• Streams of data instead of packets
• First setup route, then send streams (circuit
  switched)
• Also a userland network

10
LOGICAL VS. PHYSICAL NETWORKS

• 5 physically independent networks
• Lots of free nearest neighbor on-chip wiring
• Buffer space takes about 60 tile area vs 1.1
  for each network
• More reliable on-chip network gt less buffering
  to manage link failure

11
NETWORK TO TILE INTERFACE

• Tiles have register access to on-chip networks.
  Instructions can read/write from/to UDN, IDN or
  STN.
• MDN and UDN used indirectly on cache miss
• Register-mapped network access is provided

12
RECEIVE-SIDE HARDWARE DEMULTIPLEXING

• Tag word (sending node, stream num., message
  type)
• Receiving hardware demultiplexes message into
  appropriate queue using tag.
• On a tag miss, send data to catch all queue,
  then raise interrupt
• UDN has 4 deMUX queues, one catch all
• IDN has 2 deMUX queues, one catch all
• 128-word reverse side buffering per tile

13
RECEIVE-SIDE HARDWARE DEMULTIPLEXING(2)
14
PROTECTION

• Tile Architecture implements Multicore Hardwall
  (MH)
• MH protects UDN, IDN and STN links
• Standard memory protection mechanisms used for
  MDN and TDN
• MH blocks attempts to send traffic over
  hardwalled link, then signals an interrupt to
  system software
• Protection is implemented on outbound links

15
SHARED MEMORY COMMUNICATION AND ORDERING

• On-chip distributed shared cache
• Data could be retrieved from
• Local cache
• Home tile (request sent through TDN). Data
  available only in home tile. Coherency maintained
  here.
• Main Memory
• No guaranteed ordering between networks and
  shared memory
• Memory fence instructions used to enforce ordering

16
INTERCONNECT SOFTWARE

• C based iLib provides communication primitives
  implemented via UDN
• Lightweight socket-like streaming channels for
  streaming algorithms
• MPI-like message passing interface for adhoc
  messaging

17
COMMUNICATION INTERFACES

• iLib Socket
• Long-lived FIFO point-to-point connection between
  two processes
• Good for producer-consumer relationship
• Multiple senders-one receiver possible good for
  forwarding results to single node for aggregation
• Raw Channels low overhead use as much space as
  available in buffer
• Buffered Channels higher overhead, but
  virtualization of memory is possible

18
COMMUNICATION INTERFACES(2)

• Message Passing API
• Similar to MPI
• Messages can be sent from a node to any other at
  all times
• No need to establish connections
• Implementation
• Sender Send packet with message key and size
• Receivers catch-all queue interrupts processor
• If expecting a message with this key, send packet
  to sender to begin transfer
• Else, save notification.
• On ilib_msg_receive() with same key, send packet
  to interrupt sender to begin transfer

19
COMMUNICATION INTERFACES(3)
20
COMMUNICATION INTERFACES(4)

• UDNs maximum BW is 4 bytes/cycle
• Raw Channels max BW 3.93 bytes/cycle overhead
  due to header word and tag word
• Buffered Channel Overhead of memory read/write
• Message Passing Overhead of interrupting
  receiving tile

21
COMMUNICATION INTERFACES(5)
22
APPLICATIONS

• Corner Turn
• Reorganize distributed array from 1 dimension to
  another
• Each core send data to every other core
• Important Factors
• Network for Distribution (TDN using shared memory
  or UDN using raw channels)
• Network for tiles synchronization (STN or UDN)

23
APPLICATIONS (2)

• Raw Channel, STN synch best performance. Minimum
  overhead raw channels. STN ensures synch messages
  dont interfere with data
• Raw Channel, UDN synch UDN used for data and
  synch messages. Extra overhead data to
  distinguish between both messages.
• Shared Memory Simpler to program . Each user
  data word incurs four extra words to manage
  network and avoid deadlock

24
APPLICATIONS (3)

• Dot Product
• Pairwise element multiplication, followed by
  addition of all products.
• 65,536-element dot product
• Shared memory not scalable, higher communication
  overhead
• From 2 to 4 tiles, speedup is sublinear because
  dataset completely fits into tiles L2 cache.

25
CONCLUSION

• Tile uses unconventional architecture to achieve
  high on-chip communication BW
• Effective use of BW possible due to synergy
  between hardware architecture and software APIs
  (iLib).
