Distributed File System

1
Distributed File System
2
Outline

• Basic Concepts
• Current project
• Hadoop Distributed File System
• Future work
• Reference

3
DFS

• A distributed implementation of the classical
  time sharing model of a file system, where
  multiple users share files and storage resources.

4
Key Characteristics of DFS

• Dispersion
• Clients and files
• Multiplicity
• Clients and files

5
Primary issues of DFS

• Naming and Transparency
• Fault Tolerance

6
Naming

• Naming mapping between logical and physical
  objects.
• Multilevel mapping.
• Transparent replicas and location

7
Naming Schemes Three Main Approaches

• Host name local name
• guarantees a unique system wide name.
• Mount remote directories to local directories
• once mounted, files can be referenced in a
  location-transparent manner
• Total integration of the component file systems.
• A single global name structure
• If a server is unavailable, some arbitrary set of
  directories on on different machines also becomes
  unavailable

8
Transparency(1)

• Login Transparency User can log in at any host
  with uniform login procedure and perceive a
  uniform view of the file system.
• Access Transparency Client process on a hots has
  uniform mechanism to access all files in system
  regardeless of files are on local/remote host.
• Location Transparency The names of the files do
  not reveal their physical location.

9
Transparency(2)

• Concurrency Transparency An update to a file
  should not have effect on the correct execution
  of other process that is concurrently sharing a
  file.
• Replication Transparency Files may be
  replicated to provide redundancy for availability
  and also to permit concurrent access for
  efficiency.

10
Fault Tolerance

• Stateful Vs. Stateless
• Maintain information on client
• File Replication

11
Distinctions Between Stateful Stateless Service

• Failure Recovery.
• A stateful server loses all its volatile state in
  a crash.
• With stateless server, the effects of server
  failure and recovery are almost unnoticeable.

12
File Replication

• Several copies of a file's contents at different
  locations enable multiple servers to share the
  load of providing the service
• Naming scheme maps a replicated file name to a
  particular replica.
• Updates

13
Current Project

• HDFS Hadoop Distributed File System
• Distributed parallel fault tolerant file system.
  It is designed to reliably store very large files
  across machines in a large cluster.
• Efficient, reliable, and open source

14
Hadoop is a framework for running applications on
large clusters built of commodity hardware. The
Hadoop framework transparently provides
applications both reliability and data motion.
Hadoop implements a computational paradigm named
Map/Reduce, where the application is divided into
many small fragments of work, each of which may
be executed or reexecuted on any node in the
cluster. In addition, it provides a distributed
file system (HDFS) that stores data on the
compute nodes, providing very high aggregate
bandwidth across the cluster. Both Map/Reduce and
the distributed file system are designed so that
node failures are automatically handled by the
framework.
15
HDFS

• Hadoop's Distributed File System is designed to
  reliably store very large files across machines
  in a large cluster. It is inspired by the Google
  File System. Hadoop DFS stores each file as a
  sequence of blocks, all blocks in a file except
  the last block are the same size. Blocks
  belonging to a file are replicated for fault
  tolerance. The block size and replication factor
  are configurable per file. Files in HDFS are
  "write once" and have strictly one writer at any
  time.
• Hadoop Distributed File System Goals
• Store large data sets
• Cope with hardware failure
• Emphasize streaming data access

16
Architecture

• Like Hadoop Map/Reduce, HDFS follows a
  master/slave architecture. An HDFS installation
  consists of a single Namenode, a master server
  that manages the filesystem namespace and
  regulates access to files by clients. In
  addition, there are a number of Datanodes, one
  per node in the cluster, which manage storage
  attached to the nodes that they run on. The
  Namenode makes filesystem namespace operations
  like opening, closing, renaming etc. of files and
  directories available via an RPC interface. It
  also determines the mapping of blocks to
  Datanodes. The Datanodes are responsible for
  serving read and write requests from filesystem
  clients, they also perform block creation,
  deletion, and replication upon instruction from
  the Namenode.

17
(No Transcript)
18

• Naming central metadata server
• Synchronization write-once-read-many, give locks
  on objects to clients, using leases
• Consistency and replication server side
  replication, asynchronous replication, checksum
• Fault tolerance failure as norm
• Security no dedicated security mechanism

19
Future Work

• Robustness of data sharing model
• The preceding section, architecture, naming,
  synchronization, availability, heterogeneity and
  support for databases
• Security

20
Reference

• 1 Thanh, T.D. Mohan, S. Choi, E. SangBum
  Kim Pilsung Kim. 2008Networked Computing and
  Advanced Information Management. A Taxonomy and
  Survey on Distributed File Systems
• 2 Randy chow,1997,Distributed operating systems
  Algorithms
• 3 Eliezer Levy, Abraham Silberschatz. December
  1990 Computing Surveys (CSUR) , Volume 22 Issue
  4. Distributed file systems concepts and
  examples.
• 4http//hadoop.apache.org/common/docs/current/hd
  fs_design.htmlIntroduction
• 5http//www.snia.org/events/wintersymp2009/cloud
  /dhruba_hadoop_snia.pdf

21

• 6http//en.wikipedia.org/wiki/List_of_file_syste
  msDistributed_file_systems
• 7http//en.wikipedia.org/wiki/HadoopHadoop_Dist
  ributed_File_System
• 8http//www.cs.gsu.edu/cscyqz/courses/aos/slide
  s08/ch6.1-Fall08.pptx

22
QA?
23
Thank you!
