Meta-Level Control in Multi-Agent Systems

1
Meta-Level Control inMulti-Agent Systems

• Anita Raja and Victor Lesser
• Department of Computer Science
• University of Massachusetts
• Amherst, MA 01002

2
Bounded Rationality
A theory of rationality that does not give an
account of problem-solving in the face of
complexity is sadly incomplete. It is worse than
incomplete it can be seriously misleading by
providing solutions that are without operational
significance Herb Simon, 1958

Basic Insight Computations are actions with
costs
3
Motivation

• Control actions like scheduling and coordination
  can be expensive
• Current multi-agent systems do not explicitly
  reason about these costs
• Need to account for costs at all levels of
  reasoning to provide accurate solutions
• Build meta-level control framework with minimum
  cost that reasons about cost of different
  control actions

4
Assumptions

• Agent can pursue multiple tasks simultaneously
• Agent can partially fulfill or omit tasks
• Agent can coordinate with other agents to
  complete tasks
• Tasks have varying arrival times, deadlines and
  associated utilities
• Tasks have alternate ways of being achieved
• Objective function MAX utility over a fixed time
  horizon

5
Agent Architecture
6
Meta-level Decision Taxonomy

• Whether to accept, delay or reject an incoming
  new task?
• How much effort to put into reasoning about a new
  task?
• Whether to negotiate with another agent about
  task transfer?
• Whether to renegotiate in case of failure of
  previous negotiation?
• Whether to re-evaluate current plan when a task
  completes?

7
Decision Tree for New task arrival event
8
Some State Features
Name Description Value Complexity
F0 Relative Utility of new task High Med Low Simple
F1 Relative Deadline of new task Simple
F2 Relative Utility of current schedule Simple
F8 Relation of slack fragments to current schedule Complex
F9 Relation of other agents slack fragments to non-local task High Med Low Complex
9
Some Heuristic Decisions

• If current schedule has low priority (expected
  quality is low) and incoming task is of high
  priority (high expected quality with tight
  deadline), then drop current schedule and
  schedule new task immediately.
• If current schedule has very high priority and
  new task has low expected utility and a tight
  deadline, drop the new task
• If current task to be scheduled has high
  execution uncertainty associated with it and a
  deadline which is not tight, then introduce high
  slack in the schedule and use medium scheduling
  effort

10
Related Work

• Monitoring Progress of Anytime Algorithms (Hansen
  Zilberstein)
• Uses dynamic programming for computation of a
  non-myopic stopping rule
• Predictability versus Responsiveness (Durfee
  Lesser)
• Control amount of coordination using a user
  specified buffer
• Meta-level Control of Coordination Protocols
  (Kuwabara)
• Detects and handles exceptions by switching
  between protocols
• Does not account for overhead of reasoning process

11
Evaluation

• Compare system using hand-generated MLC
  heuristics to
• Naïve multi-agent system with no explicit MLC
• Deterministic choice MLC
• Random choice MLC
• MLC with knowledge of environment characteristics
  including arrival model
• Environments are characterized by the following
  parameters
• Type of tasks Simple (S), Complex (C),
  Combination (A)
• Frequency of Arrivals High (H), Medium (M), Low
  (L)
• Deadline Tightness High (H), Medium (M), Low
  (L)

12
An Example
13
Evaluation, Continued
14
Evaluation, Continued
15
Contributions

• Meta-level control in a complex environment
• Designed agent architecture that reasons about
  overhead at all levels of the decision process
• Parametric control algorithm which reasons about
  effort and slack
• Identified state features for control using
  reinforcement learning

16
Future Work

• Implement Reinforcement-Learning based control
  algorithm
• Function approximation (Sarsa(?) linear
  tile-coding)
• MDP states will be abstractions of actual system
  state
• Study effectiveness of RL algorithm on complex
  domain
• Compare performance of heuristic approach to RL
  approach

17
Research Questions

• What are the major obstacles to efficient
  meta-level control?
• How can costs be accurately included at all
  levels of reasoning?
• How to deal with the huge, complex state space?
• Is reinforcement learning a feasible approach to
  learn good meta-level control policies?
