Title: Gross Anatomy


1
Gross Anatomy
  • Background Review

2
Anatomical Position, terminology
  • Nomina Anatomica (Latin)
  • Normal anatomical position
  • upright, arms at side, forearm hand supine

3
(No Transcript)
4
Planes
  • imaginary lines separating the body at different
    angles
  • 1. Median - longitudinal - separates left and
    right (hit surface at anterior, posterior median
    lines)
  • 2. Coronal also referred as Frontal - vertical,
    right angle to median - separate anterior and
    post (front, back)
  • 3. Horizontal - (often transverse, not always)
    - separate superior inferior (upper
    /lower)(transverse of hand is horizontal but the
    foot is coronal)
  • 4. Sagittal - vertical off-center, parallel to
    median (include midsagittal parasagittal)

5
(No Transcript)
6
Sections / slices
  • 1. Longitudinal
  • lengthwise through body or an appendage
    (direction of its long axis)
  • can be in median, coronal or sagittal planes
  • 2. Vertical - same as longitudinal but referring
    to body in anatomical position
  • 3. Transverse - cross sections - at right angles
    to long axis (often horizontal)
  • 4. Oblique - slanted, at an angle, not in
    longitudinal or transverse

7
Relational terms
  • to localize different structures on the body in
    anatomical position
  • 1. Anterior ventral - toward front (chest,
    palms, soles) also rostral in brain
  • 2. Posterior dorsal - toward back (dorsum)
  • 3. Superior cranial cephalic - toward head
  • 4. Inferior caudal - below, toward feet (tail)
  • 5. Medial - toward midline or median plane
  • 6. Lateral - toward side, away from median
    (little toe lateral little finger medial)
  • 7. Intermediate - between 2 structures
  • 8. visceral
  • 9. parietal

8
Relative / Comparison
  • Terms to describe relative positions of to
    compare 2 structures
  • 1. Proximal - nearer trunk or point of origin
  • 2. Distal - farther from trunk or point of origin
  • 3. Superficial - to surface
  • 4. Deep - away from surface
  • 5. External - toward exterior, especially of an
    organ
  • 6. Internal - to the interior of an organ or
    inner surface
  • 7. Ipsilateral - same side of body
  • 8. Contralateral - opposite side ( Right vs.
    Left )
  • 9. Central - near or towards the center
  • 10. Peripheral - father, away from the center

9
Movements - of body parts
  • 1. Abduction - away from midline
  • 2. Adduction - toward midline
  • 3. Flexion - bend - decrease angle of a joint
  • 4. Extension - straighten - increase angle of a
    joint (hyperextension beyond straight point)
  • 5. Lateral rotation - rotate outward (e.g. leg)
  • 6. Medial rotation - rotate inward
  • 7. Circumduction - circular motion (involves 1-4)
  • 8. Inversion - sole of foot toward median plane

10
(No Transcript)
11
(No Transcript)
12
Movements - of body parts
  • 9. Eversion - sole of foot laterally - outward to
    side
  • 10. Pronation - rotate hand so palm faces
    posterior
  • 11. Supination - rotate hand so palm is anterior
  • 12. Protrusion - move anteriorly - stick out
    (e.g. chin)
  • 13. Retraction / Retrusion - move posteriorly -
    pull, tuck in (shoulders, chin)
  • 14. Elevation - lifting
  • 15. Depression - lowering to a more inferior
    position
  • 16. Opposition - move thumb towards the other
    digits
  • 17. Reposition - move thumb away from other digits

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Systems
  • 1. Integumentary - skin accessory structures
  • 2. Skeletal - bones, cartilages
  • 3. Articular - joints ( bones, ligaments at
    each)
  • 4. Muscular - muscles (part of musculoskeletal)
  • 5. Nervous - brain, spinal cord, nerves
  • 6. Circulatory - vascular - heart arteries,
    veins, capillaries lymphatic (nodes, vessels)

18
Systems
  • 7. Respiratory - lungs, diaphragm, airways
  • 8. Digestive - alimentary canal (mouth to anus)
    accessory organs (liver, pancreas etc)
  • 9. Renal / Urinary - kidneys, bladder, excretory
    tubule system
  • 10. Endocrine - endocrine glands (pituitary,
    hypothalamus, adrenals, reproductive glands)
  • 11. Reproductive - ovaries or testes (a.k.a.
    urogenital system, esp. in males)

19
Muscular System
  • function in movement, support (posture), heat
    generation

20
Skeletal Muscle
  • 1. striated, voluntary
  • 2. moves bones, skin (facial muscles) -
    typically, origin insertion are attached across
    a joint
  • - most are under our control, although many
    movements are reflexes - eg stretch reflex
  • 3. attachments
  • each has an Origin proximal attachment
    Insertion distal attachment
  • 4. structure  a. muscle fiber muscle cell
    structural unit b. motor unit one motor neuron
    all muscle fibers under its control
  • size varies inversely with precision, delicacy of
    control

21
Skeletal muscle
  • 5. movements a. agonists prime movers - carry
    out the main movement
  • b. antagonists - oppose action of agonists -
    relax as agonist contracts for smooth movement
  • c. synergists - complement/ work with/ support
    prime movers - especially to support the joint
  • d. fixators - steady proximal part of limb while
    distal part is moved (e.g. forearm vs. hand)

22
Smooth muscle
  • 1. non-striated, involuntary - controlled by ANS
  • 2. propels foodstuffs thru alimentary canal
    blood thru vessels a. undergoes peristalsis -
    rhythmic waves of contraction
  • b. maintains a constant level of tone (esp.
    important in vasculature)

23
Cardiac muscle
  • 1. striated, but involuntary - spontaneous
    excitation under control of ANS
  • 2. pumps blood through heart

24
Nervous System
  • Major Functions of the Nervous System
  • 1. Sensory - many receptor types in body sense,
    detect changes in body or surroundings
  • 2. Integration - of information received thru
    sensory system to arrive at a proper response
  • 3. Motor - nerve impulses trigger responses by
    the bodys effectors muscles, glands etc

25
Nervous System
  • Divisions
  • 1. CNS the brain spinal cord - nerves do NOT
    regenerate after injury
  • 2. PNS peripheral nerves that communicate
    between the CNS and the rest of the body- nerves
    MAY regenerate after injury

26
(No Transcript)
27
Structures
  • 1. Neurons the functional cells of the NS -
    transmit electrical impulsesa. dendrites
    receptive processes receive impulses from
    receptors other neuronsb. axon single
    transmitting process, sends impulse to other
    neurons or to effectors- myelin sheath -
    insulates axon - speeds transmission- nodes of
    Ranvier - spaces between sections of myelin

28
(No Transcript)
29
Structures
  • 2. Neuroglial cells
  • a. supportive accessory cells - insulate, connect
    neurons, attach neurons with surrounding tissue
  • b. provide nutritive support - to provide energy,
    provide central nervous system with blood
  • 3. Types of Neurons - Classified by Function
  • a. Motor
  • b. Sensory
  • c. Interneurons depends on how information
    flows

30
(No Transcript)
31
Basic terminology
  • 1. Nucleus - a group of neuronal cell bodies
    within the CNS
  • 2. Ganglion (ganglia, pl) - group of cell bodies
    outside the CNS
  • 3. Nerve - collection of axons (fibers) in PNS
    fasciculus - a bundle of nerves- plexus
    network of nerves in one area
  • 4. Tract - bundle of axons/fibers in the CNS
  • 5. Gray matter - concentrations of cell bodies in
    CNS, e.g.. cerebral cortex
  • 6. White matter - axons, processes in the CNS

32
Connective tissue meninges
  • 1. CNS meninges
  • connective tissue surround, protect the nervous
    sytem
  • a. pia mater - immediately next to the nervous
    tissue
  • b. arachnoid - middle layer
  • the 2 inner layers, leptomeninges, thin
    delicate
  • c. dura mater - outermost meninges, thicker
    very tough
  • d. cerebrospinal fluid fills space between
    arachnoid and pia mater

33
(No Transcript)
34
PNS
  • a. endoneurium thin collagenous layer,
    immediately surrounds a myelinated n fiber
  • b. perineurium CT covering surrounding a
    fascicle of nerve fibers
  • c. epineurium thick CT layer surrounding many
    fascicles wh make up a nerve trunk
  • the 3 CNS meningial layers are continuous with
    the CT layers around PNS nerves

35
(No Transcript)
36
The Peripheral Nervous System
  • 1. Cranial nerves 12 pair transmit from brain to
    head, neck, trunk (mixed, motor sensory, more
    in Neuro)
  • 2. Spinal nerves 31 pair communicate btw spinal
    cord neck, trunk, arms, legs (mixed)
  • a. Dorsal roots - sensory/afferent fibers into
    cord, dorsal root ganglia contain cell bodies of
    sensory neurons
  • b. Ventral roots - motor/efferent ff from cord to
    periphery, branch once outside cord
  • c. dorsal ventral roots combine, form spinal
    nerve, which branches again
  • dorsal primary rami supply fibers to dorsum
    (back)
  • ventral primary rami supply fibers to
    anterolateral trunk, limbs

37
Somatic Nervous System
  • 1. nerves that communicate w skin skeletal
    muscles
  • 2. functions are under conscious control

38
Autonomic Nervous System
  • 1. concerned with automatic/ visceral functions,
    homeostatic mechanisms (CVS, digestion)
  • 2. function without conscious control
  • 3. control the function of visceral organs -
    heart, smooth muscle, vessels, glands D. ANS has
    2 Divisions

39
Sympathetic Division
  • concerned primarily w survival, emergency,
    stressful situations Fight or flight system
  • a. connects with thoracic lumbar segments T1 -
    L2 or 3
  • b. many connect with Peripheral NS efferent/motor
    neuron in ganglia
  • paravertebral ganglia (sympathetic trunk)
  • prevertebral ganglia  (visceral ganglia., e.g.
    celiac ganglia.)
  • the adrenal medulla (exception, innervated by
    preganglionic fiber directly)
  • c. route spinal cord lateral horn - sympathetic
    axons (preganglionic) gt through ventral root gt
    through white ramus communicante (branch to
    ganglion) gt to paravertebral ganglia

40
Sympathetic Division
  • then either 1) passes through ganglia (without
    synapse) directly to viscera (as a splanchnic
    nerve)
  • 2) ascends or descends through trunk to another
    level, then postganglionic fibers innervate
    organs like heart, lungs, glands
  • 3) synapses in ganglia with excitor neurons gt
    postganglionic go back through gray ramus
    communicante gt then blend in with spinal nerve gt
    effectors

41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
Parasympathetic system
  • Breed and Feed
  • a. concerned w normal functions eating,
    sleeping, procreation, conserving energy
  • b. connects with cranial sacral segments
    cranial III, VII, IX, X spinal S2 - S4

46
(No Transcript)
47
(No Transcript)
48
Spinal cord
  • 1. continuation of the CNS from the brain, out of
    the skull into the vertebral column
  • 2. composed of 31 segments - a pair of spinal
    nerve exits each segment, to the periphery
  • 3. gray matter localized to central core mostly
    cell bodies, proximal unmyelinated process
  • 4. white matter surrounds central area composed
    of primarily myelinated axons, fibers

49
Spinal cord
  • 5. Function - spinal cord communicates to from
    the brain the remainder of the body
  • a. ascending tracts carry sensory input to CNS
    (some to spinal cord, some to brain)
  • b. descending tracts leaving the brain spinal
    cord carry motor output to effectors
  • c. most fiber tracts cross to contralateral side
    at some point in spinal cord or brain

50
  • mixed nerves
  • 31 pairs
  • 8 cervical (C1 to C8)
  • 12 thoracic (T1 to T12)
  • 5 lumbar (L1 to L5)
  • 5 sacral (S1 to S5)
  • 1 coccygeal (Co)

51
Dermatome
  • an area of skin that the sensory nerve fibers of
    a particular spinal nerve innervate

52
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
