Maximizing Intel Compiler Performance
usingIterative Feedback Directed Optimization
(IFDO)

• Ilya Cherny
• Software Manager
• Software and Services Group
• Thanks to Leonid Brusencov, Sergey Ermolaev,
  Artem Chirtsov, Sergey Grebenkin!
• October 23, 2008

2
Agenda

• Why IFDO
• What is IFDO
• Alternative approaches
• Experimental Results
• Future plans

3
A Performance Experiment

• Take 3 nested loops for matrix multiplication
• for(i 0 i lt N i)
• for(j 0 j lt N j)
• cij 0
• for(k 0 k lt N k)
• cij aik bkj
• Compile with maximum optimization
• icl O3 matmul.c
• Run and measure time 20 sec
• Compile with enforced vectorization
• icl -O3 mP2OPT_vec_alwaysT
• Run and measure time 11 sec

gticl help .. /O3 optimize for maximum speed
and enable high-level optimizations ..
Why dont switch on vectorization always?
4
A Performance Experiment II

• Switch i and j loops, move initialization
  loop outside
• for(i 0 i lt N i)
• for(j 0 j lt N j)
• cij 0
• for(j 0 j lt N j)
• for(i 0 i lt N i)
• for(k 0 k lt N k)
• cij aik bkj
• Compiler with O3 optimization
• Measure run time 18 sec
• Compile with enforced vectorization
• Measure run time 21 sec

Thoughtless optimization loses 15
5
Why Optimizations Do Not Always Win?

• Source code adding 4 integers

for(i0ilt4i) AiAiBi
Compile to scalar code
Compile to vector code
loop_start mov ebx, Bedi add Aedi,
ebx inc edi loop loop_start
movdqa xmm1, A paddd xmm1, B movdqa A, xmm1

• Vector code could be 2-4x times faster, but..
• ..what if array size is not a multiple of 4?
• ..what if A is not aligned by 16 bytes?
• ..what if A and B aligned differently?
• Final code has an overhead of these 3 if

6
Heuristics for Parameterization of Compiler
Optimizations

• Compiler has hundreds of performance
  optimizations
• Each optimization has at least 1 Boolean
  parameter
• Compiler has heuristics to make a decision about
  each optimization
• But still code produced by the compiler is far
  from optimal
• Each application has unique behavior (loop
  counts, memory accesses)
• Each machine has unique characteristics
  (latencies, caches)
• It is impossible to target ALL compiler
  heuristics for ALL machines for ALL applications

Compiler optimizations have considerableperforman
ce headroom if parameterized right
7
Agenda

• Why IFDO
• What is IFDO
• Alternative approaches
• Experimental Results
• Future plans

8
IFDO process
2.FeedbackRun executable with profiling

• 1. Optimization Compile executable from the
  sources

3.DirectedAnalyze results, define options for
the next compilation
4.IterativeRepeat while time permits
9
Search Algorithms

• Implemented 6 algorithms to do search in the
  options space 20
• exhaustive search with priorities
• batch elimination
• iterative elimination
• combined elimination
• genetic algorithm
• statistical selection 23

Search algorithms find the maximum much faster
than after 2n iterations
10
Compiler Optimization Options

• Selected 6 undocumented options which seem to
  have the highest impact
• loop vectorization
• loop fusion
• loop distribution
• loop unrolling
• data blocking
• memory prefetch
• Number of total independent option values is 13
• Search space for these 6 options has 7000
  combinations
• Extracted all compiler options from the sources
  and just started the runs for more than 1000
  options

11
IFDO Tool

• User defines how to build and execute his
  application
• IFDO tool outputs the best binary and all
  performance data
• Based on IFDO results user can
• change compilation options or pragmas
• modify sources
• improve compiler

IFDO tool automates iteration process
12
IFDO Sample Output - SPEC CPU2000 173.applu

• iter stat proc ticks impr noise
  parameter val parameter val
• --------------------------------------------------
  -----------------------------
• 1 ... Total 9571493442 0.00 0.21
• 1 ... _SSOR 7335205487 0.00 0.26
  VectorizeP 1 BlockP 1
• 1 ... _RHS 2218915958 0.00 0.02
  VectorizeP 1 BlockP 1
• 2 ... Total 6234529813 34.86 0.01
• 2 ... SSOR 4048766558 44.80 0.01
  VectorizeP 1 BlockP 2
• 2 ... _RHS 2168605738 2.27 0.05
  VectorizeP 1 BlockP 2
• 3 ... Total 12889959745 -34.67 0.06
• 3 ... SSOR 11309558116 -54.18 0.07
  VectorizeP 2 BlockP 1
• 3 ... RHS 1563970212 29.52 0.01
  VectorizeP 2 BlockP 1
• 4 ... Total 10806270474 -12.90 0.15
• 4 ... _SSOR 8657609979 -18.03 0.10
  VectorizeP 3 BlockP 1
• 4 ... _RHS 2102104477 5.26 0.01
  VectorizeP 3 BlockP 1
• 5 .. Total 5602632636 41.47 0.00

But Intel Compiler improved since 10.0 SPEC
173.applu has 8 only headroom now!
41 performance gain!
13
Agenda

• Why IFDO
• What is IFDO
• Alternative approaches
• Experimental Results
• Future plans

14
Comparison to other publications

• There are 23 references to the similar papers
• No publications have compiler with procedure
  level granularity
• All publications were limited by about 50
  options, while we started exploring 1000 of
  undocumented compiler options

Our work has two novel characteristics
15
Comparison to other tools
Granularity Profiling Conclusion
Manual options search - whole application or source changes -/ any profiler, but manually user time consuming
PGOprof_gen/prof_use) basic block level - basic block counters only 2 iterations only
PathScale PathOpt2 - whole application - whole application 40 less results
IFDO function or loop instrumentation, VTune not available in the product
16
Agenda

• Why IFDO
• What is IFDO
• Alternative approaches
• Experimental Results
• Future plans

17
Search Algorithms Performance Growth dependency
on Iteration

• BE works for independent options only, but just
  14 iterations
• IE and CE get 99 in 30 iterations the most
  effective

All algorithms gain 2.5-4 in CPU2000 total time
18
Procedure vs. Application granularity
8 from 22 benchmarks gain from procedure level
19
Options Values Contribution to Performance
Increase
Each option gives about 2 percent
20
1000 Options Impact on Performance
Only 600 from 3000 options have zero impact
21
Agenda

• Why IFDO
• What is IFDO
• Alternative approaches
• Experimental Results
• Future plans

22
Future Plans

• Make experiments with all undocumented options
• 3000 values if no impact on each other
• more than 23000 combinations!
• Implement storing of application properties
• number of FP expressions, number of loops, etc.
• Implement expert/machine learning system
• suggest options according to application
  properties
• may decrease number of iterations down to 1
• can substitute existing compiler heuristics?

Useful to both compiler developers and users
23
Summary

• If performances critical, try at least icl O3!

24
???????! Thanks!
25
References 1-13

• 1 F. Bodin, T. Kisuki, P. Knijnenburg, M.
  OBoyle, and E. Rohou, Iterative compilation in
  a non-linear optimization space, In Proc. ACM
  Workshop on Profile and Feedback Directed
  Compilation, 1998, Organized in conjunction with
  PACT98.
• 2 K. Cooper, D. Subramanian, and L. Torczon,
  Adaptive optimizing compilers for the 21st
  century, J. of Supercomputing, 32(1), 2002.
• 3 J. Bilmes, K. Asanovic, C. Chin, and J.
  Demmel, Optimizing matrix multiply using PHiPAC
  A portable, high- performance, ANSI C coding
  methodology, In Proc. ICS, pages 340-347, 1997.
• 4 M. Stephenson and S. Amarasinghe, Prediction
  unroll factor using supervised classification,
  In ERRR/ACM International Symposium on Code
  Generation and Optimization (CGO 2005), ERRR
  Computer Society, 2005.
• 5 Yom-Toy, J. Thomson, O. Temam, A. Zaks, H.
  Leather, C. Miranda, M. Namolaru, E. Bonilla,
  Saclay, B. Mendelson, C. Williams, Haifa, M.
  OBoyle, P. Barnard, E. Ashton, E. Courtois, F.
  Bodin MILEPOST GCC machine learning based
  research compiler, ARC, International, UK, CAPS
  Enterprise, France, 2007.
• 6 K. Hoste, L. Eeckhout, COLE Compiler
  Optimization Level Exploration, ELIS Department,
  Ghent University, Sing-Pietersnieuwstraat 41,
  B-9000 Gent, Belgium, 2008.
• 7 K. Deb, Multi-Objective Optimization using
  Evolutionary Algorithms, Wiley, 2001.
• 8 G. Fursin, J. Cavazos, M. OBoyle, and O.
  Temam, MiDataSets Creating the Conditions for a
  More Realistic Evaluation of Iterative
  Optimization, ALCHEMY Group, INRIA Futurs and
  LRI, Paris-Sud University, France, 2007.
• 9 M. Byler, M. Wolfe, J.R.B. Davies, C. Huson,
  and B. Leasure, Multiple version loops. In
  ICPP, 1987, pages 312-318, 2005.
• 10 K. D. Cooper, M. W. Hall, and K. Kennedy,
  Procedure cloning, In Proceedings of the 1992
  IEEE International Conference on Computer
  Language, pages 99-105, 1992.
• 11 P. Diniz and M. Rinard. Dynamic feedback
  An effective technique for adaptive computing,
  In Proc. PLDI, pages 71-84, 1997.
• 12 G. Fursin, C. Miranda, S. Pop, A. Cohen, O.
  Temam, Practical Run-time Adaptation with
  Procedure Cloning to Enable Continuous Collective
  Compilation, Alchemy group, INRIA Futurs and
  LRI, Paris-Sud 11 University, Orsay, France,
  2007.
• 13 V. Bala, E. Duesterwald, and S. Banerjia,
  Dynamo A transparent dynamic optimization
  system, In ACM SIGPLAN Notices, 2000.

26
References 14-23

• 14 R. H. Saavedra and D. Park, Improving the
  effectiveness of software prefetching with
  adaptive execution, In Conference on Parallel
  Architectures and Compilation Techniques
  (PACT96), 1996.
• 15 M. Voss and R. Eigemann, High-level
  adaptive program optimization with adapt, In
  Proceedings of the Symposium on Principles and
  practices of parallel programming, 2001.
• 16 G. Fursin, A. Cohen, M. OBoyle, and O.
  Temam, A Practical Method For Quickly Evaluating
  Program Optimizations, Institute for Computing
  Systems Architecture, University of Edinburgh,
  UK, 2005.
• 17 T. Sherwood, E. Perelman, G. Hamerly, and B.
  Calder, Automatically characterizing large scale
  program behavior, In 10th International
  Conference on Architectural Support for
  Programming Languages and Operating Systems,
  2002.
• 18 J. Lau, S. Schoenmackers, and B. Calder,
  Transition phase classification and prediction,
  In International Symposium on High Performance
  Computer Architecture, 2005.
• 19 Z. Pan, R. Eignmann, Fast and Effective
  Orchestration of Compiler Optimizations for
  Automatic Performance Tuning., Proceedings of
  the International Symposium on Code Generation
  and Optimization, 2006.
• 20 S. Triantafyllis, M.J. Bridges, E. Raman, G.
  Ottoni and D. August, A Framework for
  Unrestricted Whole-Program Optimization.,
  Proceedings of the 2006 ACM SIGPLAN Conference on
  Programming Language Design and Implementation,
  2006.
• 21 Z. Pan, R. Eignmann, Fast, Automatic,
  Procedure-Level Performance Tuning., Proceedings
  of the 15th International Conference on Parallel
  Architecture and Compilation Techniques, 2006.
• 22 H. Feltl, Ein Genetischer Algorithmus fuer
  das Generalized Assignment Problem,
  Diplomarbeit, 2003.
• 23 M. Haneda, P. Knijnenburg, H. Wijshoff
  Automatic Selection of Compiler Options Using
  Non-Parametristic Inferential Statistics.,
  Proceedings of the 14th International Conference
  on Parallel Architecture and Compilation
  Techniques, 2005.

27
Basic Foil with Take-Away Banner

• Use Verdana Bold for Main Body Subheadings
• Use Verdana regular for main body text.
• Use charcoal gray (RGB 51 51 51) color as the
  default
• Text size can vary. Use these minimum recommended
  font sizes
• Slide title 32 pt
• Main body subheadings 20 pt
• Bullet points 18 pt (with sub-bullets reducing
  by 2 pt each 16 pt, 14 pt, etc)
• Tables 14 pt
• Diagram and chart labels 12 pt
• Emphasize with italics, bold or color (blue)
• Use text boxes to highlight content
• Primary text should be on background color, not
  photos, etc.
• Use bullets same color as text

Standard Take-Away Banner. Add Text Here!
