Title: Security All-In-One Edition Chapter 10


1
SecurityAll-In-One EditionChapter 10
Wireless Security
  • Brian E. Brzezicki

2
Wireless
  • Look No Wires!

3
Wireless
  • Attempt at communication using non-physical
    links. Examples
  • Radio Waves
  • Light Pulses
  • Often used for networking, but can be used simply
    to eliminate wires for device to device
    communication.

4
Wireless LAN protocols
5
802.11 standard
  • Wireless LAN networking
  • Data Link layer specifications
  • Components
  • Access point (a type of bridge)
  • Wireless Card
  • SSID

6
802.11 family
  • 802.11b
  • 11Mbs
  • 2.4Ghz (same as common home devices)
  • 802.11a
  • 54Mbps
  • 5Ghz (not as commonly used, however absorbed by
    walls, yielding less range possibly)
  • 802.11g
  • 54Mbs
  • 2.4Ghz
  • Cards are generally backwards compatible and can
    serve as 802.11b or 802.11a
  • 802.11n
  • Uses Multiple Input Multiple Output (MIMO)
  • 100Mbs
  • 2.4G or 5Ghz

7
Wireless Problems
  • Easy to get access to airwaves, hard to restrict!
  • Talk about the attacks next.

8
Wireless Attacks
9
Wireless Attacks
  • War driving
  • Wireless scanners
  • Netstumber (see next slide)
  • Warchalking (2 slides)
  • (more)

10
NetStumbler
11
War chalking symbols
12
Man in the Middle
  • Airsnarfing, put up a fake access point get
    people to connect with you.

13
Evesdropping and attaining non-authorized acess
  • Evesdropping
  • Kismit
  • Air Snort breaks WEP retrieves encryption keys
    (security exam reference airsnort, even thought
    its no longer developed)
  • aircrack-ng breaks WEP and WPA-psk

14
Wireless Countermeasures
  • Turn off SSID broadcasts (problems?)
  • Enable MAC filtering (problems?)
  • Use Encryption (well talk about this next)
  • Use Enterprise Mode for authentication

15
Transmission encryption
  • There are many different types of wireless
    encryption protocols
  • WEP
  • Shared passwords (why is this bad?)
  • 64/40 or 128/104 bit key
  • Uses RC4
  • Easily crack able (due to key reuse)
  • Only option for 802.11b
  • (more)

16
Transmission Encryption
  • WPA PSK
  • Shared password
  • Uses TKIP normally
  • RC4 with changing keys
  • Can use AES (not certified)
  • 128 bit key
  • WPA2 PSK
  • Uses AES (normally)
  • 128 bit key
  • Can use TKIP
  • RC4 with changing keys
  • (more)

17
Transmission Encryption
  • WPA or WPA2 in Enterprise Mode
  • Uses 802.1X authentication to have individual
    passwords for individual users
  • RADIUS what was radius again?
  • 802.11i the official IEEE wireless security
    spec, officially supports WPA2

18
Wireless Device to Device Communication
19
Bluetooth
20
Bluetooth
  • What is Bluetooth
  • What is the purpose of Bluetooth, is it
    networking?
  • Bluetooth Modes
  • Discovery Mode
  • Automatic Pairing

21
Bluetooth Attacks
  • Bluejacking
  • Sending forged message to nearby bluetooth
    devices
  • Need to be close
  • Victim phone must be in discoverable mode
  • Bluesnarfing
  • Copies information off of remote devices
  • Bluebugging
  • More serious
  • Allows full use of phone
  • Allows one to make calls
  • Can eavesdrop on calls

22
Bluetooth Countermeasures
  • Disable it if your not using it
  • Disable auto-discovery
  • Disable auto-pairing

23
WAP
24
WAP
  • Wireless Application Protocol a protocol
    developed mainly to allow wireless devices (cell
    phones) access to the Internet.
  • Requires a Gateway to translate WAP lt-gt HTML (see
    visual)
  • Uses WTLS to encrypt data (modified version of
    TLS)
  • Uses HMAC for message authentication
  • WAP GAP problem (see visual and explain)
  • A lot of wireless devices dont need WAP anymore
    why?

25
WAP
26
WAP GAP
  • As the gateway decrypts from WTLS and encrypts as
    SSL/TLS, the data is plaintext. If someone could
    access the gateway, they could capture the
    communications

27
Chapter 10 Review Questions
  • Q. What encryption protocol does WEP use
  • Q. What 2 key lengths does WEP support
  • Q. What encryption protocol does WPA2 use?
  • Q. Why is MAC filtering or turning off SSID
    broadcasting not sufficient security?
  • Q. What does WAP use for security?

28
Chapter 10 Review Questions
  • Q. What is the WAP GAP
  • Q. Define how to accomplish a MiM attack on a
    wireless network
  • Q. What type of authentication concept would help
    against the attack above?
  • Q. What is one way office users could use
    wireless to violate network security?
  • Q. What is Bluetooth used for?
  • Q. What is Bluesnarfing?

29
Wireless security
  • Access control
  • Turn off SSID broadcasts (problems)
  • MAC filtering (problems)
  • Encryption
  • Discussed later
  • Authentication
  • Use Radius and 802.1X
  • Isolation
  • VLANs over wireless
