Sensation of Smell

1
(No Transcript)
2
Sensation of Smell

• Professor A.M.A Abdel Gader
• MD, PhD, FRCP (Lond., Edin), FRSH (London)
• Professor of Physiology, College of Medicine
• King Khalid University Hospital
• Riyadh, Saudi Arabia

3
(No Transcript)
4
The Physiology of Smell (Olfaction)

• Smell Taste
• Similar
• Chemical Senses
• Determine food flavor (intake)
• Dissimiliar
• Smell receptors telereceptors- sense projected
  the environment
• Taste is confined to mouth
• Smell pathway does not relay in the thalamus does
  not reach sensory cortex
• Taste pathway finishes in the sensory cortex (PCG)

5
Taste Smell cont.

• Chemical Senses
• vital for survival
• Determine appetite
  (Retreat from noxious stimuli)

6
Chemical Senses

• Gatekeepers molecule detectors
• identify what the body needs for survival
• identify what is dangerous and should be
  rejected
• Neurogenesis constant renewal of receptors
• Olfactory receptors 30-60 days
• Taste cells 10 days
• Affective component emotions aid in
  discrimination of molecules (good vs. bad)

7
Chemical Senses - cont

• Taste plays a vital role in food selection,
• sweet (and umami) are associated with nutritious
  food
• Bitter tastes are associated with the possible
  presence of toxins and are usually avoided.
• Taste and smell are closely linked even though
  they involve different receptors and receptive
  processes. (??overlap in central processing).
• In many species olfactory stimuli play an
  important role in reproduction although not well
  developed in humans (?).

8
The Physiology of Smell (Olfaction)

• Sense of Smell species difference
• Macrosmatic animals Dogs highly
  developed sense of smell reliance on olfactory
  system
• Microsmatic Man weakly
  developed sense of smell less reliance on
  olfactory system

9
Species differences

• Dog
• Has 40 sq inches of epithelium compared to
• 1 sq inch in humans

10
Dogs have about 40 times the area for olfaction
that humans do
11
Olfactory Receptor Neurons (ORN)

• Olf. Signal Transducers
• 1000 different types
• Each type found in only 1 zone of mucosa
• Vision
• 3 cone types, 1 type of rod
• 6 million cones, 120 million rods

12
Olfactory Receptors

• 1000 different types of receptors each has
  odorant-binding protein
• Only one protein type per ORN
• These membrane bound proteins
• Located in cilia on tips of ORNs
• ORN olfactory receptor neuron

13
Olfactory receptors (a) Location of receptors in
the roof of the nasal cavity. (b) Closeup of
olfactory cells.
14

• Olfactory epith. at roof
• of nasal cavity
• Warm nasal epithelium
• Conviction currents
• ( by sniffing)

15
The Physiology of Smell(Olfaction)

• Olfactory Receptors
• Bipolar neurons with cilia
• Receptors are genuine neurons
• (unlike photoreceptors and hair cells)
• Unlike other neurons, receptors are
• continually regenerated

16
Olfactory Epithelium

• 5 cm2 of membrane
• 10-100 million receptors

17
Cells of the Olfactory Membrane

• Olfactory epithelium made up of three types of
  cells
• Olfactory receptors
• bipolar neurons with olfactory hairs
• Supporting cells
• columnar epithelium
• Basal stem cells
• replace receptors monthly
• Olfactory (Bowmans) glands
• produce mucus
• Dissolves odorants

18
Olfactory Epithelium

• Receptors have four parts cilia, olfactory
  knob, olfactory rod and the axon
• Olfactory nerve - the axons of the olfactory
  receptors form bands which travel to the
  olfactory bulb

19
BIPOLAR OLFACTORY NEURONS IN THE NOSE.
RECEPTORS FOR ODOR MOLECULES ARE IN THE CILIA.
20
(No Transcript)
21
Olfactory System
22
Olfactory System
Each sensory cell type connects to a particular
pair of glomeruli
Each sensory cell expresses one receptor type
(indicated by color) Different colors represent
different sensory cells
23
The Physiology of Smell - (Olfaction) cont.

• Olfactory Receptors
• Bipolar neurons with cilia
• Mitose throughout life (only part of CNS that is
  known to regenerate)
• Their axons project to the olfactory bulb

24
(No Transcript)
25
Mechanism of Olfaction
26
Physiology of Olfaction Mechanism

• Molecules must dissolve in mucus
• ?
• Combine with receptors on the cilia
• ?
• Stimulation of a G-Protein
• ?
• Activation of Adenyl Cyclase
• ?
• Increase I.C. cAMP
• ?
• Opening of Na Channels
• ?
• Na influx
• ?
• Depolarization (Receptor Potential)

27
(No Transcript)
28
Threshold to Different Substances
Physiology of Olfaction cont.
Substance Threshold conc mg/L air
Ethyl ether 5.83
Chloroform 3.30
Oil of peppermint 0.02
Propyl mercaptan 0.006
Methyl mercaptan 0.0000004
29
Discrimination of Intensity

• Poor
• Requires 30 increase of intensity
• Strong smell highly water and lipid soluble
• Man can distinguish 2000-4000 different odors

30
Physiology of Olfaction cont.

• Adaptation to Smell
• Peripheral
• Central

31
Olfactory Pathway

• Axons from olfactory receptors synapse in the
  olfactory bulb
• Second-order neurons within the olfactory bulb
  form the olfactory tract
• synapses on primary olfactory area of temporal
  lobe
• conscious awareness of smell begins
• Other pathways lead to the frontal lobe where
  identification of the odor occurs

32
Early Olfactory Pathway
33
Olfactory Mucosa Olfactory Pathway
34
Early Olfactory Pathway
35
Central Olfactory Pathways
36
Central Olfactory Pathways
37
Central Olefactory Pathways
38
Central Olefactory Pathways
39
Central Olefactory Pathways
40
Central Olefactory Pathways
41

Physiology of Olfaction cont.

• Clinical Considerations
• Abnormalities of the sense of olfaction
• Anosmia Absence of the sense of smell
• Dysosmia Disturbed
• Hyposomia Reduced
• Vit. A deficiency and hypogonadism
• Hyperosmia Increased sense of smell
• (Adrenal insufficiency)

42
(No Transcript)
43
Advances in Olfactory Physiology Noble Prize
44
How does the sense of smell work?

• Discovered fairly recently (1991)
• Nobel prize in 2004, to Richard Axel and Linda
  Buck
• Discovery in part due to ( thanks to) molecular
  biology and genetic engineering

45
How did they do it?

• There are three visual receptors (to distinguish
  different colors)
• Buck got the idea that maybe smell receptors
  might be similar
• She used a genetic technique called the
  Polymerase Chain Reaction (PCR) to find them
• There are about 1000 different smell receptors in
  humans!

46
http//nobelprize.org/medicine/laureates/2004/illp
res/4_gene.htmlhttp//nobelprize.org/medicine/laur
eates/2004/illpres/4_gene.html
