Title: 8086 Microprocessor minimuim /maximuim mode


1
8086 Microprocessor minimuim /maximuim mode
  • By hitesh lad

2
8086 Pin Diagram
3
THE 8086 MEMORY BANK
UPPER BANK
LOWER BANK
ODD
EVEN
CS
CS
A0
A1---A19
BHE
D15-D8
D7-D0
4
(No Transcript)
5
Minimum Mode
6
8086 Minimum Mode
S5 Status of IF
S6 0
7
8086 Minimum Mode
S5 Status of IF
S6 0
8
Maximum Mode
9
Bus Timing for Read Operation
10
Bus Timing for Write Operation
11
Basic System Timing
12
Memory Architecture
13
(No Transcript)
14
(No Transcript)
15
TIMING SEQUENCE
  • AN EXTERNAL CLOCK GENERATOR DEVICE IS CONNECTED
    TO 8086 TO PROVIDE CLOCK SIGNALS THROUGHOUT THE
    SYSTEM.
  • ONE CYCLE OF CLOCK IS CALLED A STATE OR T-STATE.
  • EACH BASIC OPERATION SUCH AS READING A MEMORY
    LOCATION OR WRITING TO A PORT REQUIRES SEVERAL
    STATES.THIS GROUP OF STATES IS CALLED A MACHINE
    CYCLE.
  • THE TOTAL TIME REQUIRED TO FETCH AND EXECUTE AN
    INSTRUCTION IS CALLED AN INSTRUCTION CYCLE. AN
    INSTRUCTION CYCLE CONSISTS OF ONE OR MORE MACHINE
    CYCLE.

16
BASIC SIGNAL FLOW ON 8086 BUSES
BASICALLY THERE ARE TWO OPERATIONS TO SEE 1.READ
OPERATION 2. WRITE OPERATION WILL SEE WHAT IS
GOING ON DURING THIS TWO CYCLES OF OPERATION.
17
Memory READ CYCLE
  • HERE WE WILL SEE THE ACTIVITIES CARRIED OUT ON
    8086 BUSES AT VARIOUS TIME INSTANTS WHEN IT READS
    FROM A MEMORY LOCATION OR FROM A PORT.
  • HERE WE WILL ASSUME THAT THE 8086 IS OPERATED IN
    IS MINIMUM MODE.

18
T1
T2
T3
TW
T4
CLK
M/IO
ALE
MEMORY ACCESS TIME
ADDR/ DATA
A15-A0
RESERVED FOR DATA
VALID D15-D0
ADDR/ STATUS
A19-A16
RD/INTA
READY
DT/R
DEN
19
WRITE CYCLE
  • HERE WE WILL SEE THE ACTIVITIES CARRIED OUT ON
    8086 BUS AT VARIOUS TIME INSTANTS WHEN IT WRITES
    TO A PORT OR A MEMORY LOCATION.
  • HERE WE WILL ASSUME THAT THE 8086 IS OPERATED IN
    IS MINIMUM MODE.

20
T1
T2
T3
TW
T4
CLK
M/IO
ALE
ADDR/ DATA
A15-A0
DATA OUT (D15-D0)
ADDR/ STATUS
A19-A16
WR
READY
DT/R
DEN
21
i/o write timing diagram
22
T1
T2
T3
TW
T4
CLK
M/IO
ALE
ADDR/ DATA
A15-A0
DATA OUT (D15-D0)
ADDR/ STATUS
A19-A16
WR
READY
DT/R
DEN
23
ADDRESSING
1. ADDRESSING MEMORY
2. ADDRESSING PORTS
  • DECODER IS THE CIRCUITRY USED FOR ADDRESING. IT
    SERVES TWO PURPOSES
  • TO ENABLE RAM,ROM OR PORT.
  • TO MAKE SURE THAT ONLY ONE DEVICE IS ENABLED AT A
    TIME.

24
A SYSTEM ROM DECODER
  • TO UNDERSTAND THE CONCEPT A GENERAL DIGITAL
    SYSTEM WITH 8 DATA LINES AND 16 ADDRESS LINES IS
    CONSIDERED.
  • THE HARDWARE USED CONSIST
  • 2732 ROM-8(EACH-4 KB)
  • 74LS138 DECODER/DEMULTIPLEXER
  • 16 ADDRESS LINES
  • 8 DATA LINES

25
A0
A1
A2
A11
ROM 1 2732
ROM 7 2732
ROM 0 2732
CS
CS
CS
D0
D5
D6
D7
Y0 Y1 Y7
A12
74LS138
A13
G2A
G2B
G1
A14
A15
RD
5V
26
ADDRESS DECODER WORKSHEET
A15 A14-A12 A11-A8 A7-A4 A3-A0 HEX EQUI. ADDRESS
ROM0 ST. END 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 0 F F F
ROM1 ST. END 0 0 0 1 0 0 0 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 1 0 0 0 1 F F F
ROM2 ST. END 0 0 1 0 0 0 1 0 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 2 0 0 0 2 F F F
ROM3 ST. END 0 0 1 1 0 0 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 3 0 0 0 3 F F F
ROM4 ST. END 0 1 0 0 0 1 0 0 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 4 0 0 0 4 F F F
ROM5 ST. END 0 1 0 1 0 1 0 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 5 0 0 0 5 F F F
ROM6 ST. END 0 1 1 0 0 1 1 0 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 6 0 0 0 6 F F F
ROM7 ST. END 0 1 1 1 0 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 7 0 0 0 7 F F F
27
A SYSTEM RAM DECODER
TO THE SAME SYSTEM WE WANT TO ADD 16KB RAM.SO
ADDITIONAL HARDWARE WE REQUIRE
  • 2142 RAM-8(EACH 2KB)
  • ONE MORE 74LS138 DECODER/DEMULTIPLEXER
  • SINCE WE HAVE EACH RAM OF 2KB(2048 BYTES) ,WE
    NEED 11 ADDRESS LINES TO ADDRESS EACH MEMORY
    LOCATION WITHIN A RAM.AS WE HAVE OCCUPIED
    ADDRESSES 0000 THROUGH 7FFF FOR ROM.WE MUST START
    RAM ADDRESSES AFTER 7FFF.
  • SO WE HAVE 5 MORE ADDRESS LINES.WHICH WE WILL USE
    TO PROVIDE ADDRESS DECODING.

28
A0
A1
A2
A10
RAM 1 2142
RAM 7 2142
RAM 0 2142
CS
CS
CS
D0
D5
D6
D7
Y0 Y1 Y7
A11
74LS138
A12
G2A
G2B
G1
A13
A14
A15
GND
29
A SYSTEM PORT DECODER
A SYSTEM PORT CAN BE ADDRESSED IN TWO WAYS
  • USING MEMORY MAPPED I/O- HERE A PORT IS TREATED
    AS IF IT IS A MEMORY LOCATION.
  • IT USES MEMORY RELATED INSTRUCTIONS.
  • THE OPERATION IS FASTER.
  • A MAXIMUM OF 1MB INPUT AND 1MB(220) OUTPUT
    DEVICES CAN BE ADDRESSED.
  • IT USES MEM.READ AND MEM.WRITE CONTROL
    SIGNALS.
  • IT CONSUMES THE ADDRESS RANGE USED BY PROGRAM
    MEMORY.
  • DECODING IS COMPLEX.

30
  • USING DIREC I/O-HERE AN INPUT OR AN OUTPUT DEVICE
    IS TREATED AS A DISTINCT I/O DEVICE.
  • IT DOES NOT CONSUME PROGRAM MEMORY.
  • THE DECODING IS SIMPLE.
  • IT USES IN AND OUT INSTRUCTIONS.
  • A MAXIMUM OF 64K BYTE TYPE INPUT AND OUTPUT
    DEVICES CAN BE ADDRESSED OR 32K WORD TYPE INPUT
    AND OUTPUT DEVICES CAN BE ADDRESSED.
  • IT USES IORD AND IOWRT CONTROL SIGNALS.
  • OPERATION IS SLOWER.

31
I/O read timinig diagram
32
T1
T2
T3
TW
T4
CLK
M/IO
ALE
MEMORY ACCESS TIME
ADDR/ DATA
RESERVED FOR DATA
VALID D15-D0
A15-A0
ADDR/ STATUS
A19-A16
RD/INTA
READY
DT/R
DEN
33
A15
G1
Y0 Y1 Y2 Y3 Y4 Y5 Y6 Y7
A14
CS (CHIP SELECT) SIGNAL FOR PORT DEVICES
A13
G2B
74LS138
A12
G2A
A5
A4
A3
34
8086 PHYSICAL MEMORY
THE TOTAL MEMORY (1MB) OF 8086 IS ARRANGED IN TWO
BANKS. AN ODD BANK AND AN EVEN BANK. BOTH THE
BANKS HAVE EQUAL NO. OF LOCATIONS. THE ODD BANK
CONTAINS ODD NUMBERED MEM. LOCATIONS.IT IS KNOWN
AS UPPER BANK. THE EVEN BANK CONTAINS ONLY EVEN
NUMBERED MEM. LOCATIONS.IT IS KNOWN AS LOWER
BANK. THIS ARRANGE MENT IS DONE IN ORDER TO SPEED
UP THE OPERATION. THE ARRANGEMENT AND THE SIGNAL
FOLLOWED, EXPLAINS THE SAME.
35
THE 8086 MEMORY BANK
UPPER BANK
LOWER BANK
ODD
EVEN
CS
CS
A0
A1---A19
BHE
D15-D8
D7-D0
36
ADDRESSING WITH 8086
  • PROBLEM TWO 16K ROM AND TWO 32K RAM ARE REQUIRED
    TO BE INTERFACED WITH 8086 CPU.THE RAM ADDRESS
    MUST START AT 00000H.THE ROM ADDRESS RANGE MUST
    INCLUDE FFFF0H IN ITS RANGE.

37
ADDRESS MAP
THE RAM ADDRESS STARTS AT 00000H. TOTAL RAM IS
232K. SO RAM ADDRESS RANGE IS FROM 00000H TO
0FFFFH.(FFFF-0000)H216 64K. SINCE THE ROM
ADDRESS MUST INCLUDE FFFF0H. WE TAKE LAST
ADDRESS OF ROM AS FFFFFH. AS TOTAL SPACE FOR ROM
IS 216K,THE FIRST ADDRESS FOR ROM IS F8000H.
(FFFFF-F8000)H21532K.
ADDRESS LINES A1-A14 ARE CONNECTED TO ROM.ADDRESS
LINES A1-A15 ARE CONNECTED TO RAM.AND REMAINING
LINES ARE USED FOR CHIP SELECTION.(NOTE A0 IS
RESERVED FOR BANKS.)
38
TO GENERATE THE CHIP SELECT SIGNAL THE FOLLOWING
LOGIC IS USED THE CHIPSELECT SIGNAL IS ACTIVE
LOW. SO A PARTICULAR CHIP CAN BE SELECTED ONLY
WHEN THIS SIGNAL IS LOW. SECONDLY AT A TIME
ONLY ONE CHIP SHOULD BE SELECTED. FURTHER ,THE
ODD BANK WILL BE ENABLED ONLY IF BHE SIGNAL IS
ACTIVATED.AND THE EVEN BANK WILL BE ENABLED ONLY
IF AO SIGNAL IS LOW.
39
  • HERE WE CONSIDER AS AN EXAMPLE A SYSTEM WITH FEW
    PORTS.
  • AN 8251(UNIVERSAL SYNCHRONOUS ASYNCHRONOUS
    RECEIVER TRANSMITTER)
  • TWO 8255A(PROGRAMMABLE PARALLEL PORTS.)
  • AN 8279 (DISPLAY AND KEYBOARD INTERFACING.)
  • AN 8275 (CRT CONTROLLER)
  • AN 8272A(FLOPPY DISK CONTRLLER)

40
BHE OFFBOARD
P O R T S E L E C T
A15
G2A G2B
G
A5
Y0 Y1 Y2 Y3 Y4 Y5 Y6 Y7
8255-1
8255-2
A4
8251
74LS138
8279
8275
8272
A3
RESERVED FOR FUTURE USE.
A2
41
MAP FOR PORTS
A15-A5 A4 A3 A2 A1 A0 EQUI HEX ADDRESS
8255-1 1 0 0 0 F F E O F F E 3
8255-2 1 0 0 1 F F E 4 F F E 7
8251 1 0 1 0 F F E 8 F F E B
8279 1 0 1 1 F F E C F F E F
8275 1 1 0 0 F F F 0 F F F 3
8272 1 1 0 1 F F F 4 F F F 7


42
  • LINES A1 AND A0 ARE USED FOR SETTING INTERNAL
    REGISTERS OF THE ADDRESSED PORT.
  • NOTE THAT THIS IS AN ABSOLUTE ADDRESSING.i.e. A
    PORT CAN BE SELECTED FOR ONLY ONE ADDRESS.
  • NON-ABSOLUTE ADDRESING ALSO EXISTS.THERE A PORT
    CAN BE SELECTED FOR MORE THAN ONE ADDRESSES.

43
THE OFF-BOARD DECODER
  • THE SDK-86 USES AN OFF-BOARD CIRCUITRY .
  • THE PURPOSE OF THIS CIRCUITRY IS TO PRODUCE AN
    ACTIVE LOW OFF BOARD SIGNAL WHENEVER THE 8086
    ADDRESSES A PORT OR MEMORY WHICH IS NOT DECODED
    ON THE SDK-86 BOARD.
  • USUALLY WHEN WE CONNECT ADDITIONAL PORT USING
    DIRECT I/O, THIS DEVICE IS CONSIDERED AS
    OFF-BOARD(OUT OF THE DECODING MAP OF THE SYSTEM).
  • SO WHENEVER THIS PORT IS CALLED UPON,THE 8086
    ASSERTS THE OFF BOARD SINAL.
  • TO COMMUNICATE WITH OFF BOARD DEVICES,EXTRA
    HARDWARE SUCH AS 74LS138 OR AN EPROM DECODER IS
    REQUIRED FOR ADDRESSING THIS DEVICE.

44
8088 MEMORY AND PORT ADDRESSING
  • IN 8088 THERE ARE ONLY 8 DATA LINES AND 20
    ADD.LINES.
  • THE 8088 MEMORY IS NOT DEVIDED INTO ODD AND EVEN
    BANKS.BUT THERE IS ONLY A SINGLE BANK.
  • THERE ARE 1MB LOCATIONS EACH 1-BYTE LONG.SO TO
    READ OR WRITE A WORD 8088 REQUIRES TWO MACHINE
    CYCLES ALWAYS.

45
THE 8086 TIMING PARAMETERS
  • THE 8086 TIMING PARAMETERS ARE REQUIRED TO FIND
    WHETHER A PARTICULAR DEVICE IS FAST ENOUGH TO
    WORK IN OUR SYSTEM. IF NOT WE CAN USE WAIT STATES
    TO ALLOW THE SLOW DEVICE TO RESPOND.
  • THE 8086 RECEIVES TWO DIFFERENT CLOCK SIGNALS
    FRON 8284 CLOCK GENERATOR 4.9MHz AND 2.45MHz
    USING A DIVIDE BY 2 NETWORK.

46
  • NOW SUPPOSE THAT 8086 USES A FREQ. OF 4.9 MHz AND
    WE WANT TO DETERMINE WHETHER 2716 EPROMs ARE ABLE
    TO WORK CORRECTLY WITH OUR SYSTEM.
  • TO READ FROM EPROM, WE NEED TO PROVIDE ITS
    ADDRESS,WE ALSO NEED TO PROVIDE ITS CHIP SELECT
    SIGNAL AND IN ADDITION WE ALSO NEED TO ENABLE ITS
    OUTPUT.
  • FOR THIS ,THE 8086 PROVIDES ON AD0-AD15 THE
    ADDRESS OF THE PARTICULAR LOCATION,THE CE (CHIP
    ENABLE-ACTIVE LOW) SIGNAL AND OE (OUTPUT
    ENABLE-AVTIVE LOW SIGNAL).

47
  • FROM A DATA BOOK THE TYPICAL ACCESS TIMES FOR
    EPROM 2716 ARE
  • Tacc 450 ns
  • THIS MEANS THAT IF 2716 HAS ITS CE AND OE SIGNALS
    ENABLED,THAN IT WILL TAKE AT THE MAX. 450
    ns,AFTER THE ADDREES IS PUT ON AD0-AD15 LINES.
  • Tce 450 ns
  • THIS MEANS THAT THE ADDRESS AND OE SIGNALS ARE
    ALREADY ENABLED THAN IT WILL TAKE AT THE MAX.
    ,450 ns AFTER CE SIGNAL IS ENABLED.
  • Toe 120 ns
  • THIS THE MAX. TIME REQUIRED WHEN AD0-AD15 AND CE
    SIGNALS ARE ENABLED BUT OUTPUT BUFFERS OF 2716
    ARE NOT ENABLED.

48
NEXT, WE CHECK THAT EACH OF THESE TIMES ARE SHORT
ENOUGH TO WORK WITH 8086 AT 4.9MHz.
  • LOOKING AT THE WAVE FORMS OF READ CYCLE THERE IS
    A TIME GAP BETWEEN THE STARTING OF STATE-T1 AND
    THE TIME AT WHICH VALID ADDRESS IS AVAILABLE.
  • THIS TIME INTERVAL IS SYMBOLISED AS TCLAV TIME
    FROM CLOCK LOW TO ADDRESS VALID. AS PER 8086 DATA
    SHEET THIS TIME IS 110 ns MAX.
  • AGAIN LOOKING AT READ CYCLE ,WE FIND THAT VALID
    DATA MUST BE AVAILABLE BEFORE THE END OF T3.THERE
    ALSO EXISTS A TIME GAP BETWEEN ,THE LINE IS
    AVAILABLE FOR PUTTING VALID DATA AND THE END OF
    STATE-T3.
  • THIS TIME INTERVAL IS SYMBOLISED AS TDVCL TIME
    DATA MUST BE VALID BEFORE CLOCK GOES LOW. AS PER
    8086 DATA SHEET THIS TIME IS 30 ns.

49
  • THE TIME BETWEEN THE END OF TCLAV AND THE START
    OF TDVCL IS THE TIME AVAILABLE FOR GETTING THE
    ADDRESS TO THE MEMORY AND TO Tacc THE MEMORY
    DEVICE.
  • THE TIME BETWEEN THE START OF TCLAV AND THE END
    OF TDVCL IS 3 T-STATES.
  • AT 4.9 MHz ,TIME FOR ONE T-STATE IS 2.04 ns. SO
    TOTAL TIME FOR 3 STATES IS 612 ns.
  • FROM THIS WE SUBTRACT TCLAV AND TDVCL.
  • 612-110-30472 ns.

50
  • SO, 472 ns AVAILABLE FOR CALLING 2716 AND
    ACCESSING ITS DATA.
  • NOW,LOOKING AT THE MINIMUM MODE SYSTEM,WE SEE
    THAT THE ADDRESS INFORMATION FOR 2716 GOES
    THROUGH LATCHES 74S373. SO, THE PROPOGATION DELAY
    FOR THIS MUST BE SUBTRACTED FROM 472 ns.THE
    PROPAGATION DELAY (CALLING TIME OR GETTING
    ADDRESS TO 2716 TIME) IS 12 ns. THIS LEAVES
    472-12460 ns AS Tacc.
  • SO FROM THIS WE SEE THAT THE Tacc NEEDED FOR 2716
    IS 450 ns max. WHILE THE 8086 PROVIDES 460 ns, AT
    LEAST.
  • SO, WE CONCLUDE THAT WE DO NOT NEED ANY WAIT
    STATE TO BE INSERTED. AS FAR AS Tacc. IS CONCERN.

51
  • ANOTHER PARAMETER TOBE CHECKED IS Tce.
  • THE CE SIGNAL REQUIRES EITHER A0 OR BHE AS ITS
    ENABLE SIGNAL. SO,IT REQUIRES THE SAME
    CALCULATION AS THAT OF Tacc.
  • SO,Tce ALSO DOESNT NEED WAIT STATE.
  • THE LAST TO BE SEEN IS Toe.
  • THE OE SIGNAL WILL BE GENERARED WHEN RD SIGNAL IS
    APPLIED.
  • NOW, LOOKING AT THE READ CYCLE RD SIGNAL WILL NOT
    BE ASSERTED TILL THE STATE T2.THE RD SIGNAL WILL
    BE ENABLED WITHIN A TIME TCLRL AFTER T2
    STARTS.THE MAX. VALUE FOR THIS SIGNAL IS 165 ns.
    AGAIN,Toe MUST BE ACTIVE BEFORE VALID DATA IS
    PLACED ON AD0-AD15. i.e. BEFORE STARTING OF
    TDVCL.

52
  • SO, SUM OF THESE TIMINGS MUST BE SUBTRACTED FROM
    THE TOTAL TIME AVAILABLE.
  • THE TOTAL TIME AVAILABLE IS STATE-T2 T3.408
    ns.
  • 408-165-30183 ns.
  • SO, 8086 PROVIDES 183 ns FOR ENABLING OUTPUT
    BUFERS.
  • WHILE THE TIME Toe REQUIRED BY 2716 IS 120 ns.
  • SO, FOR Toe ALSO WE NEED NO WAIT STATE.

53
TROUBLESHOOTING AN 8086 BASED MICROCOMPUTER
  • TROUBLESHOOTING IS TO FIND FAULTS IN A SYSTEM
    THAT WAS WORKING WELL, ONCE.
  • THE FOLLOWING STEPS ARE RECOMMENDED FOR A
    SYSTEMATIC AND TIME-EFFECTIVE TROUBLESHOOTING.

54
  • IDENTIFYING THE SYMPTOMS.
  • CAREFULLY OBSERVE THE WORKING OF BAD SYSTEM
    AND TRY TO IDENTIFY THE SYMPTOMS.
  • 2. MAKING A CAREFUL VISUAL AND TACTILE
    INSPECTION.
  • CHECK FOR COMPONENTS THAT ARE EXCESSIVELY HOT.
  • DO NOT TOUCH FIRMLY,BECAUSE IT MAY RESULT IN
    SKIN BURN.
  • MAKE IT SURE THAT ALL ICs ARE FIRMLY SEATED IN
    THEIR SOCKETS AND NO PIN IS BENT.
  • CHECK FOR BROCKEN WIRES AND LOOSE CONNECTORS.

55
  • 3. CHECKING POWER SUPPLY.
  • FROM THE MANUAL DETERMINE THE REQUIRED
    OPERATING VOLTAGE AND COMPARE IT WITH THE
    VOLTAGES AVAILABLE. ALSO CHECK THAT THE SAME
    VOLTAGE AVAILABLE AT PIN Vcc.
  • 4. SIGNAL ROLL CALL.
  • MAKE A CHECK AT SOME KEY SIGNALS e.g. CLOCK
    SIGNAL ON A CRO.OTHER SIGNAL SUCH AS ALE , RD AND
    WR SHOULD ALSO BE CHECKED.

56
  • 5. SYSTEMATICALLY SUBSTITUTING ICs.
  • THIS STEP CAN BE USED ONLY IF THERE ARE TWO
    IDENTICAL SYSTEMS. ONE IS WORKING AND THE OTHER
    IS NOT WORKING.AND ALSO ALL ICs ARE IN SOCKETS.
  • FIRST TURN THE POWER OFF. MAKE MARKS ON THE
    ICs OF THE BAD SYSTEM.NOW EXCHANGE THE CPUs OF
    THE TWO SYSTEM AND SEE IF IT WORKS. IF SO, IT
    SURE THAT THE CPU IS BAD. IF NOT ,RESTORE THE
    ORIGINAL CPUs.IN THIS WAY GO ON TESTING ICs .
  • IF ROM IS ACCESIBLE AND RAM IS NOT,THEN TRY
    TO CHECK FOR RAM DECODER IC.
  • THIS WAY YOU CAN LOCATE BAD IC/ICs .

57
  • 6.TROUBLE SHOOTING A SYSTEM WITH SOLDERED-IN ICs.
  • MOST OF THE TIME ALL ICs EXCEPT CPU AND ROM
    ICs ARE SOLDERED.
  • TRY TO RUN THE BASIC MONITOR PROGRAM WHICH
    IS IN ROM,AND COMPARE THE SIGNALS ON THE TWO.THIS
    WILL PROBABLY LOCATE THE FAULTY IC.
  • TRY TO EXCHANGE ROM OF THE TWO SYTEMS. AND/OR
    EXCHANGE CPU.
  • THEN RUN A RAM TEST ROUTINE .THE ROUTINE WILL
    WRITE ALL 1S TO SELECTED LOCATIONS.THEN, READ
    THIS DATA BACK IF THEY ARE NOT 1S ,THEN THE
    PROBLEM MAY BE WITH SYTEM BUS,(AS IT CAN NOY
    WRITE TO DESIRED LOCATION ) OR WITH RAM OR WITH
    RAM DECODER.

58
  • 7.USING A LOGIC ANALYZER.
  • A LOGIC ANALYZER SHOWS YOU SIGNALS ON 16 TO
    64 LINES AT A TIME. IT GIVES YOU A SNAPSHOT OF
    LOGIC LEVELS WHICH ARE ON ITS INPUT LINES AT
    THE TIME OF TAKING SAMPLE OR PHOTO.
  • SO, WE CAN CONNECT ALL THE DATA,ADDRESS AND
    CONTROL LINES TO THE INPUTS OF A LOGIC ANALYZER
    AND WE CAN SEE THE ACTIVITIES ON THIS LINES. THIS
    WILL SURELY TELL IF THE FAULT IS THERE WITH YOUR
    8086.
  • USING A LOGIC ANALYZER IS A VERY EFFECTIVE
    AND THE MOST SOPHISTICATED SYSTEM OF TROUBLE
    SHOOTING.BUT IT REQUIRES EXPERTISE IN USING THE
    ANALYZER.

59
  • 8.OTHER EQUIPMENT.
  • A LOGIC ANALYZER IS A BIG INSTRUMENT AND CAN
    NOT BE CARRIED WITH.TO USE THE SAME YOU ALSO NEED
    TO KNOW THE PROGRAMMING AND THE HARDWARE OF THE
    SYSTEM IN DETAIL.
  • BUT SUPPOSE YOU ARE TO REPAIR SEVERAL
    DIFFERENT TYPES OF MICROPROCESSORS AND YOU DO NOT
    KNOW MUCH ABOUT THE PROGRAMMING OF THE SYSTEM
    WHICH YOU ARE TROUBLE SHOOTING ,THEN YOU NEED TO
    USE EQUIPMENT SUCH AS FLUKE 9010A.
  • SUCH EQUIPMENT KEEPS YOU FREE FROM THE STRESS
    OF KNOWING ALL THE SOFTWARE AND
  • HARDWARE DETAILS OF THE SYSTEM AT HAND.
Write a Comment
User Comments (0)
About PowerShow.com
