Chapter Sixteen

1
Chapter Sixteen

• Carboxylic Acids, Esters, and Other Acid
  Derivatives

2

• Carboxylic acid An organic compound with
  carboxyl functional group
• Carboxyl group A carbonyl group (CO) with a
  hydroxyl group (OH) bonded to the carbonyl
  carbon atom
• A general structural representation for a
  carboxyl group is shown below

Carbonyl group
Carboxylic acid
3
Carboxylic Acids

• Fig. 16.1
• The three simplest carboxylic acids methanoic
  acid, ethanoic acid, and propanoic acid.

4
Carboxylic Acids

• Fig. 16.2
• Benzoic acid molecule

5
Carboxylic Acids

• Carboxylic acids always contain the carboxyl
  group on __________ ____.
• A carboxyl group is a carbonyl attached to a
  hydroxyl
• Acts differently than an alcohol or a carbonyl
  compound
• O
• ??
• CH3 COH CH3COOH
• carboxyl group

6
IUPAC Rules for Naming Monocarboxylic Acids

• Rule 1 Select the longest carbon chain that
  includes the carbon atom of the carboxyl group as
  the parent chain.
• Rule 2 Name the parent chain by changing the
  -e ending of the corresponding alkane to -oic
  acid.
• Rule 3 Number the parent chain by assigning the
  1 to the carboxyl carbon atom.
• Rule 4 Determine the identity and location of
  any substituents in the usual manner, and append
  this information to the front of the parent chain
  name.

7
Naming Rules

• Identify longest chain containing the ___________
  group
• (IUPAC) Number ____________ carbon as 1
• (Common) Assign ?, ?, g to carbon atoms adjacent
  to ____________ carbon
• CH3
• CH3 CHCH2 COOH
• IUPAC 3-methylbutanoic acid
• Common ?-methylbutryic acid

8
Naming Carboxylic Acids

• Formula IUPAC Common
• alkan -oic acid prefix ic acid
• HCOOH methanoic acid formic acid
• CH3COOH ethanoic acid acetic
  acid
• CH3CH2COOH propanoic acid propionic
  acid
• CH3CH2CH2COOH butanoic acid
  butyric acid

9
First Six Unbranched Monocarboxylic Acids
10
First Six Unbranched Dicarboxylic Acids
11
Aromatic Carboxylic Acids

• Benzoic Acid is the ______________ carboxylic
  acid
• Locates substituents by assigning 1 to the carbon
  with the carboxyl group

3-chlorobenzoic acid
Benzoic acid
4-methylbenzoic acid
12
Common Acids

• Acetic Acid CH3COOH
• Vinegar is 4-8 (v/v) acetic acid solution
• Colorless liquid with sharp odor
• Oxalic acid HOOC-COOH - found in spinach and
  cabbage
• Harmful at high concentrations
• Used to remove rust, bleach straw, and leather
  and ink stains

13
Polyfunctional Carboxylic Acids

• PCAs contain at least one or more functional
  groups other than carboxyl group
• PCAs are commonly found in living organisms an
  play an important role in human body
• Occur in many fruits
• Used in over the counter skin care products and
  prescription drugs
• Common types of PCAs
• Unsaturated acids
• Hydroxy acids
• Keto acids

14
Unsaturated Acids

• Contain at least one carbon-carbon double bond
  (CC)
• Two types of monounsaturated carboxylic acids
• Trans - unsaturated carboxylic acids
• Cis unsaturated carboxylic acids
• Examples
• Propenoic acid (acrylic acid) used in the
  manufacture of polymeric materials.
• Futenedioic acid - has two forms
• Fumaric acid trans-form
• Maleic acid cis-form

15
Hydroxy Acids

• Contain at least one hydroxyl group and are
  naturally present in many foods
• Examples
• Glycolic acid present in juice from sugar cane
  and sugar beets
• Lactic acid Present sour milk, sauerkraut, and
  dill pickles
• Malic acid and tartaric acid occur naturally in
  fruits

16
Keto Acids

• Contain a carbonyl (CO) group within a carbon
  chain.
• Example
• Pyruvic acid - simplest keto acid with odor
  resembling that of vinegar (acetic acid) and it
  is also a metabolic acid

17

• Metabolic acids Polyfunctional acids formed as
  intermediates of ________________ reactions in
  the human body.
• There are eight such acids that will appear
  repeatedly in the biochemistry chapters
• Metabolic acids are derived from
• Propionic acid, (C3 mono acids) lactic,
  glyceric, and pyruvic acids
• Succinic acid (C4 diacid) fumaric, oxaloacetic,
  and malic acids
• Glutaric acid (C5 diacid) a-ketoglutaric and
  citric acids

18
(No Transcript)
19
At Room Temperature and Pressure

• Straight chain carboxylic acids with 1-9 carbon
  atoms are liquids and strong odors
• Straight chain carboxylic acids with gt10 C atoms
  are waxy solids with no odor.
• Aromatic and dicarboxylic acids Odorless solids

20
Properties of Carboxylic Acids

• Like alcohols, carboxylic acids form ___________
  intermolecular hydrogen bonds.
• Most carboxylic acids exist as ___________.
• Boiling points higher than alkanes of similar MW.
• Small carboxylic acids (1-4 carbons) are soluble
  in water

21
Boiling Points
22
(No Transcript)
23
Synthesis of Carboxylic Acids

• Synthesized from aromatic rings, primary
  alcohols and aldehydes.
• Oxidizing Agents
• K2Cr2O7 / H2SO4
• or
• KMnO4

Carboxylic Acid
24
Oxidation of Aromatic Compounds

• Benzene does not react with KMnO4.
• Alkyl groups on the ring (-R) are readily
  oxidized though.
• One product for all reactions.

25
Oxidation of Aromatic Compoundswith KMnO4
26

• Oxidation of primary alcohols and aldehydes

27

• Oxidation of alcohols to carboxylic acids.

28
Properties

• Carboxylic acids are ________ acids
• Stronger acids than alcohols
• In water they dissociate to release ___________
  (H) and form carboxylate ion (RCOO-) --
  equilibrium reactions and equilibrium lies
  towards the left indicating that small amount of
  acid is ionized
• CH3COOH H2O CH3COO H3O
• Neutralized by a base
• CH3COOH NaOH CH3COO Na H2O

29

• Monocarboxylic acids release ______ H to form
  carboxylate ion with _______ negative charge
• Dicarboxylic acids release ______ H ions to form
  carboxylate ion with _____ negative charges and
  so on

30

• Carboxylic acids are obviously _________.
• Stronger acids than alcohols, but __________ than
  mineral acids.
• Will react with _________ to give metal
  carboxylates.
• There is a large range of acidities depending on
  the substituents on a carboxylic acid.

31
Carboxylate Ions

• The conjugate base of a carboxylic acid
• Formed when a carboxylic acid loses a proton
• Named by dropping the -ic acid ending and
  replacing it with ate
• CH3CH2COO- Propionate
• CH3COO- Ethanoate (Acetate)
• CH3CH2CH2COO- Butanoate

32
Carboxylate Salts

• An ionic compound in which the negative ion is a
  carboxylate ion
• Naming the positive ion is named first,
  followed by a separate word giving the name of
  the negative ion
• Converted back to a carboxylic acid by the
  addition of a strong acid
• CH3CH2COO-Na Sodium Propionate
• CH3COO-K Potassium Ethanoate
• CH3CH2CH2COO-Li Lithium Butanoate

33
Uses of Carboxylic Acid Salts

• Good antimicrobial and antifungal agents
• Benzoate salts Effective (0.1, m/m) against
  yeast and mold in beverages, jams and jellies,
  etc.
• Sodium sorbate Inhibits mold and yeast in dairy
  products, dried fruits, some meat and fish
  products
• Propionate Used in preservation of baked goods
• Benzoate and sorbate cant be used in yeast
  leavened baked goods as they inhibit mold and
  yeast

34
Carboxylic Acids
35
Esters

• Fig. 16.12
• Methyl and ethyl esters of acetic acid.

36
Ester

• In an ester, the _______ in the carboxyl group is
  replaced with an ________ group
• O
• ??
• CH3 CO CH3 CH3COO CH3
• ester group
• Sulfur analogs of esters are called thioesters
  (sulfur replaces the hydroxyl oxygen)

37

• The name for the alcohol part of the ester
  appears _________ and is _____________ by a
  separate word giving the name for the acid part
  of the ester.
• The name for the alcohol part of the ester is
  simply the name of the R group (alkyl,
  cycloalkyl, or aryl) present in the OR portion
  of the ester.
• The name for the acid part of the ester is
  obtained by dropping the -ic acid ending for
  the acids name and adding the suffix -ate.

38
Naming Esters

• Name the alkyl from the alcohol O-
• Name the acid with the CO with ate
• acid alcohol
• O
• ?? methyl
• CH3 CO CH3
• Ethanoate methyl ethanoate (IUPAC)
• (acetate) methyl acetate (common)

39
(No Transcript)
40
Esters
41
Esterification Preparation of Esters

• Reaction of a carboxylic acid and alcohol
• Acid catalyst
• O
• ?? H
• CH3 COH HOCH2CH3
• O
• ??
• CH3 COCH2CH3 H2O

42
Hydrolysis Breaking Up Esters

• Esters react with water and acid catalyst
• Split into carboxylic acid and alcohol
• O
• ?? H
• H COCH2CH3 H2O
• O
• ??
• H COH HOCH2CH3

43
Hydrolysis
44
Saponification

• Esters react with bases
• Produce the salt of the carboxylic acid and
  alcohol
• O
• ?? H2O
• CH3COCH2CH3 NaOH
• O
• ??
• CH3CO Na HOCH2CH3
• salt of carboxylic acid
• Saponification reactions produce soaps

45
Soaps

• Carboxylate salts

46

• The following figure represents soap.
• Which end of the anion is hydrophobic?

47

• How does soap interact with grease?

48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
Dicarboxylic Acids
52
The C2 dicarboxylic acid, oxalic acid,
contributes to the tart taste of rhubarb stalks.
