Title: CS257 Modelling Multimedia Information LECTURE 6


1
CS257 Modelling Multimedia InformationLECTURE 6
2
Introduction
  • See beginning of Lecture 5

3
Queries to Video Databases
  • Users may want to query for a particular event
    involving particular people, e.g. find me video
    with Bill hitting Tom why not use a list of
    keywords hit, Bill, Tom for query and to
    represent film content?
  • ? Need more structured descriptions of whats
    happening (both for queries and for video
    metadata), i.e. who is doing what to whom with
    what and why. More on this in PART 1

4
Queries to Video Databases
  • User may want to specify a temporal sequence of
    events, e.g. find me video where this happens
    then this happens while that happens
  • More on this in PART 2

5
Queries to Video Databases
  • How to express queries / How to describe content
    can be considered two sides of the same coin
    both require dealing with the same kinds of
    issues

6
Creating Metadata for Video Data
  • Content-descriptive metadata for video often
    needs to be manually annotated
  • However, in some cases the process can be
    automated (partially) by
  • Video segmentation
  • Feature recognition, e.g. to detect faces,
    explosions, etc.
  • Extracting keywords from time-aligned collateral
    texts, e.g. subtitles and audio description

7
Overview of LECTURE 6
  • PART 1 Need to be able to formally describe
    video content in terms of objects and events in
    order to make a query to a video database, e.g.
    specify who is doing what.
  • ? Subrahmanians Video SQL
  • PART 2 May wish to specify temporal and / or
    causal relationships between events, e.g. X
    happens before Y, A causes B to happen
  • ? Allens temporal logic
  • ? Roths system for video browsing by causal
    links
  • LAB Bring coursework questions

8
PART 1 Querying Video Content
  • Four kinds of retrieval according to Subrahmanian
    (1998)
  • Segment Retrieval find all video segments where
    an exchange of a briefcase took place at Johns
    house
  • Object Retrieval find all the people in the
    video sequence (v,s,e)
  • Activity Retrieval what was happening in the
    video sequence (v,s,e)
  • Property-based Retrieval find all segments
    where somebody is wearing a blue shirt

9
Querying Video Content
  • Subrahmanian (1998) proposes an extension to SQL
    in order to express a users information need
    when querying a video database
  • Based on video functions
  • Recall that SQL is a database query language for
    relational databases queries expressed in terms
    of
  • SELECT (which attributes)
  • FROM (which table)
  • WHERE (these conditions hold)

10
SubrahmaniansVideo Functions
  • FindVideoWithObject(o)
  • FindVideoWithActivity(a)
  • FindVideoWithActivityandProp(a,p,z)
  • FindVideoWithObjectandProp(o,p,z)

11
SubrahmaniansVideo Functions (continued)
  • FindObjectsInVideo(v,s,e)
  • FindActivitiesInVideo(v,s,e)
  • FindActivitiesAndPropsInVideo(v,s,e)
  • FindObjectsAndPropsInVideo(v,s,e)

12
A Query Language for Video
  • SELECT may contain
  • Vid_Id s,e
  • FROM may contain
  • video ltsourcegt
  • WHERE condition allows statements like
  • term IN func_call
  • (term can be variable, object, activity or
    property value
  • func_call is a video function)

13
EXAMPLE 1
  • Find all video sequences from the library
    CrimeVidLib1 that contain Denis Dopeman
  • ?
  • SELECT vid s,e
  • FROM video CrimeVidLib1
  • WHERE
  • (vid,s,e) IN FindVideoWithObjects(Denis Dopeman)

14
EXAMPLE 2
  • Find all video sequences from the library
    CrimeVidLib1 that show Jane Shady giving Denis
    Dopeman a suitcase

15
EXAMPLE 2
  • SELECT vid s,e
  • FROM video CrimeVidLib1
  • WHERE
  • (vid,s,e) IN FindVideoWithObjects(Denis Dopeman)
    AND
  • (vid,s,e) IN FindVideoWithObjects(Jane Shady) AND
  • (vid,s,e) IN FindVideoWithActivityandProp(Exchange
    Object, Item, Briefcase) AND
  • (vid,s,e) IN FindVideoWithActivityandProp(Exchange
    Object, Giver, Jane Shady) AND
  • (vid,s,e) IN FindVideoWithActivityandProp(Exchange
    Object, Receiver, Denis Dopeman)

16
EXAMPLE 3
  • Which people have been seen with Denis Dopeman
    in CrimeVidLib1

17
EXAMPLE 3
  • SELECT vid s,e, Object
  • FROM video CrimeVidLib1
  • WHERE
  • (vid,s,e) IN FindVideoWithObject(Denis Dopeman)
    AND
  • Object IN FindObjectsInVideo(vid,s,e) AND
  • Object Denis Dopeman AND
  • type of (Object, Person)

18
Exercise 6-1
  • Given a video database of old sports broadcasts,
    called SportsVidLib, express the following users
    information needs using the extended SQL as best
    as possible. You should comment on how well the
    extended SQL is able to capture each users
    information need and discuss alternative ways of
    expressing the information need more fully.
  • Bob wants to see all the video sequences with
    Michael Owen kicking a ball
  • Tom wants to see all the video sequences in which
    Vinnie Jones is tackling Paul Gascoigne
  • Mary wants to see all the video sequences in
    which Roy Keane is arguing with the referee,
    because Jose Reyes punched Gary Neville, while
    Thierry Henry scores a goal, and then Roy Keane
    is sent off.

19
Bob wants to see all the video sequences with
Michael Owen kicking a ball
20
Tom wants to see all the video sequences in which
Vinnie Jones is tackling Paul Gascoigne
21
Mary wants to see all the video sequences in
which Roy Keane is arguing with the referee,
because Jose Reyes punched Gary Neville, while
Thierry Henry scores a goal, and then Roy Keane
is sent off.
22
Think about
  • What metadata would be required in order to
    execute these kinds of video query?
  • How could this be stored and searched most
    efficiently?

23
Part 2 Enriching Video Data Models and Queries
  • More sophisticated queries to video databases can
    be supported by considering
  • Temporal relationships between video intervals
  • Causal relationships between events
  • ? Need to be able to describe temporal
    relationships between intervals formally and make
    inferences about temporal sequences

24
Temporal Relationships between Intervals
  • Allens (1983) work on temporal logic is often
    discussed in the video database literature (and
    in other computing disciplines)
  • 13 temporal relationships that describe the
    possible temporal relationships that can hold
    between temporal intervals (e.g. intervals or
    events in video) ? these can be used to formulate
    video queries
  • A transitivity table allows a system to infer the
    relationship between A r C, if A r B and B r C
    are known (where r stands for one temporal
    relationship, and A, B, C are intervals)
  • SEE MODULE WEB-PAGE FOR EXTRA NOTES ON THIS

25
  • X equal Y XXXXX
  • YYYYY
  • X before Y lt gt XXXX YYYY
  • X meets Y m mi XXXXYYYY
  • X overlaps Y o oi XXXXX
  • YYYYY
  • X during Y d di XXX
  • YYYYYYYYY
  • X starts Y s si XXXX
  • YYYYYYYY
  • X finishes Y f fi XXXXX
  • YYYYYYYYYY

26
Temporal Relationships between Intervals
  • Crucial aspect of Allens work is the
    transitivity table that enables inferences to be
    made about temporal sequences
  • Inferences take the form
  • If A r B, and B r C, then r1, r2, r3 may hold
    between A and C
  • For example
  • If A lt B and B lt C, then A lt C

27
Another Example
  • If A contains B, and B lt C then what
    relationships can hold between A and C?
  • BBBBB ?CC? ?CCCC? ?CCCCC?
  • AAAAAAAAAAAAA?CCCCC?
  • ?CCCCC?
  • Possibilities A lt C A overlaps C A meets
    C A contains C A is finished by C

28
Modelling the Relationships between Entities and
Events in Film
  • Some temporal relationships might be interpreted
    as causal relationships
  • Roth (1999) proposed the use of a semantic
    network to represent the relationships between
    entities and events in a movie including causal
    relations
  • The user can then browse between scenes in a
    movie, e.g. if they are watching the scene of an
    explosion, they may browse to the scene in which
    a bomb was planted, via the semantic network
    (extra note on semantic network will be on the
    module website).

29
(No Transcript)
30
Organising and Querying Video Content
  • Should consider
  • Which aspects of the video are likely to be of
    interest to the users who access the video
    archive?
  • How to store relevant information about the video
    efficiently?
  • How to express and process queries?
  • What scope of automatic content extraction?

31
EXERCISE 6-2
  • For an video database application domain of your
    choosing write five video queries that use some
    of Allens 13 temporal relationships
  • If event A is before (lt) event B, and event B
    is during event C, then what relationships
    could hold between A and C?
  • How do you think such reasoning about temporal
    could be used in a video database?

32
LECTURE 6LEARNING OUTCOMES
  • After the lecture, you should be able to
  • Express a users query to a video database using
    Subrahmanians VideoSQL and discuss the
    limitations of this formalism
  • Explain how and why temporal and causal
    relationships between events are represented in
    metadata for video databases

33
OPTIONAL READING
  • Dunckley (2003), pages 38-39 393-395.
  • For details of the extended video SQL, see
  • Subrahmanian (1998). Principles of Multimedia
    Databases - pages 191-195. IN LIBRARY ARTICLE
    COLLECTION
  • For temporal relationships
  • Allen (1983). J. F. Allen, Maintaining
    Knowledge About Temporal Intervals.
    Communications of the ACM 26 (11), pp. 832-843.
    Especially Figure 2 for the 13 relationships and
    Figure 4 for the full transitivity table. In
    Library on shelf
  • For causal relationships
  • Roth (1999). Volker Roth, Content-based
    retrieval from digital video. Image and Vision
    Computing 17, pp. 531-540. Available online
    through library eJournals
