Title: Authentication Applications


1
Authentication Applications
In the Name of the Most High
  • Behzad Akbari
  • Fall 2010

2
Outline
  • Introduction
  • Kerberos
  • X.509 Authentication Service
  • Recommended reading and Web Sites

3
Authentication Applications
  • Authentication functions
  • developed to support application-level
    authentication digital signatures
  • Kerberos
  • a secret-key authentication service
  • X.509
  • a public-key directory authentication service

4
KERBEROS
  • In Greek mythology, a many headed dog, the
    guardian of the entrance of Hades

5
KERBEROS
  • Users wish to access services on servers.
  • Three threats exist
  • User pretend to be another user.
  • User alter the network address of a workstation.
  • User eavesdrop on exchanges and use a replay
    attack.

6
KERBEROS
  • A centralized authentication server
  • From MIT
  • To authenticate users to servers and servers to
    users
  • Relies on conventional encryption
  • Making no use of public-key encryption
  • Allows users to access services distributed in
    network
  • Without needing to trust all workstations
  • All trust a central authentication server
  • Two versions version 4 and 5
  • Version 4 makes use of DES

7
Kerberos v4 Overview
  • a basic 3rd-party authentication scheme
  • have an Authentication Server (AS)
  • users initially negotiate with AS to identify
    self
  • AS provides a non-corruptible authentication
    credential
  • ticket granting ticket (TGT)
  • have a Ticket Granting server (TGS)
  • users subsequently request access to other
    services from TGS based on users TGT

8
Kerberos Version 4
  • Terms
  • C Client
  • AS authentication server
  • V server
  • IDc identifier of user on C
  • IDv identifier of V
  • Pc password of user on C
  • ADc network address of C
  • Kv secret encryption key shared by AS and V
  • TS timestamp
  • concatenation

9
A Simple Authentication Dialogue
  • C ? AS IDc Pc IDv
  • AS ? C Ticket
  • C ? V IDc Ticket
  • Ticket EKvIDc Pc IDv
  • Kv shared by AS and Sever (V)
  • Ticket can be decrypted by Server

10
Kerberos v4 Dialogue
  • obtain ticket granting ticket from AS
  • once per session
  • obtain service granting ticket from TGS
  • for each distinct service required
  • client/server exchange to obtain service
  • on every service request

11
Version 4 Authentication Dialogue
  • Threat
  • An opponent will steal the ticket-granting ticket
    and use it before it expires
  • Countermeasure
  • How to decide the lifetime associated with the
    ticket-granting ticket?
  • If too short ? repeatedly asked for password
  • If too long ? greater opportunity to replay

12
Version 4 Authentication Dialogue
  • C ? AS IDc IDtgs TS1
  • AS ? C E(Kc,Kc,tgs ll IDtgs ll TS2 ll
    Lifetime2 ll Tickettgs)
  • Tickettgs E (Ktgs,
    Kc,tgs ll IDc ll ADcll IDtgs ll TS2Lifetime2)
  • (a) Authentication Service Exchange to obtain
    ticket-granting ticket
  • C ? TGS IDv Tickettgs Authenticatorc
  • TGS? C E(Kc,tgs Kc,v ll IDv ll TS4 ll
    Ticketv)
  • Tickettgs E(Ktgs,Kc,tgs ll IDc
    ll ADc ll IDtgs ll TS2 ll Lifetime2)
  • Ticketv E(Kv,Kc,v ll IDc ll ADc ll
    IDv ll TS4 ll Lifetime4)
  • Authenticatorc E(Kc,tgs IDc ll ADc
    ll TS3)

(b) Ticket-Granting Service Exchange to obtain
service-granting ticket
  • C ? V Ticketv Authenticatorc
  • V ? C E(Kc,v, TS5 1) (for mutual
    authentication)
  • Ticketv E (Kv, Kc,v
    ll IDc ll ADc ll IDv ll TS4 ll Lifetime4)
  • Authenticatorc E (Kc,v, IDc
    ll ADc ll TS5)

(c) Client/Server Authentication Exchange to
obtain service
Summary of Kerberos Version 4 Message Exchanges
12
13
Version 4 Authentication Dialogue
  • C ? AS IDc IDtgs TS1
  • AS ? C E(Kc,Kc,tgs ll IDtgs ll TS2 ll
    Lifetime2 ll Tickettgs)
  • Tickettgs E(Ktgs, Kc,tgs ll IDc ll
    ADcll IDtgs ll TS2 Lifetime2)
  • (a) Authentication Service Exchange to obtain
    ticket-granting ticket
  • The client requests a TGT to AS with message(1)
  • To handle the problem of captured TGT and
  • the genuiness of ticket presenter,
  • the AS provides both the TGS and the client with
  • a secret information, called a session key,
  • in a secure manner through message(2)
  • then the key is used to prove the identity of
  • the client to TGS

13
14
Version 4 Authentication Dialogue
  • C ? TGS IDv Tickettgs Authenticatorc
  • TGS? C E(Kc,tgs Kc,v ll IDv ll TS4 ll
    Ticketv)
  • Tickettgs E(Ktgs,Kc,tgs ll IDc
    ll ADc ll IDtgs ll TS2 ll Lifetime2)
  • Ticketv E(Kv,Kc,v ll IDc ll ADc ll
    IDv ll TS4 ll Lifetime4)
  • Authenticatorc E(Kc,tgs IDc ll ADc
    ll TS3)
  • (b) Ticket-Granting Service Exchange to obtain
    SGT
  • C transmits an authenticator (A) used only once
    with
  • very short lifetime in message(3)
  • Replay attack is encountered.
  • The TGS decrypts the A and the ticket with keys,
  • - The contents from the both are checked
    if those match
  • - The ticket is a way to distribute keys securely
  • - The A proves the clients identity.
  • Reply from TGS includes a session key shared b/w
    C and V.
  • It says that the key can be used by only C and V
    for authentication.

14
15
Version 4 Authentication Dialogue
  • C ? V Ticketv Authenticatorc
  • V ? C E(Kc,v, TS5 1) (for mutual
    authentication)
  • Ticketv E(Kv,Kc,v ll
    IDc ll ADc ll IDv ll TS4 ll Lifetime4)
  • Authenticatorc E(Kc,v, IDc
    ll ADc ll TS5)
  • (c) Client/Server Authentication
    Exchange to obtain service
  • The message(5) is similar to message(3)
  • V examines the contents of A and the ticket if
    the ticket presenter is genuine
  • The mutual authentication is done with message(6)
  • The value of timestamp from the A is incremented
    by 1 and encrypted by the session key.
  • The contents of the message assures C that this
    is not a replay
  • The session key is used to encrypt future
    messages b/w the two or to exchange a new random
    session key for that purpose

15
16
Version 4 Authentication Dialogue
16
17
Kerberos Realm
  • A Kerberos realms is a set of managed nodes that
    share the same Kerberos DB.
  • A Kerberos realm consists of
  • A Kerberos server, with all user IDs and their
    passwords in its DB
  • A number of clients, registered with the Kerberos
    server
  • A number of application servers, sharing a key
    and registered with the Kerberos server
  • Networks of clients and servers under different
    administrative organizations constitute typically
    different realms.

17
18
Kerberos Realms with Multiple Kerberi
  • For two realms to support interrealm auth,
  • The Kerberos server in one realm shares a secret
    key with the sever in the other realm. The two
    Kerberos servers are registered with each other
  • The participating servers in the second realm
    must trust the Kerberos server in the first realm
  • One problem with above approach
  • It does not scale well to many realms
  • It requires N(N-1)/2 secure key exchanges for
    interoperation of all realms

18
19
Request for Service in Another Realm
19
20
Password-to-key Transformation
20
21
PCBC Mode
22
Kerberos - in practice
  • currently have two Kerberos versions
  • v4
  • restricted to a single realm
  • v5
  • allows inter-realm authentication
  • Kerberos v5 is an Internet standard
  • specified in RFC1510, and used by many utilities
  • To use Kerberos
  • need to have a KDC on your network
  • need to have Kerberised applications running on
    all participating systems
  • major problem - US export restrictions
  • Kerberos cannot be directly distributed outside
    the US in source format ( binary versions must
    obscure crypto routine entry points and have no
    encryption)
  • else crypto libraries must be reimplemented
    locally

23
X.509 Authentication Service
  • A distributed set of servers that maintains a
    database about users.
  • Each certificate contains the public key of a
    user and is signed with the private key of a CA.
  • used in S/MIME, IP Security, SSL/TLS and SET.
  • RSA is recommended to use.

24
X.509 Certificates
  • issued by a Certification Authority (CA),
    containing
  • version (1, 2, or 3)
  • serial number (unique within CA) identifying
    certificate
  • signature algorithm identifier
  • issuer X.500 name (CA)
  • period of validity (from - to dates)
  • subject X.500 name (name of owner)
  • subject public-key info (algorithm, parameters,
    key)
  • issuer unique identifier (v2)
  • subject unique identifier (v2)
  • extension fields (v3)
  • signature (of hash of all fields in certificate)
  • notation CAltltAgtgt
  • denotes certificate for A signed by CA

25
X.509 Formats
26
Obtaining a Users Certificate
  • Characteristics of certificates generated by CA
  • Any user with access to the public key of the CA
    can recover the user public key that was
    certified.
  • Nobody other than the CA can modify the
    certificate without this being detected.

27
CA Hierarchy
  • both users share a common CA
  • they are assumed to know its public key
  • If XltltAgtgt and XltltBgtgt, then A has Bs certificate
    (public key)
  • otherwise CA's must form a hierarchy
  • A signed by X1, B signed by X2
  • If A doesnt know X2s public key
  • Bs certificate is useless to A
  • A can obtain X2s public key from X1 if X2 is
    also signed by X1
  • X1ltltX2gtgtX2ltltBgtgt -- certification path
  • use certificates linking members of hierarchy to
    validate other CA's
  • each CA has certificates for clients (forward)
    and parent (backward)
  • each client trusts parents certificates
  • enable verification of any certificate from one
    CA by users of all other CAs in hierarchy

28
X.509 CA Hierarchy
If XltltAgtgt, then (i) A knows Xs public key and
(ii) A can get all the public keys signed by X.
A establishes a certification path to
B XltltWgtgtWltltVgtgtVltltYgtgtYltltZgtgtZltltBgtgt B establishes a
certification path to A ZltltYgtgtYltltVgtgtVltltWgtgtWltltXgtgtX
ltltAgtgt
29
Revocation of Certificates
  • Reasons for revocation
  • The users private key is assumed to be
    compromised.
  • The user is no longer certified by this CA.
  • The CAs certificate is assumed to be
    compromised.

30
Authentication Procedures
  • X.509 includes three alternative authentication
    procedures
  • intended for use across a variety of applications
  • to use public-key signature
  • assumed for the two parties to know each others
    KU
  • The three procedures
  • One-way authentication
  • Two-way authentication
  • Three-way authentication

31
One-Way Authentication
1. AtA,rA,IDB,sgnData,EPUb,Kab
A
B
  • A single transfer of information from A to B
  • Verification of the followings
  • 1. As identity and the message generated by A
  • 2. the message intended for B
  • 3. the integrity and originality of the message
  • At minimum TS tA, nonce rA, Bs identity, As
    signature

32
Two-Way Authentication
1. AtA,rA,IDB,sgnData,EPUb,Kab
A
B
2. BtB,rB,IDA,rA,sgnData,EPUa,Kba
  • Verification of the followings
  • 4. Bs identity and the message generated by B
  • 5. the message intended for A
  • 6. the integrity and originality of the reply
  • Permission of verification for both parties
  • Reply includes As nonce, TS and nonce from B

33
Three-Way Authentication
1. AtA,rA,IDB,sgnData,EPUb,Kab
A
B
2. BtB,rB,IDA,rA,sgnData,EPUa,Kba
3. ArB
  • The signed copy of the nonce rB in the final MSG
  • TS need not to be checked
  • Replay attack can be detected by nonces echoed
  • to each other

34
X.509 Version 3
  • Has been recognized that additional information
  • is needed in a certificate
  • e-mail/URL, policy details, usage constraints
  • Include a number of optional extensions added to
    version 2 format
  • rather than continue to add fields to a fixed
    format
  • Each extension consists of extension identifier,
    criticality indicator, extension value

35
Public Key Infrastructure
  • PKI the set of hardware, software, people,
    policies, and procedures needed to create,
    manage, store, distribute, and revoke digital
    certificates based on asymmetric cryptography.
  • based on X.509

36
Recommended Reading and WEB Sites
  • www.whatis.com (search for kerberos)
  • Bryant, W. Designing an Authentication System A
    Dialogue in Four Scenes. http//web.mit.edu/kerber
    os/www/dialogue.html
  • Kohl, J. Neuman, B. The Evolotion of the
    Kerberos Authentication Service
    http//web.mit.edu/kerberos/www/papers.html
  • http//www.isi.edu/gost/info/kerberos/
Write a Comment
User Comments (0)
About PowerShow.com
