Title: Binary Search Tree


1
  • Chapter 8
  • Binary Search Tree

Fall 2010
2
Binary Trees
  • A structure with
  • a unique starting node (the root), in which
  • each node has up to two child nodes, and
  • a unique path exists from the root to every
    other node
  • Root
  • Top node of a tree structure a node with no
    parent
  • Leaf Node
  • A tree node that has no children

3
Trees level and height
  • Level distance of a node from the root
  • Height the maximum level

4
Trees
Why is this not a tree?
A tree is a structure with i) a unique starting
node (the root), in which ii) each node can have
up to two child nodes and iii) a unique path
exists from the root to every other node
5
Descendants
Descendant of a node is a child of the node, and
any child of the children, etc.
V
Q
L
T
A
E
K
S
How many descendants does Q have?
6
Ancestors
Ancestor of a node a parent of the node, the
parent of the parent, etc.
V
Q
L
T
A
E
K
S
How many ancestors does S have?
7
Binary Trees Come in Different Shapes
How many structurally different binary trees can
be made from 2 nodes? 4 nodes? 6 nodes?
8
Binary Tree Facts
  • Max. number of nodes at Nth level 2N.
  • 0th level root node 1
  • 1st level 2
  • Double as level increases by 1
  • Suppose f(n) denotes the maximum number of nodes
    at the nth level
  • f(0)1
  • f(n)2f(n-1) for ngt1
  • A recursive formula!
  • f(n)2n

9
Binary Tree Facts
  • Max. total number of nodes in a tree of height N
  • All levels are full, so add the max. number of
    nodes at each level together
  • 2021222N 2N1-1

10
Binary Tree Facts
  • Given a binary tree with N nodes, what is the
    min. number of levels?
  • Try to fill in each level
  • The answer is log2N 1
  • Max. number of levels with N nodes ?
  • One node at each level gt degenerates to a linked
    list
  • The answer is N

11
Binary Search Trees (BST)
  • A BST is a binary tree with a search property.
  • A binary tree in which, for each node
  • key value in the node is greater than the key
    value in its left child and any of the left
    childs descendents (left sub-tree)
  • key value in the node is less than the key value
    in its right child and any of the right childs
    descendents (right sub-tree)

12
Binary Search Trees
Each node is the root of a subtree rooted at the
node
13
Binary Search Tree ADT
  • Application level same as List
  • Logic Level
  • void MakeEmpty()
  • bool IsEmpty()
  • bool IsFull()
  • int GetLength()
  • RetrieveItem(ItemType item, bool found)
  • InsertItem (ItemType item)
  • DeleteItem (ItemType item)
  • Print(ofstream outFile)
  • ResetTree(OrderType order)
  • GetNextItem (ItemType item, OrderType order,bool
    finished)

14
Tree node in BST
Can you define a structure to represent a binary
tree node ?
15
Recursive Count
Lets start by counting the number of nodes in a
tree Size? Base cases(s)? General case(s)?
16
Recursive Count version 1
if (Left(tree) is NULL) AND (Right(tree) is
NULL) return 1 else return Count(Left(tree))
Count(Right(tree)) 1
Apply to these trees
17
Recursive Count version 2
if (Left(tree) is NULL) AND (Right(tree) is
NULL) return 1 else if (Left(tree) is
NULL) return Count(Right(tree)) 1 else if
(Right(tree) is NULL) return Count(Left(tree))
1 else return Count(Left(tree))
Count(Right(tree)) 1
Apply to an empty tree
18
Recursive Count version 3
if (tree is NULL) return 0 if (Left(tree)
is NULL) AND (Right(tree) is NULL) return 1 else
if (Left(tree) is NULL) return
Count(Right(tree)) 1 else if (Right(tree) is
NULL) return Count(Left(tree)) 1 else
return Count(Left(tree)) Count(Right(tree)) 1
19
Recursive Count version 4
if (tree is NULL) return 0 else return
Count(Left(tree)) Count(Right(tree)) 1
20
Recursive Count implementation
int TreeTypeGetLength() const return
Count(root) ) int TreeTypeCount(TreeNode
tree) const if (tree NULL) return 0
else return Count(tree-gtleft)
Count(tree-gtright) 1
Why do we need two functions?
21
Recursive Search

J
T
E
A
V
M
H
P
Are D, Q, and N in the tree?
22
Recursive Search
Retrieve(tree, item, found) Size? Base
case(s)? General case(s)?
23
Recursive Search
  • void TreeTypeRetrieve(TreeNode tree,
  • ItemType item, bool found) const
  • if (tree NULL)
  • found false //base case
  • else if (item lt tree-gtinfo)
  • Retrieve(tree-gtleft, item, found)
  • else if (item gt tree-gtinfo)
  • Retrieve(tree-gtright, item, found)
  • else //base case
  • item tree-gtinfo
  • found true

24
Shape of BST
  • Shape depends on the order of item insertion
  • Insert the elements J E F T A
    in that order
  • The first value inserted is always put in the
    root

25
Shape of BST
  • Thereafter, each value to be inserted
  • compares itself to the value in the root node
  • moves left it is less or
  • moves right if it is greater
  • When does the process stop?

26
Shape of BST
  • Trace path to insert F

27
Shape of BST
  • Trace path to insert T

28
Shape of BST
  • Trace path to insert A

29
Shape of BST
  • Now build tree by inserting A E F
    J T in that order

And the moral is?
30
Recursive Insertion
Insert an item into a tree Where does each new
node get inserted?
Insert(tree, item) if (tree is NULL) Get a new
node and insert at this location Set right and
left to NULL Set info to item else if (item is
larger than tree-gtinfo)
Insert(tree-gtright, item) else
Insert(tree-gtleft, item)
31
Recursive Insertion
32
Recursive Insertion
Insert item 12
33
Recursive Insertion
How must the tree be passed?
34
Recursive Insertion
  • void TreeTypeInsert(TreeNode tree, ItemType
    item)
  • if (tree NULL)
  • // Insertion place found.
  • tree new TreeNode
  • tree-gtright NULL
  • tree-gtleft NULL
  • tree-gtinfo item
  • else if (item lt tree-gtinfo)
  • Insert(tree-gtleft, item)
  • else
  • Insert(tree-gtright, item)

35
Deleting a Leaf Node
36
Deleting a Node with One Child
37
Deleting a Node with Two Children
38
Delete an existing item from BST
  • Can you summarize the three deletion cases?
  • Deleting a leaf node.
  • Deleting a node with only one child.
  • Deleting a node with two children.

39
Predecessor
  • Predecessor the element whose key immediately
    precedes (less than) the key of item
  • If the item node has a left child, the largest
    element in the left subtree (right-most child)
  • If the item has no left child,

40
Successor
  • Successor the element whose key immediately
    follows (greater than) the key of item
  • If the item node has two children, the smallest
    element in the right subtree (left-most child)
  • If the item node has no right child,

41
Recursive Deletion
  • DeleteItem(tree, item)
  • if (Left(tree) is NULL) AND (Right(tree) is NULL)
    // delete Z
  • Set tree to NULL
  • else if (Left(tree) is NULL AND (Right(tree)) is
    not NULL) delete R
  • Set tree to Right(tree)
  • else if (Right(tree) is NULL AND (Left(tree)) is
    not NULL)
  • Set tree to Left(tree)
  • else // delete Q, maintain a binary search
    tree
  • Find predecessor
  • Set Info(tree) to Info(predecessor)
  • Delete predecessor

42
Recursive Deletion
  • TreeTypeDeleteItem (ItemType item)
  • deletes item from the current object (a tree
    object)
  • void Delete( TreeNode tree, ItemType item)
  • deletes item from a tree rooted at tree
  • void DeleteNode( TreeNode tree)
  • deletes node pointed to by tree from a BST
  • void GetPredecessor( TreeNode tree, ItemType
    data)
  • finds datas predecessor the largest item in
    datas left subtree and saves the info into data.

43
Recursive Deletion
  • void TreeTypeDeleteItem(ItemType item)
  • Delete(root, item)
  • //Calls the recursive function Delete to
  • //delete item from tree.

43
44
Recursive Deletion
  • // first, find which node should be deleted.
  • void TreeTypeDelete(TreeNode tree,
  • ItemType item)
  • if (item lt tree-gtinfo)
  • Delete(tree-gtleft, item)
  • else if (item gt tree-gtinfo)
  • Delete(tree-gtright, item)
  • else
  • DeleteNode(tree) // Node found

45
Recursive Deletion
  • void TreeTypeDeleteNode(TreeNode tree)
  • ItemType data
  • TreeNode tempPtr
  • tempPtr tree
  • if ( tree-gtleft NULL)
  • tree tree-gtright
  • delete tempPtr
  • else if (tree-gtright NULL)
  • tree tree-gtleft
  • delete tempPtr
  • else
  • GetPredecessor(tree-gtleft, data)
  • tree-gtinfo data
  • Delete(tree-gtleft, data)

Tracing this function using various examples
46
Find Predecessor
  • void TreeTypeGetPredecessor( TreeNode tree,
  • ItemType data)
  • //the largest item is located in its rightmost
    node.
  • while (tree-gtright ! NULL)
  • tree tree-gtright
  • data tree-gtinfo
  • This function could be named GetLargestItem() as
    it returns the largest item stored in tree rooted
    at tree.

47
Recursive Deletion
48
Traversals
  • Tree Traversal visiting all the nodes of a tree
  • Depth-First Traversal, Breadth-First Traversal
  • Depth-First Traversal
  • Inorder Traversal
  • Preorder Traversal
  • Postorder Traversal

48
49
Inorder Traversal

  • Inorder traversal visits the root in between
    visiting the left and right subtrees
  • Inorder traversal only makes sense for binary
    trees.
  • Inorder(tree)
  • if tree is not NULL
  • Inorder(Left(tree))
  • Visit Info(tree)
  • Inorder(Right(tree))

A B C D E F G
49
50
Preorder Traversal
  • Preorder traversal visits the root first.
  • PreOrder(tree)
  • if tree is not NULL
  • Visit Info(tree)
  • Preorder(Left(tree))
  • Preorder(Right(tree)) D B A C F E G

50
51
Postorder Traversal
  • Postorder traversal visits the root last.
  • PostOrder(tree)
  • if tree is not NULL
  • Postorder(Left(tree))
  • Postorder(Right(tree))
  • Visit Info(tree)

A C B E G F D
51
52
Traversals
52
53
Printing the Tree
Traversal Algorithm Inorder traversal
53
