Title: Binary Trees


1
Binary Trees
  • Tonga Institute of Higher Education

2
Review of Ordered Arrays and Linked Lists
  • Ordered Array
  • Searching is fast.
  • Binary Search
  • O(logN)
  • Inserting and Deleting is slow.
  • Need to move many values one space over
  • O(N)
  • Linked List
  • Inserting and deleting is fast.
  • Just need to change a few references
  • O(1)
  • Searching is slow
  • Must start from the beginning of the list and
    check every link.
  • O(N)

3
Introduction to Binary Trees
  • A Binary Tree combines the advantages of ordered
    arrays and linked lists
  • Like an ordered array, we can
  • Search for an item quickly
  • Like a linked list, we can
  • Insert items quickly
  • Delete items quickly

4
What is a Tree?
  • A tree consists of nodes connected by edges
  • Nodes represent objects
  • Example Customers, plane tickets, etc.
  • Edges represent references
  • There is 1 node at the top of the tree
  • Trees are small on top and large on bottom
  • It looks like an upside down tree

5
Tree Terminology - 1
  • Path The route you must take to get to a node
  • Root The top node of the tree
  • Parent Every node must have one edge running
    upwards to another node. The node above it is a
    parent
  • Child Any node may have one or more edges
    running downward to another node. The node below
    it is a child.

6
Tree Terminology - 2
  • Leaf A node with no children
  • Subtree Any node may be considered to be the
    root of a subtree, which consists off all the
    edges and nodes under that node.
  • Visiting A node is visited when a program
    control arrives at a node to carry out an
    operation like checking a value. Just passing
    over a node on a path from one node to another is
    not considered to be visiting the node.

7
Tree Terminology - 3
  • Traversing To traverse a tree means to visit
    all nodes in a specified order.
  • Levels The level of a node refers to how many
    edges the node is from the root.
  • Keys One data field in an object stored in a
    node usually contains a key value. This value is
    used to search for the item or perform other
    operations on it.

8
Tree Rules
This is not a valid tree because there is a node
with more than one path to the root
  • The only way to move from one node to another is
    to follow a path along the lines
  • There must be only one path to the root.

9
Using Trees in Everyday Life
  • You have been using a Tree for at least half a
    year already!
  • The file structure in your computer follows these
    rules!
  • Desktop is the root node
  • Directories are nodes
  • Directories without any subdirectories or files
    in them are leaves
  • Files are leaves
  • You double-click on a folder to move from one
    node to another

10
Binary Trees
  • Binary Trees contain number keys
  • Binary Trees can only have a maximum of 2
    children
  • The key in the left child node must be less than
    or equal to the key in the right child node

11
Presentation
  • Binary Tree Applet

12
Node Class
  • We can create an class to represent a node
  • The class can contain data representing the
    object being stored
  • Employees
  • Items
  • The class must also contain
  • A key value
  • A left node
  • A right node

13
Code View
  • Node Class

14
Tree Class
  • We can create an class to represent a tree
  • A tree has only one field a node that holds the
    root
  • The tree class can have many methods
  • Find
  • Insert
  • Delete
  • Etc.

15
Code View
  • Tree Class

16
Finding a Node
  • Each node can represent an object
  • Customer
  • Item
  • Each object has a key
  • Customer ID
  • Item ID
  • We can find an item easily with these steps
  • At a node, determine whether the key of the
    object you are looking for is greater than, equal
    to, or less than the value of the node
  • If the key is less Move to the left child node
    and repeat from step 1.
  • If no left child node is available, the node does
    not exist in this tree.
  • If the key is equal We have found the node we
    are looking for
  • If the key is greater Move to the right child
    node and repeat from step 1.
  • If no right child node is available, the node
    does not exist in this tree.

17
Demonstration
  • Find in Applet

18
Code View
  • Find Code

19
Find Efficiency
  • The time required to find a node depends on the
    level that the node is located
  • This is O(logN) time

20
Inserting a Node
  • We can insert an item with these steps
  • Find the place to put the node
  • Pretend like were looking for a node
  • When we get to the last node and realize that the
    node we want to insert does not already exist, we
    add it as a left or right child node

21
Unbalanced Trees
  • Sometimes, when we add a lot of nodes, our tree
    becomes very heavy on one side
  • This condition is called an unbalance tree
  • How to handle unbalanced trees is covered in
    Algorithm Analysis and Design

22
Demonstration
  • Insert in Applet

23
Code View
  • Insert Code

24
Traversing a Tree
  • Traversing To traverse a tree means to visit
    all nodes in a specified order.
  • There are 3 ways to traverse a tree
  • Inorder
  • Preorder
  • Postorder

25
Inorder Traversal - 1
  • An inorder traversal of a binary search tree will
    cause all the nodes to be visited in ascending
    order.
  • To traverse a tree Inorder we repeat the 3
    following steps until we have visited every node
    in the binary tree
  • Go to left child
  • Visit the node
  • Go to right child

26
Inorder Traversal - 2
Start from the root node
Move to right child
Move to left child
27
Inorder, Preorder and Postorder Traversals
  • Inorder Traversal
  • Go to left child
  • Visit the node
  • Go to right child
  • Preorder Traversal
  • Visit the node
  • Go to left child
  • Go to right child
  • Postorder Traversal
  • Go to left child
  • Go to right child
  • Visit the node

28
Demonstration
  • Traversals in Applet

29
Code View
  • Traversal Code

30
Finding Maximum and Minimum Values
  • To get the minimum value, go to the left-most
    node
  • To get the maximum value, go to the right-most
    node

31
Deleting a Node with No Children
  • To delete a node with no children, set the
    reference of the parent node to be null.
  • The node will eventually be cleaned up by the
    Java garbage collector.

32
Deleting a Node with 1 Child
  • To delete a node with 1 child, set the reference
    of the parent node to be the child of the deleted
    node.

33
Deleting a Node with 2 Children - 1
  • When you are deleting a node with 2 children, we
    have a problem.
  • How do we know which node to put in the place of
    the deleted node?
  • In other words, which node is the successor?

34
Deleting a Node with 2 Children - 2
Subset of the nodes on the right
  • To find the successor we must find the smallest
    value of the subset of the nodes on the right
  • To do this
  • Go to the right child of the node to be deleted
  • Then, find the leftmost node

35
Finding a Successor Node
These nodes are the leftmost nodes of the right
child!
In this case the successor node is the right
child of the node to be deleted
In this case, the successor node is not the
right child of the node to be deleted
36
Deleting a Node when the Successor is the Right
Child of the Node to be Deleted
87 replaces 75 because it was the successor
  • When the successor is the right child of the node
    to be deleted, replace the deleted node with the
    successor

37
Deleting a Node when the Successor is a Left
Descendant of Right Child Node of the Node to be
Deleted
  1. The successor replaces the deleted node
  2. The algorithm is redone as if the successor was
    deleted until the entire tree has been redone

38
Demonstration
  • Deletions in Applet

39
Code View
  • Deletion Code

40
Code View
  • Binary Tree Summary with Driver
