An Introduction to DBMS Technology

1
An Introduction to DBMS Technology
Yelena Yesha Olga Streltchenko
2
Presentation Overview

• Database functionality
• Relational Data Model
• SQL
• Web-Database Connectivity

3
Transaction

• A transaction is an exchange of
• Information
• Goods
• Services
• Currency/currencies
• Transaction properties
• Atomicity a transaction must be all or nothing.
• Consistency a transaction takes the system from
  one consistent state to another.
• Isolation.
• Durability.

4
Databases and Information Economy

• Shift from computation to information
• corporate computing
• personal computing and the Internet
• scientific computing.
• Growing importance of transaction-orientation and
  information retrieval.
• The database field concentrates on the efficient
  management of large amounts of persistent,
  reliable shared data.

5
Database versus File System

• Database management systems (DBMS) is a software
  that provides transaction support by implementing

• Data independence
• Data access efficiency
• Concurrency control
• Data integrity
• Reliability
• Security
• Data distribution and heterogeneity.

6
Data Independence and Access Efficiency

• DBMS allows to avoid rewriting all access
  routines every time the data format changes or
  data is added/modified/deleted.
• insulate applications from data storage details.
• Logical independence protection from changes in
  logical structure of data.
• Physical independence protection from changes
  in physical structure of data.
• DBMS maintains data structures and implements
  algorithms allowing to avoid linear search
• indexing search in O(log n)
• fast access even on complex data queries.

7
Concurrency Control and Data Integrity

• Interleaving actions of different applications
  boosts performance.
• DBMS insures semantically correct access to the
  same data by concurrent applications
• two programs accessing the same data at the same
  time can result in an inconsistent update
• implement sharing in a controlled manner.
• Data semantics may require certain constraints to
  be satisfied.
• DBMS guarantees that application programs comply
  with the constraints when adding/modifying the
  data.

8
Reliability and Security

• DBMS provides techniques for recovery from
  software and hardware failures
• guarantee survival of the data across
  catastrophes.
• DBMS prevents unauthorized users from
  accessing/modifying data or denying service to
  other users.

9
Data Distribution and Heterogeneity

• Centralization is the enemy of scalability
• a vast number of modern applications are
  distributed.
• Data sharing in a distributed environment is a
  challenge.
• Heterogeneity applies to networks, hardware,
  operating systems, programming languages, data
  formats, etc.
• Distributed applications must mask the
  differences.
• Need distributed data management.

10
Categories of Data Models

• High-level or conceptual
• entities, attributes, relationships.
• Representational or implementation or logical
• relational, network hierarchical,
  object-oriented, object-relational.
• Physical or low-level
• data storage.

11
Levels of Abstraction in a Database

• Schema versus Instance
• schema description of the data that
• captures data types, relationships, constraints
  on the data
• meta-data (data about data), knowledge, e.g.,
  Employees(EmpName, EmpNo, Dept, Sal)
• is independent of any application program
• changes infrequently
• instance set of records/tuples/rows for that
  schema, the actual data in the database at a
  given time
• time-varying
• e.g., ltJane, 201, Shoe, 1Mgt,ltSusan, 302, Toy, 1Mgt

12
3-schema Architecture

• Physical level description of a database
• how things are stored on disk
• files, record structures,
• indices,
• data structures for disk blocks,
• methodology for dealing with too long records,
  etc.
• Conceptual level description of a database
• The description of application data (its schema)
  using one of the traditional data models.

13
3-Schema Architecture (cont'd)

• View-level description of a database
• What users of a particular application see
• their own customized schema, e.g., for payroll,
  for the ticket agent, for a simulation program.
• Multiple levels
• helps with data independence
• helps with maintenance.
• Many views, single logical and physical schema.
• Levels of abstraction give data independence.

14
The Entity-Relational Model

• Entity a distinguishable object.
• Entity set a set of entities all of the same
  type.
• Attribute a single property of an entity
• simple vs composite
• single-valued vs multi-valued
• stored vs derived
• null values.
• Domain set of values permitted for that
  attribute.

15
The E-R Model (2)

• Relationship an association between two or more
  entities.
• Relationship set a set of relationships all of
  the same type
• There is no correct schema for a batch of data.
  Which schema is best depends on the application.
• Many basic data modelling choices depend on an
  understanding of the application.

16
Data Model

• Data model notation for describing data, plus a
  set of operations used to manipulate that data.
• a set of primitives for defining the structure of
  a DB
• a set of operations for specifying the retrievals
  and updates on a DB
• relational, hierarchical, network,
  object-oriented.

17
The Relational Model (Codd 1970)

• The relational data model is the most important
  data model currently existing.
• Value-oriented, i.e., allows operations on
  relations whose results are relations, thus
  enables to combine operations.
• As opposed to object-oriented models, in which
• Operations cannot be applied to the result of
  other operations
• The result of an operation may be a new data
  type, and operations may not be available for
  this type.

18
Definitions Domain Relation

• A domain is a set of atomic values.
• A relation is a finite subset of the cartesian
  product of a finite list of domains
• relation is a set of tuples
• order of tuples is irrelevant and
• no relation has 2 identical tuples
• each tuple value is atomic
• no composite attributes
• no multi-valued attributes.

19
Relational Model (contd)

• Everything is represented by relations
• Formally Given sets D1, D2, ....Dn (not
  necessarily distinct), a relation R ? D1 X D2 X
  ...X Dn
• Di 's are the domains and n is the arity
  (degree) of R
• elements of R are called tuples
• number of tuples in R is the cardinality of R
• relational data model helps to view a relation as
  a table
• Observe the following properties

20
Relational Model (contd)

• Everything is represented by relations
• Given sets D1, D2, ....Dn (not necessarily
  distinct), a relation R ? D1 X D2 X ...X Dn
• Di 's are the domains and n is the arity (degree)
  of R
• elements of R are called tuples
• number of tuples in R is the cardinality of R.
• Relational data model helps to view a relation as
  a table
• each row represents a tuple (record)
• each column represents an attribute (field).
• Properties
• no two rows are identical
• the ordering of tuples is unimportant
• the ordering of columns is important.

21
Keys

• Let R be a relation schema and K ? R.
• K is a superkey of R if it can uniquely identify
  any tuple in any r(R). There are no tuples t and
  t' such that tK t'K.
• K is a candidate key if K is a minimal superkey.
  There is no K' ? K such that K' is also a
  superkey of r(R)
• A primary key is one of the candidate keys,
  remaining candidate keys are alternate keys
• Every relation has a key.
• A key is a property of a relation schema, not a
  relation.

22
Integrity Constraints

• Relational database schema is a set of relation
  schemas and a set of integrity constraints
• Integrity constraint condition that must be true
  for any instance of a database.
• Integrity constraints are expected to hold on
  every database instance of the schema
• Integrity constraints
• Structural
• key constraint uniqueness of keys
• entity integrity constraint no primary key value
  can be null
• referential integrity constraint reference from
  relation R to relation S must refer to an
  existing tuple of S
• Semantic.

23
Foreign Keys

• A set of attributes (FK) of R is a foreign key if
• the attributes in FK have the same domain as the
  primary key (PK) attributes of another relation
  S, and
• for each instance of R, the values of FK occur as
  a value of PK for some instance in S, or is null.
• In the relational model, the only way an entity
  can reference another entity is through the value
  of the primary key of the second entity.
• Foreign keys don't have to be unique or non-null,
  but if one component is null, then all components
  must be null.

24
E-R to Relations (I.e., Defining Relations)

• Done using DDL (Data Definition Language)
• Name whole database schema
• Declare domains for attributes
• Define relations
• name
• attribute names and domains
• primary and other keys
• foreign keys

25
Translating from E-R

• Represent entity set E by a relation whose
  attributes are all the E-R attributes of E. Then
  each tuple represents one entity of E.
• To represent relation R between entity sets E1,
  , Ek, create relation R with key attributes of
  E1, , key attributes of Ek, as attributes
  (rename duplicates). Each tuple of the relation
  represents one combination of entities that are
  related to one another.
• You might have some redundant relations, which
  you can delete.

26
Schema Normalization

• Formal theory of database design
• based on grouping attributes in a particular way
  using attribute dependencies to achieve good
  schemas
• 1NF, 2NF, 3NF, BCNF, 4NF,
• Goal
• dont store redundant information
• can represent everything (otherwise, the schema
  is useless!)

27
Query and Update Languages

• DDL data definition language
• used by DBA
• to define schemas, create views, create indices
• DML data manipulation language
• used by sophisticated casual user
• to query data or
• update data

28
Relational Query Languages

• Query languages allow manipulation and retrieval
  of data from a database.
• Relational model supports simple, powerful query
  languages
• strong formal foundation based on logic
• allows for optimization.
• Two mathematical languages form the basis for
  relational languages (e.g., SQL) and for
  implementation
• Relational Algebra More operational, useful for
  representing execution plans
• Relational Calculus Lets users describe what
  they want, rather than how to compute it
  (non-operational, declarative).
• Basic operations
• selection, projection, cross-product,
  set-difference, union, intersection, join,
  division

29
SQL

• SQL (Structured Query Language) is the query
  language for the System R developed at IBM San
  Jose Astraham, Gray, Lindsay, Selinger ..
• SQL is now the query language for IBM's DB2 and
  the de-facto standard on most commercial RDBMS.
• SQL is a comprehensive language providing
  statements for data definition, query and update.
  Hence it is both DDL and DML.

30
SQL (contd)

• SQL allows to create views, it can be embedded in
  a general-purpose programming language (C or
  PASCAL).
• SQL has one basic statement for retrieving data
  from the database
• the SELECT statement
  SELECT ltattribute listgt

  FROM lttable listgt
  WHERE ltconditiongt
• Standards
• SQL or SQL1 (ANSI 1986)
• SQL2 or SQL-92 (ANSI 1992)
• SQL3 underway extends SQL with OO and other
  concepts.

31
SQL Data Types

• Numeric
• Integers of various ranges INTEGER (or INT),
  SMALLINT
• Real numbers of various precision FLOAT, REAL,
  DOUBLE PRECISION
• Formatted numbers DECIMAL(i,j) or DEC(i,j) or
  NUMERIC(i,j).
• Character Strings
• Fixed length n CHAR(n) or CHARACTER(n)
• Variable length of maximum n VARCHAR(n) or CHAR
  VARYING(n) (default n 1).
• Bit strings
• Fixed length n BIT(n)
• Varying length of maximum n VARBIT(n) or BIT
  VARYING(n).

32
SQL Data Types (contd)

• Date Time SQL2
• DATE (10 positions) YYYY-MM-DD
• TIME (8 positions) HHMMSS
• TIMESTAMPdate, time with 6 fractions of seconds
  and optional time zone TIME(i) defines i decimal
  fractions of seconds
• (81i positions) HHMMSSddd...d
• TIME WITH TIME ZONE includes the displacement
  from standard universal time zone 1300 to
  -1259 (6 additional positions)
  HHMMSS/-HHMM
• INTERVAL Year/Month or Day/TIME

33
Data Definition Language

• DDL is used to define the (schema of) database
• to create a database schema
• to create a domain
• to create, drop. alter a table
• to create, remove an index defunct in SQL2
• to create or drop a view
• to define integrity constraints
• to define access privileges to users (Oracle
  CONNECT, RESOURCE, DBA)
• to GRANT or REVOKE privileges ON/TO object/user
• SQL2 supports multiple schemas
• CREATE SCHEMA name AUTHORIZATION user
• CREATE SCHEMA EMPLOYEE AUTHORIZATION yesha

34
SQL Schema

• EMP(Name,SSN,DNO,BirthPlace)
• DEPT(DName,DNO,MGRSSN)
• PROJECT(PName,PNO,PLocation,DNum)
• WORKSON(ESSN,PNO,Hours)
• CREATE SCHEMA 'COMPANY'
• CREATE TABLE EMP
• (
• EName name_dom NOT NULL,
• SSN CHAR(9) NOT NULL,
• DNO INTEGER NOT NULL,
• BirthPlace city_dom,
• PRIMARY KEY(SSN),
• FOREIGN KEY (DNO) REFERENCES DEPT (DNO)
• )

35
Drop

• DROP command can be used to remove
• a schema
• DROP SCHEMA Company CASCADE
• DROP SCHEMA Company RESTRICT
• CASCADE option removes everything tuples,
  tables, domains, ...
• RESTRICT option removes the schema if it has no
  elements in it
• a table
• DROP TABLE EMP CASCADE
• DROP SCHEMA EMP RESTRICT
• CASCADE option removes the table and all
  references to it
• RESTRICT option removes the table if it is not
  referenced

36
Alter

• The ALTER allows to
• alter the domain of an attribute
• ALTER TABLE Student
• ALTER GPA NUMBER(4,2)
• set or drop default value of an attribute
• ALTER TABLE Student
• ALTER GPA DROP DEFAULT
• ALTER TABLE Student
• ALTER GPA SET DEFAULT 0.00
• add a new attribute to a relation
• ALTER TABLE Student
• ALTER Admission DATE
• drop an attribute (not in SQL1)
• ALTER TABLE Student
• DROP GPA CASCADE/RESTRICT

37
Data Manipulation Language

• SELECT
• tuple queries
• aggregate queries
• INSERT
• DELETE
• UPDATE
• CREATE VIEW

38
Data Query SELECT

• Used for retrieval.
• Used to specify subqueries for retrieval and for
  the other operations.
• Not the sigma or select operator of the
  relational algebra.
• The general form of a SELECT statement
• SELECT ltattribute listgt
• FROM lttable listgt
• WHERE ltconditiongt
• GROUP BY ltattribute listgt
• HAVING ltconditiongt
• ORDER BY ltattribute,ASC/DESC pairgt

39
Relational Operators in SQL

• Projection SELECT A,B FROM R
• Selection SELECT FROM R WHERE F
• The WHERE condition can be a Boolean combination
  of conditions.
• Product of two tables, A X B
• SELECT R.?, S.?
• FROM R, S

40
Data Update

• Examples
• Create a new instance of an entity explicitly
  with all details
• INSERT table VALUES (v1, v2, ..., vn) inserts a
  tuple (v1, v2, ..., vn) into table
• Unspecified columns get their default value if
  available,NULL if allowed (and no default is
  defined), (fails otherwise)
• INSERT table(c1, c2, cm) VALUES (v1, v2, ..., vm)
  inserts a tuple with m columns set to (v1, v2,
  ..., vm).

41
Data Update (contd)

• Examples
• UPDATE table SET c1 v1, ..., cm vm WHERE
  expr
• Update all instances matching some local
  criterion UPDATE table SET ? WHERE ?
• Remove instances matching some local criterion
  DELETE table WHERE ?
• Remove instances matching a non-local criterion
• DELETE table FROM table, table2 WHERE AND ?

42
SQL Views

• An SQL view is a table derived from other tables
• base (physical) tablesultimately depend on these
  defining tables
• other views
• Views are
• usually virtual
• sometimes materialized

43
View Specification

• Views are specified with the paradigm
• CREATE VIEW view
• AS SELECT
• The SELECT part is the defining query
• In a view definition, we can
• define column names of view
• use aggregation (GROUP BY)

44
View Resolution

• Views are
• computed by a sort of macro expansion when
  neededview resolution
• query modification compute fresh
• view materialization store
• always up to date modifications to the defining
  tables are automatically reflected in the view

45
Updating Views

• A view tuple may have as its source a combination
  of base tuples, because of
• joins
• aggregations
• Therefore, updating a view
• is nontrivial to determine
• may potentially lead to more than one update on
  the defining relations
• is often not allowed

46
Updating Views (2)

• Restricted kinds of views may be updated. The
  subselect must have
• only one defining table
• columns including a candidate key of the table
• only column names, not expressions
• no joins, e.g., no correlative subqueries
• no DISTINCT keyword
• no aggregates

47
CHECK OPTION

• Specified for updatable views
• Checks whether an INSERT or UPDATE to a view
  would immediately cause the tuple to disappear
  from the view
• the new tuple should satisfy the WHERE clause of
  the view definition

48
SQL Constraints

• SQL allows declarative constraints such as
• CREATE ASSERTION assertion-name
• CHECK (enhanced subselect query)
• The DBMS checks if any ASSERTION is ever violated
