HYDROELECTRIC ENERGY

1
HYDROELECTRIC ENERGY

• Murat Yakut
• Ismail Yilmaz

2
CONTENT

• What is the Hydroelectric energy?
• History of Hydroelectric energy?
• Potential Energy?
• Kinetic Energy?
• Mechanical energy?
• How it works?
• Component
• Type Of Dam
• Type Of Turibine
• Advantage/Disadvantage

3
What is the Hydroelectric energy?

• Generally ,Using the power of water currents to
  generate electric power.
• Hydroelectric power is considered a renewable
  energy source.

4
History of Hydroelectric energy?

• Nearly 2000 years ago the Greeks used water
  wheels to grind wheat into flour
• The evolution of the modern hydropower turbine
  began in the mid-1700s when a French hydraulic
  and military engineer, Bernard Forest de Bélidor
  wrote Architecture Hydraulique.

5
Potential Energy?

• Potential energy exists whenever an object which
  has mass has a position within a force field.

6
Kinetic Energy?

• Kinetic energy is the energy of motion. Any
  moving object has kinetic energy.

7
Mechanical energy?

• Mechanical energy is a form of kinetic energy,
  such as in a machine. Mechanical energy has the
  ability to do work. Any object that is able to
  do work has mechanical energy.

8
How it works?

• Falling or flowing water turns a propeller like
  piece called a turbine.
• The turbine turns a metal shaft in an electric
  generator which produces electricity.

9
(No Transcript)
10
(No Transcript)
11
Block Diagram
12
Component of Hydro Power

• Dam  are massive barriers built across rivers
  and streams to confine and utilize the flow of
  water for human purposes such as irrigation and
  generation of hydroelectricity.
• Intake water from the river/spring/dam/irrigatio
  n channel is diverted from its main course.General
  ly weir used to divertwater through intake into
  open channel.
• Penstock pipeline supplying water from forebay
  to turbine. Mild steel, upvc and hdpe - most
  commonly used materials.
• Power House houses turbine  generator with mecha
  nical control valves and electrical control
  panels. Switch yard and connection to
  distribution system.
• Turbine hydro power in jet at end of penstock
  ransmitted to turbine runner - changes to
  mechanical power.
• Generator electricity generated when
  turbine drives generator.

13
Type Of Dam

• Arch Dam
• Gravity Dam
• Buttress Dam
• Embankment Dam

14
Arch Dam

• Arch shape gives strength
• Less material (cheaper)
• Narrow sites
• Need strong abutments

15
Arch Dam
16
Gravity Dam

• Weight holds dam in place
• Lots of concrete (expensive)

17
Gravity Dam
18
Buttress Dam

• Is a gravity dam reinforced by structural
  supports
• a support that transmits a force from a roof or
  wall to another supporting structure
• Face is held up by a series of supports
• Flat or curved face

19
Buttress Dam
20
Embankment (Earth) Dam

• They are trapezoidal in shape
• Earth dams are constructed where the foundation
  or the underlying material or rocks are weak to
  support the masonry dam or where the suitable
  competent rocks are at greater depth.
• Earthen dams are relatively smaller in height and
  broad at the base
• They are mainly built with clay, sand and gravel,
  hence they are also known as Earth fill dam or
  Rock fill dam

21
Embankment (Earth) Dam
22
Scale of Hydropower

• Large-hydro- More than 100 MW feeding into a
  large electricity grid
• Medium-hydro -15 -100 MW usually feeding a grid
• Small-hydro -1 -15 MW -usually feeding into a
  grid
• Mini-hydro -Above 100 kW, but below 1 MW ,Either
  stand alone schemes or more often feeding into
  the grid
• Micro-hydro -From 5kW up to 100 kW Usually
  provided power for a small community or rural
  industryin remote areas away from the grid.
• Pico-hydro -From a few hundred watts up to 5kW
  Remote areas away from the grid

23
Type Of Turibine

• Impulse Turbines
• Pelton turbine
• Turgo turbine
• Michelle-Banki turbine
• Reaction Turbines
• Francis turbine
• Kaplan turbine
• Gorlov turbine

24
PELTON TURBINES

• Entrance elbow
• Injector
• Regulator
• Bun
• Blades or spoons.

25
How it Works?

• The Pelton turbines are used with high height
  jumps.
• The gravitational power energy of the water
  dammed becomes in kinetic energy.
• The injector throws the high speed water to the
  blades that are glued to the bun.
• The water spurt transmits its kinetic energy to
  the bun, where it is transformed instantaneously
  into mechanical energy.

26
PELTON TURBINES
27
KAPLAN TURBINES

• The turbines that take his name have
  revolutionized in these years the use of jumps of
  little height.
• The Kaplan turbines are water reaction turbines
  of axial flow, with a bun that works in similar
  way to the helix of a boat.
• The Kaplan turbine is a helix turbine in which
  the blades of the bun turn itself when it is on,
  adjusting automatically according the work to the
  conditions of optimal yield.

28
KAPLAN TURBINES
29
DERIAZ TURBINES

• Deriaz invented later the turbine that takes his
  name
• This turbine is reversible
• The price of the machinery is reduced using the
  same machine like pump and turbine.

30
DERIAZ TURBINES
31
FRANCIS TURBINES

• The Francis turbine is one of the reaction
  turbines
• The radial flow causes the turn of the runner
• This turbine is reversible
• Francis turbines may be designed for a wide range
  of heads and flows

32
FRANCIS TURBINES
33
Advantage

• Hydropowers fuel supply (flowing water) is clean a
  nd isrenewed yearly by snow and rainfall.
• hydro plants do not emit pollutants into the air
  because they burn no fuel.
• With growing concern over greenhouse gas emissions
   andincreased demand for electricity, hydropower m
  ay becomemore important in the future.
• Hydropower facilities offer a range of additional
  benefits.Many dams are used to control flooding
  and regulate water supply, and reservoirs provide
  lakes for recreational purposes,such as boating
  and fishing.
• Low operating and maintenance cost

34
Disadvantage

• Damming rivers may permanently alter river systems
   and wildlife habitats. Fish, for one, may no
  longer be able to swimupstream.
• Hydro plant operations may also affect water quali
  ty bychurning up dissolved metals that may have
  been deposited byindustry long ago.
• Hydropower operations may increase silting, change
   water temperatures, and lower the levels
  of dissolved oxygen.
• Degradation of upstream catchment areas due to
  inundation of reservoir area.
• High initial capital cost.

35
THANK YOU

• Hydropower is a renewable energy source
