Title: Portable Fire Extinguisher Safety


1
Portable Fire Extinguisher Safety
2
Emergency Procedures
3
Environmental Concerns
  • Restrooms
  • Breaks
  • Temperature
  • Visibility
  • Seating
  • Sound
  • Lighting

4
Portable Fire Extinguisher Safety
Learning Objectives
  • What fire is.
  • Extinguishing methods.
  • Classifications of fire.
  • Leading fire causes.
  • Fire prevention.
  • Importance of portable fire extinguishers.

5
Portable Fire Extinguisher Safety
Learning Objectives
  • Types of portable fire extinguishers.
  • Determine state of readiness.
  • Use of portable fire extinguishers.
  • When to use/not to use PFE.
  • Making a fight or flight decision.
  • Reporting an emergency.
  • Employer expectations.

6
Portable Fire Extinguisher Safety
What is it?
A by-product of combustion.
Combustion the self-sustaining process of
rapid oxidation of a fuel, which produces heat
and light.
Fire ... the result of a rapid combustion
reaction.
7
Portable Fire Extinguisher Safety
In order to have a fire you must have 4 things,
we call this the Fire Tetrahedron.
Extinguishment Theory To extinguish a fire
you must remove one side of the Fire Tetrahedron.
Chemical Chain Reaction
8
Portable Fire Extinguisher Safety
Extinguishment Theory
Temperature Reduction
Fuel Removal
Oxygen Dilution
Inhibit Chemical Chain Reaction
9
Portable Fire Extinguisher Safety
  • Classification of Fire
  • Class A or Ordinary Combustibles
  • This includes fuels such as wood,
  • paper, plastic, rubber,
  • and cloth.

Green Triangle
10
Portable Fire Extinguisher Safety
  • Classification of Fire
  • Class B or Flammable and
  • Combustible Liquids and Gases
  • This includes all hydrocarbon
  • and alcohol based liquids and
  • gases that will support
  • combustion.

Red Square
11
Portable Fire Extinguisher Safety
  • Classification of Fire
  • Class C or Electrical
  • This includes all fires involving
  • energized electrical equipment.

Blue Circle
12
Portable Fire Extinguisher Safety
D
Classification of Fire Class D or Combustible
Metals Examples of these types metals
are zirconium, titanium, potassium, and
magnesium.
Yellow Star
13
Portable Fire Extinguisher Safety
Classification of Fire Class K for fires in
unsaturated cooking oils in well insulated
cooking appliances in commercial kitchens.
14
Portable Fire Extinguisher Safety
Potential Fire Causes In The Workplace ?
Electricity Space Heaters
Housekeeping Improper storage Construction
Machinery Flammable Combustible
Liquids Cleaning supplies Smoking Materials
Any Ideas on Prevention ?
15
Portable Fire Extinguisher Safety
The importance of portable fire extinguishers?
Your first line of defense!
16
Portable Fire Extinguisher Safety
Now lets look at
  • Types.
  • Ready state.
  • When to use/not to use.
    Fight or Flight
  • How to use.
  • Reporting an emergency.
  • Expectation of use.

17
Portable Fire Extinguisher Safety
There are many types and many manufacturers.
18
Portable Fire Extinguisher Safety
There are many different types of extinguishing
agents.
19
Portable Fire Extinguisher Safety
Characteristics
Water extinguisher 30-40 ft. 60 sec.
Dry chemical 5-20 ft. 8-35 sec.
CO2 extinguisher 3-8 ft. 8-30 sec.
20
Monthly Quick-Check Is It Ready To Use ?
  • Located in designated place.
  • There is no obstruction to access or visibility.
  • Operating instructions on nameplate are legible
    and facing outward.
  • Safety seals and tamper indicators are not broken
    or missing.
  • Fullness should be determined by weighing or
    "hefting".
  • Examination for obvious physical damage,
    corrosion, leakage, or clogged nozzle.
  • Pressure gauge reading or indicator is in the
    operable range or position.

21
Portable Fire Extinguisher Safety
Making That Fight or Flight Decision
  • You are trained in the use of extinguishers.
  • You know what is burning.
  • Fire is not spreading rapidly.
  • You dont need Personal Protective Equipment.
  • Smoke and heat has not filled the area.
  • You have a clear path of escape.
  • Follow your instincts.

22
Portable Fire Extinguisher Safety
The P.A.S.S. Method
23
Portable Fire Extinguisher Safety
  • PULL the pin.
  • AIM at the base of the fire.
  • SQUEEZE the operating lever.
  • SWEEP from side to side.

24
Portable Fire Extinguisher Safety
Reporting an Emergency
  • Dont call from the building involved in the
    emergency.
  • Help others and activate fire alarm on the way
    out.
  • Notify emergency services via 911 call. Give at
    least
  • Your name.
  • Your location.
  • Call back phone number.
  • Describe the emergency.
  • Describe current conditions.
  • Describe any special hazards or needs,such as
    hazardous materials storage or non-ambulatory
    occupants.
  • Stay on the line, unless told to do otherwise.

25
Portable Fire Extinguisher Safety
The Employers Expectation of Use.
  • Designated personnel as part of
  • an emergency plan.
  • Only certain employees are required to use fire
    extinguishers.

26
Now, lets watch a video.
27
Portable Fire Extinguisher Safety
Learning Objectives review
  • What fire is.
  • Extinguishing methods.
  • Classifications of fire.
  • Leading fire causes.
  • Fire prevention.
  • Importance of portable fire extinguishers.

28
Portable Fire Extinguisher Safety
Learning Objectives review
  • Types of portable fire extinguishers.
  • Use of portable fire extinguishers.
  • When to use/not to use PFE.
  • Making a fight or flight decision.
  • Reporting an emergency.
  • Employer expectations.

29
Portable Fire Extinguisher Safety
Thank You For Your Time!
