Guardian Kernel Module

1
Guardian Kernel Module

• Sarah Diesburg
• Louis Brooks

2
Introduction

• Previous Work St. Michael
• Design Philosophy
• What we monitor
• System Call Mappings
• System Call Integrity
• Module Hiding (cloaking)
• Modifications to running modules

3
St. Michael

• Made for the 2.2 and 2.4 series of kernels.
• Not maintained now.
• Main purpose was to protect itself, the kernel,
  and the system call table from unauthorized
  modification.
• Could even reload the running kernel from a
  restore point if kernel compromised.

4
St. Michael (cont.)

• The functionalities of St. Michael include
• Monitoring pointers to system calls for any
  changes.
• The ability to cloak itself from the running
  kernel and commands like lsmod.
• Monitoring the loading and unloading of modules
  to make sure other modules do not cloak
  themselves.

5
Kernels System Call Table
System Call Table
system call 0
system call 1
system call 2
system call 3
system call n
6
System Call Mappings

• Initialization
• We make a copy of the system call table
• Timer
• Twice every second, we compare the kernels
  system call table of pointers with our own.
• If there are discrepancies, we replace the
  kernels system call table with our own.

7
System Call Integrity

• Initialization
• We take and store md5 sums of kernels system
  calls.
• Timer
• Twice every second we take new md5 sums of the
  kernels system calls and compare them with our
  own.
• If there is a discrepancy, we point the kernel to
  a null system call until reboot.

8
How modules are loaded into the 2.6 Kernel

• insmod calls module_init
• passes information regarding module to load
• module_init
• calls module_load
• uses copy_from_user to pull module into kernel
  space
• creates the new module and returns a pointer to
  module for use by module_init

9
Kernel Module List
list_head
list_head
list_head
Module
Module
list_head
list_head
Module
Module
10
Module Monitoring

• Done in three phases
• Module List Created at GKM init
• Module init/delete
• Wrapper functions for module_init module_delete
• Changes to module loading from 2.4 to 2.6
• removed syscalls module_create and module_query
• no pointer to new module available
• Access kernel module list through pointer to
  THIS_MODULE when GKM is initialized
• Timer
• Check kernel module list and MD5 sums against
  GKMs internal list created at init

11
Module Monitoring (cont.)

• gkm_syscall_init_module
• Calls Kernels original module_init syscall
• returns 0 on success
• Calls gkm_add_mod_list
• checks for cloaked modules
• creates md5 sums
• adds module to GKM module list

12
Module Monitoring (cont.)

• gkm_syscall_delete_module
• Checks if GKM is module to be unloaded
• returns EBUSY if true
• Calls Kernels original module_delete syscall
• returns 0 on success
• Calls gkm_delete_mod_list
• delete module form list

13
Starting GKM

• Jun 15 153718 localhost kernel GKM
  Initializing Guardian Kernel Module
• Jun 15 153718 localhost kernel GKM Guardian
  Kernel Module Loaded

14
System Call Replacement Test

• Jun 15 153819 localhost kernel GKM module
  system_call_replacement detected and loaded.
• Jun 15 153819 localhost kernel GKM Found
  inconsistency in system call table!
• Jun 15 153819 localhost kernel GKM System
  call mapping restored.

15
System Call Overwrite Test

• Jun 15 154942 localhost kernel About to
  overwrite chdir at address c0159050
• Jun 15 154942 localhost kernel GKM module
  system_call_overwrite detected and loaded.
• Jun 15 154942 localhost kernel GKM System
  call number 12 has been compromised!
• Jun 15 154942 localhost kernel GKM Please
  look in unistd.h for the corresponding system
  call.
• Jun 15 154942 localhost kernel GKM System
  call number 12 has been replaced with a null
  system call.
• Jun 15 154942 localhost kernel GKM Please
  take appropriate action and reboot soon.

16
Module Cloaking Test

• Jun 15 160312 localhost kernel I'm still
  here...
• Jun 15 160312 localhost kernel GKM Cloaked
  module inserted into system!
• Jun 15 160312 localhost kernel GKM Please
  take appropriate action and reboot soon.

17
Module Overwrite Test

• Jun 15 160333 localhost kernel GKM module
  module_overwrite detected and loaded.
• Jun 15 160333 localhost kernel GKM Bad exit
  checksum for hello
• Jun 15 160333 localhost kernel GKM Please
  take appropriate action and reboot soon.

18
Conclusion

• Whats next?
• Sourceforge or Freshmeat
• Questions?
