Title: Aerial Lifts


1
Aerial Lifts Other Elevating Platforms
Chuck Northam www.safetyresourcesllc.com

2
Federal OSHA Regulations
  • 29CFR1926.453 Subpart L, Aerial Lifts
  • 29CFR1910.67 Subpart F
  • Vehicle-Mounted Elevating Rotating Work
    Platforms
  • 29CFR1910.333 Subpart S

3
ANSI Standards
  • ANSI/SIA A92.2-2001 Manual of
  • Responsibilities for Dealers, Owners, Users,
  • Operators, Lessors, and Lessees of Vehicle-
  • Mounted Elevating and Rotating Aerial Devices.
  • ANSI/SIA A92.3-1990, Manually Propelled
  • Elevating Aerial Platforms
  • ANSI/SIA A92.6-1999, Self-Propelled
  • Elevating Work Platforms
  • ANSI/SIA A92.7-1998, Airline Ground
  • Support Vehicle-Mounted Vertical Lift Devices
  • ANSI/SIA A92.8-1993 (reaffirmed 1998),
  • Vehicle-Mounted Bridge Inspection and
  • Maintenance Devices

4
Federal OSHA Exemptions
  • Remember This section does not apply to fire
    fighting equipment

5
Definitions
  • Aerial Device Any vehicle mounted or self
    propelled device, telescoping extensible or
    articulation, or both, which are designed to
    position personnel.
  • Articulation Boom An aerial device with two
    or more hinged boom sections.
  • Aerial Ladder An aerial device consisting of a
    single or multiple section extensible
    ladder.
  • Boom An elevating member the lower end of
    which is attached to a rotating or
    non- rotating base that permits elevation of
    the free or outer end.

6
Definitions - cont.
  • Elevating Work Platform A device designed to
    elevate a platform in a substantially
    vertical axis (vertical tower, scissor
    lift).
  • Extensible Boom Platform An aerial device with
    an extensible boom. Telescopic booms
    with personnel platforms
    attachments shall be considered to be
    extensible boom platforms
  • Vertical Tower An aerial device designed to
    elevate a platform in a
    substantially vertical axis.

7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Work Environment Considerations
  • Location of the work
  • Inside or outside
  • Enough room
  • Gas, propane, diesel, electric or manually
    powered
  • Operating Terrain
  • Hard or soft tires
  • Maximum height required
  • Weight capacity needed
  • Fall protection needed
  • Energized lines or equipment present

18
Manufactures Requirements
  • An operations manual is required
  • Manual must cover maintenance
  • An identification plate that includes
  • Make, model and I.D.
  • Rated capacity
  • Maximum travel height
  • Maximum operating pressure of
    hydraulic/pneumatic system
  • Rated line voltage
  • Cautions /or restrictions

19
Training
  • OSHA requires that all Operators be trained for
    the aerial device they are using (Qualified
    Operator). This training is to be documented,
    retained and available.

20
Training
21
General Requirements
  • Guardrails 42 inches high required on all
    sides. Where a guardrail is less than 42 inches
    high personal fall protection is required.
  • A midrail and toeboards are required on all
    sides.
  • No one can sit or stand on the guardrails.
  • Securing to an adjacent pole, structure or
    other equipment is prohibited.
  • Putting a scaffold, ladder, box, bucket,
    planks, etc. to increase the height of a platform
    is prohibited.
  • Aerial devices can not be leaned upon
    buildings, structures, or other equipment.

22
General Requirements - cont.
  • Articulating boom and extensible boom
    platforms, primarily designed as personnel
    carriers shall have both platform (upper) and
    lower controls.
  • Vehicles must be inspected prior to use and
    annually (ANSI Standard Requirement).

23
Elevated Platform Traveling Requirements
  • A worker can ride an aerial device in an
    elevated position when permitted by the
    manufacturer and the following conditions are met
  • Travel speed does not exceed three (3) feet per
    second
  • Units that have maximum travel height shall
    have an interlock to prohibit movement.
  • Surface is level with no hazards or
    accumulation of debris

24
Aerial Devices Around Energized Equipment or Line
  • Near energized lines/equipment aerial devices
    shall be grounded or barricaded and considered as
    energized equipment, or the aerial device shall
    be insulated for the voltage exposure.
  • Insulating booms of aerial devices used for
    work on energized high voltage conductors and
    equipment shall have a dielectric test performed
    every 12 months (ANSI regulation)
  • Equipment, materials, or tools shall not be
    passed between a pole or structure and an aerial
    device while a worker from the aerial device is
    in reaching distance of unprotected energized
    equipment/lines.

25
CFR 1910.333 Table S-5  Approach Distances for
Qualified Employees                    -- Alterna
ting Current ----------------------------------
---------------------------- Voltage range
      Minimum approach
                  distance            ----------
-------------------------------------------------
--- 300V and less.................
Avoid contact.                 Over 300V, not ove
r 750V.      1 ft. 0 in. (30.5 cm).        Ove
r 750V, not over 2kV.
1 ft. 6 in. (46 cm).          Over 2kV, not over
15kV.        2 ft. 0 in (61 cm).           Ove
r 15kV, not over 37kV.       3 ft. 0 in. (91 cm)
.          Over 37kV, not over 87.5kV.
3 ft. 6 in. (107 cm).        Over 87.5kV, not ove
r 121kV.    4 ft. 0 in. (122 cm).        Over 121
kV, not over 140kV.     4 ft. 6 in. (137 cm).
   ----------------------------------------------
---------------
26
Genie Lift
27
Compliant??
28
Retractable handrails results in personal fall
protection needed...
29
Hard tire scissor lift...
30
Aerial lift with power platform extension
31
Remove material debris from lift platform
32
Damaged equipment is to be repaired.
33
Why is a compressed gas cylinder and hot work
dangerous on an aerial lift?
34
Rough-Terrain Boom lift.
35
Another Type of Boom Lift
36
Whats missing?
37
Elevator OK??
38
Articulating Boom lift.
39
Instructions warnings on a boom lift
40
Not Even Close.
41
Only use equipment for its intended design
42
Questions??
