Title: More Distributed Garbage Collection DC4


1
More Distributed Garbage CollectionDC4
  • Reference Listing
  • Distributed Mark and Sweep
  • Tracing in Groups

2
Reference Listing
  • Idea have the skeleton keep track of the
    processes which reference it. Skeleton must keep
    more information, but references can be verified.
  • Concept Idempotent operations adding a proxy
    (process) to a RL when the proxy is already in
    the RL is idempotent. Deleting a proxy that is
    not in the RL is idempotent. Thus these
    operations can be done multiple times without
    harm.
  • So detection of duplicates in messaging can be
    relaxed. (Could still be a problem if P1
    createsdeletescreates in quick succession.)
  • Java RMI does this.

3
Reference Listing(2)
  • In Reference Listing, if P1 wants to create a
    reference to object O
  • (1) P1 sends its ID to the skeleton for O.
  • (2) Os skeleton adds P1 to the RL and acks P1.
  • (3) When P1 gets ack, it creates proxy for O.

RL
P1
4
Reference Listing (3)
  • If P1 wants to copy the reference for P2
  • (1) P1 sends reference info about O to P2.
  • (2) P2 sends message to Os skeleton requesting
    add to RL.
  • (3) Skeleton for O adds P2 and acks P2.
  • (4) When P2 gets ack, it can install proxy.

RL
P1
5
Reference Listing (4)
  • If P1 wants to pass its reference to P2 (and
    delete its own) the process is the same, except
    there can be problem (race condition) if delete
    request from P1 arrives at O before add request
    from P2 gets there.
  • Soln P1 must wait for ack from P2 that process
    is complete before requesting delete.

RL
P1
6
Reference Listing
  • Advantage RL can be checked in case of failure
    or suspected failures O just pings the processes
    in its RL (cant be done with just counts).
  • Disadvantage extra comm costs to handle race
    condition. The RLs can get long use a lot of
    memory, therefore, does not scale well.
  • Solution to scalability Many of those processes
    on the long RL dont really need the reference
    anymore, so encourage processes to get off the
    list when not needed Skeleton registers
    references for a specific time period. This is
    called a LEASE and the concept is used in many
    situations.

7
Unreachable Objects section 4.3.4
  • Previous algorithms deal with unreferenced
    objects, but objects may be referenced but only
    by other unreachable objects.
  • Problem Objects that reference each other but
    none of them are reachable from the root set
    ie, valid users and processes. (zombie process
    problem).

8
Trace Based Garbage Collection
  • Idea Check which entities can be reached from
    the root set (by tracing from the root set) and
    remove all others.
  • Centralized solution is Mark and Sweep.
  • Mark all objects white
  • Trace pointers starting at the root set. Gray
    indicates in-process.
  • Mark black all objects reachable from root set.
  • When finished, delete white objects.

9
Distributed Mark and Sweep (1)
  • 1. Each process runs local GC. Initially all
    proxies, skeletons and objects are marked white.
  • 2. Objects at node P reachable from a root at P
    are marked gray. When an object is marked gray,
    its skeleton and all proxies in it are marked
    gray (objects containing pointers or references
    are our concern).
  • 3. When a proxy is marked gray, a message is sent
    to the associated skeleton to mark itself gray.
  • 4. All objects whose skeletons are gray are
    marked gray.

Root set
10
Distributed Mark and Sweep (2)
  • 5. Whenever an object and its skeleton are gray
    and all proxies in the object have informed their
    skeletons, the object becomes black and a message
    is sent (backwards) to its associated proxies
    that it is now black. (this requires that a
    skeleton can contact the proxies which reference
    it.)

6. When a proxy receives a message that its
associated skeleton is black, it turns
black. 7. Mark phase ends when all proxies,
skeletons and objects are either white or
black. White objects can then be removed (and
skeleton and proxies within the object).
Disadvantage reachability graph must remain
unchanged during algorithm.
Root set
11
Tracing in Groups (1)
  • To address scalability issues, introduce
    tracing-in-groups. A group is a collection of
    processes, that may or may not be on the same
    node (all processes on the same node might be in
    the same group or all processes running the
    same application thus using the same objects).
  • First, collect all garbage within the group, then
    combine groups that have been internally cleaned.
  • The skeleton maintains a reference counter RC
    which counts the number of associated processes.
  • Assumption a process has no more than one proxy
    for each distributed object.

12
Tracing in Groups (2)
  • A skeleton can be marked soft or hard. A soft
    skeleton is reachable only from proxies within
    the group. A hard skeleton is reachable from a
    proxy outside the group or from a root set object
    within the group. The marking of a skeleton can
    only change from soft to hard, that is, once a
    skeleton is hard, it cannot be changed to soft.

H
S
S
Root set
13
Tracing in Groups (3)
  • A proxy can be hard, soft, or none. A proxy that
    is hard is reachable from an object in the root
    set. A soft proxy is reachable from a skeleton
    that is marked soft and is potentially not
    reachable from the root set. None means it is
    neither reachable from a soft skeleton nor an
    object in the root set at this time. Proxies can
    only harden none can be changed to soft or hard,
    soft can change to hard. (Book is wrong) Note
    that a reachable proxy from a skeleton means the
    proxy is within the object of the skeleton.

H
H
S
S
S
S
Root set
14
Tracing in Groups(4) the Algorithm
  • Step 1 Mark skeletons soft or hard as follows
    Look at reference counter for O. Say count is R.
    Count processes in the group that have proxies
    that refer to object O. If number of proxies is
    R, mark skeleton soft, since it is referred to
    only by proxies in the group. Else, there is a
    reference from outside the group, so mark the
    skeleton HARD.

S
H
S
S
S
Root set or out of group
15
Tracing in Groups(5) the Algorithm
  • 2 Each process in the group propagates marks
    from skeletons to other proxies in the same
    process or object. (process may contain objects
    and proxies). Initially all proxies are labeled
    none. Trace from skeletons marked hard as well
    as from the root set. Hard marks are propagated
    to all objects and proxies within the process
    that are reachable from the hard set.

Now trace the skeletons marked soft. A proxy
that was none can change to soft. A hard proxy
does not change.
S
H
H
S
S
S
S
S
S
Root set or out of group
16
Tracing in Groups(6) the Algorithm
  • 3 Propagate HARD marks from proxies to their
    skeletons in other processes within the group.
    Soft marks do not propagate.
  • Repeat step 2 and 3 if some skeleton changed from
    SOFT to HARD.

Garbage Collect SOFT proxies and their skeletons
and objects. Combine some groups and start over.
H
H
H
S
S
S
S
S
S
Root set or out of group
17
Tracing in Groups (7)
  • Initial marking of skeletons.

18
Tracing in Groups (8)
  • After local propagation in each process.

19
Tracing in Groups (9)
  • Final marking.
