1. dia

1
GRABO indoor sport flooring
GRABOPLAST ZRT.H-9023 GyorFehérvári út
16/b.HUNGARYtel. 36 96 506 100
2
Graboplast 100 years of experience

Graboplast is the leading interior designer
manufacturer in Central Europe. The Company has
celebrated its 100 Years Anniversary in 2005,
which appoints Graboplast as a solid and reliable
partner in our fast changing world. Our main
products are floorcoverings, although the company
was founded for artificial leather production in
1905. We have been always trying to accommodate
our activity to the market trends. We are
present with our products in more than 60
countries all around the world. We focus our
sales on a wide range of different
target-oriented floorcovering materials
transport floorings, sport floorings, special
floorcoverings, CV floorings, wooden parquets and
wallcoverings.
3
Graboplast At the beginnings
4
Graboplast 100 years of experience

Our growth factors

• High quality and cost effective production
• Latest technology on main products, which is a
  key factor in keeping us in the forefront of the
  market
• Traditionally innovative and professional R D
  team, which can secure and improve our
  competitiveness
• Tailor-made services and design development
• Long term relationship with distributors

5
Production places/products
Residential PVC flooring
Show flooring
Transport flooring
Engineered wood parquet
Sport flooring
Heterogeneous commercial flooring
6
Breakdown by product segments
2007 73 million Euro
2009 52 million Euro
Sport flooring 14
7
Reliable quality
INDEPENDENT AUDITING ORGANISATION comfirmed
that the quality certificate system ofthe
companies meets the requirements of ISO
90012001 ISO 140012004
8
The ultimate flooring, the ultimate performance
Grabo sport flooring products
9
Product segments
Sport floorings - Excellent sport and protective
functions - Long life expectancy - Wide range of
products and designs - Easy to install -
Competitive prices
Sport flooring systems - Professional sport
performance - Genuine joint and cartilage
protection also in long term use

• Specialities
• - Dance floor
• - Gymnastic mat for yoga and rehabilitation
• Protective cover
• Moisture barrier
• - Accessories

10
1) Sport floorings main properties

• Wide range
• from competition halls to home gym rooms
• floorings from 2,0 mm to 8,0 mm

• Enviromentally sound products
• no polish required reduced energy consuption
• easy to clean less cleaning agents
• extended lifespan and reduced maintenance
  requriment result less enviromental impact and
  reduced life cycle cost
• no harmful materials free from solvents and
  heavy metals

11
1) Sport floorings main properties

• Easy installation
• available in rolls easy and quick laying
• 2 m wide rolls less welding
• Weldable both by hot and cold
• High durability but light weight and flexibility

• Reliability
• More than 100 year old company
• 30 years of experience in sport floorings
  production
• Up to 15 years of warranty

12
1) Sport floorings Innovative surfaces

• TECH Surface
• A revolutionary new wear layer hardened by
  Grabo patented procedure. Due to its special
  composition (PUR Al2O3) it provides high
  durability and easy to clean properties.
• Main features
• Long life expectancy
• TECH Surface wear layer contains micronised
  Al2O3 particles, which increases its abrasion
  resistance.
• Easy maintenance
• PUR provides easy to clean properties, and you
  can reduced the maintenance costs.
• Excellent chemical resistance
• Can be cleaned with ordinary cleaning agents
  without any problems.

What is TECH Surface?
13
1) Sport floorings Innovative surfaces

• PUR Surface
• Our Gymfit series have got a protective
  polyurethane (PUR) surface treatment.
• That contributes to the attractive look of these
  floorings and simplifies their cleaning and
  maintenance due to
• continous, dirt resistant surface,
• optimal surface tension that helps to remove the
  dust and dirt and to keep the flooring clean.

14
1) Sport floorings Innovative surfaces

• CLP
• What is TECH Surface?
• A revolutionary new wear layer hardened by Grabo
  patented procedure.
• Main features
• Long life expectancy
• TECH Surface wear layer contains micronised
  Al2O3 particles, which increases its abrasion
  resistance.
• Easy maintenance
• PUR provides easy to clean properties, and you
  can reduced the maintenance costs.
• Excellent chemical resistance
• Can be cleaned with ordinary cleaning agents
  without any problems.

15
1) Sport floorings Innovative surfaces
16
Excellent safety and comfort
Extreme 80, Supreme 67, Elite 60
Multisport floorings, for every type of ball
games (handball, basketball, volleyball, futsal,
floorball), for every level of competition
Features

• PUR reinforced wear layer and micronised Al2O3
  particles long life expectancy, easy to clean
• Glass fibre mesh in the middle layer
  outstanding dimensional stability, flexible and
  durable construction
• Combined double-foam backing high shock
  absorption, optimised vertical deformation,
  efficient joint protection, good footcomfort
• Coating technology no delamination at all

Meets the requirements of EN 14904 norm
Extreme Supreme Elite
Requirement Force reduction (EN
14904) DIN 18032 37 36
31 EN 14808 34
33 28 25-75 Vertical deform.
1,2 mm 0,8 mm 1,1 mm lt5mm Ball
rebound 98 99 97
min 90 Gloss lt30
lt30 lt30 lt30 Abrasion
lt250 mg lt250mg lt250mg lt1000mg Slip
resistance 0,4-0,7 0,4-0,7 0,4-0,7
0.4-0.7
15 years of warranty
17
Robust and durable
Gymfit 60, Gymfit 44, Gymfit 25
For schools and fitness halls
Features

• PUR Surface wear layer increased cleanability,
  higher wear resistancy and easier to maintain
• Glass fibre reinforced middle layer
  dimensionally stable and flexible
• Density foam backing optimised indentation and
  comfort
• Protection against accidents raised by sliding
  or sticking

10 years of warranty
18
Definitely for badminton and table tennis
Rocket
Suitable for competitions as well as trainings
Features

• CLP wear layer durability
• Glass fibre reinforced middle layer
  dimensional stability
• Light weight and stability - also for portable
  courts
• Quick turn and optimised indentation due to
  the single foam backing
• Protection against accidents raised by sliding
  or sticking

19
graboflex Start
For school and kindergarten
Features

• CLP wear layer durability
• Glass fibre reinforced middle layer
  dimensional stability
• Light weight and stability - also for portable
  courts
• Quick turn and optimised indentation due to
  the single foam backing
• Protection against accidents raised by sliding
  or sticking

20
Highly durable but flexible
Stamina
For fitness halls
Features

• PUR reinforced wear layer and micronised Al2O3
  particles with the patented TECH surface
  technology long life expectancy
• Glass fibre reinforcement dimensionally stable
  and flexible
• Compact backing very low indentation
• Protection against accidents raised by sliding
  or sticking
• It can be used also on subfloor

21
Sport floorings the range
6,0 mm
Thickness (mm)
Elite 60
Gymfit 60
Cardio training, martial arts
Badminton, table tennis
Schools, Kindergarten
Competition
Universities, city sport halls
Aerobic/Gymnastic
Body building
22
Sport floorings the range
6,0 mm
Thickness (mm)
Elite 60
Gymfit 60
23
Sport floorings - installation

• - Normal subflor requirements (clear, smooth,
  dry, free from cracks and anti-adhesion
  substances)
• - The flooring should be conditioned 1 day
  before laying down
• In case of absorbent subfloor water dispersion
  adhesive
• In case of non-absorbent subfloor contact
  adhesive
• Heat or cold welding

24
CLEANING MAINTENANCE

• 1.) Basic cleaning
• Removal of solid soiling by sweeping or
  vacuum-cleaning
• Removal of stubborn, sticky soiling
• Tools - strong alkaline basic cleaner (pH 13-14)
• - one-disc scrubbing machine,
• - water vacuum cleaner (stick scrubber and
  floor stripper)
• Method spread the solution in an area of 5-10
  sq. meters, scrub, rinse, then wipe off with
  plenty of clean water and rinse again
  (neutralising).
• The frequency of basic care depends on the
  intensity of use. Recommended period 1/2-1 year.

25
CLEANING MAINTENANCE

• 2.) Daily cleaning
• Removal of solid soiling with sweeping or
  vacuum-cleaning
• Wet cleaning, which can be made manually or by
  machine
• Manual wet cleaning
• For daily cleaning a mop, a mop-holder and
  detergent (pH 8-9) are required.
• Cleaning should be made by two-can-technology.
• Daily cleaning by machine
• For daily care of the sport flooring, a pusher-
  or driver-type automatic cleaning machine can be
  used. It is recommended to use detergent (pH
  9-10), containing non-ionic or cationic
  surfactants to ensure excellent cleaning
  performance and to preserve the original slip
  properties.

26
2) Sport flooring systems
- Professional sport performance - Genuine
joint and cartilage protection also in long term
use
27
Efficient protection for the future
grabo SMART system
Benefits

• Absorbs the maximum impact force within 0,03
  seconds Efficient joint and cartilage
  protection
• Uniform performance in each and every point of
  the sports ground
• Reacts not only to big impacts Genuine
  protection for junior athletes as well
• Costumized configuration One can chose the
  most suitable flooring
• Easy and quick installation

28
grabo SMART system
grabo Vaporex protects the system against
moisture
29
grabo SMART system

• Protectsport ideiglenes védoburkolat kulturális
  vagy kereskedelmi rendezvények esetén
• graboSport burkolat igényszinttol függoen
  választható
• grabo SMART underlay is made up of two main
  parts
• SMART shield decrease of the chance of
  ankle-sprain
• SMART foam despite the high level of energy
  absortion the structure is properly flexible
• grabo Vaporex protects the system against
  moisture

30
grabo SMART system

• ideiglenes védoburkolat kulturális vagy
  kereskedelmi rendezvények esetén
• graboSport flooring depending on the
  requirements and budget
• grabo SMART underlay is made up of two main
  parts
• SMART shield decrease of the chance of
  ankle-sprain
• SMART foam despite the high level of energy
  absortion the structure is properly flexible
• grabo Vaporex protects the system against
  moisture

31
grabo SMART system

• Protectsport temporary protective covering
  during any events in the hall to protect the
  surface vagy kereskedelmi rendezvények esetén
• graboSport flooring depending on the
  requirements and budget
• grabo SMART underlay is made up of two main
  parts
• SMART shield decrease of the chance of
  ankle-sprain
• SMART foam despite the high level of energy
  absortion the structure is properly flexible
• grabo Vaporex protects the system against
  moisture

32
3) Specialities
- Dance floor - Gymnastic mat for yoga and
rehabilitation - Protective cover - Moisture
barrier - Accessories
33
Specialities
Broadway 17

• Main features
• Compact structure
• Dimensionally stable
• Both sides can be used
• Gluing is not necessary
• For tv studios, show rooms, etc.

34
Specialities

• Main features
• Moisture barrier under any Grabo floorings used
  for sport or commercial applications
• By using this, installation time can be shortened
• Dimensionally stable

grabo Vaporex

• Main features
• Temporary floor
• Easy to roll up and down
• Protects the sport floor during non-sportive
  events

Protectsport
35
Accessories
graboWeld
grabo Color

• Main features
• Welding rod for hot welding
• Diameter 4,5 mm
• Cross-section circle
• In various colors matching to sport floorings

• Main features
• Two-component polyurethane line marking paint
• Application is recommended by brush or by spray
  gun in two coats
• About 1 litre for 100 m line

36
The ultimate flooring, the ultimate performance
Indoor sport floorings - summary

• Experienced producer with reliable quality
  products for indoor sport activities
• Wide range of products, solutions for
  competition, training and leisure
• moisture barrier
• flexible subfloor
• sport floorings (thickness 2-8 mm)
• protective covering
• accessories
• Solvent free production technology
• Easy installation and maintenance
• Innovative R D team
• Tailor-made service

• 30 years of experience in sport floorings
  production
• World-wide distribution, covering 38 countries
• Extensive, continuous growing of year by year
• 700 000 people is testing our sport floorings,
  every day
