Title: Communication in Distributed Systems


1
Communication in Distributed Systems
2
  • Communication in Distributed Systems based on
    low level message passing offered by underlying
    network
  • Three popular models of communication
  • Remote Procedure Calls (RPC)
  • Message-oriented Middleware (MOM)
  • Data Streaming, discussion of SCTP, 3GPP
  • Sending data to multiple receivers or Multicasting

3
  • Interprocess Communication is part of the
    Client/Server Computing Model
  • A client is an application or a process that
    requests a service from some other application or
    process.
  • A server is an application or a process that
    responds to a client request.
  • Both client/server applications perform
    specialized functions in a distributed computing
    environment.
  • Intraprocess communication used between
    homogeneous systems. Example using named pipes,
    named queues, shared memory etc
  • Focus of this presentation is Interprocess
    Communication

4
  • In between the end users and large pool of
    computing resources, many applications act as
    both a client and a server, depending on the
    situation.
  • Interprocess communication is necessary to
    communicate between heterogeneous systems
  • Protocols govern the format, contents and meaning
    of messages

5
  • Two main types of Protocols
  • Connection-oriented Sender and receiver
    establish a connection and negotiate the protocol
    to use before exchanging data. At the end of
    commiunication, terminate or release the
    connection. An example TCP
  • Connectionless No connection is set up in
    advance. Sender transmits message when ready. An
    example UDP

6
  • Main differences between connection-oriented and
    connectionless protocols
  • Connection-oriented is reliable, while the other
    is not.
  • Connection-oriented is fully duplex
  • Connection-oriented is byte-stream service with
    no structure
  • Error checking an essential component of
    unreliable connectionless protocol
  • Connectionless protocol transfers packets of data
    and uses a protocol port address to specify
    receiver process

7
(No Transcript)
8
  • Lower-Level Protocols
  • Implemented in physical layer and data link layer
    of the stack. Groups data bits into frames and
    adds a pattern called checksum at either end of
    frame
  • Network layer chooses best path from sender to
    receiver by routing
  • Transport Protocols
  • TCP
  • UDP
  • Higher Level Protocols
  • FTP
  • HTTP

9
  • Middleware Protocols
  • Examples are Authentication and Authorization
    protocols, commit protocols in transaction
    databases
  • Middleware protocols support high level
    communication services
  • Protocols that allow a process to call a
    procedure or invoke an object on a remote machine
    transparently. An example RPC/RMI
  • Protocols that support the setting up and
    synchronizing of streams for transferring
    real-time data such as multimedia applications.
    An example SCTP
  • Protocols that support reliable multicast
    services to a WAN

10
Protocol Stack
Application Protocol
Application
6
Middleware
Middleware Protocol
5
Transport Protocol
Transport
4
Network Protocol
Network
3
Data Link Protocol
2
Data Link
Physical Protocol
1
Physical
Network
11
  • Types of Communication
  • Persistent communication Message submitted for
    transmission stored by communication middleware
    as long as it takes to deliver it to the
    receiver. Neither sending application nor
    receiving application need to be executing.
  • Transient communication Message stored by
    communication system only as long as sending and
    receiving application are executing.
  • Asynchronous communication Sender continues
    immediately after submitting message for
    transmission. Message temporarily stored by
    middleware on submission.
  • Synchronous communication Sender blocks until
    message received and processed and receiver
    returns acknowledgement.

12
  • Remote Procedure Calls
  • Remote procedure calls can simplify the way IPCs
    are conducted through the network.
  • Client applications use the client side network
    API to call RPCs.
  • Server side of the network API turns the RPCs
    into local function calls.
  • Return value being transmitted back to the client
    application again through the network.
  • The OSI layers are transparent to the client
    application, as if it is making a local function
    call.
  • The RPC provided by Windows enable applications
    that use RPC to communicate with applications
    running with other operating systems that support
    DCE (Distributed Computing Environment). RPC
    automatically supports data conversion to
    account for different hardware architectures and
    for byte-ordering between dissimilar
    environments.

13
  • Synchronous RPC Operation
  • Process on machine A calls procedure on machine
    B, the calling process on A is suspended and
    execution of the called procedure takes place on
    B.
  • Information is transported from caller to callee
    in the parameters and comes back in the procedure
    result
  • No message passing visible to programmer
  • Client and Server stubs are used
  • Client stub takes its parameters and packs them
    into a message (parameter marshalling) and sends
    them to the server stub

14
  • Parameter Passing
  • Passing Value Parameters
  • Client stub takes parameters and puts them in the
    message. It also puts the name or number of the
    procedure to be called in the message
  • When message arrives at server, server stub
    examines the message to see which procedure is
    needed and then makes appropriate call. Stub
    takes the result and packs it into a message.
    Message is sent back to client stub.
  • Client stub unpacks the message to extract the
    result and returns it to waiting client procedure

15
  • Passing Reference Parameters
  • Pointers and references passed by copying the
    data structure such as array into message and
    sent to server
  • Server stub calls server with a pointer to this
    array
  • Server makes changes using this pointer that also
    affects the message buffer inside server stub
  • Server finishes its work, original message sent
    back to client stub which copies it back to the
    client. This is similar to copy/restore.

16
  • Asynchronous RPC
  • Client continues immediately after issuing RPC
    request and receiving acknowledgement from
    server, it is not blocked.
  • Server sends immediately a reply or
    acknowledgement to the client the moment RPC
    request is received
  • Server then calls requested procedure
  • One-way RPC Client does not wait for even an
    acknowledgement from server. Reliability not
    guaranteed as client has no acknowledgement from
    server.
  • Deferred synchronous RPC is a combination of two
    asynchronous RPCs, where client polls the server
    periodically to see whether results are available
    yet rather than server calling back the client.

17
  • Message-Oriented Communication
  • RPC assumes that receiver process is executing at
    the time a request is issued
  • Message-oriented communication such as
    message-queuing systems is therefore needed to
    allow processes to exchange information even if
    one party is not executing at the time the
    communication is initiated.
  • Message-oriented-model (MOM) offered by transport
    layer, as part of middleware solution

18
  • Berkeley Sockets
  • Sockets interface introduced in 1970s in Berkeley
    Unix
  • Standardizes the interface of the transport layer
    to allow programmers the use of messaging
    protocols through simple set of primitives
  • Another interface XTI stands for X/Open Transport
    Interface, also formerly called Transport Layer
    Interface (TLI) developed by ATT
  • Sockets and XTI similar in their model of network
    programming but differ in their set of primitives
  • Socket forms an abstraction over the
    communication end point to which an application
    can write data that are sent over the underlying
    network and from which incoming data can be read.
  • Servers execute the first four primitives in
    table
  • When calling the socket primitive, the caller
    creates a new communication end point for a
    specific transport protocol. Internally, the OS
    reserves resources to accommodate sending and
    receiving messages for the specific protocol.

19
  • Bind primitive associates a local address with a
    newly-created socket. For example, server should
    bind the IP address of its machine together with
    a known port to a socket
  • Binding tells the OS that the server wants to
    receive messages only on the specified address
    and port
  • Listen primitive is called only in the case of
    connection-oriented communication. It is a
    nonblocking call that allows the local OS to
    reserve enough buffers for a specified of
    connections that the caller is willing to accept
  • A call to accept primitive blocks the caller
    until a connection request arrives. When the
    request arrives, the local OS creates a new
    socket with same properties as the original one
    and returns it to caller. Server can wait for
    another connection request on the original socket
  • Connect primitive on client requires that the
    caller specifies the transport level address to
    which a connection request is to be sent
  • Client is blocked until a connection is set up,
    after which info can be exchanged using
    send/receive
  • Closing the connection is symmetric as both
    server and client call the close primitive

20
Primitive Meaning
Socket Create a new communication end point
Bind Attach a local address to a socket
Listen Announce willingness to accept connections
Accept Block caller until connection request arrives
Connect Actively attempt to establish a connection
Send Send some data over the connection
Receive Receive some data over the connection
Close Release the connection
21
  • Message-Passing Interface
  • A standard defined for message passing
  • Hardware and platform independent
  • Designed for parallel applications and transient
    communication.
  • Makes use of underlying network

22
  • Assumes that serious failures such as process
    crashes or network partitions are fatal and do
    not require automatic recovery
  • MPI assumes communication takes place within a
    known group of processes
  • Each group is assigned an identifier
  • Each process within a group is also assigned a
    local identifier
  • A (groupID, processID) pair uniquely identifies
    the source or destination of a message, and is
    used instead of a transport-level address
  • Several possibly overlapping groups of processes
    involved in a computation, executing at the same
    time
  • MPI has messaging primitives to support transient
    communication shown in next table

23
Primitive Meaning
MPI_bsend Append outgoing message to a local send buffer
MPI_send Send a message and wait until copied to local or remote buffer
MPI_ssend Send a message and wait until receipt starts
MPI_sendrecv Send a message and wait for reply
MPI_isend Pass reference to outgoing message, and continue
MPI_issend Pass reference to outgoing message, and wait until receipt starts
MPI_recv Receive a message block if there is none
MPI_irecv Check if there is an incoming message, but do not block
24
  • Transient asynchronous communication is supported
    by MPI_bsend primitive
  • Sender submits a message for transmission which
    is copied to a local buffer in MPI runtime
    system. Sender continues after message is copied.
    Local MPI runtime system will remove the message
    from its local buffer and transmit as soon as a
    receiver has called a receive primitive
  • MPI_send is a blocking send operation with
    implementation dependent semantics
  • It may either block the caller until the
    specified message has been copied to the MPI
    runtime system at the senders side, or until the
    receiver has initiated a receive operation
  • MPI_ssend implements synchronous communication by
    which the sender blocks until its request is
    accepted for further processing
  • MPI_sendrecv when called by sender, sends a
    request to the receiver and blocks until the
    latter returns a reply. This corresponds to
    normal RPC.

25
  • MPI_isend allows the sender to pass a pointer to
    the message and the MPI runtime system takes care
    of the communication. Sender continues.
  • MPI_issend allows the sender to pass a pointer to
    MPI runtime system. When runtime system indicates
    it has processed the message, sender knows that
    receiver has accepted the message.
  • Caller is blocked until message arrives when
    MPI_recv is called to receive a message
  • Asynchronous variant MPI_irecv called by receiver
    indicates it is prepared to accept message

26
  • Message-Oriented Persistent Communication
  • Message Oriented Middleware(MOM) or message
    queuing systems provide support for persistent
    asynchronous communication
  • Intermediate-term storage capacity for messages.
    Does not require sender/receiver to be active
    during message transmission
  • Slower than Berkeley sockets and MPI

27
  • Message-Queuing Model
  • Applications communicate by inserting messages in
    specific queues
  • Messages are forwarded over a series of
    communication servers and delivered to the
    destination, even if it was down when message was
    sent
  • Each application has its own private queue to
    which other applications can send messages

28
  • Sender is informed that the message will be
    eventually inserted in the receivers queue. No
    time is specified.
  • Neither sender nor receiver need to be executing
    when message is placed in the queue
  • Loosely coupled communication with sender and
    receiver executing independent of each other.

29
Primitive Meaning
Put Append a message to a specified queue. A nonblocking call by sender.
Get Block until specified queue is non-empty and remove the first message
Poll Check a specified queue for messages and remove the first. Never block.
Notify Install a handler as a callback function to be called when a message is put into a specified queue
30
  • Architecture of Message Queuing System
  • Source queue to put message is local to sender
  • Message can be read only from local queue
  • Message put into a queue will contain the
    specification of a destination queue to which it
    should be transferred
  • Message queuing system responsible to provide
    the queues to sender/receiver and transfer
    messages from source to destination queue.

31
  • Message queuing system maintains mapping of
    queues distributed across multiple machines to
    network locations a distributed database of
    queue names to network locations, similar to DNS.
  • Queues managed by Queue Managers, who interact
    with the application that is sending or receiving
    a message. Special queue managers operate as
    routers/relays that forward incoming messages to
    other queue managers

32
  • Message-queuing system may grow into a complete
    application level overlay network on top of
    existing computer network
  • Relays/routers help build scalable messaging
    systems
  • Relays allow secondary processing of messages,
    for example, a message may need to be logged for
    reasons of fault tolerance or security
  • Relays can be used for multicasting purposes.
    Incoming message put into each send queue.

33
  • E-mail Systems
  • E-mail systems use underlying transport services.
    Example, mail protocol for the Internet-SMTP, a
    message is transferred by setting up a direct TCP
    connection to the destination mail server.
    Generally no routing is used.
  • Provide direct support for end users when
    compared to message-queuing system
  • E-mail systems have specific requirements such
    as automatic message filtering, support for
    advanced messaging databases to retrieve old
    messages etc
  • Message queuing system enables persistent
    communication between processes. Wide range of
    applications including e-mail.

34
  • Stream-oriented Communication
  • Communication discussed till now dealt with
    independent, complete units of information and
    time had no effect on correctness of the
    communication
  • Stream communication such as audio or video
    stream in contrast to above are time-dependent
  • Information is represented in different formats
    such as GIF/JPEG for images, audio streams are
    encoded by taking 16-bit samples using PCM

35
  • In continuous representation media, temporal
    relationship between data is retained in order to
    correctly interpret the data. For example, motion
    can be represented by a series of images with
    successive images displayed at uniform spacing T
    in time (about 30-40 msec per image)
  • In discrete representation media, temporal
    relationships between data is not fundamental to
    correctly interpreting the data. Examples are
    text, still images etc

36
  • Data stream is a sequence of data units that can
    be applied to discrete as well as continuous
    media. Examples are UNIX pipes, TCP/IP
    connections of byte-oriented discrete data
    streams. Playing an audio file requires setting
    up a continuous data stream between the file and
    the audio device
  • Time is crucial to continuous data streams

37
  • Three types of transmission modes exist for data
    streams
  • Asynchronous transmission mode where data items
    are transmitted one after the other but no time
    constraints as to when the transmission of each
    item takes place. Example for discrete data
    streams file transmission
  • Synchronous transmission mode where there is a
    maximum end-to-end delay defined for each data
    unit in stream. Example is Temperature sampled by
    sensors and passed over network
  • Isochronous transmission mode where time
    constraint is rigid and data units are
    transferred subject to maximum and minimum
    end-end delay (bounded (delay) jitter). Example
    are distributed multimedia systems such as
    audio/video

38
  • Focus in the presentation is on continuous data
    streams (streams) using isochronous transmission
  • Simple stream consists of single sequence of data
  • Complex stream consists of several related simple
    streams called substreams that are interdependent
    on each other based on time. Example is a video
    stream such as movie where two substreams
    continuously synchronized to transmit audio for
    the movie, a video substream, and a substream
    containing subtitles for the deaf or different
    language translation. All substreams are
    synchronized.

39
(No Transcript)
40
  • Architecture in the figure reveals some issues
    such as compression needed to reduce required
    storage and network capacity especially more for
    video than audio
  • Quality of transmission and synchronization to be
    controlled
  • Timing requirements expressed by Quality of
    Service(QoS) QoS for continuous data streams
    concerns the timeliness, volume and reliability
    of transmission.

41
  • QoS Specification
  • The required bit rate at which data is
    transported
  • Maximum delay until a session is set up(i.e.,
    when an application can start sending the data).
  • Maximum end-to-end delay
  • Maximum delay variance or jitter

42
  • Enforcing QoS
  • Use buffers to reduce jitter
  • Use forward error correction to compensate for
    lost packets- encode the outgoing packets such
    that any k out of n received packets is enough to
    reconstruct k correct packets
  • Many distributed systems for stream-oriented
    communication are built on top of Internet
    protocol stack. Internet provides differentiating
    classes for data using differentiated services.
    Sending host can mark outgoing packets as
    belonging to one of several classes. Expedited
    forwarding class specifies that the packet should
    be forwarded by the router with absolute
    priority. With assured forwarding class, traffic
    is divided into 4 subclasses along with three
    ways to drop packets if the network gets
    congested. This means a range of priorities can
    be assigned to the packets to differentiate
    time-critical packets from non-critical ones.

43
  • Stream Synchronization
  • Maintains temporal relationships between
    streams/substreams , for example between discrete
    data stream and continuous data stream, or
    between continuous data streams
  • Synchronization takes place at the level of data
    units
  • Synchronization mechanisms concerned with
    synchronizing data streams and distribution of
    the mechanism in a networked environment

44
  • Multimedia middleware offers a collection of
    interfaces for controlling audio and video
    streams including interfaces for controlling
    devices such as monitors, cameras, microphones
    etc.
  • Each device and stream has its own high level
    interface including interfaces for notifying an
    application when some event occurred. Latter used
    for writing handlers for synchronizing streams.
  • Distribution of synchronization mechanism -
    receiving side has to have complete
    synchronization specification locally available

45
  • This approach is followed by MPEG streams
  • MPEG standards form a collection of algorithms
    for compressing video and audio
  • MPEG -2 designed for compressing broadcast
    quality video into 4 to 6 Mbps. Unlimited number
    of continuous and discrete streams merged into
    single stream. Input stream turned into a stream
    of packets that carry timestamp based on 90kHz
    clock. These streams multiplexed into a program
    stream consisting of variable length packets with
    common time base. Receiving side demultiplexes
    the stream using timestamp for interstream
    synchronization. Better to do synchronization at
    the sender rather than at receiver.

46
  • Stream Control Transmission Protocol
  • (SCTP)
  • SCTP is a reliable transport protocol operating
    on top of a connectionless packet network such as
    IP. It is described in RFC 4960, RFC 3286. It
    offers the following services to its users
  • -- acknowledged error-free non-duplicated
    transfer of user data
  • -- data fragmentation to conform to
    discovered path size
  • -- sequenced delivery of user messages
    within multiple streams, with an option for
    order-of-arrival delivery of individual user
    messages
  • -- optional bundling of multiple user
    messages into a single SCTP packet
  • -- network-level fault tolerance through
    supporting of multi-homing at either or both ends
    of an association
  • The design of SCTP includes appropriate
    congestion avoidance behavior and resistance to
    flooding and masquerade attacks.

47
  • The Stream Control Transmission Protocol (SCTP)
    is a new IP transport protocol, existing at an
    equivalent level with UDP (User DatagramProtocol)
    and TCP (Transmission Control Protocol), which
    provide transport layer functions to many
    Internet applications.
  • SCTP has been approved by the IETF as a Proposed
    Standard
  • Like TCP, SCTP provides a reliable transport
    service, ensuring that data is transported across
    the network without error and in sequence.
  • Like TCP, SCTP is a session-oriented mechanism,
    meaning that a relationship is created between
    the endpoints of an SCTP association prior to
    data being transmitted, and this relationship is
    maintained until all data transmission has been
    successfully completed.
  • Unlike TCP, SCTP provides a number of functions
    that are critical for telephony signaling
    transport, and at the same time can potentially
    benefit other applications needing transport with
    additional performance and reliability. The
    original framework for the SCTP definition is
    described in 3.

48
SCTP User Application
SCTP User Application
SCTP Transport Service
SCTP Transport Service
One or more IP Address Appearances
One or more IP Address Appearances
IP Network Service
IP Network Service
SCTP Node B
SCTP Node A
Network Transport
An SCTP Association
49
  • Message Format

Common Header
Chunk No 1

Chunk No n
50
  • Chunk ID 0 through 255. Each ID has Chunk Type
    defined as follows
  • 0 - Payload Data (DATA)
  • 1 - Initiation (INIT)
  • 2 - Initiation Acknowledgement (INIT ACK)
  • 3 - Selective Acknowledgement (SACK)
  • 4 - Heartbeat Request (HEARTBEAT)
  • 5 - Heartbeat Acknowledgement (HEARTBEAT ACK)
  • 6 - Abort (ABORT)
  • 7 - Shutdown (SHUTDOWN)
  • 8 - Shutdown Acknowledgement (SHUTDOWN ACK)
  • 9 - Operation Error (ERROR)
  • Etc

51
  • SCTP Common Header Format

Source Port No Destination Port No
Verification Tag
Check Sum
52
  • Source Port Number 16 bits (unsigned integer).
    This is the SCTP senders port number. It can be
    used by the receiver in combination with the
    source IP address, the SCTP destination port, and
    possibly the destination IP address to identify
    the association to which this packet belongs. The
    port number 0 MUST NOT be used.
  • Destination Port Number 16 bits (unsigned
    integer). This is the SCTP port number to which
    this packet is destined. The receiving host will
    use this port number to de-multiplex the SCTP
    packet to the correct receiving
    endpoint/application. The port number 0 MUST NOT
    be used.

53
  • Verification Tag 32 bits (unsigned integer). The
    receiver of this packet uses the Verification Tag
    to validate the sender of this SCTP packet. On
    transmit, the value of this Verification Tag must
    be set to the value of the Initiate Tag received
    from the peer endpoint during the association
    initialization, with the following exceptions
  • - A packet containing an INIT chunk MUST have a
    zero Verification Tag.
  • - A packet containing a SHUTDOWN COMPLETE chunk
    with the T bit set MUST have the Verification Tag
    copied from the packet with the SHUTDOWN ACK
    chunk.
  • - A packet containing an ABORT chunk may have the
    verification tag copied from the packet that
    caused the ABORT to be sent.
  • An INIT chunk MUST be the only chunk in the SCTP
    packet carrying it.
  • Checksum 32 bits (unsigned integer). This field
    contains the checksum of this SCTP packet.

54
  • Basic SCTP Features
  • SCTP is a unicast protocol, and supports data
    exchange between exactly 2 endpoints, although
    these may be represented by multiple IP
    addresses.
  • SCTP provides reliable transmission, detecting
    when data is discarded, reordered, duplicated or
    corrupted, and retransmitting damaged data as
    necessary. SCTP transmission is full duplex.
  • SCTP is message oriented and supports framing of
    individual message boundaries. In comparison, TCP
    is byte oriented and does not preserve any
    implicit structure within a transmitted byte
    stream without enhancement.
  • SCTP is rate adaptive similar to TCP, and will
    scale back data transfer to the prevailing load
    conditions in the network. It is designed to
    behave cooperatively with TCP sessions attempting
    to use the same bandwidth
  • SCTP Multi-Streaming Feature
  • The name Stream Control Transmission Protocol is
    derived from the multi-streaming function
    provided by SCTP. This feature allows data to be
    partitioned into multiple streams that have the
    property of independently sequenced delivery, so
    that message loss in any one stream will only
    initially affect delivery within that stream, and
    not delivery in other streams.

55
  • SCTP accomplishes multi-streaming by creating
    independence between data transmission and data
    delivery. In particular, each payload DATA
    "chunk" in the protocol uses two sets of sequence
    numbers, a Transmission Sequence Number that
    governs the transmission of messages and the
    detection of message loss, and the Stream
    ID/Stream Sequence Number pair, which is used to
    determine the sequence of delivery of received
    data.
  • This independence of mechanisms allows the
    receiver to determine immediately when a gap in
    the transmission sequence occurs (e.g., due to
    message loss), and also whether or not messages
    received following the gap are within an affected
    stream.
  • SCTP Multi-Homing Feature
  • Another core feature of SCTP is multi-homing, or
    the ability for a single SCTP endpoint to support
    multiple IP addresses. The benefit of
    multi-homing is potentially greater survivability
    of the session in the presence of network
    failures. To support multi-homing, SCTP
    endpoints exchange lists of addresses during
    initiation of the association. Each endpoint must
    be able to receive messages from any of the
    addresses associated with the remote endpoint in
    practice, certain operating systems may utilize
    available source addresses in round robin
    fashion, in which case receipt of messages from
    different source addresses will be the normal
    case. A single port number is used across the
    entire address list at an endpoint for a specific
    session.

56
  • Security Objectives
  • As a common transport protocol designed to
    reliably carry time-sensitive user messages, such
    as billing or signaling messages for telephony
    services, between two networked endpoints, SCTP
    has the following security objectives.
  • availability of reliable and timely data
    transport services
  • integrity of the user-to-user information carried
    by SCTP
  • SCTP Responses to Potential Threats
  • SCTP may potentially be used in a wide variety of
    risk situations. It is important for operators of
    systems running SCTP to analyze their particular
    situations and decide on the appropriate
    countermeasures.
  • Operators of systems running SCTP should consult
    RFC2196 for guidance in securing their site.
  • Countering Insider Attacks
  • The principles of RFC2196 should be applied to
    minimize the risk of theft of information or
    sabotage by insiders. Such procedures include
    publication of security policies, control of
    access at the physical, software, and network
    levels, and separation of services.

57
  • Protecting against Data Corruption in the Network
  • Protecting Confidentiality
  • As with the supplementary checksum service, user
    data encryption MAY be performed by the SCTP user
    application.
  • Alternately, the user application may use an
    implementation-specific API to request that the
    IP Encapsulating Security Payload (ESP) RFC4303
    be used to provide confidentiality and integrity.
  • Protecting against Blind Denial-of-Service
    Attacks
  • A blind attack is one where the attacker is
    unable to intercept or otherwise see the content
    of data flows passing to and from the target SCTP
    node. Blind denial-of-service attacks may take
    the form of flooding, masquerade, or improper
    monopolization of services
  • Flooding
  • The objective of flooding is to cause loss of
    service and incorrect behavior at target systems
    through resource exhaustion, interference with
    legitimate transactions, and exploitation of
    buffer-related software bugs. Flooding may be
    directed either at the SCTP node or at resources
    in the intervening IP Access Links or the
    Internet. Where the latter entities are the
    target, flooding will manifest itself as loss of
    network services, including potentially the
    breach of any firewalls in place.

58
  • In general, protection against flooding begins at
    the equipment design level, where it includes
    measures such as
  • - avoiding commitment of limited resources
    before determining that the request for service
    is legitimate.
  • - giving priority to completion of processing
    in progress over the acceptance of new work.
  • - identification and removal of duplicate or
    stale queued requests for service.
  • - not responding to unexpected packets sent to
    non-unicast addresses
  • Network equipment should be capable of generating
    an alarm and log if a suspicious increase in
    traffic occurs.
  • Blind Masquerade
  • Masquerade can be used to deny service in several
    ways
  • - by tying up resources at the target SCTP node
    to which the impersonated node has limited
    access. For example, the target node may by
    policy permit a maximum of one SCTP association
    with the impersonated SCTP node. The masquerading
    attacker may attempt to establish an association
    purporting to come from the impersonated node so
    that the latter cannot do so when it requires it.

59
  • - by deliberately allowing the impersonation
    to be detected, thereby provoking
    counter-measures that cause the impersonated node
    to be locked out of the target SCTP node.
  • - by interfering with an established
    association by inserting extraneous content such
    as a SHUTDOWN request.
  • SCTP reduces the risk of blind masquerade attacks
    through IP spoofing by use of the four-way
    startup handshake. Because the initial exchange
    is memory-less, no lockout mechanism is triggered
    by blind masquerade attacks. In addition, the
    INIT ACK containing the State Cookie is
    transmitted back to the IP address from which it
    received the INIT. Thus, the attacker would not
    receive the INIT ACK containing the State Cookie.
    SCTP protects against insertion of extraneous
    packets into the flow of an established
    association by use of the Verification Tag.
  • Logging of received INIT requests and
    abnormalities such as unexpected INIT ACKs might
    be considered as a way to detect patterns of
    hostile activity.

60
  • Improper Monopolization of Services
  • Attacks under this heading are performed openly
    and legitimately by the attacker. They are
    directed against fellow users of the target SCTP
    node or of the shared resources between the
    attacker and the target node. Possible attacks
    include the opening of a large number of
    associations between the attackers node and the
    target, or transfer of large volumes of
    information within a legitimately established
    association.
  • Policy limits should be placed on the number of
    associations per adjoining SCTP node. SCTP user
    applications should be capable of detecting large
    volumes of illegitimate or "no-op" messages
    within a given association and either logging or
    terminating the association as a result, based on
    local policy.
  • SCTP Interactions with Firewalls
  • It is helpful for some firewalls if they can
    inspect just the first fragment of a fragmented
    SCTP packet and unambiguously determine whether
    it corresponds to an INIT chunk (for further
    information, refer to RFC1858).
  • Accordingly, the requirements, (1) an INIT
    chunk MUST NOT be bundled with any other chunk in
    a packet, and (2) a packet containing an INIT
    chunk MUST have a zero Verification Tag.

61
3GPP
  • The 3rd Generation Partnership Project (3GPP) is
    a collaboration between groups of
    telecommunications associations, to make a
    globally applicable third-generation (3G) mobile
    phone system specification within the scope of
    the International Mobile Telecommunications-2000
    project of the International Telecommunication
    Union (ITU). 3GPP specifications are based on
    evolved Global System for Mobile Communications
    (GSM) specifications. 3GPP standardization
    encompasses Radio, Core Network and Service
    architecture. Some details of 3 GPP can found in
    RFC 3314.

62
  • Much of the standard addresses upgrading 3G UMTS
    to 4G mobile communications technology, which is
    essentially a mobile broadband system with
    enhanced multimedia services built on top.
  • The standard includes
  • Peak download rates of 326.4 Mbit/s for 4x4
    antennas, and 172.8 Mbit/s for 2x2 antennas
    (utilizing 20 MHz of spectrum).
  • Peak upload rates of 86.4 Mbit/s for every 20 MHz
    of spectrum using a single antenna.
  • Five different terminal classes have been defined
    from a voice centric class up to a high end
    terminal that supports the peak data rates. All
    terminals will be able to process 20 MHz
    bandwidth.
  • At least 200 active users in every 5 MHz cell.
    (Specifically, 200 active data clients)

63
  • Security Issues
  • Security documents can be located at
    ftp//ftp.3gpp.org
  • GSM was the first public telephone system to use
    integrated cryptographic mechanisms
  • GSM security features
  • Secure user access to telecommunications
    services
  • Identity of user authenticated by network
    operator
  • User and signaling traffic confidentiality
  • Protects user voice and data traffic, and
    signaling data from eavesdropping on radio path
  • User anonymity
  • Attacker who knows users IMSI can be prevented
    from tracking location of user and eavesdropping
    on radio path

64
  • GSM security mechanisms
  • Cryptographic authentication verifies the
    subscription with the
  • home network when service is requested
  • Challenge / response authentication protocol
    based on a
  • subscriber specific secret authentication key
  • Radio interface encryption prevents
    eavesdropping and
  • authenticates the use of the radio channel
  • The encryption mechanism is based on a
    symmetric stream
  • cipher
  • The key for encryption is established as part
    of the
  • authentication protocol
  • The allocation and use of temporary identities
    helps to provide
  • user anonymity

65
  • Multicast Communication
  • Sending data to multiple receivers
  • Explicit communication paths set up could be at
    Application Level for peer-to-peer solutions
  • Without explicit communication paths, gossip
    based information dissemination provides simple
    but less efficient way to implement multicasting.

66
  • Application level multicasting
  • Nodes organize into an overlay network that is
    used to disseminate information to its members
  • Network routers not involved in group membership
  • Overlay network could be organized into a tree or
    a mesh network. Former provides a unique overlay
    path between every pair of nodes, while latter
    has each node connected to multiple neighbors
    higher robustness in the event a connection
    breaks

67
  • Multicast Session
  • Node generates a multicast identifier mid
    (randomly chosen 160 bit key). It then looks up
    succ(mid) that is the node responsible for this
    key and promotes it to become the root of the
    multicast tree that is used to send data to
    interested nodes
  • To join the tree, a node P executes operation
    LOOKUP(mid) that allows a lookup message with
    request to join the multicast group mid to be
    routed from P to succ(mid).
  • On the way up to the root, join request will add
    forwarder nodes or helpers for the group
  • Multicasting implemented by a node sending a
    multicast message towards the root by executing
    LOOKUP(mid) after which message can be sent along
    the tree.

68
  • Gossip based data dissemination
  • Spreading information without explicit
    communication paths in large distributed systems
    using epidemic protocols.
  • These protocols rapidly propagate information
    among large collection of nodes using only local
    information without any central component to
    coordinate information dissemination
  • Avoid write conflicts by allowing only a single
    node to initiate updates for a specific data item

69
  • Node is infected if it holds data that it is
    willing to spread to other nodes.
  • Node that has not seen the data is called
    susceptible.
  • Updated node that is not willing or able to
    spread the data is said to be removed.
  • Data is timestamped
  • Anti-entropy model of propagation has three
    approaches for updates for node P propagating to
    random node Q
  • P only pushes its own updates to Q
  • P only pulls its own updates from Q
  • P and Q send updates to each other (push-pull
    approach) This is the best

70
  • Rumor spreading or gossiping allows node P to
    push update to arbitrary node Q if it is not yet
    updated. If Q already updated by another node, P
    loses interest in spreading the update further-
    it becomes removed.
  • Deletion of data item needs the use of death
    certificates to be recorded and spread through
    all the nodes.
  • Death certificates are time-stamped and they are
    removed after a maximum propagation time has
    elapsed

71
Conclusion
  • In this presentation, following topics were
    discussed
  • Three popular models of communication in
    distributed systems
  • Remote Procedure Calls (RPC)
  • Message-oriented Middleware (MOM)
  • Data Streaming, discussion of SCTP, 3GPP
  • Sending data to multiple receivers or
    Multicasting

72
  • References
  • 1 Stewart, R., Xie, Q., Morneault, K., Sharp,
    C., Schwarzbauer, H., Taylor, T., Rytina, I.,
    Kalla, M., Zhang, L. and V. Paxson, "Stream
    Control Transmission Protocol", RFC 2960, October
    2000.
  • 2 Stewart, Sharp, et. al., "SCTP Checksum
    Change", Work in Progress.
  • 3 Ong, L., Rytina, I., Garcia, M.,
    Schwarzbauer, H., Coene, L., Lin, H., Juhasz, I.,
    Holdrege, M. and C. Sharp, "Framework
    Architecture for Signaling Transport", RFC 2719,
    October 1999.
  • 4 Jungmeier, Rescorla and Tuexen, "TLS Over
    SCTP", Work in Progress.
  • 5 www.ietf.org
  • 6 RFC4960
  • 7 RFC3286
  • 8 RFC2196
  • 9 RFC1858
  • 10 RFC3314
  • 11 ftp//ftp.3gpp.org

73
Bibliography
  • 1. A. Tanenbaum, M.V. Steen, Distributed
    Systems Principles and Paradigms, Pearson(2nd
    Ed), 2007.
About PowerShow.com
