Supercooled liquids

1
Supercooled liquids
Zhigang Suo Harvard University
Prager Medal Symposium in honor of Bob
McMeeking SES Conference, Purdue University, 1
October 2014
1
2
Mechanics of supercooled liquids
Jianguo Li
Qihan Liu Laurence
Brassart

• Journal of Applied Mechanics 81, 111007 (2014)

3
Supercooled liquid
liquid
Volume
supercooled liquid
melting point
crystal
Temperature
4
A simple picture of liquid

• A single rate-limiting step molecules change
  neighbors
• Two types of experiments viscous flow and
  self-diffusion

5
Stokes-Einstein relation
Stokes (1851)
particle
Einstein (1905)
liquid
6
Success and failure of Stokes-Einstein relation
TNB
IMC
OTP
Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014). Based on
experimental data in the literature
7
A supercooled liquid forms a dynamic structure
The dynamic structure jams viscous flow, but not
self-diffusion.
Ediger, Annual Review of Physical Chemistry 51,
99 (2000).
8
Our paper
Given that the Stokes-Einstein relation fails,
we regard viscous flow and self-diffusion as
independent processes, and formulate a new
fluid mechanics.
Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014)
9
Homogeneous state
Helmholtz free energy of a composite system
Liquid force reservoir
Incompressible molecules
Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014)
10
Thermodynamic equilibrium
reservoir
liquid
membrane
osmosis
Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014)
11
Linear, isotropic, viscous, porous liquid

• Analogous to Biots poroelasticity.
  (Poroviscosity?)
• Different from Newtons law of viscosity

Alternative way to write the model
change shape change volume
Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014)
12
Inhomogeneous field
Diffusion flux
Net flux
Convection flux
Suo. Journal of Applied Mechanics 71, 77 (2004)
13
Boundary-value problem
4 partial differential equations
4 boundary conditions
Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014)
14
Length scale
Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014)
15
Time scale
Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014)
16
A cavity in a supercooled liquid

• A small object evolves by self-diffusion.
• A large object evolves by viscous flow.

Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014)
17
Summary

1. A supercooled liquid is partially jammed. A drop
   in temperature jams viscous flow, but does not
   retard self-diffusion as much.
2. We regard viscous flow and self-diffusion as
   independent processes, and formulate a new
   fluid mechanics.
3. A characteristic length exists. A small object
   evolves by self-diffusion, and a large object
   evolves by viscous flow.
4. Other partially jammed systems cells, gels,
   glasses, batteries.

Li, Liu, Brassart, Suo. Journal of Applied
Mechanics 81, 111007 (2014)
