Title: ACS-1805 Introduction to Programming using Alice


1
ACS-1805Introduction to Programmingusing
Alice

2
Alice
  • The basics of computer programming
  • Pages 5/6/7/8 in 2nd edition
  • Computer program
  • Just a set of instructions for computer to
    follow
  • At its heart, programming is really very
    simple.
  • All computer programs are made from very simple
    ideas
  • A list of instructions (algorithm)
  • Ifs (decisions)
  • Repeating behaviour (repetition)
  • Breaking things into smaller pieces
    (decomposition)
  • Computing a result (functions)

3
Alice
  • Flowcharting (2nd edition, page 7)
  • terminal
  • Input/output
  • Processing
  • Call
  • Decision
  • Flow lines
  • Connectors on page, off page
  • Also chapter 2, page 38, the use of parallelism
    later

4
Alice
  • Virtual world
  • Started by playing a virtual world
  • Can play like a movie, or played like an
    interactive game
  • Developing a world begins with a template (e.g.
    ground sky)
  • Object
  • Objects are added to the world (e.g. a person, a
    robot, a ball)
  • Objects are chosen from a gallery of 3D models
  • Objects are commanded to do things
  • 3D Model
  • Created by Alice developers
  • Is a blueprint for objects size, color,
    actions,
  • Programming
  • Build methods containing commands for objects
  • Build methods to respond to events
  • Event
  • Pressing a key on the keyboard, etc.

5
Alice
  • Emphasizes programming fundamentals
  • Programs are composed of methods
  • Methods contain Alice instructions
  • Objects are asked to do things they know how to
    do
  • Events can trigger execution of program
    components
  • Programs always run
  • The Alice editor is user-friendly its a smart
    editor with visual drag drop features

6
Kinds of Animations
  • Two kinds
  • Movie
  • Passive user watches the animation
  • Interactive
  • Active user clicks on mouse, types a key on
    keyboard make into a game
  • Actions of user are called events

7
Appendix A
  • Read both appendixes (especially A at this time)
  • Appendix A
  • Part 1 Running virtual worlds
  • Explains some things about the Alice startup
  • World 1
  • Open and play the first example in the textbook
    tab
  • World 2
  • Open and play the second example in the
    textbook tab
  • World 3
  • Creating a new world from the snow template
    adding arranging objects
  • Part 2 using popup menus for the initial scene

8
Appendix B
  • Appendix B
  • Searching the gallery
  • Creating your own people models
  • Using the clipboard
  • Deleting code using wastebasket and dissolve
  • Exporting code to html
  • Exporting a world (viewing a world on the web
    requires the user to have Java 3D or Java Media
    Frameworks installed)

9
Techniques and Tools
  • Setting up a world
  • Gallery is used to
  • obtain objects
  • Mouse is used to
  • approximately position objects in the scene
  • Camera Navigation is used to
  • set the camera point of view
  • Drop-down menu methods are used to
  • resize objects
  • position objects in the scene
  • Quadview is used to
  • position one object relative to another object
  • precise positioning of objects in the scene

10
Objects
  • An "object" is
  • any thing that can be identified as unique from
    other things
  • How is an object unique?
  • has a name
  • has properties
  • width, height, color, location
  • can perform actions (methods)
  • associated actions it can perform
  • tasks it can carry out

11
Galleries
  • Classes (3D models) are found in the galleries
  • Local gallery (installed with the software)
  • Minimum or complete options
  • CD Gallery (when CD is in the machine)
  • Web gallery

12
Object Parts
  • Objects may be composed of parts
  • aliceLiddell has a rightArm
  • The rightArm comprises a shoulder, and forearm,
    and the forearm has subparts too.
  • A means there are subparts that can be listed
    by clicking on the
  • A - means the subparts are listed. To suppress
    the listing of subparts click the -
  • The picture on the right is showing the objects
    in a tree view

13
Object Parts
Consider the aliceLiddell object to the right. A
computer scientist typically uses tree diagrams
for complex hierarchical structures. Can you
complete this for neck and lowerBody?
aliceLiddell
rightArm
leftArm
neck
lowerBody


shoulder
forearm
forearm
shoulder
hand
hand
thumb
fingers
thumb
fingers
fingerTips
fingerTips
14
3 Dimensions, 6 Directions
up
  • A 3D object has
  • 3 dimensions
  • height, width, depth
  • 6 degrees of freedom

right
backward
forward
left
down
