Title: The Atmosphere


1
The Atmosphere
  • Chapter 6 Notes

2
Composition of the Atmosphere
  • Atmosphere a mixture of gasses that surround the
    Earth
  • Contains the oxygen you breathe and protects you
    from harmful rays from the sun.
  • Water Vapor make up part of the atmosphere .
    When conditions change the water vapor can change
    to a liquid (rain) or solid (snow)

3
Atmospheric Pressure
  • The atmosphere is held around Earth by gravity.
  • Gravity pulls gas molecules toward Earths
    surface which causes Air Pressure.
  • Air Pressure the measure of the force with which
    air molecules push on a surface

4
Air Pressure
  • Air pressure is strongest on Earths surface.
  • As altitude increases the pressure decreases.

5
Atmospheric Temperature
  • Differences in the temperature of the atmosphere
    result from the amount of solar energy absorbed.
  • Some parts contain more gases which make them
    absorb more solar energy
  • Other parts contain less gases which mean they
    are absorb less solar energy and are cooler.

6
Layers of the Atmosphere
Draw this picture
7
The First Layer
  • Troposphere
  • Lowest layer next to Earths surface
  • Densest layer
  • Contains 90 of the mass of the atmosphere
  • The layer we live in
  • Gases continuously mix in this layer
  • Temperatures vary in this layer

8
The Second Layer
  • Stratosphere
  • Gases are layered and do not mix in this layer
  • The air is very thin and contains little moisture
  • Lower stratosphere is very cold -60 degree temp.
    But temperatures rise as altitudes rise
  • This layer is the home of the ozone layer, a
    protective layer that soaks of ultraviolet rays
    from the sun.

9
stratosphere
troposphere
10
The Third Layer
  • Mesosphere
  • The coldest layer
  • Temperatures can be as low as -93 degrees Celsius
    at the top of the Mesosphere

11
The Fourth Layer
  • Thermosphere
  • High temperatures 1000 degrees Celsius or higher
  • It does not feel hot. The particles are moving
    very fast but they are not heating up.

12
(No Transcript)
13
Ionosphere
  • This occurs between the mesosphere and
    thermosphere.
  • Gas particles become electrically charged
    particles called ions
  • These ions radiate energy in the form of
    shimmering light called auroras

14
Atmospheric Heating
  • Energy from the sun is absorbed by the
    atmosphere, land, and water and is changed into
    thermal energy.

15
Heat TransferConduction, Convection and
Radiation
16
To Make Foldable
1. On the short side of the paper, fold it down
an inch. 2. Now fold it in half, hamburger
style. 3. Now fold it in 1/3.
Outside of Foldable
Inside of Foldable
Conduction
Convection
Radiation
Examples Definition
Examples Definition
Examples Definition
Heat Transfer
17
Thermal Energy Transfer
  • Thermal energy transfer is heat moving from a
    warmer object to a cooler object. This is known
    as thermal energy transfer.

18
How is Heat Transferred?
  • There are THREE ways heat can move.
  • Conduction
  • Convection
  • Radiation

19
CONDUCTION
  • Heat is transferred from one particle of matter
    to another in an object.
  • Conduction CONTACT/ TOUCH

20
Have you ever
  • Touched a metal spoon sitting in a pan of boiling
    water only to be surprised by HOW hot it is??

Think back to what you know about metals and
nonmetals. What conducts heat better, metal or
nonmetal? Why?
21
Example of Conduction
  • Think of a metal spoon in a pot of water being
    heated.
  • The fast-moving particles of the fire collide
    with the slow-moving particles of the cool pot.
  • Because of these collisions, the slower particles
    move faster and heat is transferred.
  • Then the particles of the pot collide with the
    particles in the water, which collide with the
    particles at one end of the spoon.
  • As the particles move faster, the metal spoon
    gets hotter. This process of conduction is
    repeated all along the metal until the entire
    spoon is hot.

22
EXAMPLE OF CONDUCTION
  • A piece of cheese melts as heat is transferred
    from the meat to the cheese (Contact)

23
CONVECTION
  • Convection is the movement that transfers heat
    within fluids and air (gas)
  • Heat is transferred by currents within the fluid
    or gas
  • Convection VENTS (through air and liquid
    particles)
  • Convection moves in
  • a circular pattern

24
Examples of Convection
  • Have you ever noticed that the air near the
    ceiling is warmer than the air near the floor? Or
    that water in a pool is cooler at the deep end?
  • Examples air movement in a home, pot of heating
    water.
  • Pick one of these examples and draw the circular
    pattern in your notes.

25
Explaining Convection
  • Convection currents cause the cooler breezes you
    experience by a large body of water.
  • These currents also cause the movement of magma
    within the earth.

26
RADIATION
  • Radiation is the transfer of energy by
    electromagnetic waves
  • Radiation does NOT require matter to transfer
    thermal energy
  • Radiation Radiates (heat escaping the sun)

27
Radiation May Come From Other Sources
  • Have you ever sat too close to a campfire while
    cooking marshmallows? Youre enjoying the warmth
    .. only to notice that your skin is really warm?

28
Examples of RADIATION
  1. Fire
  2. Heat Lamps
  3. Sun

29
Radiation Energy Transfer by Waves
  • Radiation is the transfer of energy as
    electromagnetic waves.
  • The sun radiates huge amounts of energy But Earth
    only receives two-billionths of this energy
  • Energy from the sun drives the weather and makes
    Earth habitable.

30
Conduction Energy Transfer by Contact
  • Thermal Conduction is the transfer of energy
    through a material
  • Always transferred from warm to cold areas
  • Occurs when air molecules come in direct contact
    with the warm surface of the Earth.

31
Convection Energy Transfer by Circulation
  • Convection is the transfer of thermal energy by
    the circulation or movement of a liquid or gas
  • Most thermal energy is transferred through
    convection

32
Convection
  • Example, as air is heated, it becomes less dense
    and rises. Cool air is denser, so it sinks. As
    the cool air sinks, it pushes the warm air up.
    The cool air is eventually heated by the Earth's
    surface and begins to rise again. This is called
    a convection current

33
Greenhouse Effect
  • 70 of the radiation that enters the atmosphere
    is absorbed by the clouds or by the Earths
    surface.
  • The energy is converted into thermal energy.

34
Greenhouse Effect
  • The greenhouse effect is the process by which the
    gases in the atmosphere absorb thermal energy and
    radiate it back to the Earth.
  • Acts much like the glass walls and roof in a
    greenhouse.

35
Radiation Balance
  • In order for the Earth to remain livable, the
    amount of radiation coming into the Earth must
    equal the amount of thermal energy the Earth
    releases into space.
  • There must be BALANCE!!

36
Global Warming
  • Global warming is the gradual increase in average
    global temperature
  • Causes the icecaps to start to melt
  • Possible causes
  • Too many greenhouse gases
  • Human activity
  • People are not doing their part to keep the Earth
    clean and safe
  • Using too many Fossil Fuels!!

37
Global Winds and Local Winds
  • Wind the movement of air caused by differences
    in air pressure
  • The greater the pressure, the faster the wind
    moves.
  • Ex Hurricanes

38
Hurricane Andrew
39
Air Rises at the Equator and Sinks at the Poles
  • Differences in air pressure are caused by unequal
    heating of the Earth.

Equator Poles
Receives more solar energy Air is warmer and less dense The air rises creating an area of low pressure The warm air flows towards the poles Receives the warm air, which becomes colder and denser The cold air sinks creating an area of high pressure The cold air then flows back towards the equator.
40
Pressure belts are found every 30º
  • Air travels in many large circular patterns
    called convection cells.
  • Convection cells are separated by pressure belts
    that include bands of high and low pressure every
    30 of latitude

41
(No Transcript)
42
Coriolis Effect
  • The Coriolis effect is the apparent curving
    motion of winds and ocean currents due to Earths
    rotation.
  • Northern Hemisphere the winds traveling north
    curve to the east and winds traveling to the
    south curve to the west

43
Global Winds
  • The combination of convection cells found at
    every 30º of latitude and the Coriolis effect
    produces patterns of air circulation called
    global winds.

44
Polar Easterlies
  • The wind belts that extend from the poles to 60
    latitude in both hemispheres are called the polar
    easterlies.
  • They are formed as the cold sinking air moves
    from the poles toward 60 north and 60 south
    latitude.
  • The polar easterlies are responsible for bringing
    cold arctic air over the United States.

45
Prevailing Westerlies
  • The wind belts found between 30 and 60 latitude
    in both hemispheres are called the westerlies.
  • The westerlies flow towards the poles from west
    to east
  • The westerlies are responsible for bringing moist
    air to the United States.

46
Trade Winds
  • The winds that blow from 30 latitude almost to
    the equator are called trade winds.
  • The Coriolis effect causes the trade winds to
    curve west in the Northern Hemisphere and east in
    the Southern Hemisphere
  • Early traders used these winds to sail from
    Europe to the Americas.

47
The Doldrums
  • The trade winds meet in an area around the
    equator called the doldrums.
  • There is very little wind because there is very
    low pressure.
  • This is why it is called the doldrums.

48
Horse Latitudes
  • At about 30 north and 30 south latitude,
    sinking air creates an area of high pressure. The
    winds are weak in this area called the horse
    latitudes.
  • Legend says that sailors would get stuck in this
    windless area. Instead of wasting drinking water
    they would through the horses overboard.
  • Most of the Earths deserts are located at this
    latitude.

49
(No Transcript)
50
Jet Streams Atmospheric Conveyor Belts
  • Jet Streams are a narrow belt of strong winds
    that blow in the upper troposphere.
  • Can reach maximum speeds of 400km/h
  • Do not follow regular patterns
  • Important for pilots and meteorologists.

51
Local Winds
  • Local winds move short distances and can blow
    from any direction.
  • Shorelines or mountains can create local wind
    patterns

52
  • Sea Breeze- during the day, air over the ocean
    is cooler and forms an area of high pressure. The
    cool air flows to the land producing a sea
    breeze.

53
  • Land Breeze- at night air over the land is cooler
    and forms an area of high pressure. The cooler
    air moves toward the ocean producing a land
    breeze.

54
Sea and Land Breezes
55
  • Mountain Breeze- at night air along the mountain
    slopes cool . This cool air moves down the slopes
    into the valley producing a mountain breeze.

56
  • Valley Breeze during the day, the sun warms the
    air along the mountain slopes. This warm air
    rises up the mountain creating a valley breeze.

57
Air Pollution
  • In December 1952, one of London's dreaded "pea
    souper" fogs settled on the city. But this was no
    ordinary fogit was thick with coal smoke and air
    pollution. It burned people's lungs, and the sky
    grew so dark that people could not see their
    hands in front of their faces. When the fog
    lifted four days later, thousands of people were
    dead!

58
Air Pollution
  • Air Pollution is the contamination of the
    atmosphere by the introduction of pollution from
    human and natural sources
  • Air pollution is common in many places
  • Must be reduced

59
Primary Pollutants
  • Pollutants that are put directly into the air by
    humans or natural activity are primary pollutants
  • Ex dust, sea salt, volcanic gases and ash, smoke
    for forest fires, and pollen, carbon monoxide,
    dust, smoke, vehicle exhaust

60
Primary Pollutants
61
Secondary Pollutants
  • Pollutants that form when primary pollutants
    react with other primary pollutants or with
    naturally occurring substances are secondary
    pollutants.
  • Ex ozone and smog

62
Formation of Smog
  • Smog forms when ozone and vehicle exhaust react
    with sunlight
  • Pollution controls have been put in effect in
    some places to control the amount of pollution
    and reduce the amount of smog.

63
(No Transcript)
64
Sources of human caused air pollution
  • Transportation is a major cause of air pollution
  • It causes10-20 of the pollution in the United
    States
  • Vehicle exhaust contains nitrogen oxide which
    contributes to smog

65
Industrial Air Pollution
  • Industrial plants and electrical power plants
    burn fossil fuels to produce energy.
  • Oil refineries, chemical manufacturing plants,
    dry-cleaning businesses, furniture refinishers,
    and auto body shops all produce air pollution.

66
Indoor Air Pollution
67
Indoor Air Pollution
  • Indoor air pollution can be reduced by
  • Ventilation-mixing of indoor air with outdoor air
  • Reduce indoor air pollution by limiting the use
    of chemical solvents and cleaners

68
Acid Precipitation
  • Precipitation such as rain, sleet, or snow that
    contains acids from air pollution is called acid
    precipitation.
  • The burning of fossil fuels releases sulfur
    dioxide and nitrogen oxide into the atmosphere.
  • They combine with water in the atmosphere to form
    sulfuric acid and nitric acid.

69
Acid Precipitation and Plants
  • Soil naturally has acid.
  • Acid precipitation can cause the soil acidity to
    increase
  • This is called acidification.
  • When acidification occurs
  • Some nutrients are dissolved
  • Aluminum and toxic metals are released and
    absorbed by the roots of plants

70
The Effects of Acid Precipitation on Forests
  • Eastern Europe Poland
  • Forests have been severely damaged by acid
    precipitation

71
Acid Precipitation and Aquatic Ecosystems
  • If the amount of acid increases in the water then
    the plants, fish, and other organisms may die.
  • A rapid change in a body of waters acidity is
    called acid shock.
  • Some communities use powered lime a base to
    reduce the amount of acid in the water.

72
The Ozone Hole
  • 1985 scientists reported that the ozone layer
    over Antarctic regions was thinning.
  • Chemicals called CFC were causing the ozone to
    break down into oxygen

73
The Ozone Hole
  • 1987 action was taken to solve the ozone problem
  • A ban of all CFC chemicals was created
  • CFC alternatives were developed
  • CFC chemicals take 60 to 120 years to quit
    working. Therefore even with the ban CFCs used
    30 years ago are still harming the ozone now!!!

74
Air Pollution and Human Health
Short Term Effects Long Term Effects
Headache Nausea Irritation to eyes, nose, and throat Coughing Upper respiratory infection Worsening of asthma and emphysema Emphysema Lung cancer Permanent lung damage Heart disease
75
Cleaning up air pollution
  • 1970 the United States Clean Air Act was passed
    by Congress.
  • This act gives the Environmental Protection
    Agency the authority to control the amount of
    pollutants that can be released from any source.
  • The EPA checks air quality.
  • The Clean Air Act was strengthened in 1990.

76
Air Pollution from Industry
  • The Clean Air Act requires factories to use
    scrubbers.
  • A scrubber is a device that is used to remove
    some pollutants before they are released by
    smokestacks.

77
The Allowance Trading System
  • The Allowance Trading System the EPA gives
    allowances for the amount of pollutants that
    companies can release.
  • If a company goes over--- they pay fines.
  • If a company is under they can sell there extra
    allowances to other businesses.

78
Reducing Air Pollution from Vehicles
  • The EPA requires car makers to meet certain
    criteria for exhaust.
  • Use of cleaner fuels and more efficient engines
  • Hybrids, carpools, public transportation, or
    biking and walking all reduce air pollution.
About PowerShow.com
