C Programming: Program Design Including Data Structures, Second Edition

1
C Programming Program Design Including Data
Structures, Second Edition

• Chapter 4 Control Structures I (Selection)

2
Objectives

• In this chapter you will
• Learn about control structures
• Examine relational and logical operators
• Explore how to form and evaluate logical
  (Boolean) expressions
• Discover how to use the selection control
  structures if, if...else, and switch in a program
• Learn to use the assert function to terminate a
  program

3
Control Structures

• A computer can proceed
• In sequence
• Selectively (branch) - making a choice
• Repetitively (iteratively) - looping
• Some statements are executed only if certain
  conditions are met
• A condition is represented by a logical (Boolean)
  expression that can be true or false
• A condition is met if it evaluates to true

4
C control structures

• Selection
• if
• if . . . else
• switch
• Repetition
• for loop
• while loop
• do . . . while loop

5
(No Transcript)
6
Relational Operators

• Relational operators
• Allow comparisons
• Require two operands (binary)
• Return 1 if expression is true, 0 otherwise
• Comparing values of different data types may
  produce unpredictable results
• For example, 8 lt '5' should not be done
• Any nonzero value is treated as true

7
Relational Operators

• are used in expressions of form
• ExpressionA Operator ExpressionB
• temperature gt humidity
• B B - 4.0 A C gt 0.0
• abs (number ) 35
• initial ! Q

8
(No Transcript)
9
(No Transcript)
10

• int x, y
• x 4
• y 6
• EXPRESSION VALUE
• x lt y true
• x 2 lt y false
• x ! y true
• x 3 gt y true
• y x false
• y x2 true
• y x 3 7 (true)

11
In C

• the value 0 represents false
• ANY non-zero value represents true
• C lt G is true
• c lt g is true
• c lt G is false,
• because G comes before in the sequence of the
  ASCII character set
• Compare ints with ints, floats with floats, chars
  with chars otherwise implicit type coercion takes
  place.
• Use explicit type casting
• someFloat lt static_castltfloatgt (someInt)
• boolVar lt 4 is true, why? boolVar yields

12
Comparing string Types

• Relational operators can be applied to strings
• Strings are compared character by character,
  starting with the first character
• Comparison continues
• until either a mismatch is found or
• all characters are found equal
• If two strings of different lengths are compared
  and the comparison is equal to the last character
  of the shorter string
• The shorter string is less than the larger string

13
string Comparison Example

• Suppose we have the following declarations
• string str1 "Hello"
• string str2 "Hi"
• string str3 "Air"
• string str4 "Bill"

14
Logical (Boolean) Operators

• Logical (Boolean) operators enable you to combine
  logical expressions
• Three logical (Boolean) operators
• ! - not
• and
• - or
• Logical operators
• take logical values as operands and yield logical
  values as results
• ! is unary and are binary operators
• Putting ! in front of a logical expression
  reverses its value

15
(No Transcript)
16
Precedence of Operators

• Relational and logical operators are evaluated
  from left to right
• so the associativity is left to right
• Parentheses can override precedence

17
(No Transcript)
18

• //Chapter 4 Logical operators p.157
• include ltiostreamgt
• using namespace std
• int main()
• bool found true
• bool flag false
• int num 1
• double x 5.2
• double y 3.4
• int a 5, b 8
• int n 20
• char ch 'B'
• cout ltlt "Line 1 !found evaluates to "
• ltlt !found ltlt endl //Line 1
• cout ltlt "Line 2 x gt 4.0 evaluates to "
• ltlt (x gt 4.0) ltlt endl //Line 2
• cout ltlt "Line 3 !num evaluates to "

19
Short-Circuit Evaluation

• Short-circuit evaluation evaluation of a logical
  expression are evaluated left to right and stops
  as soon as the value of the expression is known
• Example
• Assume age 25 grade B
• (age gt 21) ( x 5) //Line 1
• (grade A) (x gt 7) //Line 2

20
Short-Circuit Example

• int age, height
• age 25
• height 70
• EXPRESSION
• (age gt 50) (height gt 60)
• false
• Evaluation can stop now because result of is
  only true when both sides are true. It is
  already determined that the entire expression
  will be false.

21
The bool Data Type and Logical (Boolean)
Expressions

• The data type bool has logical (Boolean) values
  true and false
• bool, true, and false are reserved words
• The identifier true has the value 1
• The identifier false has the value 0

22
Logical (Boolean) Expressions (continued)

• Logical expressions can be unpredictable
• The following expression appears to represent a
  comparison of 0, num, and 10
• 0 lt num lt 10
• It always evaluates true because 0 lt num
  evaluates to either 0 or 1, and 0 lt 10 is true
  and 1 lt 10 is true
• The correct way to write this expression is
• 0 lt num num lt 10

23
One-Way (if) Selection

• The syntax of one-way selection is
• if(expression)
• statement
• Statement is executed if the value of the
  expression is true
• Statement is bypassed if the value is false
  program goes to the next statement

24

• The syntax of one-way selection is
• if(expression)
• statement
• Statement is executed if the value of the
  expression is true
• Statement is bypassed if the value is false
  program goes to the next statement

25
One-Way (if) Selection (continued)

• The expression is sometimes called a decision
  maker
• because it decides whether to execute the
  statement that follows it
• The statement following the expression is
  sometimes called the action statement
• The expression is usually a logical expression
• The statement is any C statement
• if is a reserved word

26
Comparing float Values

• do not compare float values for equality, compare
  them for near-equality.

float myNumber float yourNumber cin
gtgt myNumber cin gtgt yourNumber if ( fabs
(myNumber - yourNumber) lt 0.00001 ) cout ltlt
They are close enough! ltlt endl
27

• Two-way selection takes the form
• if(expression)
• statement1
• else
• statement2
• If expression is true, statement1 is executed
  otherwise statement2 is executed
• statement1 and statement2 are any C statements
• else is a reserved word

28

• //Program Weekly wages
• include ltiostreamgt
• include ltiomanipgt
• using namespace std
• int main ()
• double wages, rate, hours
• cout ltlt fixed ltlt showpoint ltlt setprecision(2) //
  Line 1
• cout ltlt "Line 2 Enter working hours and rate
  " //Line 2
• cin gtgt hours gtgt rate //Line 3
• if (hours gt 40.0) //Line 4
• wages 40.0 rate 1.5
  rate (hours - 40.0) //Line 5
• else //Line 6
• wages hours rate //Line 7

29
Compound (Block of) Statement

• Compound statement (block of statements)
• statement1
• statement2
• .
• .
• .
• statementn
• A compound statement is a single statement

30
Compound Statement Example

• if(age gt 18)
• coutltlt" Eligible to vote."ltltendl
• coutltlt" No longer a minor."ltltendl
• else
• coutltlt"Not eligible to vote."ltltendl
• coutltlt"Still a minor."ltltendl

31
Use of blocks recommended

• if ( Expression )
• else

if clause
else clause
32

• What happens if you omit braces?
• if ( (carDoors 4 ) (driverAge gt 24) )
• premium 650.00
• cout ltlt LOW RISK
• else
• premium 1200.00
• cout ltlt HIGH RISK
• monthlyPayment premium / 12.0 5.00
• COMPILE ERROR OCCURS. The if clause is the
  single statement following the if.

33
Braces can only be omitted when each clause is a
single statement

• if ( lastInitial lt K )
• volume 1
• else
• volume 2
• cout ltlt Look it up in volume
• ltlt volume ltlt of NYC phone book

34
Nested if Statements

• if ( Expression1 )
• Statement1
• else if ( Expression2 )
• Statement2
• .
• .
• .
• else if ( ExpressionN )
• StatementN
• else
• Statement N1
• EXACTLY 1 of these statements will be executed.

35
Multi-way Branching

• if ( creditsEarned gt 90 )
• cout ltlt SENIOR STATUS
• else if ( creditsEarned gt 60 )
• cout ltlt JUNIOR STATUS
• else if ( creditsEarned gt 30 )
• cout ltlt SOPHOMORE STATUS
• else
• cout ltlt FRESHMAN STATUS

36
Nested if

• Nesting one control statement in another
• An else is associated with the most recent if
  (that has not been paired with an else)
• For example
• if(score gt 90)
• coutltlt"The grade is A"ltltendl
• else if (score gt 80)
• coutltlt"The grade is B"ltltendl
• else
• coutltlt"The grade is F"ltltendl

37
Bad Example has output FAIL

• float average
• average 100.0
• if ( average gt 60.0 )
  // line 3
• if ( average lt 70.0 ) // line 4
• cout ltlt Marginal PASS // line 5
• else
  // line 6
• cout ltlt FAIL //
  line 7
• WHY? The compiler ignores indentation and pairs
  the else with the second if.
• An else is always paired with the closest
  precedence if (that doesnt have an else paired
  with it.)

100.0
average
38
To correct the problem, use braces

• float average
• average 100.0
• if ( average gt 60.0 )
• if ( average lt 70.0 )
• cout ltlt Marginal PASS
• else
• cout ltlt FAIL

100.0
average
39
Input Failure and the if Statement

• If input stream enters a fail state
• All subsequent input statements associated with
  that stream are ignored
• Program continues to execute
• May produce erroneous results

40
Each I/O stream has a state (condition)

• An input stream enters fail state when you
• try to read invalid input data
• try to open a file which does not exist
• try to read beyond the end of the file

• An output stream enters fail state when you
• try to create a file with an invalid name
• try to create a file on a write-protected disk
• try to create a file on a full disk

41
How can you tell the state?

• Can use if statements to check status of input
  stream?
• If stream enters the fail state, include
  instructions that stop program execution
• The stream identifier can be used as if it were a
  Boolean variable. It has value false (meaning
  the last I/O operation on that stream failed)
  when the stream is in fail state.
• When you use a file stream, you should check on
  its state.

42
Checking on the State

• ofstream myOutfile
• myOutfile.open (A\\myOut.dat)
• if ( ! myOutfile )
• cout ltlt File opening error.
• ltlt Program terminated. ltlt endl
• return 1
• // otherwise send output to myOutfile

42
43
Conditional Operator (?)

• Conditional operator (?) takes three arguments
  (ternary)
• Syntax for using the conditional operator
• expression1 ? expression2 expression3
• If expression1 is true, the result of the
  conditional expression is expression2.
• Otherwise, the result is expression3
• max (a gtb) ? a b

44

• expressions value determines which statement is
  selected for execution

45
switch Structures

• Switch structure alternate to if-else
• Switch expression is evaluated first
• Value of the expression determines which
  corresponding action is taken
• Expression is sometimes called the selector

46
switch Structures (continued)

• Expression value can be only integral
• Its value determines which statement is selected
  for execution
• A particular case value should appear only once

47
C Built-In Data Types
Simple
Composite
Integral
Floating
array struct union class
char short int long enum
float double long double
48
switch Structures (continued)

• One or more statements may follow a case label
• Braces are not needed
• to turn multiple statements into a single
  compound statement
• The break statement may or may not appear after
  each statement
• switch, case, break, and default are reserved
  words

49
switch Statement Rules

• When value of the expression is matched against a
  case value,
• Statements execute until break statement is found
  or the end of switch structure is reached
• If value of the expression does not match any of
  the case values
• Statements following the default label execute If
  no default label and no match the entire switch
  statement is skipped
• A break statement causes an immediate exit from
  the switch structure

50

switch (a) //Line 4 case
0 //Line 5 case 1 cout ltlt
"Hello " //Line 6 case 2 cout ltlt
"there. " //Line 7 case 3 cout ltlt "I
am " //Line 8 case 4 cout ltlt
"Mickey." ltlt endl //Line 9
break //Line 10 case 5 cout ltlt
"How " //Line 11 case
6 //Line 12 case
7 //Line 13 case 8 cout ltlt "are
you?" ltlt endl //Line 14
break //Line 15 case 9
break //Line 16 case 10 cout ltlt
"Have a nice day." ltlt endl //Line 17
break //Line 18 default cout ltlt
"Sorry, the number is out of " ltlt "range."
ltlt endl //Line 19 cout ltlt "Out
of switch structure." ltlt endl //Line 20
return 0

• //Program Effect of break statements in a switch
  structure
• include ltiostreamgt
• using namespace std
• int main ()
• int a
• cout ltlt "Enter an integer between 0 and 10
  " //Line 1
• cin gtgt a //Line 2
• cout ltlt "\nThe number you entered is " ltlt a ltlt
  endl //Line 3

51
The assert Function

• Certain types of errors that are very difficult
  to catch can occur in a program
• For example, division by zero can be difficult to
  catch using any of the programming techniques
  examined so far
• The predefined function, assert,
• is useful in stopping program execution when
  certain elusive errors occur

52
The assert Function (continued)

• The syntax for assert
• assert(expression)
• expression is any logical expression
• If expression evaluates to true,
• the next statement executes
• If the expression evaluates to false,
• the program terminates and indicates where in the
  program the error occurred
• assert (denominator)
• quotient numerator / denominator
• if denominator 0, an error msg displays similar
  to that
• Assertion failed denominator, file
  c\temp\assertfunction\assertfunction.cpp, line
  20

53
The assert Function (continued)

• To use assert, include cassert header file
• Assert is useful for enforcing programming
  constraints during program development
• After developing and testing a program, remove or
  disable assert statements
• The preprocessor directive
• define NDEBUG //must be placed before the
  directive include ltcassertgt //to disable the
  assert statement

54
Programming Example

• This programming example calculates a customers
  bill for a local cable company (the solution with
  functions in ch6 p.289)
• There are two types of customers
• Residential
• Business
• Two rates for calculating a cable bill
• One for residential customers
• One for business customers

55
Rates

• For residential customer
• Bill processing fee 4.50
• Basic service fee 20.50
• Premium channel 7.50 per channel
• For business customer
• Bill processing fee 15.00
• Basic service fee 75.00 for first 10
  connections and 5.00 for each additional
  connection
• Premium channel cost 50.00 per channel for any
  number of connections

56
Requirements

• Ask user for account number and customer code
• Assume R or r stands for residential customer and
  B or b stands for business customer

57
Input and Output

• Input
• Customer account number
• Customer code
• Number of premium channels
• For business customers extra, number of basic
  service connections
• Output
• Customers account number
• Billing amount

58
Program Analysis

• The purpose of the program is to
• calculate and
• print billing amount
• Calculating the billing amount requires
• Customer for whom the billing amount is
  calculated (residential or business)
• Number of premium channels to which the customer
  subscribes
• For a business customers, you need extra
• Number of basic service connections

59
Program Analysis (continued)

• Data needed to calculate the bill, such as bill
  processing fees and the cost of a premium
  channel, are known quantities
• The program should print the billing amount to
  two decimal places

60
Algorithm Design

• Set precision to two decimal places
• Prompt user for account number and customer type
• If customer type is R or r
• Prompt user for number of premium channels
• Compute and print the bill
• If customer type is B or b
• Prompt user for number of basic service
  connections and number of premium channels
• Compute and print the bill

61
Variables

• int accountNumber //customer acct. num
• char customerType //customer code
• int numberOfPremiumChannels // number of
• //premium channels
• int numberOfBasicServiceConnections //
  // number of basic service connections

• double amountDue //billing amount

62
Named Constants

• //Named constants residential customers
• const double rBillProcessingFee 4.50
• const double rBasicServiceCost 20.50
• const double rCostOfaPremiumChannel 7.50
• //Named constants business customers
• const double bBillProcessingFee 15.00
• const double bBasicServiceCost 75.00
• const double bBasicConnectionCost 5.00
• const double bCostOfaPremiumChannel 50.00

63
Formulas

• Billing for residential customers
• amountDue
• rBillProcessingFee rBasicServiceCost
• numberOfPremiumChannels CostOfaPremiumChannel

64
Formulas (continued)

• Billing for business customers
• if(numberOfBasicServiceConnections lt 10)
• amountDue bBillProcessingFee
  bBasicServiceCost
• numberOfPremiumChannels bCostOfaPremiumChannel
• else
• amountDue bBillProcessingFee
• bBasicServiceCost
• (numberOfBasicServiceConnections 10)
  bBasicConnectionCost
• numberOfPremiumChannels bCostOfaPremiumChannel


65
Main Algorithm

• Output floating-point numbers in fixed decimal
  with decimal point and trailing zeros
• Output floating-point numbers with two decimal
  places, set the precision to two decimal places
• Prompt user to enter account number
• Get customer account number
• Prompt user to enter customer code
• Get customer code

66
Main Algorithm (continued)

• If the customer code is r or R,
• Prompt user to enter number of premium channels
• Get the number of premium channels
• Calculate the billing amount
• Print account number and billing amount

67
Main Algorithm (continued)

• If customer code is b or B,
• Prompt user to enter number of basic service
  connections
• Get number of basic service connections
• Prompt user to enter number of premium channels
• Get number of premium channels
• Calculate billing amount
• Print account number and billing amount
• If customer code is other than r, R, b, or B,
  output an error message

68

• include ltiostreamgt
• include ltiomanipgt
• using namespace std
• //Named constants - residential customers
• const double rBillProcessingFee 4.50
• const double rBasicServiceCost 20.50
• const double rCostOfaPremiumChannel 7.50
• //Named constants - business customers
• const double bBillProcessingFee 15.00
• const double bBasicServiceCost 75.00
• const double bBasicConnectionCost 5.00
• const double bCostOfaPremiumChannel 50.00
• int main()
• //Variable declaration

69

• switch (customerType)
• case 'r' //Step 6
• case 'R' cout ltlt "Enter the number"
• ltlt " of premium channels " //Step 6a
• cin gtgt numberOfPremiumChannels //Step 6b
• cout ltlt endl
• amountDue rBillProcessingFee //Step
  6c
• rBasicServiceCost numberOfPremiumChannels
  rCostOfaPremiumChannel
• cout ltlt "Account number " ltlt accountNumber
  ltlt endl //Step 6d
• cout ltlt "Amount due " ltlt amountDue ltlt
  endl // Step 6d
• break
• case 'b'
  //Step 7
• case 'B' cout ltlt "Enter the number of basic
  "
• ltlt "service connections "
  //Step 7a
• cin gtgt noOfBasicServiceConnections
  //Step 7b
• cout ltlt endl

70
Summary

• Control structures alter normal control flow
• Most common control structures are selection and
  repetition
• Relational operators , lt, lt, gt, gt, !
• Logical expressions evaluate to 1 (true) or 0
  (false)
• Logical operators ! (not), (and), (or)

71
Summary

• Two selection structures one-way selection and
  two-way selection
• The expression in an if or if...else structure is
  usually a logical expression
• No else statement in C. Every else has a
  related if
• A sequence of statements enclosed between braces,
  and , is called a compound statement or block
  of statements

72
Summary

• Using assignment in place of the equality
  operator creates a semantic error
• Switch structure handles multiway selection
• Break statement ends switch statement
• Use assert to terminate a program if certain
  conditions are not met
