ETL

1
ETL

• Theres a New Sheriff in Town
• Oracle
• OR
• Not Just another Pretty Face

Presented by Bonnie ONeil
2
Introduction
ETL (Extract, Transformation and Loading) is
having a paradigm shift. Previously, ETL was done
with tools outside the database. Ab Initio, Data
Stage and Informatica were kings of the ETL
world. However, there were major disadvantages
to this paradigm. Third party ETL tools required
a separate box because they had no controls on
the consumption of CPU resources. Third party
ETL tools were not integrated into the database.
This meant that ETL developers became experts in
running the tool, but often they had no knowledge
on how the tool related to the database. These
tools often did not keep up with the new releases
of Oracle and would not take advantage of
Oracles new features. In order to create fast
and efficient ETL processes, you needed to know
both.
3
Introduction

• Oracle 9i is changing the ETL paradigm.
• Oracle 9i supports such important features as
• External tables
• MERGE statements (INSERT/UPDATE)
• Conditional multi-table inserts
• Pipelined Table functions
• Native Compilation of PL/SQL programs

4
Introduction
With External Tables, you can now read flat files
in parallel into a virtual table. This virtual
table can be accessed just as any other table.
With the MERGE statement, you can replace a
complex update the row if it exists otherwise
insert it logic with one easy to understand
statement. With conditional multi-table inserts,
I can read a row from an external table and
insert it into many tables based upon conditions.
I can replace most ETL processes with a
relatively simple INSERT statement. Pipelined
table functions allow Oracle to pass a set of
rows to a function and send the results out after
each row is finished. With Native Compilation of
PL/SQL programs, I can now take a slow PL/SQL
program and compile it into C code and then link
it to the database.
Flat Files
Virtual Table
5
External Tables

• The first component of the new Oracle ETL package
  is External Tables. External Tables are flat
  files that Oracle can read and treat as regular
  tables.
• No indexes can be on External tables.
• External Tables are read only ( No DML allowed
  )
• In the past, you had to load the data to
  temporary tables utilizing SQLLOADER, do some
  transformations, and then load the data into
  tables. Now, you can just read the data straight
  from flat files. This eliminates much overhead
  with rollback segments, writing out data to the
  temporary table and Redo Log activity.
• If you have enough memory, you can cache the
  table in memory. Additionally, you can specify a
  degree of parallelism for accessing the external
  flat files.

6
External Tables

• Steps to using external tables.
• Create a directory for accessing the flat files.
  This is required by the access driver.
• CREATE DIRECTORY extdir AS /u01/app/oracle/extfil
  es
• Grant access to the directory
• GRANT read,write ON DIRECTORY extdir TO scott
• This Directory object is used in the External
  Table clause
• Using the LOCATION clause for input files
• To specify the location for output files.

7
External Tables
External tables are based upon a SQLLOADER
format. In the future, a format of EXPORT /
IMPORT will also be supported. KEYWORD CREATE
TABLE . ORGANIZATION EXTERNAL TYPE type
oracle_loader
create table tag_ext( log_type
varchar2(60), user_id varchar2(128),
trans_id varchar2(64), trans_name
varchar2(128), dttm timestamp(4)) organiz
ation external ( type oracle_loader
default directory extdir access parameters

DEFAULT DIRECTORY specifies the directory to use
for input/output files if no location is
specified.
8
External Tables

• Access Parameters - Contains two sections
• Record Format
• Contains information about the record such as the
  format of the records, names of output files, and
  what rules are used to exclude data from being
  loaded.

access parameters ( records delimited by
newline load when log_typeT1 badfile
extdirt1.bad nodiscardfile logfile
extdirt1.log skip 1 fields terminated by
''

• Use SKIP statement if your flat file contains a
  header row.
• Output files can contain p (process number) or
  a (agent number) as part of the filename to
  create unique output files.

9
External Tables

• Field Format
• Describes what characters are used to separate
  fields, what character is optionally used to
  enclose fields, and the data format of the fields
  in the datafile.

fields terminated by '' missing field values
are null ( log_type char(60), user_id
char(128), trans_id char(64), trans_name
char(128), trx_class char(10), dttm
date(24) mask dd-mm-yyyy hh24missxff ) )
10
External Tables
Use the LOCATION clause to specify the filenames
of the input files. REJECT LIMIT specifies the
maximum number of rejected records that are
allowed. This number applies to each parallel
slave used to query the data. PARALLEL specifies
the number of access drivers that are started to
process the datafiles.
location(t1.dat,t2.dat) ) reject limit
unlimited parallel 2 /
11
External Tables

• Data Dictionary Views
• DBA_EXTERNAL_TABLES
• DBA_EXTERNAL_LOCATIONS
• Some DDL statements are allowed on external
  tables
• REJECT LIMIT, PARALLEL, DEFAULT LOCATION, ACCESS
  PARAMETERS, LOCATION, ADD/MODIFY/DROP COLUMN,
  RENAME TO
• Performance Issues
• Fixed width is faster than delimited fields
• Not writing log, bad and discard files
• No conditions clauses

12
Merge Statement

• Before Oracle 9i, a common load, which entailed
  updating a row if it existed and if it does not
  insert the row, required two statements or
  writing PL/SQL code. This data load now can be
  done in a single statement.
• This statement is sometimes called an UPSERT a
  cross between an update and an insert statement.
• The merge fires any Insert or Update Triggers.
• Cannot update the same row of the target table
  multiple times in the same MERGE statement.
• ORA-30926 unable to get a stable set of rows in
  the source tables

13
Merge Statement
Source can be a table or the results of a query
MERGE INTO tag t USING tag_ext x ON
(t.user_idx.user_id AND t.trans_idx.trans_id) WH
EN NOT MATCHED THEN INSERT(log_type,user_id,tran
s_id,trans_name,dttm) VALUES(x.log_type,x.user_i
d,x.trans_id,x.trans_name,x.dttm) WHEN MATCHED
THEN UPDATE SET log_typex.log_type,
trans_namex.trans_name, dttmx.dttm
Update cannot update columns Used in the ON
condition
14
Merge Statement

• Common Errors
• Running merge statement and get
• ORA-00904 ltcolumn_namegt invalid identifier
• CAUSE The reason for this is because you
  specified the column name in ON clause and the
  UPDATE clause. Columns used in the ON clause for
  the join cannot be updated.

15
Multi-table Inserts

• In Oracle 9i, a single insert statement can place
  data values into multiple tables, both
  unconditionally and conditionally. This is more
  efficient than having to parse and execute
  several insert statements. The format is an
  extension of the INSERT SELECT statement.
• Unconditional Multi-table Insert
• The ALL keyword is required.
• INSERT ALL
• INTO emp VALUES(empno,ename,title,salary)
• INTO commision VALUES(empno,comm)
• SELECT empno,ename,title,salary,salary.10 comm
• FROM employees_external

16
Multi-Table Inserts
In addition, Oracle 9i allows a conditional
clause to be included is a multi table insert. A
conditional insert will insert into a table if
the WHEN condition is true. You can insert based
on the FIRST WHEN clause that evaluates to true
or ALL WHEN clauses that evaluate to true.
INSERT FIRST WHEN (titleOracle DBA) THEN
INTO high_paid_employees VALUES(empno,ename,tit
le,salary) WHEN (titleSQL Server DBA) THEN
INTO low_paid_employees VALUES(empno,ename,title
,salary) SELECT FROM employees_external
FIRST keyword means that each row will be
evaluated until the row is evaluated as true with
a WHEN clause. After that the row is not
evaluated against the other WHEN conditions.
17
Multi-Table Inserts
Use the ALL keyword to specify that the INSERT
should occur for all WHEN clauses that evaluate
to true. INSERT ALL WHEN (titleOracle DBA)
THEN INTO bonus_due VALUES(empno,ename,title,s
alary) WHEN (salary gt 100000) THEN INTO
high_paid_employees VALUES(empno,ename,title,sal
ary) ELSE INTO low_paid_employees
VALUES(empno,ename,title,salary) SELECT FROM
employees_external
18
Table Functions - Pipelined

• Table functions produce sets of rows as output.
  Pipelined table functions return the data
  iteratively, instead of in a batch, thus
  eliminating the need for intermediate staging.
  Table functions use the TABLE keyword.
• Table functions return not a single row but a
  set or collection of rows.
• The result set can be a nested table or varray.
• Table functions can be queried like any table in
  the FROM clause of a query.
• Table functions can accept a collection type as
  input or a REF cursor.
• Table functions can be parallelized.
• Table functions can return all the rows at once
  or PIPELINE the results as they are produced.
  (one row at a time).

19
Table Functions - Pipelined
KEYWORD PIPELINED PIPELINED functions use less
memory because the object cache doesnt have to
materialize the entire result set. PIPELINED
functions can accept a REF Cursor as an input
parameter. CREATE FUNCTION managerlist( cur
cursor_emp_pkg.emp_cur ) RETURN
emp_type_table PIPELINED IS The keyword pipe
row returns the row immediately rather than
waiting for all rows to be processed. Table
functions can perform the complex transformations
in an efficient manner.
20
Table Functions - Pipelined
-- Create a Type to define the result type
collection CREATE OR REPLACE TYPE emp_type AS
OBJECT( empno number(4), ename varchar2(10), job
varchar2(9), Sal number(7,2)) / -- Create a
collection used as the return type Create type
emp_type_table as table of emp_type / -- Create a
REF CURSOR as a package variable CREATE OR
REPLACE PACKAGE cursor_emp_pkg AS type emp_rec
is record ( empno number(4),
ename varchar2(10), job varchar2(9),
sal number(7,2)) type strong_emp_cur
is ref cursor return emp_rec End /
21
Table Functions - Pipelined
-- Create Function CREATE FUNCTION DBA_LIST(cur
cursor_emp_pkg.strong_emp_cur) RETURN
emp_type_table PIPELINED IS out_rec emp_type
emp_type(NULL,NULL,NULL,NULL) in_rec
curROWTYPE BEGIN LOOP FETCH cur INTO
in_rec EXIT WHEN curNOTFOUND IF
in_rec.job 'DBA' THEN out_rec.empno
in_rec.empno out_rec.ename
in_rec.ename out_rec.job
in_rec.job out_rec.sal
in_rec.sal PIPE ROW(out_rec)
out_rec.sal in_rec.sal .10 PIPE
ROW(out_rec) END IF END LOOP CLOSE
cur RETURN END /
22
Table Functions - Pipelined
SELECT empno,ename,job,sal from emp where
jobDBA EMPNO ENAME JOB
SAL ---------- ---------- --------- ----------
7788 SCOTT DBA 3000
7902 FORD DBA 3000 SELECT
FROM TABLE(DBA_LIST(CURSOR(SELECT
empno,ename,job,sal FROM emp))) EMPNO ENAME
JOB SAL ---------- ----------
--------- ---------- 7788 SCOTT DBA
3000 7788 SCOTT DBA
300 7902 FORD DBA
3000 7902 FORD DBA 300
23
Table Functions - Pipelined
OBSERVATIONS Explain plan output for Pipelined
Table Functions Rows Execution Plan -------
--------------------------------------------------
- 0 SELECT STATEMENT GOAL CHOOSE
4 VIEW 4 COLLECTION ITERATOR (PICKLER
FETCH) OF 'DBA_LIST Although the number of
records returned is twice as many, the SQLNet
roundtrips to/from client remained the
same. Many more recursive calls for the
pipelined function.
24
Native Compilation
Before Oracle 9i, PL/SQL programs were compiled
to P-code and interpreted at runtime.
Interpreted languages are much slower than
compiled languages. This interpreted feature
allows PL/SQL to be portable. Oracle 9i offers
an option to turn the PL/SQL code into C code
automatically. You write the same PL/SQL code
and Oracle will covert it, compile it and execute
it when the PL/SQL code is called. SQL
statements do not run much faster. NO CODE
CHANGES IN THE PL/SQL CODE!
25
Native Compilation

• To utilize Native Compilation, you must set
  several INIT.ORA parameters.
• plsql_compiler_flagsNATIVE
• Default is INTERPRETED (can be changed at
  session level)
• plsql_native_make_utility/usr/ccs/bin/make
• plsql_native_make_file_name /u01/app/oracle/prod
  uct/9.2.0/plsql/spnc_makefile.mk
• plsql_native_library_dir/u01/app/oracle/lib
• Location where shared libraries are created
• plsql_native_c_compiler/opt/SUNWspro/bin/cc
• plsql_native_linker/usr/sbin/link

26
Native Compilation
CREATE FUNCTION CALC_BONUS(. Produces a C file
called CALC_BONUS__SCOTT__1.c and the shared
library file CALC_BONUS__SCOTT__1.so in the
directory defined by the parameter
plsql_native_library_dir. You can check to see
how code was compiled by viewing the PARAM_NAME
and PARMA_VALUE from the dictionary view
DBA_STORED_SETTINGS SELECT param_name,param_value
FROM user_stored_settings WHERE
object_nameCALC_BONUS PARAM_NAME
PARAM_VALUE ------------------------------
-------------------- plsql_compiler_flags
NATIVE,NON_DEBUG
27
Native Compilation

• Check metalink for latest patches and documents
  regarding NATIVE compilation.
• There are known bugs (unexpected features) with
  compiling on a client versus the server.
• Error compiling from client.
• PLS-00923 Native compilation falied
  makespdtexmk?
• Also, issues with 32 bit versus 64 bit O/Ss. On
  Sun 2.8, I ran into a problem that had to be
  fixed by setting an environment variable and
  bouncing the listener.

28
Conclusion

• The ETL paradigm shift is under way. We will
  start seeing more ETL be done inside the database
  as opposed to outside the database. With the ETL
  processing done at the database level, Oracle 9i
  can take advantage of resource allocations using
  resource groups. These changes will eventually
  result in a simpler and more efficient ETL
  process at a lower cost of ownership.
• Oracle 9i offers vast improvements in ETL
  functionality.
• Economics
• Efficiency
• Performance

29
Thank You
Suzanne Riddell President Apex Solutions,
Inc. 303 216 9491...office 303 809
4914...cell suzanne_at_apexsolutions.com www.apexsolu
tions.com "The Business Intelligence Source"
